Intel BS-E098 User manual

USER
MANUAL
BS-E098
Fanless Embedded PC
with Intel®Apollo Lake
PentiumTM /Celeron®SoC
BS-E098 M1

BS-E098
Fanless Embedded PC with Intel® Apollo
Lake PentiumTM /Celeron® SoC
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
This manual is copyrighted in March 2017. You may not reproduce or
transmit in any form or by any means, electronic, or mechanical,
including photocopying and recording.
DISCLAIMER
This user’s manual is meant to assist users in installing and setting up
the system. The information contained in this document is subject to
change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
FCC NOTICE
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment
not expressly approve by the party responsible for compliance could
void your authority to operate such equipment.
CAUTION: Danger of explosion may occur when the battery
is incorrectly replaced. Replace the battery only with the
same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s
instructions.
WARNING: Some internal parts of the system may have high
electrical voltage. We strongly recommend that only qualified
engineers are allowed to service and disassemble the
system. If any damages should occur on the system and are
caused by unauthorized servicing, it will not be covered by
the product warranty.

i
Contents
1Introduction .........................................................................................1-1
1.1 About This Manual ....................................................................1-2
2Getting Started ....................................................................................2-1
2.1 Packing List...............................................................................2-2
2.2 System Overview ......................................................................2-3
2.2.1 Front View .........................................................................2-3
2.2.2 Rear View..........................................................................2-3
2.2.3 Top View............................................................................2-4
2.2.4 Side View...........................................................................2-4
2.2.5 Bottom View ......................................................................2-5
2.2.6 Quarter View......................................................................2-6
2.3 BS-E098 Specifications.............................................................2-7
2.4 Safety Precautions....................................................................2-9
3Hardware Configuration.....................................................................3-1
3.1 External System I/O Ports Diagrams ........................................3-2
3.1.1 Front I/O Ports Diagram ....................................................3-2
3.1.2 Rear I/O Ports Diagram.....................................................3-2
3.2 JUMPER & CONNECTOR QUICK REFERENCE TABLE........3-3
3.3 COMPONENT LOCATIONS OF SYSTEM MAIN BOARD .......3-4
3.3.1 Top View of System Main Board (BE-0981RA-**N) ..........3-4
3.3.2 Jumper Setting of System Main Board (BE-0981RA-**N).3-5
3.3.3 Bottom View of System Main Board (BE-0981RA-N0N/
BE-0981RA-N1N)..............................................................3-6
3.3.4 HOW TO SET JUMPERS..................................................3-7

ii
3.4 Setting Connectors and Jumpers..............................................3-9
3.4.1 COM3 and COM4 PIN9 Definition Selection Guide..........3-9
3.4.2 COM PORT .....................................................................3-10
3.4.3 DC-IN 3 Pins Terminal Block...........................................3-12
3.4.4 VGA PORT ......................................................................3-12
3.4.5 DISPLAY PORT...............................................................3-13
3.4.6 LAN PORT.......................................................................3-14
3.4.7 Dual USB 3.0 PORT (USB1)...........................................3-15
3.4.8 USB 3.0 PORT (USB2) ...................................................3-15
3.4.9 Programmable DIGITAL I/O PIN HEADER .....................3-16
3.4.10 I2C WAFER.....................................................................3-16
3.4.11 SYSTEM FAN CONNECTOR .........................................3-17
3.4.12 DC POWER INPUT CONNECTOR.................................3-17
3.4.13 MINI PCI EXPRESS SLOT .............................................3-18
3.4.14 mSATA Connector ...........................................................3-19
3.4.15 LVDS CONNECTOR .......................................................3-20
3.4.16 FRONT PANEL CONNECTOR........................................3-21
3.4.17 HD AUDIO CONNECTOR...............................................3-21
3.4.18 PANEL INVERTER CONNECTOR..................................3-22
3.4.19 SATA 3.0 CONNECTOR..................................................3-22
3.4.20 SATA Power CONNECTOR ............................................3-22
3.4.21 BIOS RESET CONNECTOR...........................................3-23
3.4.22 LVDS BACKLIGHT CONTROL SELECTION..................3-23
3.4.23 LVDS VCC VOLTAGE SELECTION................................3-24
3.4.24 CLEAR CMOS DATA SELECTION .................................3-25
4Software Utilities.................................................................................4-1
4.1 Introduction................................................................................4-2
4.2 Installing Intel®Chipset Software Installation Utility..................4-3

iii
4.3 Installing VGA Driver Utility .......................................................4-4
4.4 Installing LAN Driver Utility........................................................4-5
4.5 Installing Sound Driver Utility ....................................................4-6
5BIOS SETUP ........................................................................................5-1
5.1 Introduction................................................................................5-2
5.2 Accessing Setup Utility..............................................................5-3
5.3 Main...........................................................................................5-6
5.4 Advanced ..................................................................................5-8
5.4.1 Advanced - ACPI Settings.................................................5-9
5.4.2 Advanced –Onboard Device Configuration....................5-10
5.4.3 Advanced –Hardware Monitor........................................5-11
Smart Fan Mode Configuration ...................................................5-12
Smart Fan Mode Configuration - [Manual Duty Mode]................5-13
5.4.4 Advanced - F81846 Watchdog........................................5-14
5.4.5 Advanced - S5 RTC Wake Settings ................................5-15
S5 RTC Wake Settings [Fixed Time]...........................................5-16
S5 RTC Wake Settings [Dynamic Time]......................................5-17
5.4.6 Advanced - CPU Configuration .......................................5-18
Socket 0 CPU Information...........................................................5-19
CPU Power Management Configuration.....................................5-20
5.4.7 Advanced - F81846 Super IO Configuration...................5-22
F81846 Super IO Configuration - Serial Port 1 Configuration.....5-23
F81846 Super IO Configuration - Serial Port 2 Configuration.....5-24
F81846 Super IO Configuration - Serial Port 3 Configuration.....5-25
F81846 Super IO Configuration - Serial Port 4 Configuration.....5-26
5.4.8 Advanced - USB Configuration .......................................5-27
5.5 Chipset ....................................................................................5-29

iv
5.5.1 Chipset - North Bridge.....................................................5-30
North Bridge - LCD Control .........................................................5-31
5.5.2 Chipset - South Bridge ....................................................5-32
South Bridge - HD-Audio Configuration ......................................5-33
South Bridge - LPSS Configuration.............................................5-34
South Bridge - PCI Express Configuration..................................5-35
South Bridge - SATA Drives.........................................................5-39
South Bridge - Miscellaneous Configuration...............................5-40
5.6 Security ...................................................................................5-41
5.7 Boot.........................................................................................5-43
5.7.1 Boot - CSM Configuration ...............................................5-44
5.8 Save & Exit..............................................................................5-46
Appendix A System Diagrams....................................................A-1
BS-E098 System Exploded Diagram ............................................A-1
BS-E098 SATA HDD Exploded Diagram.......................................A-3
Appendix B Technical Summary................................................B-1
Interrupt Map ............................................................................................B-2
I/O MAP..................................................................................................B-19
Memory Map...........................................................................................B-21
Configuring WatchDog Timer .................................................................B-23
Flash BIOS Update.................................................................................B-26

v
Revision History
The revision history of BS-E098 User Manual is described below:
Version No.
Revision History
Date
M1
Initial Release
2017/03/17

BS-E098 SERIES USER MANUAL
Page: 1-1
1 Introduction
This chapter provides the introduction for BS-E098 system
as well as the framework of the user manual.
The following topic is included:
•About This Manual

Chapter 1 Introduction
BS-E098 SERIES USER MANUAL
Page: 1-2
1.1 About This Manual
Thank you for purchasing our BS-E098 system. The BS-E098 provides faster
processing speed, greater expandability and can handle more tasks than before. This
manual is designed to assist you how to install and set up the whole system. It
contains 5 chapters and 2 appendixes. Users can configure the system according to
their own needs. This user manual is intended for service personnel with strong
hardware background. It is not intended for general users.
The following section outlines the structure of this user manual.
Chapter 1 Introduction
This chapter provides the introduction for the BS-E098 system as well as the
framework of the user manual.
Chapter 2 Getting Started
This chapter describes the package contents and outlines the system specifications.
Read the safety reminders carefully on how to take care of your system properly.
Chapter 3 System Configuration
This chapter describes the external I/O ports, outlines the locations of the
motherboard components and their respective functions. You will learn how to set the
jumpers and configure the system to meet your own needs.
Chapter 4 Software Utilities
This chapter contains helpful information for proper installations of the Intel Chipset
Software Installation Utility, VGA Driver Utility, LAN Driver Utility and Sound
Driver Utility.
Chapter 5 AMI BIOS Setup
This chapter indicates you how to change the BIOS configurations.
Appendix A Technical Summary
This appendix provides the information about the allocation maps for the system
resources, Watchdog Timer Configuration and Flash BIOS Update.
.

BS-E098 SERIES USER MANUAL
Page: 2-1
2 Getting Started
This chapter provides the information for the BS-E098
system. It describes the package contents and outlines the
system specifications.
The following topics are included:
•Package List
•System Overview
•System Diagrams
•System Specification
•Safety Precautions
Experienced users can go to Chapter 3 System
Configuration on page 3-1 for a quick start.

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-2
2.1 Packing List
If you discover any of the items listed above are damaged or list,
please contact your local distributor immediately.
Item
Q’ty
BS-E098
1
Quick Reference Guide
1
Manual / Driver DVD
1
Mini Jumper (2.0 mm)
6

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-3
2.2 System Overview
Unit: mm
2.2.1 Front View
2.2.2 Rear View

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-4
2.2.3 Top View
2.2.4 Side View

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-5
2.2.5 Bottom View

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-6
2.2.6 Quarter View

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-7
2.3 BS-E098 Specifications
System
CPU
BS-E098RA-N1B: Pentium N4200 4C/6W/2.5GHz
BS-E098RA-N0B: Celeron N3350 2C/6W/2.4GHz
BS-E098RA-U1B: Pentium N4200 4C/6W/2.5GHz
BS-E098RA-U0B: Celeron N3350 2C/6W/2.4GHz
Memory Support
1x SO-DIMM socket,supporting 1600/1867 DDR3L
DRAM up to 8G (non-ECC)
Storage Support
Supports 1 x 2.5inch 7mm SATAIII HDD / SSD
Power Supply
Supports only DC 12V power input (3 pins lockable
terminal block)
O.S. Support
Windows®10 64bit
Ubuntu14.04 64bit (kernel 4.4)
BIOS
AMI UEFI BIOS
Dimension (W x H x D)
217.5mm x 45mm x 148mm
Weight
2 kg
I/O Ports
USB
BS-E098RA-N1B and BS-E098RA-N0B: 4 x USB 3.0
on rear I/O, 2 x USB 2.0 on front I/O (6 x USB ports)
BS-E098RA-U1B and BS-E098RA-U0B: 4 x USB 3.0
on rear I/O, 4 x USB 2.0 on front I/O (8 x USB ports)
Serial Ports
COM1~COM3 on front I/O
COM4 on rear I/O
COM2 supports RS-232/422/485 (default: RS-232,
selected by BIOS)
RS-485 supports auto flow control (default: non-auto,
selected by BIOS)
COM3/4 pin9 supports RI/5V/12V(default:RI, selected
by jumper)
Antenna Hole
2 x antenna holes for reservation
LAN
2 Gigabit LAN (on reat I/O panel), supports
Wake-on-LAN
Expansion Slot/mSATA
BS-E098RA-N1B and BS-E098RA-N0B: 1 full-sized
mPCIe, 1 full-sized mSATA (with USB signals)
BS-E098RA-U1B and BS-E098RA-U0B: 1 full-sized

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-8
mSATA (with USB signals)
Display
Display
1 x DP1.2 resolution: up to 4096x2160@60Hz
(on rear I/O Panel)
1 x VGA resolution: up to 1920x1200@60Hz
(on rear I/O Panel)
Power Mode
ATX Power Mode
(1) Auto boot-up when AC power is restored for the first
time (default setting)
(2) Non-auto boot-up whenever AC power is restored
(selected by BIOS)
Way to boot up from S5: (1) Power Button
(2) Wake-On-LAN (3) mPCIe-wake (4) RTC-wake
Way to Shutdown to S5/S4/S3: (1) Power Button
(2) OS Command
Supports S0/S3/S4/S5
Others
Sound
1 Line Out (on rear I/O panel)
Software Support
Hardware Monitor API (for Temp)
WatchDog API
Optional Accessory
60W Power adapter with lockable 3-pin terminal block
Environment
EMC & Safety
CE / FCC
Operating Temp.
SSD: 0°C ~60°C (32°F~140°F)
HDD: 0°C ~40°C (32°F~104°F)
Storage Temp.
-40°C ~85°C (-40°F~185°F)
Humidity
20%~ 95%

Chapter 2 Getting Started
BS-E098 SERIES USER MANUAL
Page: 2-9
2.4 Safety Precautions
Before operating this system, read the following information carefully to protect your
systems from damages, and extend the life cycle of the system.
1. Check the Line Voltage
•The operating voltage for the power supply should be within the range of
100V to 240VAC; otherwise the system may be damaged.
2. Environmental Conditions
•Place your BS-E098 on a sturdy, level surface. Be sure to allow enough
space around the system to have easy access needs.
•Avoid installing your BS-E098 system in extremely hot or cold places.
•Avoid direct sunlight exposure for a long period of time (for example, in a
closed car in summer time. Also avoid the system from any heating device.).
Or do not use BS-E098 when it has been left outdoors in a cold winter day.
•Avoid moving the system rapidly from a hot place to a cold place, and vice
versa, because condensation may occur inside the system.
•Protect your BS-E098 from strong vibrations which may cause hard disk
failure.
•Do not place the system too close to any radio-active device. Radio-active
device may cause signal interference.
•Always shut down the operating system before turning off the power.
3. Handling
•Avoid placing heavy objects on the top of the system.
•Do not turn the system upside down. This may cause the hard drive to
malfunction.
•Do not allow any objects to fall into this device.
•If water or other liquid spills into the device, unplug the power cord
immediately.
4. Good Care
•When the outside case gets stained, remove the stains using neutral washing
agent with a dry cloth.
•Never use strong agents such as benzene and thinner to clean the surface of
the case.
•If heavy stains are present, moisten a cloth with diluted neutral washing
agent or alcohol and then wipe thoroughly with a dry cloth.
•If dust is accumulated on the case surface, remove it by using a special
vacuum cleaner for computers.

BS-E098 SERIES USER MANUAL
Page: 3-1
3 Hardware Configuration
This chapter contains helpful information about the
external I/O Ports diagrams, and jumper & connector
settings, and component locations for the main board.
The following topics are included:
•External I/O Ports Diagrams
•Main Board Jumper Settings and Component
Locations
•How to Set Jumpers
•Setting Main Board Connectors and Jumpers
