Instrumentarium Orthopantomograph OP100 D Guide

Orthopantomograph® OP100 D
Orthoceph® OC100 D
Installation & Adjustments Manual
63547-IMG rev 2
Orthopantomograph® OP100 D
Orthoceph® OC100 D
Installation & Adjustments Manual
63547-IMG rev 2
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

Copyright Code: 63547-IMG rev 2 Date: 12 June 2007
Document code: 63547-IMG1TPH-1 rev 2
Copyright © 06/2007 by PaloDEx Group Oy.
All rights reserved.
Manufactured by Instrumentarium Dental
Nahkelantie 160 (P.O. Box 20)
FI-04300 Tuusula
FINLAND
Tel. [phone]
Fax. [phone]
Orthopantomograph®and Orthoceph®are registered trademarks of
Instrumentarium Dental. U.S. patents 4,641,336; 5,016,264;
5,425,065, 5,444,754, 6,731,717 and 6,829,326. German patent
4,344,745. Finnish patents 112594 and 114383. Windows®is
trademark of Microsoft Corporation in the United States of America
and other countries. Pentium®is a registered trademark of Intel
Corporation. Iomega®Jaz®is a registered trademark of Iomega Corp.
Documentation, trademark and the software are copyrighted with all
rights reserved. Under the copyright laws the documentation may not
be copied, photocopied, reproduced, translated, or reduced to any
electronic medium or machine readable form in whole or part, without
the prior written permission of Instrumentarium Dental.
The original language of this manual is English.
Instrumentarium Dental reserves the right to make changes in
specification and features shown herein, or discontinue the product
described at any time without notice or obligation. Contact your
Instrumentarium Dental representative for the most current
information.
For service, contact your local distributor.
Copyright Code: 63547-IMG rev 2 Date: 12 June 2007
Document code: 63547-IMG1TPH-1 rev 2
Copyright © 06/2007 by PaloDEx Group Oy.
All rights reserved.
Manufactured by Instrumentarium Dental
Nahkelantie 160 (P.O. Box 20)
FI-04300 Tuusula
FINLAND
Tel. [phone]
Fax. [phone]
Orthopantomograph®and Orthoceph®are registered trademarks of
Instrumentarium Dental. U.S. patents 4,641,336; 5,016,264;
5,425,065, 5,444,754, 6,731,717 and 6,829,326. German patent
4,344,745. Finnish patents 112594 and 114383. Windows®is
trademark of Microsoft Corporation in the United States of America
and other countries. Pentium®is a registered trademark of Intel
Corporation. Iomega®Jaz®is a registered trademark of Iomega Corp.
Documentation, trademark and the software are copyrighted with all
rights reserved. Under the copyright laws the documentation may not
be copied, photocopied, reproduced, translated, or reduced to any
electronic medium or machine readable form in whole or part, without
the prior written permission of Instrumentarium Dental.
The original language of this manual is English.
Instrumentarium Dental reserves the right to make changes in
specification and features shown herein, or discontinue the product
described at any time without notice or obligation. Contact your
Instrumentarium Dental representative for the most current
information.
For service, contact your local distributor.
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

63547-IMG rev 2 Instrumentarium Dental i
Table of Contents
1 Introduction .............................................................................................. 1
1.1 General ................................................................................................................. 1
1.2 Markings and abbreviations .................................................................................. 2
1.3 Radiation protection guidelines ............................................................................. 3
1.4 Manufacturer’s liability........................................................................................... 4
2 Pre installation ......................................................................................... 5
2.1 OP100 D / OC100 D layout models ...................................................................... 5
2.2 Differences between right and left handed units ................................................... 6
2.3 Checking the site................................................................................................... 7
2.4 Tools and hardware ............................................................................................ 10
3 OP100 D shipment ................................................................................. 11
3.1 Unpacking the column......................................................................................... 11
3.2 Unpacking the carriage ....................................................................................... 12
3.3 Installation options .............................................................................................. 16
4 Panoramic unit assembly...................................................................... 17
4.1 Wall mount bracket ............................................................................................. 17
4.2 Column unit ......................................................................................................... 18
4.3 Vertical carriage .................................................................................................. 21
4.4 Transportation bolts & supports .......................................................................... 23
4.5 Vertical carriage cables....................................................................................... 27
4.6 Control panel....................................................................................................... 28
4.7 Remote exposure button..................................................................................... 29
5 Installing the cephalostat kit................................................................. 31
5.1 Unpacking the crate ............................................................................................ 31
5.2 Installing the arm angle ....................................................................................... 31
5.3 Assembling the cephalostat kit............................................................................ 32
5.4 Installing the cephalostat kit ................................................................................ 34
5.5 Removing the cephalostat head cover................................................................ 35
5.6 Removing the transport supports ........................................................................ 35
5.7 Fastening the camera holder .............................................................................. 36
5.8 Adjusting the cephalostat arm............................................................................. 36
6 Connections ........................................................................................... 39
6.1 Connecting to the mains voltage......................................................................... 39
6.2 Permanent installation to mains voltage ............................................................. 41
6.3 Installation of pc system...................................................................................... 43
6.3.1 Site selection.......................................................................................................43
6.3.2 Parts needed to connect PC hardware to OP100 D unit.....................................43
6.3.3 PCI Board and optical fibres installation .............................................................43
6.3.4 Software installation ............................................................................................45
7 Connecting and disconnecting the ccd camera ................................. 47
8 Alignment of the unit ............................................................................. 49
8.1 Panoramic beam check and alignment ............................................................... 49
8.1.1 OP100 D units.....................................................................................................49
8.1.2 OC100 D units.....................................................................................................51
63547-IMG rev 2 Instrumentarium Dental i
Table of Contents
1 Introduction .............................................................................................. 1
1.1 General ................................................................................................................. 1
1.2 Markings and abbreviations .................................................................................. 2
1.3 Radiation protection guidelines ............................................................................. 3
1.4 Manufacturer’s liability........................................................................................... 4
2 Pre installation ......................................................................................... 5
2.1 OP100 D / OC100 D layout models ...................................................................... 5
2.2 Differences between right and left handed units ................................................... 6
2.3 Checking the site................................................................................................... 7
2.4 Tools and hardware ............................................................................................ 10
3 OP100 D shipment ................................................................................. 11
3.1 Unpacking the column......................................................................................... 11
3.2 Unpacking the carriage ....................................................................................... 12
3.3 Installation options .............................................................................................. 16
4 Panoramic unit assembly...................................................................... 17
4.1 Wall mount bracket ............................................................................................. 17
4.2 Column unit ......................................................................................................... 18
4.3 Vertical carriage .................................................................................................. 21
4.4 Transportation bolts & supports .......................................................................... 23
4.5 Vertical carriage cables....................................................................................... 27
4.6 Control panel....................................................................................................... 28
4.7 Remote exposure button..................................................................................... 29
5 Installing the cephalostat kit................................................................. 31
5.1 Unpacking the crate ............................................................................................ 31
5.2 Installing the arm angle ....................................................................................... 31
5.3 Assembling the cephalostat kit............................................................................ 32
5.4 Installing the cephalostat kit ................................................................................ 34
5.5 Removing the cephalostat head cover................................................................ 35
5.6 Removing the transport supports ........................................................................ 35
5.7 Fastening the camera holder .............................................................................. 36
5.8 Adjusting the cephalostat arm............................................................................. 36
6 Connections ........................................................................................... 39
6.1 Connecting to the mains voltage......................................................................... 39
6.2 Permanent installation to mains voltage ............................................................. 41
6.3 Installation of pc system...................................................................................... 43
6.3.1 Site selection.......................................................................................................43
6.3.2 Parts needed to connect PC hardware to OP100 D unit.....................................43
6.3.3 PCI Board and optical fibres installation .............................................................43
6.3.4 Software installation ............................................................................................45
7 Connecting and disconnecting the ccd camera ................................. 47
8 Alignment of the unit ............................................................................. 49
8.1 Panoramic beam check and alignment ............................................................... 49
8.1.1 OP100 D units.....................................................................................................49
8.1.2 OC100 D units.....................................................................................................51
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

ii Instrumentarium Dental 63547-IMG rev 2
8.2 Image layer check ............................................................................................... 53
8.3 Light projectors.................................................................................................... 56
8.4 Midsagittal light ................................................................................................... 56
8.5 Frankfort FH light ................................................................................................ 57
8.6 Layer light............................................................................................................ 57
8.7 Adjusting the cephalostat collimator.................................................................... 58
8.8 Cephalostat beam check and alignment ............................................................. 59
8.9 Adjusting the secondary collimator ..................................................................... 62
8.10 Test images......................................................................................................... 63
8.11 Calibrating the detection sensitivity..................................................................... 64
8.12 Calibrating the AEC............................................................................................. 66
8.13 Ear rod alignment................................................................................................ 67
8.14 Adjusting the laser light ....................................................................................... 69
8.15 Calibrating the nasion frequency......................................................................... 69
8.16 Installing cephalostat covers ............................................................................... 70
9 Checking the operation ......................................................................... 73
9.1 Dose settings ...................................................................................................... 73
9.2 Quality assurance test......................................................................................... 73
9.3 AEC principles..................................................................................................... 74
9.4 Panel functions.................................................................................................... 75
10 User training & review of radiation safety rules................................ 77
11 Changing the layout of the ceph head ............................................... 79
11.1 Changing the ceph head from right to left sided ................................................. 79
11.2 Changing the ceph head from left to right sided ................................................. 80
12 Appendix A, changing the layout of the panoramic unit.................. 83
12.1 Changing the panoramic unit from right to left handed ....................................... 83
12.2 Positioning panel................................................................................................. 83
12.3 Control panel....................................................................................................... 83
12.4 FH light projector................................................................................................. 84
12.5 Layer light projector............................................................................................. 86
12.6 Changing the panoramic unit from left to right handed ....................................... 87
12.7 Positioning panel................................................................................................. 88
12.8 Control panel....................................................................................................... 88
12.9 FH light projector................................................................................................. 88
12.10Layer light projector ............................................................................................ 91
13 Appendix B, installing the base plate ................................................ 93
14 Appendix C, repacking instructions................................................... 95
14.1 Introduction ......................................................................................................... 95
14.2 Repacking OP100 D / OC100 D ......................................................................... 95
14.2.1 Repacking the vertical carriage...........................................................................95
14.3 Repacking the column & base plate.................................................................... 97
14.4 Repacking the cephalostat.................................................................................. 98
15 Appendix D, OP100 D installation
check list................................................................................................. 99
ii Instrumentarium Dental 63547-IMG rev 2
8.2 Image layer check ............................................................................................... 53
8.3 Light projectors.................................................................................................... 56
8.4 Midsagittal light ................................................................................................... 56
8.5 Frankfort FH light ................................................................................................ 57
8.6 Layer light............................................................................................................ 57
8.7 Adjusting the cephalostat collimator.................................................................... 58
8.8 Cephalostat beam check and alignment ............................................................. 59
8.9 Adjusting the secondary collimator ..................................................................... 62
8.10 Test images......................................................................................................... 63
8.11 Calibrating the detection sensitivity..................................................................... 64
8.12 Calibrating the AEC............................................................................................. 66
8.13 Ear rod alignment................................................................................................ 67
8.14 Adjusting the laser light ....................................................................................... 69
8.15 Calibrating the nasion frequency......................................................................... 69
8.16 Installing cephalostat covers ............................................................................... 70
9 Checking the operation ......................................................................... 73
9.1 Dose settings ...................................................................................................... 73
9.2 Quality assurance test......................................................................................... 73
9.3 AEC principles..................................................................................................... 74
9.4 Panel functions.................................................................................................... 75
10 User training & review of radiation safety rules................................ 77
11 Changing the layout of the ceph head ............................................... 79
11.1 Changing the ceph head from right to left sided ................................................. 79
11.2 Changing the ceph head from left to right sided ................................................. 80
12 Appendix A, changing the layout of the panoramic unit.................. 83
12.1 Changing the panoramic unit from right to left handed ....................................... 83
12.2 Positioning panel................................................................................................. 83
12.3 Control panel....................................................................................................... 83
12.4 FH light projector................................................................................................. 84
12.5 Layer light projector............................................................................................. 86
12.6 Changing the panoramic unit from left to right handed ....................................... 87
12.7 Positioning panel................................................................................................. 88
12.8 Control panel....................................................................................................... 88
12.9 FH light projector................................................................................................. 88
12.10Layer light projector ............................................................................................ 91
13 Appendix B, installing the base plate ................................................ 93
14 Appendix C, repacking instructions................................................... 95
14.1 Introduction ......................................................................................................... 95
14.2 Repacking OP100 D / OC100 D ......................................................................... 95
14.2.1 Repacking the vertical carriage...........................................................................95
14.3 Repacking the column & base plate.................................................................... 97
14.4 Repacking the cephalostat.................................................................................. 98
15 Appendix D, OP100 D installation
check list................................................................................................. 99
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

1 Introduction
63547-IMG rev 2 Instrumentarium Dental 1
1 Introduction
1.1 GENERAL
Orthopantomograph® OP100 D is software controlled diagnostic
panoramic dental x-ray equipment for producing high quality digital
images of dentition and TM-joints.
This manual covers the installation of panoramic unit, PC system and
optical link between PC and OP100 D unit. As the manufacturer we
strongly recommend that you read this manual before installation. For
information about how to use the OP100 D unit and CliniView software
please refer to the appropriate manuals.
Following manuals and documents are shipped with the OP100 D:
• OP100 D Installation & Adjustments Manual
• OP100 D User Manual
• OP100 D User Program Manual
• Installation and User Manual for CliniView software
These manuals and future updates will be available on request from
Instrumentarium Dental.
As the manufacturer we strongly recommend that you review the
OP100 D manuals before using this equipment.
Use only approved cables and plugs.
Mains connector types:
NEMA 6-15P or similar Hospital grade (US)
HBL8215C or similar Hospital grade (JAPAN)
Power supply cord:
For UL-countries: SJT, SJTO, SJO, ST, SO or STO, AWG 14x3
H05VV-F3G 10-16A 250V (CE)
1 Introduction
63547-IMG rev 2 Instrumentarium Dental 1
1 Introduction
1.1 GENERAL
Orthopantomograph® OP100 D is software controlled diagnostic
panoramic dental x-ray equipment for producing high quality digital
images of dentition and TM-joints.
This manual covers the installation of panoramic unit, PC system and
optical link between PC and OP100 D unit. As the manufacturer we
strongly recommend that you read this manual before installation. For
information about how to use the OP100 D unit and CliniView software
please refer to the appropriate manuals.
Following manuals and documents are shipped with the OP100 D:
• OP100 D Installation & Adjustments Manual
• OP100 D User Manual
• OP100 D User Program Manual
• Installation and User Manual for CliniView software
These manuals and future updates will be available on request from
Instrumentarium Dental.
As the manufacturer we strongly recommend that you review the
OP100 D manuals before using this equipment.
Use only approved cables and plugs.
Mains connector types:
NEMA 6-15P or similar Hospital grade (US)
HBL8215C or similar Hospital grade (JAPAN)
Power supply cord:
For UL-countries: SJT, SJTO, SJO, ST, SO or STO, AWG 14x3
H05VV-F3G 10-16A 250V (CE)
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

1 Introduction
2 Instrumentarium Dental 63547-IMG rev 2
1.2 MARKINGS AND ABBREVIATIONS
The following markings are used in this manual:
NOTE!
Contains useful information for the reader about the unit and its use.
CAUTION!
Contains important instructions. If these instructions are not observed,
malfunction of the unit or damage to the unit or other property may
occur.
WARNING!
Contains warnings and instructions about the safety of the unit. if
these warnings are not respected, serious risks and injury may be
caused to the patient and operator.
The following abbreviations may be used in this manual.
PC Personal computer
HD Hard disk
Hz Hertz; cycles per second
MHz Millions of hertz
CPU Central processing unit (computer)
RAM Random access memory
MB Mega bytes
GB Giga bytes
CCD Charge-coupled device
CD-R Compact disc (read)
CD-RW Compact disc (read and write)
DVD-RW Digital Versatile Disc (read and write)
HDD High density drive
PCI Peripheral Component Interconnect
LAN Local Area Network
1 Introduction
2 Instrumentarium Dental 63547-IMG rev 2
1.2 MARKINGS AND ABBREVIATIONS
The following markings are used in this manual:
NOTE!
Contains useful information for the reader about the unit and its use.
CAUTION!
Contains important instructions. If these instructions are not observed,
malfunction of the unit or damage to the unit or other property may
occur.
WARNING!
Contains warnings and instructions about the safety of the unit. if
these warnings are not respected, serious risks and injury may be
caused to the patient and operator.
The following abbreviations may be used in this manual.
PC Personal computer
HD Hard disk
Hz Hertz; cycles per second
MHz Millions of hertz
CPU Central processing unit (computer)
RAM Random access memory
MB Mega bytes
GB Giga bytes
CCD Charge-coupled device
CD-R Compact disc (read)
CD-RW Compact disc (read and write)
DVD-RW Digital Versatile Disc (read and write)
HDD High density drive
PCI Peripheral Component Interconnect
LAN Local Area Network
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

1 Introduction
63547-IMG rev 2 Instrumentarium Dental 3
1.3 RADIATION PROTECTION GUIDELINES
X-ray equipment may cause injury if used improperly. The instructions
contained in this manual must be read and followed when operating
the Orthopantomograph® OP100 D. All government regulations
pertaining to radiation safety must be observed.
NOTE!
For USA: Many provisions of these regulations are based on
recommendations of the National Council on Radiation Protection and
Measurements. Recommendations for dental x-ray protection are
published in NCRP Report #35 available from NCRP Publications,
7910 Woodmont Avenue, Suite 1016, Bethesda, MD 20814.
During the exposure the operator must protect himself/herself by
either staying behind a protective wall or use other means for personal
protection and stay at least 2 meters (7 ft.) from the radiation source
yet maintaining visible contact with the patient and technique factors.
This allows immediate termination of radiation by the release of the
exposure button in the event of a malfunction or disturbance.
Personal radiation monitoring and protective devices are available and
recommended for staff members. It is also recommended to provide
the patient with a protective apron. Consult physician before taking
images of pregnant patients.
Fig 1.1. Caution information on Control panel
WARNING!
Orthopantomograph OP100 D must not be used in rooms where an
explosion hazard exists.
1 Introduction
63547-IMG rev 2 Instrumentarium Dental 3
1.3 RADIATION PROTECTION GUIDELINES
X-ray equipment may cause injury if used improperly. The instructions
contained in this manual must be read and followed when operating
the Orthopantomograph® OP100 D. All government regulations
pertaining to radiation safety must be observed.
NOTE!
For USA: Many provisions of these regulations are based on
recommendations of the National Council on Radiation Protection and
Measurements. Recommendations for dental x-ray protection are
published in NCRP Report #35 available from NCRP Publications,
7910 Woodmont Avenue, Suite 1016, Bethesda, MD 20814.
During the exposure the operator must protect himself/herself by
either staying behind a protective wall or use other means for personal
protection and stay at least 2 meters (7 ft.) from the radiation source
yet maintaining visible contact with the patient and technique factors.
This allows immediate termination of radiation by the release of the
exposure button in the event of a malfunction or disturbance.
Personal radiation monitoring and protective devices are available and
recommended for staff members. It is also recommended to provide
the patient with a protective apron. Consult physician before taking
images of pregnant patients.
Fig 1.1. Caution information on Control panel
WARNING!
Orthopantomograph OP100 D must not be used in rooms where an
explosion hazard exists.
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

1 Introduction
4 Instrumentarium Dental 63547-IMG rev 2
1.4 MANUFACTURER’SLIABILITY
As a manufacturer we can only assume liability of safe and reliable
operation of this unit when
• Installation of OP100 D unit, PCI board and optical link between
PC and OP100 D unit was performed according to the OP100 D
Installation & Adjustments Manual and
• Unit is used according to the OP100 D User Manual
• CliniView PC software was installed according to the Installation
& User Manual for CliniView Software.
• CliniView PC software is used according to the “Installation and
User Manual for CliniView Software”.
• Maintenance and repairs are performed by a qualified
Orthopantomograph Dealer and
• Original or authorized spare parts are used and
If service on the unit is performed, work order describing the type and
extent of repair, must be provided by the service technician. This must
contain information of changes of nominal data or work range
performed. The work order must furthermore indicate the date of
repair, the name of the company concerned and a valid signature.
User should keep this work order for future references.
NOTE!
For PC system: Instrumentarium Dental can guarantee OP100 D PCI
board and CliniView software compatibility with other PC hardware
and software only if that configuration been tested by Instrumentarium
Dental. Any later changes to the hardware and software may void this
test.
1 Introduction
4 Instrumentarium Dental 63547-IMG rev 2
1.4 MANUFACTURER’SLIABILITY
As a manufacturer we can only assume liability of safe and reliable
operation of this unit when
• Installation of OP100 D unit, PCI board and optical link between
PC and OP100 D unit was performed according to the OP100 D
Installation & Adjustments Manual and
• Unit is used according to the OP100 D User Manual
• CliniView PC software was installed according to the Installation
& User Manual for CliniView Software.
• CliniView PC software is used according to the “Installation and
User Manual for CliniView Software”.
• Maintenance and repairs are performed by a qualified
Orthopantomograph Dealer and
• Original or authorized spare parts are used and
If service on the unit is performed, work order describing the type and
extent of repair, must be provided by the service technician. This must
contain information of changes of nominal data or work range
performed. The work order must furthermore indicate the date of
repair, the name of the company concerned and a valid signature.
User should keep this work order for future references.
NOTE!
For PC system: Instrumentarium Dental can guarantee OP100 D PCI
board and CliniView software compatibility with other PC hardware
and software only if that configuration been tested by Instrumentarium
Dental. Any later changes to the hardware and software may void this
test.
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

2 Pre installation
63547-IMG rev 2 Instrumentarium Dental 5
2 Pre installation
NOTE!
This unit is designed for fixed installation only, therefore mobile
installation is prohibited!
2.1 OP100 D / OC100 D LAYOUT MODELS
OP100 D is available in standard wall mount and optional free
standing models.
OP100 D
Dimensions in millimeters and inches:
Fig 2.1. OP100 D Wall mount, standard column and free standing, standard column
2 Pre installation
63547-IMG rev 2 Instrumentarium Dental 5
2 Pre installation
NOTE!
This unit is designed for fixed installation only, therefore mobile
installation is prohibited!
2.1 OP100 D / OC100 D LAYOUT MODELS
OP100 D is available in standard wall mount and optional free
standing models.
OP100 D
Dimensions in millimeters and inches:
Fig 2.1. OP100 D Wall mount, standard column and free standing, standard column
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

2 Pre installation
6 Instrumentarium Dental 63547-IMG rev 2
OC100 D DIMENSIONS
2.2 DIFFERENCES BETWEEN RIGHT AND LEFT
HANDED UNITS
OP100 D is designed to be universal, i.e. every model can be
operated from the left or from the right side of the unit; the way of
patient positioning and operation can be changed during the
installation and later at any time. This applies also to the field
upgrades.
2 Pre installation
6 Instrumentarium Dental 63547-IMG rev 2
OC100 D DIMENSIONS
2.2 DIFFERENCES BETWEEN RIGHT AND LEFT
HANDED UNITS
OP100 D is designed to be universal, i.e. every model can be
operated from the left or from the right side of the unit; the way of
patient positioning and operation can be changed during the
installation and later at any time. This applies also to the field
upgrades.
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

2 Pre installation
63547-IMG rev 2 Instrumentarium Dental 7
OC100 D
2.3 CHECKING THE SITE
Patient Access Area:
OP100 D should have a minimum clearance of 80 inches/203cm
(wide) and 61 inches/155cm for the patient entry, patient positioning
and for servicing the unit.
Radiation Shielding:
Follow the governmental and local regulations for radiation shielding
of the x-ray room.
Location:
OP100 D unit is normally installed next to the wall. The operation is
either from the left or right side of the unit. The swivel joint of the wall
bracket allows the unit to be installed at an angle, e.g. in the corner
when the space is limited. OP100 D PC hardware can be located
almost anywhere in the dental office. Limited factor is actually fibre
optic cable which is either 10m or 20m long.
LL Controls on the left side of unit. Left sided operator’s view for
panoramic patient positioning. Cephalostat arm on the left.
Controls and ceph arm can be reversed any later date.
RR Controls on the right side of unit. Right sided operator’s view
for panoramic patient positioning. Cephalostat arm on the
right. Controls and ceph arm can be reversed any later date.
LR Controls on the left side of unit. Left side operator’s view for
panoramic patient positioning, cephalostat arm on the right.
Controls and ceph arm can be reversed any later date.
RL Controls on the right side of unit. Right side operator’s view
for panoramic patient positioning, cephalostat arm on the
left. Controls and ceph arm can be reversed any later date.
2 Pre installation
63547-IMG rev 2 Instrumentarium Dental 7
OC100 D
2.3 CHECKING THE SITE
Patient Access Area:
OP100 D should have a minimum clearance of 80 inches/203cm
(wide) and 61 inches/155cm for the patient entry, patient positioning
and for servicing the unit.
Radiation Shielding:
Follow the governmental and local regulations for radiation shielding
of the x-ray room.
Location:
OP100 D unit is normally installed next to the wall. The operation is
either from the left or right side of the unit. The swivel joint of the wall
bracket allows the unit to be installed at an angle, e.g. in the corner
when the space is limited. OP100 D PC hardware can be located
almost anywhere in the dental office. Limited factor is actually fibre
optic cable which is either 10m or 20m long.
LL Controls on the left side of unit. Left sided operator’s view for
panoramic patient positioning. Cephalostat arm on the left.
Controls and ceph arm can be reversed any later date.
RR Controls on the right side of unit. Right sided operator’s view
for panoramic patient positioning. Cephalostat arm on the
right. Controls and ceph arm can be reversed any later date.
LR Controls on the left side of unit. Left side operator’s view for
panoramic patient positioning, cephalostat arm on the right.
Controls and ceph arm can be reversed any later date.
RL Controls on the right side of unit. Right side operator’s view
for panoramic patient positioning, cephalostat arm on the
left. Controls and ceph arm can be reversed any later date.
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

2 Pre installation
8 Instrumentarium Dental 63547-IMG rev 2
CAUTION!
Do not locate PC hardware closer than 2 meters from the OP100 D
unit otherwise patient could have a possibility to touch the PC
hardware during exposure.
Door width: A minimum door width of 32 inches/80cm is required to
bring OP100 D crates and boxes into the installation room.
Height: Minimum room height is 93 inches/235 cm for standard
column.
Wall: The wall and mounting hardware must sustain a pull of 350 lbs./
1500N, from each wall bracket bolt. If the wall is constructed with
metal, an optional support plate (part #9955) may be used to help
support this style of construction. Wall brackets are predrilled at 16
inch and 12 inch / 406mm and 305mm centers. Optional Wall mount
short (part #60564) does not have the swivel and it brings the unit
about 3’’/76mm closer to the wall.
Floor: The floor must withstand the minimum weight of 120 lbs/sqft/
500kg/m2.
Free Standing:
An optional base plate allows a free standing installation in sites where
the wall mount is not used. For maximum stability, wall mounting is
recommended in addition to the base plate.
Exposure button:
Some local building codes will require a remote exposure button. If
needed order part # 69961. If necessary, the control panel and coiled
cord can also be remote mounted on the wall with an additional holder
(part #61228, not included).
Fig 2.2. Support plate mounted
behind the wall
60564
Fig 2.3. Wall mount, short (for special
use).
2 Pre installation
8 Instrumentarium Dental 63547-IMG rev 2
CAUTION!
Do not locate PC hardware closer than 2 meters from the OP100 D
unit otherwise patient could have a possibility to touch the PC
hardware during exposure.
Door width: A minimum door width of 32 inches/80cm is required to
bring OP100 D crates and boxes into the installation room.
Height: Minimum room height is 93 inches/235 cm for standard
column.
Wall: The wall and mounting hardware must sustain a pull of 350 lbs./
1500N, from each wall bracket bolt. If the wall is constructed with
metal, an optional support plate (part #9955) may be used to help
support this style of construction. Wall brackets are predrilled at 16
inch and 12 inch / 406mm and 305mm centers. Optional Wall mount
short (part #60564) does not have the swivel and it brings the unit
about 3’’/76mm closer to the wall.
Floor: The floor must withstand the minimum weight of 120 lbs/sqft/
500kg/m2.
Free Standing:
An optional base plate allows a free standing installation in sites where
the wall mount is not used. For maximum stability, wall mounting is
recommended in addition to the base plate.
Exposure button:
Some local building codes will require a remote exposure button. If
needed order part # 69961. If necessary, the control panel and coiled
cord can also be remote mounted on the wall with an additional holder
(part #61228, not included).
Fig 2.2. Support plate mounted
behind the wall
60564
Fig 2.3. Wall mount, short (for special
use).
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

2 Pre installation
63547-IMG rev 2 Instrumentarium Dental 9
NOTE!
OP100 D can be programmed so that the exposure can be initiated
only from the remote exposure button, except in Test (T) mode. See
OP100 D Service Program Manual or Service Manual for details.
Radiation Safety:
During the exposure the operator must use a radiation shielded
protective wall or use other means for personal protection and stay at
least 7 ft. / 2 meters from the radiation source yet maintaining visible
contact with the patient and technique factors.
Mains voltage:
Verify the mains voltage (3 wire: single-phase, 110V or 230V with
protective ground).
Fuses: Verify that the OP100 D power is supplied through a circuit
breaker with current rating of max. 16 A slow blow.
NOTE!
Some countries may have regulations on fault current protection. Such
regulations must be observed.
Protective ground:
Verify the protective ground.
Voltage: Voltage range:
230 Vac line 185-245 Vac
110 Vac line 90-123 Vac
Voltage: Fuse:
230 Vac line 10 A Slow blow
110 Vac line 15 A Slow blow
2 Pre installation
63547-IMG rev 2 Instrumentarium Dental 9
NOTE!
OP100 D can be programmed so that the exposure can be initiated
only from the remote exposure button, except in Test (T) mode. See
OP100 D Service Program Manual or Service Manual for details.
Radiation Safety:
During the exposure the operator must use a radiation shielded
protective wall or use other means for personal protection and stay at
least 7 ft. / 2 meters from the radiation source yet maintaining visible
contact with the patient and technique factors.
Mains voltage:
Verify the mains voltage (3 wire: single-phase, 110V or 230V with
protective ground).
Fuses: Verify that the OP100 D power is supplied through a circuit
breaker with current rating of max. 16 A slow blow.
NOTE!
Some countries may have regulations on fault current protection. Such
regulations must be observed.
Protective ground:
Verify the protective ground.
Voltage: Voltage range:
230 Vac line 185-245 Vac
110 Vac line 90-123 Vac
Voltage: Fuse:
230 Vac line 10 A Slow blow
110 Vac line 15 A Slow blow
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

2 Pre installation
10 Instrumentarium Dental 63547-IMG rev 2
2.4 TOOLS AND HARDWARE
NOTE!
All screws, bolts, nuts and washers used in OP100 D are Metric sizes!
The following tools are required during the installation:
• Metric Allen wrench set
• Electric drill, drill bits (8 mm & 10 mm or equal)
• Mounting hardware for wall bracket
• Level
• Flat screw drivers
• Pozidrive or phillips screwdrivers (PZD-1 and PZD-2) (Phillips
PH-1 and PH-2)
•Pliers
• Wrenches, 13 mm and 19 mm
• Tape measure
• Ball & pin phantom, product # 69980
• Fluorescent tool OP100 D #68662
Make sure that you have all tools and items needed prior to
installation!
2 Pre installation
10 Instrumentarium Dental 63547-IMG rev 2
2.4 TOOLS AND HARDWARE
NOTE!
All screws, bolts, nuts and washers used in OP100 D are Metric sizes!
The following tools are required during the installation:
• Metric Allen wrench set
• Electric drill, drill bits (8 mm & 10 mm or equal)
• Mounting hardware for wall bracket
• Level
• Flat screw drivers
• Pozidrive or phillips screwdrivers (PZD-1 and PZD-2) (Phillips
PH-1 and PH-2)
•Pliers
• Wrenches, 13 mm and 19 mm
• Tape measure
• Ball & pin phantom, product # 69980
• Fluorescent tool OP100 D #68662
Make sure that you have all tools and items needed prior to
installation!
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

3 OP100 D shipment
63547-IMG rev 2 Instrumentarium Dental 11
3 OP100 D shipment
Orthopantomograph® OP100 D shipment consists of 2 packages.
Orthoceph®OC100 D shipment consists of 3 packages.
3.1 UNPACKING THE COLUMN
The column is packed front side up and supported with styrofoam
plates.
Move the cardboard box near the mounting location and cut the metal
straps.
NOTE!
During lifting the packages use assistance.
Card board box: Open the cover of the package and remove the top
styrofoam pieces and use them as supports under the column. Rotate
the package upside down. Remember to keep the cover beside the
package so that the column can flow down from the package.
OP100 D
Packages
COLUMN
(Wooden
crate)
CARRIAGE
(Card board)
Cephalostat
package
Size (LxWxH)
cm: ft:
230,5 x 36 x
35
98 x 98 x 71
3,2 x 3,2 x 2,3
65 x 74 x 122
2.1 x 2.4 x 4.0
Gross weight
approx.:
110 kg /
242 lbs
106 kg
234 lbs
85 kg
187 lbs
Net weight
approx.:
85 kg / 187 lbs 89 kg
168 lbs
76kg
196 lbs
3 OP100 D shipment
63547-IMG rev 2 Instrumentarium Dental 11
3 OP100 D shipment
Orthopantomograph® OP100 D shipment consists of 2 packages.
Orthoceph®OC100 D shipment consists of 3 packages.
3.1 UNPACKING THE COLUMN
The column is packed front side up and supported with styrofoam
plates.
Move the cardboard box near the mounting location and cut the metal
straps.
NOTE!
During lifting the packages use assistance.
Card board box: Open the cover of the package and remove the top
styrofoam pieces and use them as supports under the column. Rotate
the package upside down. Remember to keep the cover beside the
package so that the column can flow down from the package.
OP100 D
Packages
COLUMN
(Wooden
crate)
CARRIAGE
(Card board)
Cephalostat
package
Size (LxWxH)
cm: ft:
230,5 x 36 x
35
98 x 98 x 71
3,2 x 3,2 x 2,3
65 x 74 x 122
2.1 x 2.4 x 4.0
Gross weight
approx.:
110 kg /
242 lbs
106 kg
234 lbs
85 kg
187 lbs
Net weight
approx.:
85 kg / 187 lbs 89 kg
168 lbs
76kg
196 lbs
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

3 OP100 D shipment
12 Instrumentarium Dental 63547-IMG rev 2
Lift the column and place it front side upwards over the styrofoam
plates.
3.2 UNPACKING THE CARRIAGE
Card board box on a pallet contains the complete vertical carriage and
the accessories.
Move the crate near the installation site and cut the tie straps. Move or
lift the crate aside from the wooden pallet.
Remove the crate top by removing the staples from sides and lifting
the top away.
Remove the staples holding the card board bottom flaps. Unfold the
flaps.
Lift the styrofoam top (H) with accessories and set aside.
3 OP100 D shipment
12 Instrumentarium Dental 63547-IMG rev 2
Lift the column and place it front side upwards over the styrofoam
plates.
3.2 UNPACKING THE CARRIAGE
Card board box on a pallet contains the complete vertical carriage and
the accessories.
Move the crate near the installation site and cut the tie straps. Move or
lift the crate aside from the wooden pallet.
Remove the crate top by removing the staples from sides and lifting
the top away.
Remove the staples holding the card board bottom flaps. Unfold the
flaps.
Lift the styrofoam top (H) with accessories and set aside.
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

3 OP100 D shipment
63547-IMG rev 2 Instrumentarium Dental 13
From the styrofoam bottom (G), remove the wall mount assembly (C)
and a bag of column accessories (A).
Locate all the accessories and check against the packing list
enclosed.
Tilt the carriage assembly and the styrofoam bottom so that it is
standing on its back.
Remove the styrofoam bottom by tilting the carriage slightly and
pulling out the foam.
G
C
A
3 OP100 D shipment
63547-IMG rev 2 Instrumentarium Dental 13
From the styrofoam bottom (G), remove the wall mount assembly (C)
and a bag of column accessories (A).
Locate all the accessories and check against the packing list
enclosed.
Tilt the carriage assembly and the styrofoam bottom so that it is
standing on its back.
Remove the styrofoam bottom by tilting the carriage slightly and
pulling out the foam.
G
C
A
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12

3 OP100 D shipment
14 Instrumentarium Dental 63547-IMG rev 2
CAUTION!
Do not lift or otherwise apply force on the CCD camera! Damage to
the unit and/or degrade to imaging quality may occur if done so!
Tilt the carriage up to its normal position. Remove the 2 rear styrofoam
package supports (F) from the rear of the carriage. The carriage will
be standing on its own.
Remove the package support (D) from CCD camera and package
support (E) from the main support / the rotating unit. Do not remove
supports (C) at this time.
Remove the main support cover (2 screws) and carriage top plate (4
screws).
3 OP100 D shipment
14 Instrumentarium Dental 63547-IMG rev 2
CAUTION!
Do not lift or otherwise apply force on the CCD camera! Damage to
the unit and/or degrade to imaging quality may occur if done so!
Tilt the carriage up to its normal position. Remove the 2 rear styrofoam
package supports (F) from the rear of the carriage. The carriage will
be standing on its own.
Remove the package support (D) from CCD camera and package
support (E) from the main support / the rotating unit. Do not remove
supports (C) at this time.
Remove the main support cover (2 screws) and carriage top plate (4
screws).
Approved
Reviewed: Salmenkivi Mika 18.06.07 15:30:12
Approved: Järvi Mika 19.06.07 09:36:58
See the PaloDEx Group Oy PDM system to determine the status of this document. Printed out: 29.09.08 09:29:12
