insys icom SCR-E200 User manual

ENGLISH
Quick Installation Guide
SCR-E
www.insys-icom.com
These short operating instructions apply for the following devices of INSYS icom:
▪SCR-E200
▪SCR-E300
www.insys-icom.com/manual 
It is intended for a quick commissioning by the operator. Refer to the associated manual for further information.
This and other associated manuals can be found on our website in the menu Support and Downloads >
Documentation. Scan the QR code above or enter the URL into your web browser.
Tec hnical Data
The product is only intended for the use within the permissible technical limits specified in the data sheets. These limits must be observed.
Operating voltage (redundant)
12 V … 24 V DC (±20%)
Temperature range
-30 °C … 70 °C
(75 °C extended)
Power consumption
typ. 1.5 W, max. 3 W
Maximum permissible humidity
95% non-condensing
Level input
HIGH level = 10 ... 24 V
LOW level = 0 ... 5 V
Contact open condition:
LOW
IP rating
Housing IP40
Current consumption input at
HIGH potential
max. 3 mA at 24 V DC
Digital output (open collector),
max. load
24 V (DC), 100 mA
Max. voltage drop of the output
in condition ON
< 1 V (DC) at 100 mA load
Tec hnical Boundaries
Max. line length for antennas, power supply, serial interfaces, inputs and outputs as well as other signals: 30 m
Cable cross-section: 0.25 … 1.5 mm², flexible lines require end sleeves
Su pport
If you need further support, please contact your sales partner or INSYS icom support. You can contact our support department via e-mail
under [e-mail].
Defects Liability Terms
A use other than the intended use, an ignorance of the safety instructions and the documentation, the use of insufficiently qualified
personnel as well as unauthorised modifications exclude the liability of the manufacturer for damages resulting from this. The liability of the
manufacturer ceases to exist.
Int ended Use
The product may only be used for the purposes specified in the function overview of the manual. In addition, it may be used f or the
following purposes:
▪Usage and mounting in an industrial cabinet.
▪Switching and data transmission functions in machines according to the machine directive 2006/42/EC.
▪Usage as data transmission device, e.g. for a PLC.
The product may not be usedfor the following purposes and used or operated under the following conditions:
▪Use, control, switching and data transmission in machines or systems in explosive atmospheres.
▪Controlling, switching and data transmission of machines, which may involve risks to life and limb due to their functions or when a
breakdown occurs.

ENGLISH
Quick Installation Guide
SCR-E
www.insys-icom.com
A
Router connection
1. Connect supply voltage (12 V … 24 V DC (±20%))
to the terminals V- and V+
2. Connect router (ETH 1) to the configuration PC
via Ethernet cable
3. Connect router (ETH 2) to the network
that is used to establish the Internet connection
After completing the configuration, the router must be connected to the network in
which your system is located (local application network) via ETH1. The configuration PC
can be connected to the local application network for further access.
B
LAN settings of configurations PC (Windows 7)
If a DHCP client is active on the PC, proceed with step C. Otherwise, either enable the
DHCP client or configure a static IP address.
4. Open Network and Sharing Center (e.g. key and search for "sharing")
5. Select LAN connection and Properties
6. Select Internet Protocol Version 4 (TCP/IP) and Properties
Enable DHCP client
7. Obtain an IP address automatically
It is recommended to unplug the
network cable briefly and plug it
again upon activation of the DHCP
client.
Configure a static IP address
Use the following IP address (example):
IP address: 192 . 168 . 1 . 2
Subnet mask: 255 . 255 . 255 . 0
Standard gateway 192 . 168 . 1 . 1
Preferred DNS server: 192 . 168 . 1 . 1
Please note the previous values before
changing the TCP/IP settings to be able
to restore them later.
C
Web interface access
8. Enter IP address of the router in address bar of the browser
(default: 192.168.1.1)
If a proxy server is enabled in your browser, this must be disabled or the IP address of
the router must be added as exception.
9. Login with Name (default: insys) and Password (icom)
10. Open the Inline Help using the button (Display help text) in the header
The links in the Inline Help lead to the Online Help with further information.
All modified data will only be stored in the opened profile after clicking the Save
settings button and become effective upon clicking the (Activate profile) button.

ENGLISH
Quick Installation Guide
SCR-E
www.insys-icom.com
D
Integration into a network
11. In Menu Help > Wizards: Select Startup Wizard
12. Under Internet access
activate DHCP client, if a DHCP server
is active
OR
enter static IP address
by entering IP adress and netmask of the
existing network as well as default
gateway address and DNS server
address of the WAN connection
13. Enter IP address of the local
application network
If the router is to be configured for the
icom Connectivity Suite - VPN
(https://connectivity.insys-icom.de),
select icom Connectivity Suite –VPN
under VPN connection and enter
Customer name and Device code (from
icom Connectivity Suite –VPN, “My VPN
Hub” tab). Then, the IP address in the
local network will be assigned by the
icom Connectivity Suite - VPN.
14. Click on Execute wizard
The WAN LED flashes green during connection establishment and is illuminated green
as soon as a connection is established.
If the web interface of the router does not return upon executing the wizard, click on
“Reload” in the browser (or Ctrl+F5).
E
Configuration of access data
User name and password for web interface access of the existing user in the default
settings must be changed to prevent a manipulation of the configuration by
unauthorised persons.
15. Menu Administration > Users: Enter or change User name and Password and select
User group "Read/Write"
16. Store settings in profile with Save setting s and activate profile with
A typo during entering or forgetting the configured access data require a reset to
default settings to be able to access the router again.
All essential configuration steps are completed with this. Further configuration depends on your specific
application. Other frequently required settings are available on the following page.

ENGLISH
Quick Installation Guide
SCR-E
Mat. no. 10020648 –Vers. 25 January 2019 11:09:26 –Subject to technical changes and correction
www.insys-icom.com
Availability of the router upon configuration
The wizard deactivates the configuration network (IP net 1) and assigns ETH1 to the
local application network (IP net 2). In addition, it configures the previous default
address 192.168.1.1 as additional IP address for IP net 2 that the configuration PC still
has access after executing the wizard (if this has not already been assigned in the local
application network).
After the router has been connected to the local application network for productive
operation, access to the web Interface for a possible further configuration must be
made from a PC in the local application network.
Using the router as icom Smart Gateway
If the router is to be used as an icom Smart Energy Gateway or icom Smart Machinery
Gateway for example, this is the best time now to install the icom Data Suite required
for this. A wizard is available for this in the Help menu. Refer to the Quick Installation
Guide of the icom Data Suite (https://www.insys-icom.com/manual#deviceapps) or the
respective Configuration Guide (https://docs.insys-icom.de/icom_data_suite.html).
Resetting the router
If it is necessary to reset the router during configuration, this is possible without losing
the settings.
1. Menu Administration > Reset
2. Click on Reboot device now
Alternatively, press reset key on the device front once for a short time (soft reset)
Resetting the router to default settings
If the router is to be reset to default settings, it can be reset to delivery state.
1. Menu Administration > Reset: check all options
2. Click on Reset now
Alternatively, press reset key on the device front three times for a short time within
2 seconds
Resetting and initialising the router
If the router is not available any more for any reason, it can be reset and initialised
(settings do not get lost).
1. Press reset key on the device front for at least 3 seconds (hard reset)
The Inline Help opens upon selecting the button ? (Display help text) and provides helpful
information regarding each individual parameter directly in the web interface.
The Online Help is opened using the links in the Inline Help or in the Help menu in the web
interface and provides further information to the respective topics.
The Configuration Guides are available under https://docs.insys-icom.de and provide helpful
information regarding the integration of your product into your application.
Hereby, INSYS Microelectronics GmbH declares that herein described device types are in compliance with Directives 2014/30/EU
and 2011/65/EU. The full text of the EC Declaration of Conformity is available under www.insys-ic om.com/manual.
