Intel® Desktop Board
DG965RY
Specification Update
May 2008
Order Number D65907-005US
The Intel®Desktop Board DG965RY contain design defects or errors known as errata, which may cause the product to deviate from
published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DG965RY Specification Update
Revision History
Revision Revision History Date
-001 This document is the first Specification Update for the
Intel®Desktop Board DG965RY. August 7, 2006
-002 Added Specification Change 1. November 2006
-003 Updated General Information table and added Specification
Change 2. February 2007
-004 Updated General Information table. December 2007
-005 Updated General Information and Specification Changes Sections. May 2008
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT
INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”
or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for
conflicts or incompatibilities arising from future changes to them.
The Intel®Desktop Board DG965RY may contain design defects or errors known as errata which may cause
the product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your
product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from:
Intel Corporation
P.O. Box 5937
Denver, CO 80217-9808
or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,
Germany 44-0-1793-421-333, other Countries 708-296-9333
Intel, the Intel logo, Intel Core, and Pentium are trademarks of Intel Corporation in the United States and
other countries.
* Other names and brands may be claimed as the property of others.
Copyright ©2006-2008 Intel Corporation.

Intel Desktop Board DG965RY Specification Update 3
Contents
Specification Update for the Intel®Desktop Board DG965RY
Terminology ............................................................................................ 5
General Information .................................................................................5
Summary of Changes ............................................................................... 6
Specification Changes...............................................................................7

4 Intel Desktop Board DG965RY Specification Update
Specification Update for the
Intel®Desktop Board DG965RY
This document is an update to the specifications contained in the Intel®Desktop Board
DP965RY Technical Product Specification (Order Number D56011). It is intended for
hardware system manufacturers and software developers of applications, operating
systems, or tools. It will contain Specification Changes, Errata, Specification
Clarifications, and Documentation Changes.
For specification updates concerning the Intel processor that may apply to this desktop
board, refer to the following:
•Intel®Core™2 Extreme Processor X6800∆and Intel®Core™2 Duo Desktop
Processor E6000∆Sequence Specification Update (Order Number: 313279)
•Intel®Pentium®4 Processor 6x1∆Sequence Specification Update (Order
Number: 310309)
•Intel®Pentium®4 Processor on 90 nm Process Specification Update (Order
Number: 302352)
•Intel®Pentium®4 Processor Specification Update (Order Number: 249199)
Unless otherwise noted in this document, it should be assumed that any processor
errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)
associated with that stepping.
Refer to the Intel®P965 Broadwater Chipset Specification Update (Order
Number: 313054) for specification updates concerning the 82G965 MCH Controller and
that may apply to the desktop board DG965RY. Unless otherwise noted in this
document, it should be assumed that any MCH errata for a given stepping are
applicable to the Altered Assembly (AA) revision(s) associated with that stepping.
Refer to the Intel®IO Controller Hub8 (ICH8) Family Specification Update (Order
Number: 313057) for specification updates concerning the 82801HB I/O Controller
Hub and that may apply to the desktop board DG965RY. Unless otherwise noted in
this document, it should be assumed that any ICH8 errata for a given stepping are
applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Intel Desktop Board DG965RY Specification Update 5
Terminology
Specification Changes are modifications to the current published specifications.
These changes will be incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop
board behavior to deviate from published specifications. Hardware and software
designed to be used with any given Altered Assembly (AA) and BIOS revision level
must assume that all errata documented for that AA and BIOS revision level are
present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further
highlight a specification’s impact to a complex design situation. These clarifications
will be incorporated in the next release of the specifications.
Documentation Changes include typos, errors, or omissions from the current
published specifications. These changes will be incorporated in the next release of the
specifications.
General Information
Basic Desktop Board DG965RY Identification Information
AA Revision BIOS Revision Notes
D41691-205 MQ96510J.86A.0816 1,2
D41691-206 MQ96510J.86A.1612 1,2
D41691-207 MQ96510J.86A.1612 1,2
D41691-208 MQ96510J.86A.1676 1,2
D41691-209 MQ96510J.86A.1687 1,2
D41691-301 MQ96510J.86A.1687 1,2
D41691-302 MQ96510J.86A.1687 1,2
D41691-303 MQ96510J.86A.1715 1,2
NOTES:
1. The AA number is found on a small label on the component side of the board.
2. The 965 Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers
82G965 C2 L9R5
82801HB B0 L9MN

6 Intel Desktop Board DG965RY Specification Update
Summary of Changes
The following table indicates the Specification Changes, Errata, Specification
Clarifications, or Documentation Changes that apply to the Intel®Desktop Board
DG965RY. Intel intends to fix some of the errata in a future revision of the desktop
board, and to account for the other outstanding issues through documentation or
specification changes as noted.
The following notations are used in the table:
Doc: Document change or update that will be implemented.
Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.
Fixed: This erratum has been previously fixed.
No Fix: There are no plans to fix this erratum.
Shaded: This erratum is either new or modified from the previous version of the document.
No. Plans Specification Changes
1 Doc Changes to Section 1.7.2 Audio Connectors.
2 Doc Changes to Section 1.8.1 Intel®82566DC Gigabit Ethernet Controller.
3 Doc Section 3.11 has been added to the Technical Specification.
No. Plans Errata
There are no characterized erratum for this product

Intel Desktop Board DG965RY Specification Update 7
Specification Changes
Changes to the feature description in the board technical product specification.
Typically the customer does not have to do anything to achieve proper device
functionality as a result of the change.
1. The following note will be added to the Technical Product Specification in
Section 1.7.2 Audio Connectors:
 INTEGRATOR’S NOTES
Electrostatic discharge (ESD) can damage desktop board components. Front-
panel connectors should provide sufficient protection to prevent ESD damage to
components inside the chassis enclosure.
2. Section 1.8.1 of the Technical Specification will be updated in its entirety as follows
to remove reference to Jumbo frame support.
1.8.1 Intel®82566DC Gigabit Ethernet Controller
The Intel®82566DC Gigabit Ethernet Controller supports the following features:
•PCI Express link
•10/100/1000 IEEE 802.3 compliant
•Compliant to IEEE 802.3x flow control support
•TCP, IP, UDP checksum offload
•Transmit TCP segmentation
•Advanced packet filtering
•Full device driver compatibility
•PCI Express Power Management Support
3. Section 3.11 has been added to the Technical Specification.
3.11 Intel®System Recovery Tool
The Intel®Desktop Board DP965LT incorporates the Intel®System Recovery Tool.
The Intel System Recovery Tool is an embedded backup and recovery tool located in
the BIOS of this Intel®Architecture motherboard.
Intel System Recovery Tool is built on the Unified Extensible Firmware Interface
(UEFI) specification and is embedded in the motherboard BIOS. Therefore, it is easy
to use and suitable for multiple usage models.
Backup
The Backup feature allows you to backup all data from a specified partition to
another partition or to a USB disk.

8 Intel Desktop Board DG965RY Specification Update
Restore
Restore allows you to restore a partition using an image file from a previous backup.
Hard Drives Required 1 or 2
Advantage Graphic user interface – Simple and easy-to-use
Streamlined backup & restore process – Only three quick steps
Good for all PC users. No IT background required
No installation required, built into BIOS.
Disadvantage Decreased volume capacity if single drive used, no decrease in volume
capacity if second drive used. May be internal or external such as USB disk.
Application System and data protection; restoration of the master drive to a previous or
default state.
You can learn more about Intel System Recovery Tool at
http://platformadmintech.intel.com/srt/
