Intel NUC 13 Pro NUC13ANHi7 User manual

1
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
Intel® NUC 13 Pro Mini PC NUC13ANHi7
Intel® NUC 13 Pro Mini PC NUC13ANHi5
Intel® NUC 13 Pro Mini PC NUC13ANHi3
User Guide
March 2023

2
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel products
described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which includes subject
matter disclosed herein.
No license (express or implied, by estoppel or otherwise) to any intellectual property rights is granted by this document.
All information provided here is subject to change without notice. Contact your Intel representative to obtain the latest Intel product
specifications and roadmaps.
The products described may contain design defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Copies of documents which have an order number and are referenced in this document may be obtained by calling 1-800-548-4725 or by
visiting: http://www.intel.com/design/literature.htm.
Intel technologies' features and benefits depend on system configuration and may require enabled hardware, software or service activation.
Performance varies depending on system configuration. No computer system can be absolutely secure.
Intel and the Intel logo are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2023, Intel Corporation. All rights reserved.

3
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
Contents
1.0 Introduction.......................................................................................................................................................5
1.1 Before You Begin ...........................................................................................................................................5
1.2 Installation Precautions.............................................................................................................................5
1.3 Observe Safety and Regulatory Requirements.........................................................................6
2.0 Open the Chassis...........................................................................................................................................7
3.0 Upgrade System Memory ........................................................................................................................8
3.1 Upgrade to Different Memory ...............................................................................................................8
3.2 Install Additional Memory........................................................................................................................9
4.0 Changing the M.2 SSD............................................................................................................................ 10
5.0 Close the Chassis........................................................................................................................................ 12
6.0 Use the VESA Bracket (Optional) .................................................................................................... 13
7.0 Connect Power.............................................................................................................................................. 15
8.0 Set Up Microsoft® Windows 11........................................................................................................ 16
9.0 Install the Latest Device Drivers and Software..................................................................... 17
10.0 Operating System Recovery ............................................................................................................... 18

4
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
Revision History
Date
Revision
Description
March 2023
1.0
Initial release.

5
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
1.0 Introduction
This User Guide provides step-by-step installation instructions for these products:
•Intel® NUC 13 Pro Mini PC NUC13ANHi7
•Intel® NUC 13 Pro Mini PC NUC13ANHi5
•Intel® NUC 13 Pro Mini PC NUC13ANHi3
1.1 Before You Begin
CAUTIONS
The steps in this guide assume you’re familiar with computer terminology and
with the safety practices and regulatory compliance required for using and
modifying computer equipment.
Disconnect the computer from its power source and from any network before
performing any of the steps described in this guide.
Failure to disconnect power, telecommunications links, or networks before you open
the computer or perform any procedures can result in personal injury or equipment
damage. Some circuitry on the board can continue to operate even though the front
panel power button is off.
Follow these guidelines before you begin:
•Always follow the steps in each procedure in the correct order.
•Create a log to record information about your computer, such as model,
serial numbers, installed options, and configuration information.
•Electrostatic discharge (ESD) can damage components. Perform the
procedures described in this chapter only at an ESD workstation using an
antistatic wrist strap and a conductive foam pad. If such a station isn’t
available, you can provide some ESD protection by wearing an antistatic wrist
strap and attaching it to a metal part of the computer chassis.
1.2 Installation Precautions
When you install and test the Intel NUC, observe all warnings and cautions in the
installation instructions.
To avoid injury, be careful of:

6
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
•Sharp pins on connectors
•Sharp pins on circuit boards
•Rough edges and sharp corners on the chassis
•Hot components (such as SSDs, processors, voltage regulators, and heat sinks)
•Damage to wires that could cause a short circuit
Observe all warnings and cautions that instruct you to refer computer servicing
to qualified technical personnel.
1.3 Observe Safety and Regulatory Requirements
If you don’t follow these instructions, you increase your safety risk and the possibility
of noncompliance with regional laws and regulations.

7
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
2.0 Open the Chassis
Unscrew the four corner screws on the bottom of the chassis and lift the cover.

8
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
3.0 Upgrade System Memory
The Intel® NUC 13 Pro Mini PC NUC13ANH has two 260-pin DDR4 SO-DIMM sockets.
Pre-installed memory
Intel® NUC 13 Pro Mini PC NUC13ANHi7
2x 4GB DDR4-3200 SODIMMs
Intel® NUC 13 Pro Mini PC NUC13ANHi5
2x 4GB DDR4-3200 SODIMMs
Intel® NUC 13 Pro Mini PC NUC13ANHi3
2x 8GB DDR4-3200 SODIMMs
To upgrade memory, be sure to select memory modules that meet these
requirements:
•1.2V low voltage memory
•2400/2666/3200 MHz SO-DIMMs
•Non-ECC
•Up to 64GB of system memory supported with 2 SO-DIMMs using 32GB
memory modules
Find compatible memory modules in the Intel Product Compatibility Tool:
•Intel® NUC 13 Pro Mini PC NUC13ANHi7
•Intel® NUC 13 Pro Mini PC NUC13ANHi5
•Intel® NUC 13 Pro Mini PC NUC13ANHi3
NOTE
If you plan to install only one memory module, install it in the lower
memory socket.
3.1 Upgrade to Different Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Remove the pre-installed memory module
a. Gently spread the retaining clips at each end of the memory socket, which
causes the module to pop out of the socket (C).
b. Holding the module by the edges, lift it away from the socket, and
store it in an anti-static package.
6. Install the new memory module
a. Align the small space at the bottom edge of the memory module
with the key in the socket.
b. Insert the bottom edge of the module at a 45-degree angle into

9
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
the socket (A).
c. When the module is inserted, push down on the outer edges of
the module until the retaining clips snap into place (B). Make sure
the clips are firmly in place (C).
3.2 Install Additional Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Install the additional module:
a. Align the small space at the bottom edge of the memory module with the
key on the socket.
b. Insert the bottom edge of the module at a 45-degree angle into the
socket (A).
c. When the module is inserted, push down on the outer edges of
the module until the retaining clips snap into place (B). Make
sure the clips are firmly in place (C).
6. Reinstall and reconnect any parts you removed or disconnected to reach the
memory sockets.
7. Replace the computer’s cover and reconnect the power cord.

10
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
4.0 Changing the M.2 SSD
The Intel® NUC 13 Pro Mini PC NUC13ANH contains
•one 80mm connector supporting NVMe and
•one 42mm connector supporting SATA SSD
Pre-installed M.2
Intel® NUC 13 Pro Mini PC NUC13ANHi7
512GB Gen 4 NVMe SSD
Intel® NUC 13 Pro Mini PC NUC13ANHi5
512GB Gen 4 NVMe SSD
Intel® NUC 13 Pro Mini PC NUC13ANHi3
512GB Gen 4 NVMe SSD
Find compatible M.2 SSDs in the Intel Product Compatibility Tool:
•Intel® NUC 13 Pro Mini PC NUC13ANHi7
•Intel® NUC 13 Pro Mini PC NUC13ANHi5
•Intel® NUC 13 Pro Mini PC NUC13ANHi3
To install a different M.2 SSD:
1. Remove the small silver screw from the 80mm or 42mm metal standoff on the
board (A).
2. Remove the pre-installed SSD from the connector.
3. Align the space at the bottom of the new M.2 SSD to the key on the connector.
4. Insert the bottom edge of the M.2 SSD into the connector (B).
5. Secure the card to the standoff with the small silver screw (C).

11
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023

12
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
5.0 Close the Chassis
After all components have been installed, close the Intel NUC chassis. Intel
recommends this be done by hand with a screwdriver to avoid over-tightening and
possibly damaging the screws.

13
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
6.0 Use the VESA Bracket (Optional)
Follow these instructions to attach and use the VESA mount bracket:
1. Using the four small black screws that were included in the box, attach the
VESA bracket to the back of the monitor or TV.
2. Attach the two slightly larger black screws to the bottom chassis cover of the
Intel NUC.

14
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
3. Slide the Intel NUC onto the VESA mount bracket.

15
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
7.0 Connect Power
Each Intel NUC model includes a region-specific AC power cord.
Product codes
Power cord type
RNUC13ANHI70QA6
RNUC13ANHI50WA6
RNUC13ANHI30WA6
CN power cord included.

16
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
8.0 Set Up Microsoft® Windows 11
Microsoft Windows 11 is already installed on the Intel NUC. The first time you start the
computer, you are guided through the Windows 11 setup steps, including:
•Selecting your region and language.
•Accepting the Microsoft Windows license terms.
•Personalizing Windows and assign a PC Name.
•"Get Online" dialog to pick a wireless network (this step is optional).
•Choosing Express Settings or Customize.
•Assigning a Username and Password.
Reinstalling the Operating System
If you upgrade or replace the computer’s drive, you may need to install a new version
of the operating system. See these resources:
•Supported Operating Systems
•Windows Setup Guide

17
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
9.0 Install the Latest Device Drivers and Software
Here are the options for keeping device drivers current:
•Allow the Intel® Driver & Support Assistant (Intel® DSA) to detect out-of-
date drivers
•Manually download drivers, BIOS, and software from Download Center:
oIntel® NUC 13 Pro Mini PC NUC13ANHi7
oIntel® NUC 13 Pro Mini PC NUC13ANHi5
oIntel® NUC 13 Pro Mini PC NUC13ANHi3

18
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
10.0 Operating System Recovery
There’s a Windows recovery partition on the Intel NUC. You can use this partition to
Refresh, Reset, or Restore Windows. Here is what each of these actions do:
Refresh
If your PC isn't performing as well as it once did, and you don't
know why, you can refresh your PC. This action doesn’t delete any
of your personal files or change your settings. Refresh does the
following:
•Files and personalization settings won’t change.
•PC settings are changed back to their defaults.
•Apps from the Windows Store are kept.
•Apps installed from disks or websites are removed.
•List of removed apps is saved on the desktop.
Reset
If you want to recycle your PC, give it away, or start over with it, you
can reset it completely. This process removes everything. Reset
does the following:
•All personal files and apps are removed.
•PC settings are changed back to their defaults.
•Windows is reinstalled.
Restore
If a recently installed app or driver is causing problems with your
PC, you can restore Windows back to an earlier point in time,
called a restore point. System Restore doesn’t change your
personal files, but it can remove recently installed apps and
drivers.
Caution - Before performing a Refresh or Reset:
•Make sure to back up all personal data to external storage.

19
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide –March 2023
To access the recovery media:
If Windows starts
From Windows Start, type Recovery and select
Recovery Options.
See Recovery options in Windows 10/11 for
complete details on how to use the recovery options.
If Windows doesn’t start
The recovery process should automatically start. If
Recovery doesn’t automatically start, you can try to
initiate it as follows:
1. Press F8 during boot, when you see the
prompt “F8 to Activate Windows 8.1/10
Recovery Mode”.
2. Follow the recovery steps.
