Intech Instruments Ltd TES-1330A User manual

TES-1330A/1332A/1334A Light Meter
Spectral Sensitivity close to CIE photo pic Curve
Cosine Angular corrected
Analog output jack for recording (TES-1332A/1334A)
Data Hold function, Peak Hold function for 1334
Display 3 1/2 digit LCD
Measuring Range
20/200/2000/20000 Lux
(1330A also Footcandle for 1334A)
200/2000/20000/200000 Lux (1332A)
20000 lux-reading x 10;
200000 lux-reading x 100
Overrange Display Hightest digit of (1) is displayed
Resolution 0.01 Lux(1330A,1334A) & 0.1 Lux(1332A)
Accuracy
+/- 3% rdg +/- 0.5% f.s.(<10,000 lux)
+/- 4% rdg +/- 10dgts (>10,000 lux)
(calibrated to standard incandescent lamp, 2856 K)
Repeatability ±2%
Temperature Characteristics ±0.1%
Measuring Rate Approx. 2 times/sec.
Recorder Output DC 2V/f.s. (full scale) (TES-1332A)
Operating Temperature &
Humidity 0 ° to 40 (32 to 104 ) < 70% R.H.
Power Source one 9V battery
Dimensions 100mm(L) x 60mm(W) x 27mm(H)
Dimension 135mm(L) x 72mm(W) x 33mm(H)
Weight 250g
Accessories Carrying case, 9V battery & Instruction Manual

6520
105
24
24 35
Fits 20mm nom. conduit (3/4")
TWN-LUX
Light Sensor.
Ordering Information.
TWN-LUX Standard Calibration: 0~1000lux Nominal.
Specifications.
Input Adjustable from 1~10lux to 0~1000lux Nominal.
Turn Trimpot fully clockwise = 0~10lux Nominal.
Turn Trimpot fully anticlockwise = 0~1000lux Nominal.
(Note: Trimpot requires 25 turns to go from one end to the other.)
Output -Voltage 0~10Vdc.
Output Impedance = 1kΩ
(Note:Witha12Vdcpowersupplyoutputmayonlyrisewithinapprox.95%FSO.)
-Current 4~20mA, 3 wire.
Maximum Load = 300Ω@ 12Vdc.
Maximum Load = 900Ω@ 24Vdc.
PowerSupply 12~24Vdc.
Current Draw -Voltage Output 20mA @ 24Vdc P/S with 10Vdc out.
-Current Output 40mA @ 24Vdc P/S with 20mA out.
Operating Temperature 0~70C.
Storage Temperature -20~80C.
OperatingHumidity 90%RH Max. Non-Condensing.
Note 1. Specifications based on Standard Calibration Unit, unless otherwise specified.
Note 2. Due to ongoing research and development, designs, specifications, and documentation are subject to change without notification.
No liability will be accepted for errors, omissions or amendments to this specification.
Connection Example. Dimensions.
12~24Vdc
PowerSupply.
Eg.Indicator,2100-M,
etc. With
4~20mACurrent Input.
(See Note Beside.)
TWN-LUX
V+ 1
mA 2
Vout 3
COM 4
The Proper Installation & Maintenance of TWN-LUX.
MOUNTING.
(1) Mount in a clean environment away from power control equipment. Be mindful of positioning the light sensor, (mounted at
the end of the enclosure) so that the desired level of illumination reaches the sensor. Do Not mount the sensor in direct light
or sunlight - measure reflected light.
(2) Do not subject to vibration or excess temperature or humidity variations.
WIRING.
(1) All cables should be good quality overall screened INSTRUMENTATION CABLE with the screen earthed at one end only.
(2) Signal cables should be laid a minimum distance of 300mm from any power cables.
(3) For 2 wire current loops Austral Standard Cables B5102ES is recommended. For three wire transmitters, RTD's and
Resistance Probes, Austral Standard Cables B5103ES is recommended.
(4) It is recommended that you do not ground current loops and use power supplies with ungrounded outputs.
(5) Lightning arrestors should be used when there is a danger from this source.
(6) Refer to diagrams for connection information.
COMMISSIONING.
(1) Once all the above conditions have been carried out and the wiring checked apply power to the TWN-LUX and allow five
minutes for it to stabilize.
(2) ItisadvisedtoadjusttheoutputoftheTWN-LUXtotheluxlevelrequiredusingacalibratedluxmeter,oncethe"room"being
measured is complete. This is necessary as every installation has a unique reflective pattern, depending on colours,
windows, positioning of walls, furniture, etc. Turn the Trimpot clockwise to increase the output reading, and anticlockwise
to decrease the output reading.
MAINTENANCE.
(1) Repeat (3) of the commissioning instructions. Do it regularly - at least once every 12 months.
twn-lux.p65
ISSUE 280999
Christchurch Nelson Auckland
Ph: 03 343 0646 Ph: 03 546 6840 Ph: 09 827 1930
Fx: 03 343 0649 Fx: 03 548 8797 Fx: 09 827 1931
Intech INSTRUMENTS LTD.
LED Sensor
Light Intensity (LUX)
Sensor and 3 Wire
Output Transmitter.
+
-
Eg.Indicator,2100-M,
etc. With
0~10VdcVoltage Input.
(See Note Beside.)
+
-
+
-
Note: Only one output (mA or V)
need to be connected.
However both may be used.
TECHNOLOGY
& QUALITY
A
1997
W A R D
ISO9001
E
G
I
S
T
E
R
R
E
D
S
U
P
P
I
R
E
L
Description.
TheTWN-LUXincorporatesasiliconphotodiodelightsensor,inahermeticalsealedcase,especially
designedforhighprecisionlinearapplications.Thesensorhasaflatglasswindowwithabuiltincolour
correction filter, giving an approximation to the spectral response in the human eye. As an aid in
adjustment an LED is mounted next to the sensor, with a gradual turn on at approx. 30% FSO.
1.01-1
132mm
25
25
41
17.5 75
110
Fits 20mm nom. conduit. (3/4")
