How To Use This Manual ATC6430M Mainboard
HOW TO USE THIS MANUAL
This manual is written in a user-friendly style. It would be
advisable for users to read it in an orderly sequence :
1. For Hardware Information:
Read COMPONENT LOCATION DIAGRAM,Page A: QUICK JUMPER &
CONNECTOR SETTING,Page B: Slot 1 and CPU Installation, Page C:
CONNECTORS AND JUMPERS DESCRIPTION and Page D:List of Packaging.
2. For Mainboard and System Features:
Read “Chapter 1 System Features” , and you will find helpful information
on mainboard and system features. Especially, when you want to do some
feature setup, detailed instructions are provided therein to help you through.
3. For CPU, Memory and Drivers Installation:
Read “Chapter 2 Installation” for your CPU, memory and application drivers
installation. Detailed instructions are provided to guide all kinds of users.
4. For BIOS Update and Setup:
Read “Chapter 3 Award BIOS Setup” for updating your mainboard BIOS and
setting up your BIOS Configuration.
5. For other Technical Support:
Read “APPENDIX A”, fill and send the Request Form to your dealer for other
technical support.
The default settings on a mainboard is not necessarily what user expects. A
user-friendly manual would be the handiest assistant to help change the on-board
configuration or default setting. In case this manual cannot solve all your problems,
please ask your dealer for help and be sure the warranty on your system is still valid.
REMARK: Intel®is a registered trademark of Intel Corporation.
All other brands and product names are registered trademarks of their respective companies

ATC6430M Mainboard Contents
CONTENTS
QUICK JUMPER & CONNECTOR SETTING..........................A
SLOT 1 AND PENTIUM II/III INSTALLATION...................B
CONNECTORS AND JUMPERS DESCRIPTION....................C
CHECKLIST OF PACKAGING................................................D
HOW TO USE THIS MANUAL
TABLE OF CONTENTS
CHAPTER 1 System Features......................................................1
1-1 Introduction.............................................................................. 1
1-2 System Specifications................................................................2
1-3 Features Highlight...................................................................... ...3
1-3-1 Add-on Features for VGA in Intel 810.................................4
1-3-2 Add-on Features for Audio...................................................4
1-3-3 AMR and AC'97 CODEC Controller...................................5
1-3-4 Software Power Off Control.................................................5
1-3-5 Modem Ring On...................................................................6
1-3-6 SB-Link Sideband Signal.....................................................6
1-3-7 Ultra DMA 66 Cable(Optional)............................................7
1-3-8 Wake-On-LAN......................................................................8
CHAPTER 2 Installation..................................................................9
2-1 Installation Procedure .................................................................9
2-2 CPU Installation...........................................................................10
2-3 System Memory Installation.........................................................11
2-4 Intel 810 Driver Installation...........................................................12
2-5 VGA Driver Installation................................................................12
2-6Sound Driver Installation..............................................................12
CHAPTER 3 Award BIOS Setup...................................................13
3-1 Update BIOS Procedure..............................................................14
3-2 System BIOS Configuration Setup ...............................................16
3-2-1 Standard CMOS Features......................................................................18
3-2-2 Advanced BIOS Features.......................................................................21
3-2-3 Advanced Chipset Features...................................................................24
3-2-4 Integrated Peripherals............................................................................26

Contents ATC6430 Mainboard
3-2-5 Power Management Setup......................................................................27
3-2-6 PNP/PCI Configuration..........................................................................31
3-2-7 PC Health Status ...................................................................................33
3-2-8 Frequency / Voltage Control...................................................................34
3-2-9Load Fail-Safe Defaults...........................................................................35
3-2-10 Load Optimized Defaults.................... ..................................................35
3-2-11SupervisorPassword/User Password......................................................35
3-2-12Save & Exit Setup.................................................................................35
3-2-13Exit without Saving................................................................. ...............35
Appendix A Technical Support Request Form

ATC6430M Mainboard Chapter 1 System Features
1
CHAPTER 1
System Features
1-1 Introduction
6430M mainboard is designed to run with Intel 810 chipset to enhance the
performance and extraordinary value of the Intel CeleronTM processor-powered
PC.Ontheotherhand,itismountedwithbothSlot1andSocket 370 connector for
users to make their CPU choice. It supports 66MHz, 100MHz and 133MHz Host
Bus Intel PPGA CeleronTM CPUs. To enhance its peripheral support, 5 PCI slots
are mounted on board, with an optional ISA slot to meet some exceptional users’
requirements. In addition to the incorporated VGA in Intel 810, its wide and
inclusive add-on features are described one by one in later part of this chapter.
Before that, let us see some architectural features of Intel 810.
Chipset Combination FW82810DC100 / FW82810E
+ FW82801AA
With 4MB Display cache Yes
Supporting UDMA 66 Yes
Shared Memory After
installing VGA driver 7MB
Users should check with your dealer for the right chipset type on your mainboard.

Chapter 1 System Features ATC
6430M Mainboard
2
1-2 System Specifications of 6430M Mainboard
:CPU Support:
uSingle CPU, with both Slot 1 and PPGA Socket 370 on board for choice.
uSupports CPU Clock 66MHz, 100MHz and 133MHz (133MHz support “Slot
1” socket only). CPU Clock Ratios from 3.0x to 8.0x (step 0.5x).
uSupports CPUs : Pentium II 233MHz~450MHz, Celeron 300MHz~500MHz,
and Pentium III 450MHz~650MHz.
uCPU Core Voltage 1.30V~2.05V (step 0.05V), and 2.1V~3.5V (Step 0.1V);
CPU~I/O Voltage 3.3V.
uBuilt-in Switching Voltage Regulator, supporting Vcore autodetection.
:Memory Support:
uTwo DIMM sockets on board supporting up to 512MB SDRAM.
uPC-66 / PC-100 compatible.
:I/O System
uOn-board Intel 810 Chipset for I/O Control:
FW82810DC100 / FW82810E + FW82801AA.
uBus Frequency 66MHz/100MHz
u5 PCI slots on board, compliant with version 2.2 PCI Local Bus spec.
uOne Optional ISA slot.
uOne AMR (Audio, Modem Riser) slot on board.
uDual Master IDE connectors, supporting UDMA33/66 for 4 IDE devices such
as high capacity HDD, CD-ROM, LS-120 and tape backup etc.
uTwo USB connectors in stack supporting up to 127 USB devices.
uPS/2 Keyboad and PS/2 Mouse connectors.
uOne Infrared (IrDA TX/DX) connector.
uOne FDD port supporting two Floppy drives of : 1.2MB / 1.44MB / 2.88MB.
uOne parallel port for SSP/EPP/ECP mode printer.
uTwo 16550A Fast UART compatible connectors for serial and VGA port.
uOne Game /Midi port and 3 Audio Jacks for Speak-out, Line-in and
Microphone-in.
uOne SB-Link Connector for Sound Card and PCI connection.

ATC6430M Mainboard Chapter 1 System Features
3
:BIOS Support:
uBuilt-in VGA BIOS in Intel 810; and built-in Keyboard BIOS;.
uAWARD BIOS in Intel 810, providing CMOS Setup Utilities:
-Standard CMOS Features Setup for Date, Drives and VGA ;
-Advanced BIOS Features Setup for CPU Cache, Self Test, Boot Device,
Typematic Rate , and Security Options etc.;
-Advanced Chipset Features Setup for SDRAM CAS, RAS, System BIOS
Cacheable, and Video BIOS Cacheable etc.;
-IntegratedPeripheralsSetup for IDE Mode, USB, Audio, and Modem etc.;
-Power Management Setup on Video, HDD, CPU etc.;
-PnP/PCI Configurations Setup for PnP, Reset, Resources etc.;
-PC Health Status Control and Setup;
-Frequency / Voltage Control on CPU, SDRAM, PCI & SSC etc.;
-Load Fail-Safe Defaults;
-Load Optimized Defaults;
-Set Supervisor/User Password;
:Board Dimension :308mm x 202mm, in ATX form Factor. with one ATX Power
Connector.

Chapter 1 System Features ATC
6430M Mainboard
4
1-3 Features Highlight
1-3-1 Add-on Features for VGA in Intel 810:
:Integrated Graphics Controller
u3D Hyper Pipelined Architecture.
uFull 2D H/W Acceleration.
uMotion Video Acceleration.
:3D Graphics Visual Enhancements
uFlat & Gouraud Shading.
uMip Maps with Bilinear and Anisotropic Filtering.
uFogging Atmospheric Effects.
uZ Buffering.
u3D Pipe 2D Clipping.
uBackface Culling.
:3D Graphics Texturing Enhancements
uPer Pixel Perspective Correction Texture Mapping.
uTexture Compositing.
uTexture Color Keying/Chroma Keying.
uIntegrated 24-bit 230MHz RAMDAC.
:2D Graphics
uUp to 1600 x 1200 in 8-bit Color at 85 Hz Refresh.
uHardware Accelerated Functions.
:H/W Motion Compensation Assistance for S/W MPEG2 Decode
uSoftware DVD at 30fps.
uH/W Overlay Engine with Bilinear Filtering.
1-3-2 Add-on Features for Audio:
:Intel 810 ICH with built-in AC’97 controller.
:Supporting HRTF-based 3D positional audio, A3D, Q3D, wavetable, and 3D
surround sound.
Note: If you want to enable the onboard AC’
97 CODEC, you need to set JP9 pin
2-3closed. But in this way, the AMR slot will only accept a
riser board with
Modem CODEC and cannot accept another Audio Riser.

ATC6430M Mainboard Chapter 1 System Features
5
1-3-3 AMR and AC’97 CODEC Controller
AMR slot and AC’97 CODEC are integrated into the Mainboard to enable audio and
modem playback.
AMR (Audio/Modem Riser) slot is mounted on board to connect riser board with
Audio and/or Modem CODEC (AMC/AC/MC Adapters). The AMR specification
developed by Intel provides a mechanism for AC’97 codes to be on a riser card.
To enable the onboard AC’97 CODEC, set JP9 pin 2-3closed. And in such way,
you can further plug ariser board with Modem CODEC to the AMR slot. Otherwise,
disabling onboard AC’97 CODEC by setting JP9 1-2 closed, you can plug ariser
board with Audio/Modem CODEC to the AMR slot.
See Page A for AMR location on 6430M Mainboard.
1-3-4 Software Power Off Control
This mainboard supports Software Power Off Control feature through the SMM code
in the BIOS under Windows 95/98, and MS-DOS operation system environment.
First, you should connect the power switch cable to the connector “PS-ON” on the
mainboard. In the BIOS screen of POWER MANAGEMENT SETUP’, choose “User
Define” (or “Min. Power Saving” or “Max. Power Saving”) in ‘Power Management’.
In Windows 95/98, if you want to power off the system, you just need to choose
“shutdown the computer?” in the “Shut Down Windows” of Windows 95/98. Then the
system power will be off directly, and stay at the stand-by status. If you want to restart
the system, just press the power switch button..
Note : If you are going to leave your system idle for several days, we suggest you
use hardware power off to shut down your system.
Status Power LED Light Turbo LED Light
Software power off control Light off Light off
APM mode Light on Light on
System running Light on Light on
To locate “PS-ON” header, please see “Page A Quick Jumper & Connector Setting”.

Chapter 1 System Features ATC
6430M Mainboard
6
1-3-5 Modem Ring On
With Modem Ring On function, the computer can wake up by remote signal
through a connected modem. This function enables users to access their computer data
from anywhere in the world. Users have to enable “Power On by Ring” in “Power
Management Setup” of the AWARD BIOS setup screens.
1-3-6SB-Link Sideband Signals
In order to migrate the legacy Sound Blaster compatible audio to the PCI bus,
EMU8008 incorporates a pair of SB-Link request/grant sideband signals (PCPCIR
EQN and PCPCIGNTN) to interface to the PCI bus. SB-Link is a mechanism that was
defined and developed by Intel as a docking solution which allows ISA slots to exist in
docking stations connected to desktop PC PCI bus.
SB-Link 2x3 sideband header, sound will also
has a 2x3 header and a cable.
PCI 5
PCI 4
SB Link
SIRQ
REQ#
GND
GNT#A GND

ATC6430M Mainboard Chapter 1 System Features
7
1-3-7 Ultra DMA 66 Cable (optional)
Ultra DMA 66 cable (40-pin connector & 80-line cable) is packaged while utilizing
FW82801AA chip which supports both UDMA 33 & UDMA 66 on the mainboard. In
other words, Ultra DMA 33 cable is only used with FW82801AB chip And the Ultra
DMA 66 color coded connectors are shown as bellow:
1-3-8 Wake-On-LAN
The remote Wake-On-LAN (WOL) mode of operation is a mechanism that uses
Advanced Micro Device Magic Packet technology to power on a sleeping workstation
on the network. This mechanism is accomplished when the LAN card receives a
specific packet of information, called a Magic Packet, addressed to the node on the
network. For additional protection, Secure ON is an optional security feature that can
be added to the Magic Packet that requires a password to power on the sleeping
workstation. When LAN card is in remote Wake-On-LAN mode, main system power
can be shut down leaving power only for the LAN card and auxiliary power
recondition.
The LAN card performs no network activities while in the remote Wake-On-LAN
mode of operation. It only monitors the network for receipt of a Magic Packet. If a
Magic Packet is addressed to the LAN card on the network, the LAN card wake up the
system. If the Secure ON feature has been enabled, the password added to the Magic
Packet is also verified prior to waking up the system.
You should select two kinds of PCI Ethernet cards with WOL function. One is
Intel and the other is with PME signal supporting. And you can set “PCI PME#
Grey to Slave
IDE Peripheral
Blue to Mainboard Black to
Master
IDE Peripheral

Chapter 1 System Features ATC
6430M Mainboard
8
Function” enabled through “ Power Management Setup” from the BIOS setup screen.
Caution: For Wake-On-LAN, the +5V standby line for the power supply should be
capable of delivering +5V ±5% at 720mA. Failure to provide adequate standby current
when implementing Wake-On-LAN will damage the power supply.
+
WOL connector

6430M Mainboard Chapter 2 Installation
9
CHAPTER 2
INSTALLATION
2-1 INSTALLATION PROCEDURE
Before installing the computer, please prepare all components such as CPU, DRAM;
peripherals such as hard drive, keyboard, CD-ROM and accessories such as cables.
Then, install the system as following:
-Put CPU / heat sink (refer to CeleronTM CPU installation guide or see
the following setup chapter), and DRAM modules on the mainboard.
-Plug add-on cards into PCI slots, if needed.
-Connect cables to peripheral devices, especially for COM2 connector.
-Make sure all components and devices are well connected, turn on the
power and setup System BIOS based on your configuration.
-Install peripheral devices, add-on card drivers and test them.
-If all of above procedures are running successfully, turn the power off
and screw the chassis cover to the chassis.

Chapter 2 Installation 6430M Mainboard
10
2-2 CPU INSTALLATION
This mainboard supports PPGA Socket 370 and Slot 1
processors.
The 6430M mainboard has built-in Switching Voltage Regulator to support CPU Vcore
autodetection. That is, It is smart enough to detect and recognize the CPU voltage,
clock,ratio and enables usersto set up the CPU frequency from the BIOS Setup
Screen. Users can adjust the frequency through “Frequency /Voltage Control” of the
BIOS Setup Screen.
B. How to install CPU for Slot 1:
For Slot 1 CPU installation, please refer to “Page B Slot 1 installation” of this manual.
Socket 370
CPU for Socket 370
Locking
Lever
Pin 1
Corner
A. How to install CPUs for Socket 370:
1. Insert CPU Pin 1 to Pin 1 corner
of Socket 370 and lock it. 2. Insert Slot 1"Terminator Kit"
to Slot 1.
" Terminator Kit"

6430M Mainboard Chapter 2 Installation
11
2-3 SYSTEM MEMORY INSTALLATION
6430M mainboard provides two 3.3V 168-pin DIMM sockets for system memory
expansion from 8MB to 512MB SDRAM. These two DIMMs are arranged to two
banks, please refer to page A.
Bank/DIMM PC-100 Memory Module Total Memory
Bank0/DIMM1 8/16/32/64/128/256MB 8MB~256MB
Bank1/DIMM2 8/16/32/64/128/256MB 8MB~256MB
Total System Memory 8MB~512MB
DIMM type, Size, parity supported:
6PC-66/100 or higher performance memory module.
6Both parity or non-parity are available.
63.3V, single/double-side.
68/16/32/64/128/256Mbytes.
uForeither66MHz,100MHzand133MHzhostbusCPUs,pleaseuse10nsorfaster
and PC-100 compliant modules .

Chapter 2 Installation 6430M Mainboard
12
2-4 INTEL 810 DRIVER INSTALLATION
ØØ INF Files for Windows 95/98 :
1. Start Windows 95/98.
2. Put the All-In-One CD into your CD-ROM drive.
3. Choose Intel 810/820 Inf Files on the Autorun main menu.
4. Then follow the instruction on the screen.
(INF Files that enable the Intel 810/820 Chipsets to be recognized by
listed operating systems.)
2-5VGA DRIVER INSTALLATION
Install Intel 810 AGP Driver For Win95/98/NT
1. Start Windows 95/98/NT.
2. Put the All-In-One CD into your CD-ROM drive.
3. Choose Intel 810 AGP Driver on the Autorun main menu.
4. Press Next to install the driver.
5. Follow the instructions on the screen to complete the installation.
2-6 SOUND DRIVER INSTALLATION
Install Sound Driver For Win95/98/NT
1. Start Windows 95/98/NT.
2. Put the All-In-One CD into your CD-ROM drive.
3. Choose Audio Device Driver on the Autorun main menu.
4. Follow the instructions on the screen to finish the installation.
(Please refer to readme.doc file to get more detailed information.)
Install YAMAHA Software Synthesizer For Win95/98/NT
1. Start Windows 95/98/NT.
2. Put the All-In-One CD into your CD-ROM drive.
3. Choose YAMAHA Software Synthesizer on the Autorun main menu.
4. Follow the instructions on the screen to finish the installation.
(Please refer to readme.doc file to get more detailed information.)
Note : the sound driver is not supported under DOS operating system.

ATC6430M Mainboard Chapter 3Award BIOS Setup
13
CHAPTER 3
AWARD BIOS SETUP
Award BIOS manufacturer provides access to the system BIOS through the hardware
and software on mainboard. The hardware consists of a Flash ROM (4MB in 6430M
mainboard) and the software is a group of programs that are installed in the ROMBIOS
along with all the other data that should be included into the BIOS.
After the BIOS is updated, if you want to clear the old setup data stored in the CMOS,
then you can reset CMOS as follow.
NOTE:IncaseCMOSshouldbereset,firstunplugthepowercord,thensetJumper
8 2-3 closed for at least 5 seconds, reset JP8 1-2 closed so as to return to normal
position and plug the power cord again.
JP8
Normal 1-2
Reset CMOS 2-3
123
+
JP8
PCI 1 Slot

Chapter 3Award BIOS SetupATC6430M Mainboard
14
3-1 UPDATE BIOS PROCEDURE
3-1-1 BIOS Update:
If the BIOS needs to be updated, you can get a CD with the updated BIOS utility in the
package. The CD includes :
“awdflash.exe” -- BIOS update utility program
“awdflash.doc”
The update procedure is as following:
1. Boot the system to DOS mode in a normal manner.
2. Insert the updated CD to drive D (or E).
3. Change working directory to CD-ROM drive, D or E, which contains the update
BIOS CD. -- Type “d:\” or “e: \”, then press “ENTER”.
4. Type “cd flash”, then press “ENTER”.
5. Type “awdflash”, then press “ENTER”-- for running the BIOS update utility.
6. Type “(update BIOS file name with version number).bin”, ENTER.
7. If you do not want to save the old BIOS, type “N” when the screen displays the
message : " Do you want to save BIOS (Y/N) ?".
8. Type “Y“ when the screen shows the message : " Are you sure to program
(Y/N) ?".
9. Follow instructions displayed on the screen. DO NOT remove the update BIOS
CD from the CD-ROM drive nor turn the system power off until the BIOS update
is completed.
10. Turn the power off. Clear the data in CMOS according to the procedure described
in the previous page.
11. Turn the system power on and test that your system is working properly.

ATC6430M Mainboard Chapter 3Award BIOS Setup
15
3-1-2 UPDATE MICROCODE API
Intel also provides MICROCODE API (Applications Programming Interface) for
mainboard user to update data block in BIOS quickly and easily. (You can find this
utility in the All-In-One CD in the mainboard package).
The BIOS code on the mainboards contains data that is specific to each silicon
stepping of the processor. Integrators must ensure that this BIOS stepping data
matches the used processor stepping. When the BIOS does not contain stepping data
that matches the processor stepping, integrators must update the data in the BIOS
before shipping the system. Historically, the systems have been updated by replacing
the entire BIOS with a new revision of BIOS that contains the correct stepping data.
Intel’s BIOS update API allows just the stepping data within the BIOS to be
updated as needed. Mainboards that contain a BIOS with the Intel-defined BIOS
update API can be quickly and easily updated, if required, without obtaining a
complete BIOS upgrade. Using this utility, integrators can easily verify that the correct
stepping data is present in all mainboards. However, if the stepping data requires to be
updated, the mainboard BIOS must contain the Intel-defined BIOS update API,
otherwise a complete BIOS upgrade is required from the mainboard vendor.
Since API program can only be executed under DOS Real Mode, you must enter
Real Mode first and load the API program to Drive C.
To load the program to C by following steps:
(1) Type “ md c:\api ” and press Enter. Directory “api” is made in Drive C now.
(2) Insert the Driver/Utility CD into CD ROM Drive E.
(3) Then type “ copy e:\api\*.* c:\api ” and press Enter.
(API program is loaded to Drive C now.)
(4) Type “ C:\api \checkup ” to execute this program.
The main menu should now be displayed with the following four options :
1) Check and load update
2) Specify stepping data file [current : pep.pdb]
3) Help
4) Quit without loading update
Select 1 to know the stepping filename, select 2 to load right patch code, then
select 1 to update proper patch code. Now, the screen will show the message “please
remove the CD from CD-ROM drive”. Then cold boot (mechanical power off) system
to continue. For more information, please refer to “CHECKUP.HLP“ file.

Chapter 3Award BIOS SetupATC6430M Mainboard
16
3-2 SYSTEM BIOS CONFIGURATION SETUP
The following pages explain how to set up the BIOS configuration under the
Award BIOS. The SETUP program is stored in the Read-Only-Memory (ROM) on the
mainboard. To do the SETUP procedure, press the <Del> key when the system is
booting up. The following main menu will appear. Please select " STANDARD CMOS
FEATURE" to enter the next screen.
CMOS Setup Utility -Copyright ( C ) 1984-1998
Standard CMOS Feature
Advanced BIOS Feature
Advanced Chipset Feature
Integrated Peripherals
Power Management Setup
PnP/PCI Configurations
PC Health Status
Frequency/Voltage Control
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
Esc : Quit ↑↑ ↓↓ ←← →→ : Select Item
F10 : Save & Exit Setup
Time, Date, Hard Disk Type….
The section at the bottom of the main menu explains how to control this screen. The
upper section displays the items highlighted in the list.

ATC6430M Mainboard Chapter 3Award BIOS Setup
17
Control Key Description 
UP ARROW Move to the previous item
DOWN ARROW Move to the next item
LEFT ARROW Move to the item on the left
RIGHT ARROW Move to the item on the right
Esc KEY Esc Main Menu : Quit without saving changes
Setup menu : Exit current page and return to
main menu
PgUp KEY Increase the numeric value or make changes
PgDn KEY Decrease the numeric value or make changes
F1 KEY Help General help
F5 KEY Old Value Restore the pervious CMOS value from
CMOS
F6 KEY Load Fail-Safe
Defaults Load the fail-safe default CMOS value from BIOS default table
F7 KEY Load Optimized
Defaults Load the optimized default
F10 KEY Save & Exit
Setup Save all the CMOS changes and Exit setup, only for Main Menu
