TESTO 330i Service manual

testo 330i · Flue gas measuring instrument
testo 330i LX · Flue gas measuring instrument
Startup & Safety

2

1 Commissioning
3
Pos: 1 /TD/Erste Sc hritte/testo 330/ testo 330i App installier en @ 17\mod_143504277172 8_79.docx @ 214027 @ 222255 @ 1
1Commissioning
1.1. Installing the App
A mobile terminal device (tablet or smartphone) with the Android or
iOS operating system and Bluetooth® interface is required to
operate the testo 330i / testo 330i LX measuring instrument.
The testo 330i App also needs to be installed on this mobile
device:
1. Open the AppStore on the mobile terminal device.
2. Enter the search term Testo SE to start searching.
3. Select the testo 330i App and install.
Information on the compatibility of the App with your mobile
terminal device can be found in the respective AppStore.
Observe the documentation for your mobile terminal device when
installing the App!
1.2. Establishing a connection
✓The testo 330i App must be installed on your mobile terminal
device.
1. Switch on the measuring instrument: Press the key.
- Measuring instrument starts up: The blue LED flashes (0.05 s
on / 0.5 s off).
- Connecting mode is activated: The blue LED flashes (0.5 s on /
0.5 s off).
2. Start up the testo 330i App on your mobile terminal device.
- The Find Device function is activated: Any compatible devices
within radio range are displayed (product name + last 4 digits of
the device serial number).
3. Tap instrument designation to select a measuring instrument.
- It may take around 30 s to establish the connection.
- A Bluetooth®connection is established: The blue LED is
constant.
If it is not possible to establish a connection, various
corrective measures are displayed. If you are unable to
implement these successfully, please refer to the section
Tips and assistance and/or contact your dealer or Testo
Customer Service. For contact details, please visit
www.testo.com/service-contact.
- The first time a connection is established with a measuring
instrument the Country version function opens.

2 Safety and the environment
4
The Country version configuration affects the measurement
parameters, fuels, fuel parameters, and the basis of and formulas
for calculations activated in the measurement box.
4. Tap the Country version to be activated.
5. Tap Continue to perform a restart.
6. Restart the testo 330i App.
7. Tap instrument designation to select a measuring instrument.
- The Flue gas function opens.
- The instrument is operational.
1.3. Further information
It is paramount that you read and observe the warning and safety
instructions in the Safety and the environment section before using
the measuring instrument!!
Tutorial
A description of the most important operating controls and functions
can be opened in the App.
> | Help | Tutorial
Instruction manual
For further information please download the instruction manual as a
PDF file from our website:
www.testo-international.com/330imanuals
The website can also be called up directly from your mobile
terminal device (internet connection required):
> | Help | Help online
Pos: 2 /TD/Übersc hriften/2. Sic herheit und Umwelt @ 0\mod_11737 74719351_79.docx @ 292 @ 1 @ 1
2Safety and the environment
Pos: 3 /TD/Sic herheit und Umwelt/Zu diese m Dokument/Verwendung/V erwendung (Standar d) @ 0\mod_1173775068554_ 79.docx @ 337 @ 5 @ 1
Use
> Please read this documentation through carefully and
familiarize yourself with the product before putting it to use. Pay
particular attention to the safety instructions and warning advice
in order to prevent injuries and damage to the products.
> Keep this document to hand so that you can refer to it when
necessary.
> Hand this documentation on to any subsequent users of the
product.

2 Safety and the environment
5
Pos: 4 /TD/Übersc hriften/2.2 Sic herheit gewährleisten @ 0\m od_1173780783960_7 9.docx @ 366 @ 2 @ 1
2.1. Ensure safety
Pos: 5 /TD/Sic herheit und Umwelt/330i W arnhinweise für IAL @ 18\mod_ 1438183605526_79.doc x@ 216317 @ 555 @ 1
Please note for transportation and use:
Strong holding magnets on the back of the instruments!
WARNING
Magnetic field
May be harmful to those with pacemakers.
> Keep a minimum distance of 15 cm between pacemaker and
instrument.
ATTENTION
Magnetic field
Damage to other devices!
>Keep a safe distance away from products that could be
damaged by the effects of magnetism (e.g. monitors,
computers or credit cards).
For differential pressure measurements please note:
WARNING
Dangerous mixture of gases
Danger of explosion!
> Make sure there are no leaks between the sampling point and
the measuring instrument.
> Do not smoke or use naked flames during measurement.
Please note when emptying condensate:
CAUTION
Condensate entering the gas path.
Damage to sensors and flue gas pump!
> Do not empty the condensate container while the flue gas
pump is in operation.
Pos: 6 /TD/Sic herheit und Umwelt/Sicher heit gewährleisten/S icherheitsrele vante Symbole auf dem Gerä t@ 8\mod_12966516439 92_79.docx @ 76793 @ @ 1

2 Safety and the environment
6
Safety related symbols on the instrument
Representation Explanation
If the product is not used in strict compliance
with this documentation, the intended
protection may be impaired.
> Operate the product only as described in
this documentation.
> Please consult your dealer or the
manufacturer if in doubt.
Pos: 7 /TD/Sic herheit und Umwelt/Sicher heit gewährleisten/ Grundlegende Sic herheitshinweise @ 18\mod _1438256496472_79. docx @ 216441 @ 5 @ 1
Fundamental safety instructions
Pos: 8 /TD/Sic herheit und Umwelt/Si cherheit gewähr leisten/Produkt besti mmungsgemäß ver wenden @ 0\mod_117378126 1848_79.docx @ 386 @ @ 1
> Only operate the product properly, for its intended purpose and
within the parameters specified in the technical data. Do not
use any force.
Pos: 9 /TD/Sic herheit und Umwelt/Si cherheit gewähr leisten/Gerät bei Beschädigungen ni cht in Betrieb ne hmen @ 0\mod_1186985945 375_79.docx @ 2252 @ @ 1
> Do not operate the instrument if there are signs of damage at
the housing, mains unit or feed lines.
Pos: 10 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/Keine Messung an spann ungsführenden Teilen @ 0\mod_11756925 64164_79.docx @ 592 @ @ 1
> Do not perform contact measurements on non-insulated, live
parts.
Pos: 11 /TD/Sic herheit und Umwelt/Si cherheit gewährlei sten/Nicht mit Lö sungsmitteln la gern @ 0\mod_11756923751 79_79.docx @ 583 @ @ 1
> Do not store the product together with solvents. Do not use any
desiccants.
Pos: 12 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/Nur beschriebene W artungsarbeiten durc hführen @ 0\mod_11756927 05195_79.docx @ 601 @ @ 1
> Carry out only the maintenance and repair work on this
instrument that is described in the documentation. Follow the
prescribed steps exactly. Use only original spare parts
from Testo.
Pos: 13 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/testo 350/testo 350 Si cherheit @ 5\mod_1261385 845735_79.doc x@ 53306 @ @ 1
> Any further or additional work must only be carried out by
authorised personnel. Testo will otherwise refuse to accept
responsibility for the proper functioning of the measuring
instrument after repair and for the validity of certifications.
Pos: 14 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/Nur in geschlossenen, tr ockenen Räumen betrei ben @ 0\mod_11869857978 28_79.docx @ 2243 @ @ 1
> Only use the device in closed, dry rooms and protect it from rain
and moisture.
Pos: 15 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/Temperaturangaben auf Sonden/Fühler n @ 0\mod_117569329307 0_79.docx @ 610 @ @ 1
> Temperatures given on probes/sensors relate only to the
measuring range of the sensors. Do not expose handles and
feed lines to any temperatures in excess of 70 °C unless they
are expressly permitted for higher temperatures.
Pos: 16 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/testo 330/Sichtbar er Schaden @ 13\mod_136999 9619300_79.doc x@ 16253 4 @ @ 1
> The testo 330 must be checked before commissioning for any
visible damage. Do not commission the testo 330 if there are
signs of damage on the housing, mains unit or supply lines.
Electrical risk.

2 Safety and the environment
7
Pos: 17 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/vor Ort gültige Sic herheitsbestimmungen be achten @ 0\mod_11869971 07328_79.docx @ 2298 @ @ 1
> Dangers may also arise from the systems being measured or
the measuring environment: Note the safety regulations valid in
your area when performing the measurements.
Pos: 18 /TD/Sic herheit und Umwelt/Sicher heit gewährleiste n/Option Bluetooth tes to 330 @ 7\mod_12814223209 10_79.docx @ 68203 @ 5 @ 1
For products with Bluetooth®(optional)
Changes or modifications that have been made without the explicit
consent of the responsible approval authority, may cause the
retraction of the type approval.
Data transfer may be disturbed by equipment that uses the same
ISM-band, e.g. WLAN, microwave ovens, ZigBee.
The use of radio communication links is not permitted, among
others, in aeroplanes and hospitals. For this reason the following
points must be ensured before entering:
> Switch off the device:
> Isolate the device from any external power sources (mains
cable, external rechargeable batteries, ...).
Pos: 19 /TD/Übersc hriften/2.3 Umwel tsc hützen @ 0\mod_117378084 3645_79.docx @ 375 @ 2 @ 1
2.2. Protecting the environment
Pos: 20.1 /TD/Si cherheit und Umwelt/ Umwelt schützen/Akkus/ Batterien entsorgen @ 0\mod_117569 3637007_79.docx @ 619 @ @ 1
> Dispose of faulty rechargeable batteries/spent batteries in
accordance with the valid legal specifications.
Pos: 20.2 /TD/Si cherheit und Umwe lt/Umwelt schützen/ Produkt entsorgen @ 0\mod_1173780 307072_79.doc x@ 357 @ @ 1
> At the end of its useful life, send the product to the separate
collection for electric and electronic devices (observe local
regulations) or return the product to Testo for disposal.
=== Ende der Li stef ür Textmarke Inhalt ===

0970 3340 en 02 en_EN
