Intec I-Starter 2.8 User manual

Manuale d’uso / User manual
AVVIATORE D’EMERGENZA
2.8


Italiano 4
Descrizione prodotto 4
Istruzioni per l’uso 5
Specifiche tecniche 7
Domande più frequenti 8
Problemi / Soluzioni 8
Avvertenze 9
English 10
Product description 10
Instruction for use 11
Technical specifications 13
Most frequently asked questions 14
Problem / Solutions 14
Warning 15

4
Grazie per aver scelto un prodotto i-Starter.
Seguire accuratamente le istruzioni contenute nel presente manuale.
La non osservanza delle disposizioni di sicurezza può causare danni a cose e persone, e
danneggiare irreparabilmente il dispositivo.
Conservare il Manuale per future consultazioni.
DESCRIZIONE PRODOTTO
Italiano
1. Ingresso cavi con pinze
2. Pulsante
3. Indicatore
4. Porta USB 5V 2.1A
5. Porta USB per ricarica ultrarapida
6. Lampada LED
7. Presa di ricarica Micro-USB
Ingresso cavi con pinze Porta USB per ricarica veloce
Cavo di avviamento intelligente
12
3
2
4
567
Presa di ricarica Micro-USB
Caricatore

5
ISTRUZIONI PER L’USO
Indicatore
Premere il pulsante per controllare lo stato di carica del dispositivo.
Indicatore Spento 1 Led 2 Led 3 Led 4 Led
Livello carica 0% 25% 50% 75% 100%
L’indicatore lampeggerà un led alla volta durante la ricarica. Le luci fisse indicano il
livello di carica. L’indicatore si spegne a carica completa.
Istruzioni per la ricarica
1. Connettere il cavo USB al caricatore e collegarlo ad una presa di corrente.
2. Collegare il cavo Micro-USB alla presa di ricarica del dispositivo.
In alternativa, collegare il cavo Micro-USB alla presa di ricarica del dispositivo quindi
connetterlo ad un porta USB attiva.
Italiano
Prima di avviare un veicolo 12V
Inserire il connettore blu del cavo con pinze nell’ingresso
12V (1) assicurandosi che non ci siano indicatori LED accesi.

6
Avviamento di emergenza
1. Il dispositivo deve essere ben carico, con i quattro LED blu dell’indicatore accesi.
2. Connettere la pinza rossa al terminale positivo (+) della batteria oppure al polo
positivo remoto. Connettere la pinza nera al polo negativo (-) della batteria oppure
al polo negativo remoto.
3. È importante che la connessione venga fatta con entrambi i lati della pinza
saldamente ancorati sul metallo. In caso di depositi solforosi sul polo, questi
devono essere preventivamente rimossi.
4. Verificare lo stato dei LED sul blocchetto delle pinze secondo lo schema sottostante:
Italiano
Stato dei led Indicazione Soluzione
VERDE FISSO Tutto OK, Avviare il motore
VERDE LAMPEGGIANTE Batteria veicolo quasi
scarica
Premere BOOST, quando
VERDE FISSO avviare il
motore
ENTRAMBI SPENTI Batteria a zero V o assente Premere BOOST, quando
VERDE FISSO avviare il
motore
ROSSO FISSO (1) Temperatura eccessiva
dell’avviatore
Far raffreddare l’avviatore
ROSSO FISSO (2) L’avviatore è scarico Ricaricare l’avviatore
ROSSO FISSO (3) Cattiva connessione delle
pinze
Migliorare la connessione,
pulire i poli batteria
ROSSO LAMPEGGIANTE Carico di avviamento
eccessivo
Attendere 30 sec. circa e
riprovare
LAMPEGGIO
ALTERNATO VERDE
ROSSO
Superato il limite di
avviamenti in 10 min*
Attendere 10 min circa e
riprovare
ROSSO FISSO E
ALLARME ACUSTICO
Inversione di polarità Connettere Pinza Rossa su
+ e Pinza nera su -
(*) L’avviatore va in auto-protezione quando si effettuano 4 avviamenti in meno di 10 minuti

7
5. Avviare il veicolo per un massimo di 3 secondi e far riposare almeno tre minuti tra
un tentativo ed il successivo.
6. Quando il veicolo è in moto rimuovere una pinza alla volta, riporla negli appositi
alloggiamenti e ricaricare il dispositivo appena possibile.
Attenzione: quando viene premuto il pulsante BOOST, viene inibita per 30 secondi la
funzione di sicurezza del dispositivo. È importante che, ad avviamento effettuato, i cavi
vengano rapidamente disconnessi dalla batteria, per non sottoporre il dispositivo ad un
pericoloso sovraccarico.
Ricarica di telefoni e tablet
1. Connettere il dispositivo elettronico alla porta USB per la ricarica veloce (5).
2. Premere il pulsante dell’avviatore per avviare la ricarica, i-Starter 2.8 riconoscerà
automaticamente l’amperaggio di cui necessita il dispositivo da ricaricare.
Utilizzo della lampada LED
Premere per 3 secondi il pulsante per accendere la lampada. La luce può essere: Fissa,
Lampeggiante, SOS.
SPECIFICHE TECNICHE
Capacità batteria litio (LiPo)* 13.000 mAh (48.1 Wh)
Uscite 5V-2.1A; Ricarica veloce (5V-2.4A; 9V-2A;
12V-1.5A),12V per avviamento
Ingresso Ricarica veloce 5V / 9V
Tempo di ricarica Circa 3 ore
Ampere di Avviamento 500A
Ampere di picco 1500A
Temperature di utilizzo -20°C / 60°C
Dimensioni 151x81x32 mm
Peso 440 gr
(*) Batteria al Litio-Polimero
Italiano

8
PROBLEMI / SOLUZIONI
Problema Causa Rimedio
i-Starter 2.8 non è
completamente carico
anche se i LED sono
accesi
In caso di lungo
inutilizzo il dispositivo
potrebbe non essere
completamente carico
anche se i led sono
accesi
Ricaricare l’apparecchio
connettendolo al suo
caricatore per qualche ora
Premendo l’interruttore i
LED non si accendono
E’ entrata in funzione
la protezione di basso
voltaggio
Connettere subito il dispositivo
al suo caricabatteria
D: Come si spegne il dispositivo?
R: Il dispositivo si spegne da solo automaticamente quando non c’è carico o quando la
ricarica è completa.
D: Quanto tempo impiega l’i-Starter 2.8 a caricarsi completamente?
R: Se il dispositivo è completamente scarico possono essere necessarie circa 3 ore.
D: Quante volte posso ricaricare il mio telefono?
R: Con questo dispositivo potete in media ricaricare fino a 5 volte il vostro iPhone 6
D: Per quante volte il dispositivo carico al 100% è in grado di avviare un veicolo a
benzina di media cilindrata?
R: Fino a 20 volte, dipende da altri fattori quali la temperatura e lo stato della batteria
del veicolo.
D: Ogni quanto tempo devo caricarlo?
R: Consigliamo vivamente di caricarlo almeno una volta ogni tre mesi o dopo ogni utilizzo.
DOMANDE PIÙ FREQUENTI
Italiano

9
AVVERTENZE
1. Entrambe le pinze devono essere ben connesse ai poli della batteria o ai terminali
remoti. Questi devono essere esenti da ruggine, sporco o solfati.
2. Se la vettura nonparte dopo il terzo tentativo occorrefar raffreddare convenientemente
il dispositivo, altrimenti verrà irreparabilmente danneggiato. Controllare che la vettura
non abbia altri problemi che ne impediscono la messa in moto.
3. NON connettere tra di loro le due pinze, rischio di scintille ed incendio.
4. NON aprire il dispositivo, rischio di incendio.
5. L’uso incorretto del dispositivo può danneggiare in modo irreparabile la batteria
6. La garanzia non si applica alla batteria in quanto materiale di consumo.
7. L’avviatore deve sempre essere ricaricato in ambienti ben areati e a idonea
distanza da materiali facilmente infiammabili.
8. La non osservanza delle istruzioni può portare ad un grave danneggiamento
dell’unità.
Inoltre:
• Usare sempre la massima attenzione nell’uso per avviamento
• Tenere al di fuori della portata dei bambini
• Non tenere in luogo umido
• Non immergere in acqua
• Non usare in vicinanza di liquidi infiammabili o in presenza di gas infiammabili
• Qualunque intervento deve essere fatto da personale autorizzato
• Non esporre a fonti di calore
• La ricarica deve essere effettuata a temperatura ambiente e solo con il
caricabatteria in dotazione
• Se utilizzato al di fuori degli standard operativi si possono verificare perdite di
liquidi. Evitare attentamente il contatto con gli occhi, la pelle e gli abiti. In caso di
contatto con occhi o pelle lavare con acqua abbondante e rivolgersi ad un medico.
Italiano

10
Thank you for choosing a i-Starter product.
We advise you to carefully follow the instructions contained in this manual.
Non-compliance with the safety regulations can lead to damage to persons or
goods and cause irreparable damage to the device.
Keep this instruction Manual for future consultations.
PRODUCT DESCRIPTION
English
1. Jump start socket
2. Switch
3. Indicator
4. 5V2.1A output port
5. Quick Charge output port
6. LED Flash Light
7. Quick Charge input port
12
3
2
4
567
Jump start socket Quick Charge output port
Intelligent jumper cable
Quick Charge input port
Home charger

11
INSTRUCTIONS FOR USE
Indicator
Press the push button in order to check the charge state of the device.
Indicator Switched off 1 Led 2 Led 3 Led 4 Led
Charge level 0% 25% 50% 75% 100%
One led at a time will flash in the indicator during recharge. Steady-on-lights indicate the
charge level. The indicator switches off once fully charged.
Recharge instructions
1. Plug the home charger into the USB cable.
2. Connect the Micro connector to the i-Starter 2.8 host.
Otherwise plug the USB charger cable to any working USB output port and connect the
Micro connector to the i-Starter 2.8 host.
English
Jump start 12V vehicle Instruction
Connect the blue plug fully seated into the host, and make
sure the Cable Indicator is off.

12
Emergency start
1. The device must be properly charged, with the four blue LEDs of the indicator
switched on.
2. Connect the red clamp to the positive terminal (+) of the battery, or to the remote
positive pole. Connect the black clamp to the negative pole (-) of the battery or to
the remote negative pole.
3. The connection must be realized with both sides of the clam firmly attached to the
metal. In case of sulphur deposits on the pole, these must be previously removed.
4. Check the LED status on clamps box following below panel:
English
Led Status Indications Solutions
GREEN ON Ok, you can start the vehicle
GREEN FLASHING Vehicle battery is deeply
discharged
Press BOOST 2 sec. When
green LED on start the
vehicle
BOTH OFF Vehicle battery at 0V or
removed
Press BOOST 2 sec. When
green LED on start the
vehicle
RED ON (1) Over-Temperature protection Cool down the Jumpstarter
RED ON (2) The jump starter is in low
voltage
Charge the jumpstarter
RED ON (3) Connection is not good Make a better connection on
battery poles
RED FLASHING Over-Current protection Wait 30 sec. and start again
RED AND GREEN
FLASHING
More than 4 jumps in 10
minutes*
Wait 10 minutes and start
again
RED ON AND BUZZER Reversed polarity Check + (Red) and – (Black)
connections
(*) Jumpstarter enters auto-protection mode when used more than 4 times in 10 minutes.

13
5. Turn the ignition key for a maximum of 3 seconds and then wait for a further 3
minutes before attempting to jump start again.
6. When the engine is running, remove one clamp at a time, return the clamps to their
housing and recharge the starter as soon as possible.
Note: when the push button BOOST is pressed, the security function of the device is
inhibited for 30 seconds. Once the engine has been jump started, the cables must be
quickly disconnected from the battery in order not to overload it.
Charging of cell phones and tablets
1. Plug the switch cable to Quick Charge output port.
2. Select appropriate connector and connect it to your mobile phones or tablet.
3. Touch the switch button, it can recognise eletronic products’s suitable parameters,
start to charge for mobile phone/tabletc etc.
Use of the LED lamp
Press the switch 3 seconds to start the LED flash light.
There are 4 modes of LED light appear in order (normal, strobe. SOS, off) if you press
slightly.
TECHNICAL SPECIFICATIONS
Lithium Battery Capacity (LiPo)* 13000 mAh (48.1 Wh)
Outputs 5V-2.1A; Quick Charge (5V-2.4A; 9V-2A;
12V-1.5A); 12V jump start
Input socket Quick Charge 5V / 9V
Recharge time About 3 hours
Cranking Ampere 500A
Peak Ampere 1500A
Operating temperatures -20°C / 60°C
Sizes 151x81x32 mm
Weight 440 gr
(*) Lithium polymer Battery
English

14
PROBLEMS / SOLUTIONS
Problem Cause Solution
The i-Starter 2.8 is not
fully charged despite the
LEDs being switched on
If not used for a long
period of time, the
device could not be fully
charged despite the
LEDs being on
Recharge the device by
connecting it to its charger
for a few hours
By pressing the push
button, the LEDs do not
switch on
Low-voltage protection
has been activated
Connect the device to its
charger immediately
Q: How do I switch off the device?
A: The device shuts down automatically when it is not on charge or when the recharge
process is over.
Q How many times can I recharge my cell phone?
A: This device allows you to recharge your iPhone 6 up to 5 times on average.
Q: How long does the charger provided take to recharge the i-Starter 2.8?
A: If the device is completely dead, it may take up to 3 hours.
Q: How many times is a 100% charged device able to start a mid-size petrol vehicle?
A: Up to 20 times. It depends on other factors such as temperature and the state of the
vehicle battery.
Q: How often shall I recharge it?
A: We warmly recommend you to charge it at least once every three months or after
each use.
MOST FREQUENTLY ASKED QUESTIONS
English

15
WARNING
1. Both clamps must be well connected to the battery poles or to the remote
terminals. They must be free of rust, dirt or sulphates.
2. If your car does not start after the third attempt, you’d better let the device cool
down properly to avoid irreparable damage. Search for other problems that may
prevent your car from starting.
3. DO NOT connect the two clamps together as this may cause sparks or fires.
4. DO NOT open the device to avoid fire risk.
5. Incorrect use of the device can irreparably damage the battery.
6. The guarantee does not apply to the battery as this is a consumable item.
7. The booster must always be recharged in well-ventilated places and away
from easily inflammable materials.
8. Non compliance with the above instructions may lead to serious damage of the
unit.
Furthermore:
• Always pay the utmost attention when using the device for engine starting
• Keep out of children’s reach
• Do not keep in a humid place
• Do not soak in water
• Do not use in close proximity to inflammable liquids or in the presence of
inflammable gases
• Any intervention must be carried out by authorized personnel only
• Do not expose to heat sources
• Battery charging must be carried out at room temperature and only by using the
charger provided
• If the device is not used in compliance with the operational standards, leaking of
fluids may occur. Carefully avoid contact with eyes, skin and clothes. In case of
contact with eyes or skin, wash with plenty of water and see a doctor.
English

I
DICHIARAZIONE DI CONFORMITÀ
Noi, INTEC S.r.l.
Indirizzo: Via A. De Francisco 148/4, Settimo
T.se (TO),
dichiariamo sotto la nostra esclusiva
responsabilità che i prodotti ai quali questa
dichiarazione si riferisce sono conformi a quanto
previsto dalle direttive: 2014/30/UE, 2014/35/UE
GB
DECLARATION OF CONFORMITY
We, INTEC S.r.l.
Address: Via A. De Francisco 148/4, Settimo
T.se (TO),
declare under our sole responsibility that the
following products to which this declaration
relates conform with the provisions of Directives:
2014/30/UE, 2014/35/UE
F
DECLARATION DE CONFORMITÉ
Nous, INTEC S.r.l.
Addresse: Via A. De Francisco 148/4, Settimo
T.se (TO),
déclarons sous notre seule responsabilité que
les produits auxquels se réfère cette déclaration
sont conformes aux dispositions des Directives:
2014/30/UE, 2014/35/UE
D
KONFORMITÄTSERKLÀRUNG
Wir, INTEC S.r.l.
Anschrift: Via A. De Francisco 148/4, Settimo
T.se (TO),
erklären auf eigene Verantwortung, daß folgende
Produkte, auf die sich diese Erklärung bezieht,
mit den Bedingungen der Direktiven 2014/30/
UE, 2014/35/UE, übereinstimmen.
E
DECLARACIÒN DE CONFORMIDAD
Nosotros, INTEC S.r.l.
Direcciòn: Via A. De Francisco 148/4, Settimo
T.se (TO),
declaramos bajo nuestra exclusiva
responsabilidad la conformidad de los productos
a los que refiere esta declaraciòn, con las
disposiciones de Directiva:
2014/30/UE, 2014/35/UE
Modello / Model / Modèle / Modell / Modelo
I-Starter 2.8
Marco Bartolozzi - Amministratore Delegato
29/05/2020
vr. 2.1 20201211
i-Starter è un marchio distribuito dalla INTEC srl
Via A. De Francisco 148/4 - 10036 Settimo T.se (TO)
T. +39 011 8957403 F. +39 011 8958012
Table of contents
Languages:
Other Intec Measuring Instrument manuals
