RP-800T

860 MHz UHF FM VOICE TRANSMITTER

OPERATING MANUAL

INTRODUCTION

This Voice Transmitter has been specifically designed for use in combination with the Voice Pager (receiver) model RP-800R, for

the following purposes :

- as a transmitter for Voice Paging Systems in Tourists Guided Tours

- as a transmitter for Voice Paging Systems in Conferences, Congresses, Meetings, Voice Interpretation, etc.

- as a transmitter for Voice Paging Systems in stores, hotels, restaurants, resorts, factories, warehouses, offices, shops,

motorcycle driving schools, etc. and wherever a message or a voice communication from a main transmitter must be received

by either one or more groups of persons or by a single person.

The transmitter operates on the 860 MHz UHF FM band, which is usually free from interferences. Transmitter is fully programmable

by the system manager in the PROGRAM mode. Please read the following operating instructions before using the radio.

KEYS AND CONTROLS

1. High efficency Antenna

2. UP Key

3. Hole for Necklace

4. DOWN Key

5. Window for Operator Card

6. Desk Charger Contacts

7. MO (MODE) Key

8. EMG Key

9. Power ON-OFF Key

10. TX Key

11. Belt Clip

12. Battery door

13. Backlighted LCD

14. Microphone Jack

LCD DISPLAY

A. Transmitting Icon

B. Channel Number

C. Battery Level Indicator

D. EMG Channel Icon

E. VOX (Handsfree use) Icon

BATTERY INSTALLATION

1. Remove the Belt Clip (11). To

remove the belt clip, pull the block

tab toward exterior and slide the

clip toward the up side of the unit.

2. Slide down and remove the

battery door (12) by unlocking the

block tab.

3. Install 3 x AA size batteries.

Please respect correct polarity.

4. Re-install the battery door (12).

5. Re-install the Belt Clip (11).

BATTERY CHARGING / MULTIPLE DESK CHARGER (Mod. MDC-800)

When the battery capacity is low, the Battery Level Indicator (C) shows one bar only. Recharge batteries at this time. Otherwise the

transmitter will be automatically switched OFF after few minutes. When the battery capacity is low, switch OFF the transmitter and

insert it in the Multiple Desk Charger.

Please refer to the instruction manual supplied with the Multiple Desk Charger.

WARNING !

1. If the product will not be used for a long period of time, please take out the batteries.

2. Please dispose of old or defective batteries in a safe and environmentally friendly manner.

3. Do not dispose of batteries in fire.

4. Do not recharge batteries for more than 12 hours, to avoid overcharge or overheating, which could damage the radio.

5. Do never try to recharge alkaline batteries, as this might cause damage to the radio or explosion of the batteries.

6. Do not use chargers or accessories others than the original ones, otherwise damage to the radio may occur.

BASIC OPERATION - USER MODE

When radio is turned ON, it always sets in the USER MODE. In this mode, user can only operate the following basic functions, in

order to avoid entering any wrong command or change the radio settings and programming.

Power ON/OFF

1. Switch ON the radio by pressing and holding the PWR (9) key for about 2 seconds.

2. The LCD Display (13) will shortly show all the icons.

3. Then the LCD Display (13) will show the Channel Number (B) and the Battery Level (C).

4. To switch OFF the radio, press and hold the PWR (9) key for about 2 seconds.

Transmitting Mode / PTT (Push-To-Talk) Function

1. Connect the supplied microphone to the MIC jack (14).

2. Quickly press the TX (10) key to transmit. The T Icon (A) appears on the LCD (13).

3. Speak with a normal voice into the microphone.

4. To stop transmission, shortly press again the TX key (10). If not, transmission will continue and it will automatically stop after 5

minutes. According to the current regulations, a continuous transmission cannot last more than 5 minutes.

5. Press again the TX (10) key to return to the transmitting mode.

Transmitting Mode / VOX (Handsfree use) Function

The radio is equipped with a Voice Operated Transmitter function (VOX), that is used for automatic voice transmission (handsfree

use). In this mode, transmission is automatically initiated by speaking into the microphone and there is no need to push the TX (10)

key. The VOX function is programmable only in the PROGRAM MODE.

1. If VOX function is enabled, the V icon (E) appears on the LCD (13).

2. Connect the supplied microphone to the MIC jack (14).

3. Speak with a normal voice into the microphone to activate the transmission.

4. Transmission will automatically stop at the end of the communication.

Emergency Channel

This functions allows to select and program an alternate channel, if the primary operating channel is already in use by other users.

Press and hold the EMG (8) key for about 3 seconds to select the programmed Emergency Channel. The EMG Icon (D) appears

on the LCD (13). To return on the operating channel, press and hold the EMG (8) key. The EMG Icon (D) will disappear from the

LCD (13). The Emergency Channel is programmable only in the PROGRAM MODE.

ADVANCED FUNCTIONS - PROGRAM MODE

Transmitter may be programmed by the system manager in the PROGRAM MODE. The following functions are programmable only

in the PROGRAM MODE. In the normal USER MODE, the user cannot access, program or modify any of these functions, in order

to avoid entering any wrong command or change the settings programmed by the system manager.

1. Channel selection (1-79)

2. Emergency Channel selection (1-79)

3. VOX Setting

To enter the PROGRAM MODE, proceed as follows :

1. Switch OFF the radio.

2. Switch ON the radio by pressing simultaneously the ON-OFF (8), the MO (7) key and the DOWN(4) key, until radio is ON.

3. The LCD Display (13) will shortly show all the icons. Then the LCD Display (13) will show the Channel Number (B)

4. Press the MO (7) key several times to scroll the various programmable functions.

Switch OFF the radio to exit the PROGRAM MODE.

Channel Selection

1. In the PROGRAM MODE the Channel Number (B) blinks on the LCD (13).

2. Press the UP (2) or DOWN (4) keys to select the desired channel number (1-79). Press and hold the UP (3) or DOWN (4) key,

to advance the channel selection quicker.

3. To confirm and store the selection and to move to the next function, press the MO (7) key.

Emergency Channel Selection

1. In the PROGRAM MODE press the MO Key (7) until the Channel Number (B) blinks and the EMG Icon (D) appears on the

LCD (12).

2. Press the UP (2) or DOWN (4) keys to select the desired Emergency channel number (1-79). Press and hold the UP (3) or

DOWN (4) key, to advance the channel selection quicker.

3. To confirm and store the selection and to move to the next function, press the MO (7) key.

Channels Table

VOX Setting

1. In the PROGRAM MODE press the MO Key (7) until the Channel Number (B) blinks.

2. Press again the MO Key (7) until V Icon (E) appears and the VOX level blinks on the LCD Display (13).

3. Press the UP (2) or DOWN (4) keys to select the desired VOX Level, from 1 (high sensitivity) to 3 (low sensitivity).

4. If level 0 is selected, the VOX function is disabled.

5. To confirm and store the selection and to exit the PROGRAM MODE, press the MO (7) key.

SPECIFICATIONS

Channels 79 Channels

Mode NFM

Operating Frequency Range 863.025 – 864.975 MHz

Transmitter Power 10mW ERP

Power Source 3.6V (3 x AA 1.2V 1500mAh Ni-MH Rechargeable Battery)

4.5V (3 x AA 1.5V Alkaline Battery)

Current Drain 90mA (in TX Mode)

Dimensions H120 x L62 X D21 mm

Weight gr. 150 (battery included)

IMPORTANT INFORMATION

Important !

Changes or modifications to this product could void your authority to operate this unit. Any adjustment to your radio must be made by a qualified authorized

technician or service station. Never open the cabinet of your radio. Never change or replace anything in your radio (except batteries).

Hazardous Environments

Do not operate the radio in hazardous environments. Do not keep radio under direct rain.

Care and Safety

To clean the radio, use a soft cloth dampened with water. Do not use cleaners or solvents because they can harm the body of the unit and leak inside, causing

permanent damage. Use a dry, lint-free cloth to clean the battery contacts. Do not submerge the unit in water or use it on a wet environment. If the unit gets

wet, turn it off and remove the battery immediately. Dry the battery and the battery compartment with a soft cloth to minimize potential water damage. Leave the

battery compartment cover off overnight to ensure complete drying. Do not use the radio until it is completely dry.

Battery Operation / Wasting

Dispose of battery in the proper manner, according to federal, state and local regulations that apply in your area. A battery may leak electrolyte if it is mixed in a

set with different battery types, if inserted incorrectly, if disposed of in fire, or if an attempt is made to charge a battery not intended to be charged. Discard leaky

batteries immediately. Leaking batteries can cause skin burns or other personal injury.

Warning !

The use of this device may be subject to national restrictions or regulations. Check your local authority or dealer before purchasing and using this product.

User Information

In accordance with art. 13 of the Legislative Decree of 25th July 2005, no. 15 ”Implementation of Directives 2002/95/EC, 2002/96/EC and

2003/108/EC, relative to reduction of the use of hazardous substances in electrical and electronic equipment, in addition to waste disposal”. The

crossed bin symbol shown on the equipment indicates that at the end of its working life the product must be collected separately from other

waste. The user must therefore take the above equipment to the appropriate differentiated collection centres for electronic and electro technical

waste, or return it to the dealer when purchasing a new appliance of equivalent type, in a ratio of one to one. Appropriate differentiated waste

collection for subsequent recycling, treatment and environment-friendly disposal of the discarded equipment helps to prevent possible negative

environmental and health effects and encourages recycling of the component materials of the equipment. Illegal disposal of the product by the user will be

punished by application of the administrative fines provided for by the legislative decree no. 22/1997 (article 50 and following of the legislative decree no.

22/1997).
