INOXPA NHS VERTICAL AGITATOR Ex Manual

1
INSTALLATION, SERVICE AND
MAINTENANCE INSTRUCTIONS
ANNEX FOR CE MARKED EQUIPMENT ACCORDING TO THE ATEX
DIRECTIVE 2014/34/EU:
NHS VERTICAL AGITATOR Ex
The content of this Annex supplements the information in the instruction
manual. The instructions in this Annex must be taken into account in
conjunction with the equipment marked according to Directive
2014/34/EU.
This Annex is complemented by the manuals of the ATEX-certified
components comprising the assembly (e.g. drives, etc).
Original Manual
20.050.30.02EN
(A) 2021/11

(1) where X is a numeric character
(2) stainless steel splash ring
EU Declaration of Conformity
We:
INOXPA, S.A.U.
Telers, 60
17820 - Banyoles (Girona)
Hereby declare under Our sole responsibility that the machine
VERTICAL AGITATOR
Model
NHS
From serial number IXXXXXXXXX to IXXXXXXXXX (1)
is in compliance (2) with all applicable provisions of the following directive:
Directive ATEX 2014/34/UE
Harmonized technicals norms applicable:
EN ISO 80079-36:2016
EN ISO 80079-37:2016
EN 1127-1:2019
EN 13237:2012
EN 15198:2007
EN IEC 60079-0:2018
This Declaration of Conformity covers equipment with the following ATEX
marking:
The technical documentation referenced 174324-771316 is on file with the
notified body LABORATOIRE CENTRAL DES INDUSTRIES ELECTRIQUES
(LCIE), 33, Av. du Général Leclerc BP 8, 92266 Fontenay-aux-Roses, France.
Reference num. 0081.
The person authorized to compile the technical documentation is the signer of
this document.
II 2G Ex h IIB T4…T3 Gb
II 2D Ex h IIIB T125 ºC…T200 oC Db
Banyoles, 2022
David Reyero Brunet
Technical Office Manager
II 2G Ex h IIB T4…T3 Gb
II 2D Ex h IIIB T125 ºC…T200 oC Db
20.050.30.06EN
(A) 2022/10

2
1. Safety Instructions
1.1. SAFETY INSTRUCTIONS
In addition to the instruction manual, this annex to the manual contains basic guidelines which must be followed during the
installation, start-up, and maintenance of this machine. Therefore, it is essential that both the installers and technical staff
responsible for the plant read this annex to the instruction manual prior to the installation, and to ensure that it is permanently
available next to the agitator or corresponding installation.
The safety instructions detailed in this section as well as all the special measures and recommendations included in the other
sections of this annex must be observed and fulfilled.
1.2. SYMBOLS USED
Danger of formation of explosive atmospheres or generation of ignition sources of potentially explosive
atmospheres
1.3. GENERAL SAFETY INSTRUCTIONS
•Read the instructions in this annex in addition to the manual before installing and starting the agitator.
•The installation and use of the agitator must always be carried out in accordance with applicable health and safety
regulations.
•All electrical work must be carried out by authorised specialised personnel.
•Check the characteristics of the motor and its control panel, especially in areas with a risk of fire or explosion (classified
areas). The technical manager or other responsible person of the company operating the system must define risk areas
(zones 0 - 1 - 2).
•When disassembling the agitator, the possible formation of potentially explosive atmospheres must be considered, and the
responsible person at the operating site must issue the corresponding safe work permits.
•Do not exceed the agitator's maximum operating conditions. Do not modify the operating parameters initially set for the
agitator without prior written authorisation from INOXPA.
•The limit values for the operating conditions in explosive atmospheres shall not be exceeded under any circumstances.
•Standard agitators are not designed to operate during tank filling or draining processes. Ignoring this may cause premature
wear of the motor bearings, resulting in a temperature increase up to levels which could be unacceptable for the respective
classified zone.
1.4. WARRANTY
Any warranty will be void immediately and lawfully and, in addition, INOXPA shall be compensated for any product liability
claims submitted by third parties in the case of non-compliance with any of the indications given in the attached annex or in
the following cases:

3
The agitator was selected for use in explosive atmospheres at the time of placing the order, according to
ATEX form. INOXPA is not liable for any damage that may arise if the information provided by the buyer
is incomplete or incorrect (liquid type, viscosity, RPM, classification of the potentially explosive area, gas
generated by the potentially explosive atmosphere, etc.)
The General Terms of Delivery already in your possession are also applicable.
1.5. INSTRUCTION MANUAL AND ANNEX FOR ATEX EQUIPMENT
The information published in the instruction manual and this complementary annex is based on updated data.
We reserve the right to modify the design and/or manufacturing specifications of our products as required, devoid of any
obligation on our part to adapt any product supplied prior to such alteration.
The technical and technological information made available in this annex, along with any graphs, charts and technical
specifications provided, remain our property and shall not be used (except for starting up this machine), copied, photocopied,
made available or otherwise communicated to third parties without our prior written consent.
INOXPA reserves the right to modify this annex to the instruction manual without prior notice.

4
Table of contents
1. Safety Instructions
1.1. Safety instructions .......................................................................................................1.1
1.2. Symbols used...............................................................................................................1.1
1.3. General safety instructions ..........................................................................................1.2
1.4. Warranty......................................................................................................................1.3
1.5. Instruction manual.......................................................................................................1.3
1.6. INOXPA Service.........................................................................................................1.3
Table of contents
2. Reception, storage and transport
2.1. Reception.....................................................................................................................2.1
2.2. Storage ........................................................................................................................2.1
2.3. Transport......................................................................................................................2.1
3. Identification, description and use
3.1. Identification................................................................................................................3.1
3.2. Description ..................................................................................................................3.1
3.3. Using the agitator.........................................................................................................3.1
4. Installation and assembly
4.1. Installation and assembly.............................................................................................4.1
4.2. Installation site.............................................................................................................4.1
4.3. Assembly.....................................................................................................................4.1
4.4. Electrical connection ...................................................................................................4.3
5. Start-up, operation and shutdown
5.1. Start-up ........................................................................................................................5.1
5.2. Operation.....................................................................................................................5.2
6. Maintenance and storage
6.1. Maintenance ................................................................................................................6.1
6.2. Lubrication ..................................................................................................................6.1
6.3. Spare parts ...................................................................................................................6.1
6.4. Repair ..........................................................................................................................6.1
7. Operating problems: causes and solutions
8. Disassembly and assembly
8.1. Electrical safety ...........................................................................................................8.1
8.2. Disassembly.................................................................................................................8.1
8.3. Assembly.....................................................................................................................8.1
9. Technical specifications
9.1. Technical specifications and dimensions.....................................................................9.1
9.2. NHS Agitator: parts list...............................................................................................9.2
9.3. Sealing: Lip seal ..........................................................................................................9.3
