Intel®Server Platforms SR6850HW4 and
SR6850HW4/M Product Guide

2 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Disclaimer
Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel or
otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions
of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating
to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability,
or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical,
life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time,
without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined."
Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising
from future changes to them.
This document contains information on products in the design phase of development. Do not finalize a design with this
information. Revised information is published when the product is available. Verify with your local sales office that you have
the latest datasheet before finalizing a design.
The Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide may contain design defects or errors known
as errata that may cause the product to deviate from published specifications. Current characterized errata are available on
request.
I2C is a two-wire communications bus/protocol developed by Philips. SMBus is a subset of the I2C bus/protocol and was
developed by Intel. Implementation of the I2C bus/protocol or the SMBus bus/protocol may require licenses from various
entities, including Philips Electronics N.V. and North American Philips Corporation.
Intel and Itanium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and
other countries.
Copyright © Intel Corporation 2005. *Other brands and names may be claimed as the property of others.

3
Preface
About this Manual
Thank you for purchasing and using the Intel®Server Platform SR6850HW4 or SR6850HW4/M.
This manual is written for system and service technicians who are responsible for troubleshooting,
upgrading, and repairing this Intel®Server Platform. This document provides a brief overview of
the features of the board/chassis, a list of accessories or other components you may need,
troubleshooting information, and instructions on how to add and replace components on the Intel®
Server Platforms SR6850HW4 and SR6850HW4/M. For the latest version of this manual, see
http://support.intel.com/support/motherboards/server/
Manual Organization
This manual consists of four parts:
Preface (this part): provides safety information and where to find more information about this
product and information about components that will work with this product.
Part 1: User’s Guide describes the server platform and procedures that do not require the
services of a qualified service technician.
Part 2: Service Technician’s Guide describes procedures that require the services of a qualified
service configuration technician.
Appendices include technical information, an equipment log, troubleshooting information,
regulatory information, and a glossary.
Product Accessories
You may need or want to purchase one or more of the following accessory items for your server:
Processor
Memory DIMMs
Hard drives
PCI adapters
Operating system
For information about which of these items have been tested and can be used with your Server
Platform, and for ordering information for Intel products, see
http://support.intel.com/support/motherboards/server/.

Preface
4 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Additional Information and Software
If you need more information about this product or information about the accessories that can be
used with this server, use the resources located at
http://support.intel.com/support/motherboards/server/
Unless otherwise indicated in the table below, once on this Web page, type the document or
software name in the search field at the left side of the screen and select the option to search “This
Product.”
For this information or software Use this Document or Software
For in-depth technical information
about this product, including BIOS
settings and chipset information
Technical Product Specification
If you just received this product and
need to install it Intel®Server Board SR6850HW4/M Quick Start User’s Guide in the product box
For virtual system tours and
interactive repair information A link to the SMaRT Tool is available under “Other Resources” at the right side of the screen at
http://support.intel.com/support/motherboards/server/
Accessories or other Intel server
products Spares and Configuration Guide
Hardware (peripheral boards,
adapter cards) and operating
systems that have been tested with
this product
Tested Hardware and Operating System List
Chassis that have been tested with
this product Reference Chassis List
Processors that have been tested
with this product Supported Processors
DIMMs that have been tested with
this product Supported Memory
To make sure your system falls
within the allowed power budget Power Budget
For software to manage your Intel®
server Intel®Server Management
For drivers Driver (for an extensive list of drivers available)
Operating System Driver (for operating system drivers)
For firmware and BIOS updates Firmware Update
For diagnostics test software Diagnostics

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 5
Safety Information
WARNINGS
Before working with your server product, whether you are using this guide or
any other resource as a reference, pay close attention to the safety instructions.
You must adhere to the assembly instructions in this guide to ensure and
maintain compliance with existing product certifications and approvals. Use
only the described, regulated components specified in this guide. Use of other
products / components will void the UL listing and other regulatory approvals of
the product and will most likely result in noncompliance with product
regulations in the region(s) in which the product is sold.
Emissions Disclaimer
To ensure EMC compliance with your local regional rules and regulations, the final
configuration of your end system product may require additional EMC compliance
testing. For more information, contact your local Intel Representative.
See “Regulatory and Integration Information” for product Safety and EMC
regulatory compliance information. This is an FCC Class A device. Integration of it
into a Class B chassis does not result in a Class B device.
Intended Uses
This product was evaluated as Information Technology Equipment (ITE), which may
be installed in offices, schools, computer rooms, and similar commercial type
locations. The suitability of this product for other product categories and
environments (such as: medical, industrial, telecommunications, NEBS, residential,
alarm systems, test equipment, etc.), other than an ITE application, may require
further evaluation.
EMC Testing
If the server board set is to be integrated into a non-Intel chassis, make sure that the
chassis, power supply, and other modules have passed EMC testing using the server
board set with a microprocessor from the same family (or higher) and operating at the
same (or higher) speed as the microprocessor used on this server board.
System power on/off: The power button DOES NOT turn off the system AC
power. To remove power from system, you must unplug all AC power cords from the
wall outlet. Make sure all AC power cords are unplugged before you open the
chassis, add, or remove any components.
Hazardous conditions, devices and cables: Hazardous electrical conditions
may be present on power, telephone, and communication cables. Turn off the server
and disconnect the power cord, telecommunications systems, networks, and modems
attached to the server before opening it. Otherwise, personal injury or equipment
damage can result.

Preface
6 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Electrostatic discharge (ESD) and ESD protection: ESD can damage disk
drives, boards, and other parts. Perform all procedures using ESD protection
procedures. Some ESD protection can be provided by wearing an antistatic wrist
strap attached to a chassis ground⎯any unpainted metal surface⎯on your server
when handling parts.
ESD and handling boards: Always use ESD protection when handling ESD
sensitive hardware. Always handle boards carefully. Hold boards only by their edges.
After removing a board from its protective wrapper or from the server, install it
directly into the server or replace it directly into its protective wrapper. If you need to
set the board down, place it component side up on a grounded, static free surface.
Use a conductive foam pad if available. Do not set the board on the top of its anti-
static bag. Do not slide a board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor
that slips over two jumper pins. Some jumpers have a small tab on top that you can
grip with your fingertips or with a pair of fine needle nosed pliers. If your jumpers do
not have such a tab, take care when using needle nosed pliers to remove or install a
jumper; grip the narrow sides of the jumper with the pliers, never the wide sides.
Gripping the wide sides can damage the contacts inside the jumper, causing
intermittent problems with the function controlled by that jumper. Use caution when
removing a jumper so you do not bend or break any pins on the server board.
Removing server top cover: Unless otherwise noted in this document, only a
QUALIFIED SERVICE TECHNICIAN is authorized to remove the server’s top
cover and to access any of the components inside the server. For proper cooling and
airflow, always install the server top cover before turning on the system. Operating
the system without the cover in place can lead to damage to system parts.
Risk of burns: Some exposed circuits exceed 240 VA when the system is
connected to a power source, and may cause burn injury if accidentally contacted.
Anchor the equipment rack: The equipment rack must be anchored to an
unmovable support to prevent it from falling over when one or more servers are
extended in front of the rack on slides. The anchors must be able to withstand a force
of up to 113 kg (250 lbs.). You must also consider the weight of any other device
installed in the rack. A crush hazard exists should the rack tilt forward which could
cause serious injury.
Main AC power disconnects: Users are responsible for installing an AC power
disconnect for the entire rack unit. This main disconnect must be readily accessible,
and it must be labeled as controlling power to the entire unit, not just to the server(s).
Grounding the rack installation: To avoid the potential for an electrical shock
hazard, users must include a third wire safety-grounding conductor with the rack
installation. If the server power cord is plugged into an AC outlet that is part of the
rack, then users must provide proper grounding for the rack itself. If the server power
cord is plugged into a wall AC outlet, the safety-grounding conductor in the power
cord provides proper grounding only for the server. Users must provide additional,
proper grounding for the rack and other devices installed in it.

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 7
Overcurrent protection: The server is designed for an AC line voltage source
with up to 20 amperes of overcurrent protection. If the power system for the
equipment rack is installed on a branch circuit with more than 20 amperes of
protection, you must provide supplemental protection for the server.
Hazardous conditions, power supply: Hazardous voltage, current, and energy
levels are present inside the power supply. There are no user-serviceable parts inside
the power supply; technically qualified personnel should do servicing.
Hazardous conditions, devices, and cables: Hazardous electrical conditions
may be present on power, telephone, and communication cables. Turn off the system
and disconnect the power cords, telecommunications systems, networks, and modems
attached to the system before opening it. Otherwise, personal injury or equipment
damage can result.
Hazardous conditions, processors, and VRMs: Hazardous thermal conditions
may be present in the system. Allow all fans to continue to spin until they shut down
on their own after power has been turned off. After the fans stop, you can remove the
power cords.
Power Cord Rating: Do not attempt to modify or use an AC power cord that is not
the exact type required. You must use a power cord that meets the following criteria:
The power cored must have an IEC 320 C19 connector to plug into the power
supply on the server.
For North America or similar electrical distribution systems, the cord must be UL
Listed/CSA Certified, 14/3 type SJT/SO/STO, with NEMA 5-15P (for 100-
127V) or 16/3 type SJT/SO with NEMA 6-15P (for 200-240V) or equivalent
attachment.
For Europe or similar electrical distribution systems, the cord must be flexible
VDE certified or HAR rated 250V, 3 x 1.0mm2 minimum conductor size with
IEC 320 C19 and C20 connectors, and rated for no less than the product ratings.
Cord length and flexibility: Cords must be less than 4.5 meters (14.76 feet) long.

Preface
8 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
CAUTIONS
Temperature:The range of temperatures in which the server operates when
installed in an equipment rack, must not go below 10 °C (50 °F) or rise above 35 °C
(95 °F). Extreme fluctuations in temperature can cause a variety of problems in your
server.
Ventilation:The equipment rack must provide sufficient airflow to the front of the
server to maintain proper cooling. The rack must also include ventilation sufficient to
exhaust a maximum of 1500 W (5,100 BTU/hr) for the server. The rack selected and
the ventilation provided must be suitable to the environment in which the server will
be used.
Power Cord Notes
For all power cord sets, the AC wall attachment plug shall be a three conductor
grounding type, rated at 125% of the total input current rating, and must be for the
specific region or country. The AC wall attachment plug must bear at least an
accepted safety agency certification mark for the specific region or country.
The cord must be no longer than 4.5 meters (14.76 feet).
Do not attempt to modify or use an AC power cord that is not the exact type required.
Surge Suppressor Recommendations: In geographic regions that are susceptible to
electrical storms, we highly recommend that you plug the server into a surge
suppressor.

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 9
Safety Cautions
Read all caution and safety statements in this document before performing any of the instructions.
See also Intel®Server Boards and Server Chassis Safety Information on the Intel®Server Platforms
SR6850HW4 and SR6850HW4/M Deployment Toolkit CD and/or at
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
The power supply in this product contains no user-serviceable parts. There may be more
than one supply in this product. Refer servicing only to qualified personnel.
Do not attempt to modify or use the supplied AC power cord if it is not the exact type
required. A product with more than one power supply will have a separate AC power cord
for each supply.
The power button on the system does not turn off system AC power. To remove AC power
from the system, you must unplug each AC power cord from the wall outlet or power supply.
The power cord(s) is considered the disconnect device to the main (AC) power. The socket
outlet that the system plugs into shall be installed near the equipment and shall be easily
accessible.
SAFETY STEPS: Unless otherwise noted, whenever you remove the chassis covers to
access the inside of the system, follow these steps:
1. Turn off all peripheral devices connected to the system.
2. Turn off the system by pressing the power button.
3. Unplug all AC power cords from the system or from wall outlets.
4. Label and disconnect all cables connected to I/O connectors or ports on the back of the
system.
5. Provide some electrostatic discharge (ESD) protection by wearing an antistatic wrist
strap attached to chassis ground of the system—any unpainted metal surface—when
handling components.
6. Do not operate the system with the chassis covers removed.
After you have completed the six SAFETY steps above, you can remove the system covers.
To do this:
1. Unlock and remove the padlock from the back of the system if a padlock has been
installed.
2. Remove and save all screws from the covers.
3. Remove the covers.
For proper cooling and airflow, always reinstall the chassis covers before turning on the
system. Operating the system without the covers in place can damage system parts. To
install the covers:
1. Check first to make sure you have not left loose tools or parts inside the system.
2. Check that cables, add-in boards, and other components are properly installed.
3. Attach the covers to the chassis with the screws removed earlier, and tighten
them firmly.
4. Insert and lock the padlock to the system to prevent unauthorized access inside
the system.
5. Connect all external cables and the AC power cord(s) to the system.
A microprocessor and heatsink may be hot if the system has been running. In addition,
there may be sharp pins and edges on some board and chassis parts. Contact should be
made with care. Consider wearing protective gloves.

Preface
10 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the equipment manufacturer. Dispose of used batteries
according to manufacturer’s instructions.
The system is designed to operate in a typical data center or office environment. Choose a
site that is:
Clean and free of airborne particles (other than normal room dust).
Well-ventilated and away from sources of heat including direct sunlight.
Away from sources of vibration or physical shock.
Isolated from strong electromagnetic fields produced by electrical devices.
In regions that are susceptible to electrical storms, we recommend you plug your system
into a surge suppresser and disconnect telecommunication lines to your modem during an
electrical storm.
Provided with a properly grounded wall outlet.
Provided with sufficient space to access the power supply cord(s), because they serve as
the product’s main power disconnect.

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 11
Wichtige Sicherheitshinweise
Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine
der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel®-
Serverplatinen und -Servergehäusen auf der Intel®Server Platforms SR6850HW4 and
SR6850HW4/M Deployment Toolkit CD oder unter
http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
Benutzer können am Netzgerät dieses Produkts keine Reparaturen vornehmen. Das
Produkt enthält möglicherweise mehrere Netzgeräte. Wartungsarbeiten müssen von
qualifizierten Technikern ausgeführt werden.
Versuchen Sie nicht, das mitgelieferte Netzkabel zu ändern oder zu verwenden, wenn es
sich nicht genau um den erforderlichen Typ handelt. Ein Produkt mit mehreren Netzgeräten
hat für jedes Netzgerät ein eigenes Netzkabel.
Der Wechselstrom des Systems wird durch den Ein-/Aus-Schalter für Gleichstrom nicht
ausgeschaltet. Ziehen Sie jedes Wechselstrom-Netzkabel aus der Steckdose bzw. dem
Netzgerät, um den Stromanschluß des Systems zu unterbrechen.
SICHERHEISMASSNAHMEN: Immer wenn Sie die Gehäuseabdeckung abnehmen um an
das Systeminnere zu gelangen, sollten Sie folgende Schritte beachten:
1. Schalten Sie alle an Ihr System angeschlossenen Peripheriegeräte aus.
2. Schalten Sie das System mit dem Hauptschalter aus.
3. Ziehen Sie den Stromanschlußstecker Ihres Systems aus der Steckdose.
4. Auf der Rückseite des Systems beschriften und ziehen Sie alle Anschlußkabel von den
I/O Anschlüssen oder Ports ab.
5. Tragen Sie ein geerdetes Antistatik Gelenkband, um elektrostatische Ladungen (ESD)
über blanke Metallstellen bei der Handhabung der Komponenten zu vermeiden.
6. Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein.
Nachdem Sie die oben erwähnten ersten sechs SICHERHEITSSCHRITTE durchgeführt
haben, können Sie die Abdeckung abnehmen, indem Sie:
1. Öffnen und entfernen Sie die Verschlußeinrichtung (Padlock) auf der Rückseite des
Systems, falls eine Verschlußeinrichtung installiert ist.
2. Entfernen Sie alle Schrauben der Gehäuseabdeckung.
3. Nehmen Sie die Abdeckung ab.
Zur ordnungsgemäßen Kühlung und Lüftung muß die Gehäuseabdeckung immer wieder
vor dem Einschalten installiert werden. Ein Betrieb des Systems ohne angebrachte
Abdeckung kann Ihrem System oder Teile darin beschädigen. Um die Abdeckung wieder
anzubringen:
1. Vergewissern Sie sich, daß Sie keine Werkzeuge oder Teile im Innern des Systems
zurückgelassen haben.
2. Überprüfen Sie alle Kabel, Zusatzkarten und andere Komponenten auf
ordnungsgemäßen Sitz und Installation.
3. Bringen Sie die Abdeckungen wieder am Gehäuse an, indem Sie die zuvor gelösten
Schrauben wieder anbringen. Ziehen Sie diese gut an.
4. Bringen Sie die Verschlußeinrichtung (Padlock) wieder an und schließen Sie diese, um
ein unerlaubtes Öffnen des Systems zu verhindern.
5. Schließen Sie alle externen Kabel und den AC Stromanschlußstecker Ihres Systems
wieder an.

Preface
12 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Der Mikroprozessor und der Kühler sind möglicherweise erhitzt, wenn das System in
Betrieb ist. Außerdem können einige Platinen und Gehäuseteile scharfe Spitzen und
Kanten aufweisen. Arbeiten an Platinen und Gehäuse sollten vorsichtig ausgeführt werden.
Sie sollten Schutzhandschuhe tragen.
Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf
nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp
ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers
entsprechend.
Das System wurde für den Betrieb in einer normalen Büroumgebung entwickelt. Der
Standort sollte:
sauber und staubfrei sein (Hausstaub ausgenommen);
gut gelüftet und keinen Heizquellen ausgesetzt sein (einschließlich direkter
Sonneneinstrahlung);
keinen Erschütterungen ausgesetzt sein;
keine starken, von elektrischen Geräten erzeugten elektromagnetischen Felder aufweisen;
in Regionen, in denen elektrische Stürme auftreten, mit einem Überspannungsschutzgerät
verbunden sein; während eines elektrischen Sturms sollte keine Verbindung der
Telekommunikationsleitungen mit dem Modem bestehen;
mit einer geerdeten Wechselstromsteckdose ausgerüstet sein;
über ausreichend Platz verfügen, um Zugang zu den Netzkabeln zu gewährleisten, da der
Stromanschluß des Produkts hauptsächlich über die Kabel unterbrochen wird.
重要安全指导
在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。参见Intel®Server
Platforms SR6850HW4 and SR6850HW4/M Deployment Toolkit CD（资源光盘）
和/或http://support.intel.com/support/motherboards/server/sb/cs-010770.htm 上的
Intel
Server Boards and Server Chassis Safety Information
（《Intel
服务器主板与服务器机箱安全信息》）。

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 13
Consignes de sécurité
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document
avant de suivre toute instruction. Consultez Intel®Server Boards and Server Chassis Safety
Information sur le Intel®Server Platforms SR6850HW4 and SR6850HW4/M Deployment Toolkit
CD ou bien rendez-vous sur le site http://support.intel.com/support/motherboards/server/sb/cs-
010770.htm.
Le bloc d'alimentation de ce produit ne contient aucune pièce pouvant être réparée par
l'utilisateur. Ce produit peut contenir plus d'un bloc d'alimentation. Veuillez contacter un
technicien qualifié en cas de problème.
Ne pas essayer d'utiliser ni modifier le câble d'alimentation CA fourni, s'il ne correspond pas
exactement au type requis. Le nombre de câbles d'alimentation CA fournis correspond au
nombre de blocs d'alimentation du produit.
Notez que le commutateur CC de mise sous tension /hors tension du panneau avant
n'éteint pas l'alimentation CA du système. Pour mettre le système hors tension, vous devez
débrancher chaque câble d'alimentation de sa prise.
CONSIGNES DE SÉCURITÉ -Lorsque vous ouvrez le boîtier pour accéder à l’intérieur du
système, suivez les consignes suivantes:
1. Mettez hors tension tous les périphériques connectés au système.
2. Mettez le système hors tension en mettant l’interrupteur général en position OFF
(bouton-poussoir).
3. Débranchez tous les cordons d’alimentation c.a. du système et des prises murales.
4. Identifiez et débranchez tous les câbles reliés aux connecteurs d’E-S ou aux accès
derrière le système.
5. Pour prévenir les décharges électrostatiques lorsque vous touchez aux composants,
portez une bande antistatique pour poignet et reliez-la à la masse du système (toute
surface métallique non peinte du boîtier).
6. Ne faites pas fonctionner le système tandis que le boîtier est ouvert.
Une fois TOUTES les étapes précédentes accomplies, vous pouvez retirer les panneaux du
système. Procédez comme suit:
1. Si un cadenas a été installé sur à l’arrière du système, déverrouillez-le et retirez-le.
2. Retirez toutes les vis des panneaux et mettez-les dans un endroit sûr.
3. Retirez les panneaux.
Afin de permettre le refroidissement et l’aération du système, réinstallez toujours les
panneaux du boîtier avant de mettre le système sous tension. Le fonctionnement du
système en l’absence des panneaux risque d’endommager ses pièces. Pour installer les
panneaux, procédez comme suit:
1. Assurez-vous de ne pas avoir oublié d’outils ou de pièces démontées dans le système.
2. Assurez-vous que les câbles, les cartes d’extension et les autres composants sont bien
installés.
3. Revissez solidement les panneaux du boîtier avec les vis retirées plus tôt.
4. Remettez le cadenas en place et verrouillez-le afin de prévenir tout accès non autorisé
à l’intérieur du système.
5. Rebranchez tous les cordons d’alimentation c. a. et câbles externes au système.

Preface
14 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Le microprocesseur et le dissipateur de chaleur peuvent être chauds si le système a été
sous tension. Faites également attention aux broches aiguës des cartes et aux bords
tranchants du capot. Nous vous recommandons l'usage de gants de protection.
Danger d'explosion si la batterie n'est pas remontée correctement. Remplacer uniquement
avec une batterie du même type ou d'un type équivalent recommandé par le fabricant.
Disposez des piles usées selon les instructions du fabricant.
Le système a été conçu pour fonctionner dans un cadre de travail normal. L'emplacement
choisi doit être:
Propre et dépourvu de poussière en suspension (sauf la poussière normale).
Bien aéré et loin des sources de chaleur, y compris du soleil direct.
A l'abri des chocs et des sources de vibrations.
Isolé de forts champs électromagnétiques géenérés par des appareils électriques.
Dans les régions sujettes aux orages magnétiques il est recomandé de brancher votre
système à un supresseur de surtension, et de débrancher toutes les lignes de
télécommunications de votre modem durant un orage.
Muni d'une prise murale correctement mise à la terre.
Suffisamment spacieux pour vous permettre d'accéder aux câbles d'alimentation (ceux-ci
étant le seul moyen de mettre le système hors tension).

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 15
Instrucciones de seguridad importantes
Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel® Server Boards and Server Chassis Safety Information
en el Intel®Server Platforms SR6850HW4 and SR6850HW4/M Deployment Toolkit CD y/o en
http://support.intel.com/support/motherbords/server/safecert.htm.
El usuario debe abstenerse de manipular los componentes de la fuente de alimentación de
este producto, cuya reparación debe dejarse exclusivamente en manos de personal técnico
especializado. Puede que este producto disponga de más de una fuente de alimentación.
No intente modificar ni usar el cable de alimentación de corriente alterna, si no corresponde
exactamente con el tipo requerido.
El número de cables suministrados se corresponden con el número de fuentes de
alimentación de corriente alterna que tenga el producto.
Nótese que el interruptor activado/desactivado en el panel frontal no desconecta la
corriente alterna del sistema. Para desconectarla, deberá desenchufar todos los cables de
corriente alterna de la pared o desconectar la fuente de alimentación.
INSTRUCCIONES DE SEGURIDAD: Cuando extraiga la tapa del chasis para acceder al
interior del sistema, siga las siguientes instrucciones:
1. Apague todos los dispositivos periféricos conectados al sistema.
2. Apague el sistema presionando el interruptor encendido/apagado.
3. Desconecte todos los cables de alimentación CA del sistema o de las tomas de
corriente alterna.
4. Identifique y desconecte todos los cables enchufados a los conectores E/S o a los
puertos situados en la parte posterior del sistema.
5. Cuando manipule los componentes, es importante protegerse contra la descarga
electrostática (ESD). Puede hacerlo si utiliza una muñequera antiestática sujetada a la
toma de tierra del chasis — o a cualquier tipo de superficie de metal sin pintar.
6. No ponga en marcha el sistema si se han extraído las tapas del chasis.
Después de completar las seis instrucciones de SEGURIDAD mencionadas, ya puede
extraer las tapas del sistema. Para ello:
1. Desbloquee y extraiga el bloqueo de seguridad de la parte posterior del sistema, si se
ha instalado uno.
2. Extraiga y guarde todos los tornillos de las tapas.
3. Extraiga las tapas.
Para obtener un enfriamiento y un flujo de aire adecuados, reinstale siempre las tapas del
chasis antes de poner en marcha el sistema. Si pone en funcionamiento el sistema sin las
tapas bien colocadas puede dañar los componentes del sistema. Para instalar las tapas:
1. Asegúrese primero de no haber dejado herramientas o componentes sueltos dentro del
sistema.
2. Compruebe que los cables, las placas adicionales y otros componentes se hayan
instalado correctamente.
3. Incorpore las tapas al chasis mediante los tornillos extraídos anteriormente,
tensándolos firmemente.
4. Inserte el bloqueo de seguridad en el sistema y bloquéelo para impedir que pueda
accederse al mismo sin autorización.
5. Conecte todos los cables externos y los cables de alimentación CA al sistema.

Preface
16 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Si el sistema ha estado en funcionamiento, el microprocesador y el disipador de calor
pueden estar aún calientes. También conviene tener en cuenta que en el chasis o en el
tablero puede haber piezas cortantes o punzantes. Por ello, se recomienda precaución y el
uso de guantes protectores.
Existe peligro de explosión si la pila no se cambia de forma adecuada. Utilice solamente
pilas iguales o del mismo tipo que las recomendadas por el fabricante del equipo. Para
deshacerse de las pilas usadas, siga igualmente las instrucciones del fabricante.
El sistema está diseñado para funcionar en un entorno de trabajo normal. Escoja un lugar:
Limpio y libre de partículas en suspensión (salvo el polvo normal).
Bien ventilado y alejado de fuentes de calor, incluida la luz solar directa.
Alejado de fuentes de vibración.
Aislado de campos electromagnéticos fuertes producidos por dispositivos eléctricos.
En regiones con frecuentes tormentas eléctricas, se recomienda conectar su sistema a un
eliminador de sobrevoltage y desconectar el módem de las líneas de telecomunicación
durante las tormentas.
Provisto de una toma de tierra correctamente instalada.
Provisto de espacio suficiente como para acceder a los cables de alimentación, ya que
éstos hacen de medio principal de desconexión del sistema.

Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide 17
Rivolgersi ad un tecnico specializzato per la riparazione dei componenti dell'alimentazione
di questo prodotto. È possibile che il prodotto disponga di più fonti di alimentazione.
Non modificare o utilizzare il cavo di alimentazione in c.a. fornito dal produttore, se non
corrisponde esattamente al tipo richiesto. Ad ogni fonte di alimentazione corrisponde un
cavo di alimentazione in c.a. separato.
L’interruttore attivato/disattivato nel pannello anteriore non interrompe l’alimentazione in c.a.
del sistema. Per interromperla, è necessario scollegare tutti i cavi di alimentazione in c.a.
dalle prese a muro o dall’alimentazione di corrente.
PASSI DI SICUREZZA: Qualora si rimuovano le coperture del telaio per accedere
all’interno del sistema, seguire i seguenti passi:
1. Spegnere tutti i dispositivi periferici collegati al sistema.
2. Spegnere il sistema, usando il pulsante spento/acceso dell’interruttore del sistema.
3. Togliere tutte le spine dei cavi del sistema dalle prese elettriche.
4. Identificare e sconnettere tutti i cavi attaccati ai collegamenti I/O od alle prese installate
sul retro del sistema.
5. Qualora si tocchino i componenti, proteggersi dallo scarico elettrostatico (SES),
portando un cinghia anti-statica da polso che è attaccata alla presa a terra del telaio del
sistema – qualsiasi superficie non dipinta – .
6. Non far operare il sistema quando il telaio è senza le coperture.
Dopo aver seguito i sei passi di SICUREZZA sopracitati, togliere le coperture del telaio del
sistema come seque:
1. Aprire e rimuovere il lucchetto dal retro del sistema qualora ve ne fosse uno installato.
2. Togliere e mettere in un posto sicuro tutte le viti delle coperture.
3. Togliere le coperture.
Per il giusto flusso dell’aria e raffreddamento del sistema, rimettere sempre le coperture del
telaio prima di riaccendere il sistema. Operare il sistema senza le coperture al loro proprio
posto potrebbe danneggiare i componenti del sistema. Per rimettere le coperture del telaio:
1. Controllare prima che non si siano lasciati degli attrezzi o dei componenti dentro il
sistema.
2. Controllare che i cavi, dei supporti aggiuntivi ed altri componenti siano stati installati
appropriatamente.
3. Attaccare le coperture al telaio con le viti tolte in precedenza e avvitarle strettamente.
4. Inserire e chiudere a chiave il lucchetto sul retro del sistema per impedire l’accesso non
autorizzato al sistema.
5. Ricollegare tutti i cavi esterni e le prolunghe AC del sistema.
Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore
potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti
taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione.
Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto. Utilizzare
solo pile uguali o di tipo equivalente a quelle consigliate dal produttore. Per disfarsi delle
pile usate, seguire le istruzioni del produttore.

Preface
18 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
Il sistema è progettato per funzionare in un ambiente di lavoro tipo. Scegliere una
postazione che sia:
Pulita e libera da particelle in sospensione (a parte la normale polvere presente
nell'ambiente).
Ben ventilata e lontana da fonti di calore, compresa la luce solare diretta.
Al riparo da urti e lontana da fonti di vibrazione.
Isolata dai forti campi magnetici prodotti da dispositivi elettrici.
In aree soggette a temporali, è consigliabile collegare il sistema ad un limitatore di corrente.
In caso di temporali, scollegare le linee di comunicazione dal modem.
Dotata di una presa a muro correttamente installata.
Dotata di spazio sufficiente ad accedere ai cavi di alimentazione, i quali rappresentano il
mezzo principale di scollegamento del sistema.

19
Contents
Preface ................................................................................................................. 3
Safety Information...................................................................................................................5
Part I: User’s Guide........................................................................................... 29
1Platform Description.................................................................................... 30
Platform Features..................................................................................................................32
Platform Front .......................................................................................................................33
Standard Control Panel................................................................................................34
Intel®Local Control Panel ............................................................................................36
Platform Rear........................................................................................................................37
Processors............................................................................................................................39
Plug-in Voltage Regulator Module (VRM) Converters..................................................39
System Memory....................................................................................................................39
Available Memory Configurations.................................................................................40
Power Subsystem.................................................................................................................42
Cooling Subsystem...............................................................................................................44
Hot-swap PCI Slots...............................................................................................................45
Peripherals............................................................................................................................46
Hard Disk Drive Support...............................................................................................47
Removable Media Bay Support....................................................................................48
Platform Board Set................................................................................................................48
Main Board...................................................................................................................50
Memory Board..............................................................................................................54
Front Panel I/O Board ..................................................................................................55
Front Panel Control Board............................................................................................55
SCSI Backplane Board.................................................................................................56
Power Distribution Board..............................................................................................57
Server Management..............................................................................................................57
2Starting Up and Shutting Down the Server ............................................... 59
Plugging the Server into AC Power.......................................................................................59
Powering On the Server........................................................................................................59
Shutting Down the Server.....................................................................................................60
3Intel®Server Deployment Toolkit................................................................ 61
Running Software Utilities from the CD.................................................................................61
4Server Platform Utilities............................................................................... 62
BIOS Setup Utility .................................................................................................................62
BIOS Setup Utility Page Layout ...................................................................................62
Keyboard Commands...................................................................................................63
Configuring Memory Options........................................................................................64
System Configuration Reset .................................................................................................66
BIOS Upgrades and Recovery..............................................................................................68
BIOS Upgrades iflash32...............................................................................................68

Contents
20 Intel® Server Platforms SR6850HW4 and SR6850HW4/M Product Guide
BIOS Recovery ............................................................................................................70
Rolling BIOS.................................................................................................................71
Console Redirection..............................................................................................................71
Serial Configuration Settings........................................................................................71
Keystroke Mappings.....................................................................................................72
Limitations....................................................................................................................72
Interface to Server Management..................................................................................73
LSI Logic* MPT SCSI Utility..................................................................................................74
Platform Confidence Test.............................................................................................80
Installing the Platform Confidence Test........................................................................80
Platform Confidence Test Options ...............................................................................81
System Configuration Wizard (SCW)....................................................................................81
Starting the System Configuration Wizard ...................................................................82
Using the Server Configuration Wizard Option ............................................................83
Configuring SDRs and FRUs .......................................................................................85
Configuring Channels...................................................................................................86
Configuring the Serial/Modem Channel .......................................................................93
Select Users to Configure Screen................................................................................98
Configure Users Screen...............................................................................................99
Setting a System Asset Tag.......................................................................................101
Configuring the Advanced Features...........................................................................102
Saving the Configuration to a Disk.............................................................................106
Saving the Configuration to the Server ......................................................................107
Running Utilities from the SCW..................................................................................107
Creating Diskettes...............................................................................................................109
Creating Disk Sets by Operating System...................................................................110
Device Driver Diskettes..............................................................................................111
Install an Operating System.......................................................................................111
FRUSDR Load Utility ..........................................................................................................111
Running the FRUSDR Load Utility.............................................................................112
SEL Viewer Utility................................................................................................................118
Using the SELViewer Utility........................................................................................118
Graphical User Interface ............................................................................................119
FRU Viewer Utility...............................................................................................................125
Using the FRU Viewer Utility......................................................................................126
Graphical User Interface (GUI)...................................................................................126
Save and Restore System Configuration (SYSCFG)..........................................................132
Upgrading the Firmware......................................................................................................132
Running the Firmware Update Utility..........................................................................132
Firmware Update Utility Command-line Options........................................................134
Extensible Firmware Interface (EFI) Shell...........................................................................136
Part II: Service Guide...................................................................................... 138
5User Serviceable Platform Components.................................................. 138
Tools and Supplies Needed................................................................................................138
Equipment Log...........................................................................................................138
Removing and Installing the Top Cover..............................................................................138
Removing the Top Cover ...........................................................................................139
Installing the Top Cover .............................................................................................140
