Intel Quark SoC X1000 User manual

Order Number: 329679-001US
Intel®Quark SoC X1000 Core
Developer’s Manual
October 2013

Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
2Order Number: 329679-001US
Legal Lines and Disclaimers
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR
OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS
OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING
TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
A "Mission Critical Application" is any application in which failure of the Intel Product could result, directly or indirectly, in personal injury or death.
SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND
ITS SUBSIDIARIES, SUBCONTRACTORS AND AFFILIATES, AND THE DIRECTORS, OFFICERS, AND EMPLOYEES OF EACH, HARMLESS AGAINST ALL
CLAIMS COSTS, DAMAGES, AND EXPENSES AND REASONABLE ATTORNEYS' FEES ARISING OUT OF, DIRECTLY OR INDIRECTLY, ANY CLAIM OF PRODUCT
LIABILITY, PERSONAL INJURY, OR DEATH ARISING IN ANY WAY OUT OF SUCH MISSION CRITICAL APPLICATION, WHETHER OR NOT INTEL OR ITS
SUBCONTRACTOR WAS NEGLIGENT IN THE DESIGN, MANUFACTURE, OR WARNING OF THE INTEL PRODUCT OR ANY OF ITS PARTS.
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics
of any features or instructions marked "reserved" or "undefined". Intel reserves these for future definition and shall have no responsibility whatsoever
for conflicts or incompatibilities arising from future changes to them. The information here is subject to change without notice. Do not finalize a design
with this information.
The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-
4725, or go to: http://www.intel.com/design/literature.htm
Any software source code reprinted in this document is furnished for informational purposes only and may only be used or copied and no license, express
or implied, by estoppel or otherwise, to any of the reprinted source code is granted by this document.
Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor family, not across different
processor families. Go to: http://www.intel.com/products/processor_number/
Code Names are only for use by Intel to identify products, platforms, programs, services, etc. (“products”) in development by Intel that have not been
made commercially available to the public, i.e., announced, launched or shipped. They are never to be used as “commercial” names for products. Also,
they are not intended to function as trademarks.
Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2013, Intel Corporation. All rights reserved.

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 3
Revision History—Intel®Quark Core
Revision History
Date Revision Description
September 2013 001 First external release of document.

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
4Order Number: 329679-001US
Contents
1.0 About this Manual.......................................................................................................17
1.1 Manual Contents................................................................................................17
1.2 Notation Conventions .........................................................................................18
1.3 Special Terminology...........................................................................................19
1.4 Related Documents............................................................................................20
2.0 Intel®Quark SoC X1000 Core Overview.........................................................................21
2.1 Intel®Quark Core Architecture............................................................................21
3.0 Architectural Overview.................................................................................................22
3.1 Internal Architecture ..........................................................................................22
3.2 System Architecture...........................................................................................22
3.3 Memory Organization .........................................................................................22
3.3.1 Address Spaces......................................................................................23
3.3.2 Segment Register Usage..........................................................................24
3.4 I/O Space.........................................................................................................25
3.5 Addressing Modes..............................................................................................25
3.5.1 Addressing Modes Overview.....................................................................25
3.5.2 Register and Immediate Modes.................................................................26
3.5.3 32-Bit Memory Addressing Modes .............................................................26
3.5.4 Differences Between 16- and 32-Bit Addresses ...........................................28
3.6 Data Types .......................................................................................................28
3.6.1 Data Types ............................................................................................28
3.6.1.1 Unsigned Data Types.................................................................29
3.6.1.2 Signed Data Types ....................................................................29
3.6.1.3 BCD Data Types........................................................................30
3.6.1.4 Floating-Point Data Types...........................................................30
3.6.1.5 String Data Types .....................................................................30
3.6.1.6 ASCII Data Types......................................................................31
3.6.1.7 Pointer Data Types....................................................................32
3.6.2 Little Endian vs. Big Endian Data Formats ..................................................33
3.7 Interrupts.........................................................................................................33
3.7.1 Interrupts and Exceptions........................................................................33
3.7.2 Interrupt Processing................................................................................34
3.7.3 Maskable Interrupt..................................................................................34
3.7.4 Non-Maskable Interrupt...........................................................................35
3.7.5 Software Interrupts.................................................................................36
3.7.6 Interrupt and Exception Priorities..............................................................36
3.7.7 Instruction Restart..................................................................................37
3.7.8 Double Fault ..........................................................................................38
3.7.9 Floating-Point Interrupt Vectors................................................................38
4.0 System Register Organization.......................................................................................39
4.1 Register Set Overview........................................................................................39
4.2 Floating-Point Registers......................................................................................39
4.3 Base Architecture Registers.................................................................................39
4.3.1 General Purpose Registers .......................................................................40
4.3.2 Instruction Pointer..................................................................................41
4.3.3 Flags Register ........................................................................................41
4.3.4 Segment Registers..................................................................................44
4.3.5 Segment Descriptor Cache Registers .........................................................44
4.4 System-Level Registers ......................................................................................45
4.4.1 Control Registers....................................................................................46

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 5
Contents—Intel®Quark Core
4.4.1.1 Control Register 0 (CR0)............................................................47
4.4.1.2 Control Register 1 (CR1)............................................................51
4.4.1.3 Control Register 2 (CR2)............................................................51
4.4.1.4 Control Register 3 (CR3)............................................................51
4.4.1.5 Control Register 4 (CR4)............................................................51
4.4.2 System Address Registers .......................................................................52
4.5 Floating-Point Registers......................................................................................53
4.5.1 Floating-Point Data Registers...................................................................53
4.5.2 Floating-Point Tag Word..........................................................................54
4.5.3 Floating-Point Status Word ......................................................................54
4.5.4 Instruction and Data Pointers...................................................................58
4.5.5 FPU Control Word...................................................................................61
4.6 Debug and Test Registers...................................................................................62
4.6.1 Debug Registers.....................................................................................62
4.6.2 Test Registers........................................................................................62
4.7 Register Accessibility .........................................................................................62
4.7.1 FPU Register Usage ................................................................................63
4.8 Reserved Bits and Software Compatibility.............................................................63
4.9 Intel®Quark Core Model Specific Registers (MSRs)................................................64
5.0 Real Mode Architecture................................................................................................65
5.1 Introduction .....................................................................................................65
5.2 Memory Addressing...........................................................................................66
5.3 Reserved Locations............................................................................................66
5.4 Interrupts ........................................................................................................67
5.5 Shutdown and Halt............................................................................................67
6.0 Protected Mode Architecture ........................................................................................68
6.1 Addressing Mechanism.......................................................................................68
6.2 Segmentation...................................................................................................69
6.2.1 Segmentation Introduction ......................................................................69
6.2.2 Terminology ..........................................................................................70
6.2.3 Descriptor Tables ...................................................................................70
6.2.3.1 Descriptor Tables Introduction....................................................70
6.2.3.2 Global Descriptor Table..............................................................71
6.2.3.3 Local Descriptor Table ...............................................................71
6.2.3.4 Interrupt Descriptor Table..........................................................71
6.2.4 Descriptors............................................................................................72
6.2.4.1 Descriptor Attribute Bits ............................................................72
6.2.4.2 Intel®Quark Core Code, Data Descriptors (S=1) ..........................72
6.2.4.3 System Descriptor Formats ........................................................74
6.2.4.4 LDT Descriptors (S=0, TYPE=2)..................................................75
6.2.4.5 TSS Descriptors (S=0, TYPE=1, 3, 9, B) ......................................75
6.2.4.6 Gate Descriptors (S=0, TYPE=4–7, C, F)......................................75
6.2.4.7 Selector Fields..........................................................................77
6.2.4.8 Segment Descriptor Cache.........................................................77
6.2.4.9 Segment Descriptor Register Settings..........................................77
6.3 Protection ........................................................................................................81
6.3.1 Protection Concepts................................................................................81
6.3.2 Rules of Privilege....................................................................................82
6.3.3 Privilege Levels......................................................................................82
6.3.3.1 Task Privilege...........................................................................82
6.3.3.2 Selector Privilege (RPL) .............................................................82
6.3.3.3 I/O Privilege and I/O Permission Bitmap ......................................83
6.3.3.4 Privilege Validation....................................................................85
6.3.3.5 Descriptor Access .....................................................................85
6.3.4 Privilege Level Transfers..........................................................................86

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
6Order Number: 329679-001US
6.3.5 Call Gates..............................................................................................87
6.3.6 Task Switching.......................................................................................88
6.3.6.1 Floating-Point Task Switching......................................................89
6.3.7 Initialization and Transition to Protected Mode............................................89
6.4 Paging..............................................................................................................91
6.4.1 Paging Concepts.....................................................................................91
6.4.2 Paging Organization................................................................................91
6.4.2.1 Page Mechanism .......................................................................91
6.4.2.2 Page Descriptor Base Register.....................................................91
6.4.2.3 Page Directory..........................................................................92
6.4.2.4 Page Tables..............................................................................92
6.4.2.5 Page Directory/Table Entries.......................................................92
6.4.2.6 Paging-Mode Modifiers ..............................................................92
6.4.3 PAE Paging ............................................................................................93
6.4.3.1 PDPTE Registers........................................................................93
6.4.3.2 Linear-Address Translation with PAE Paging..................................94
6.4.4 #GP Faults for Intel®Quark SoC X1000 Core ..........................................100
6.4.5 Access Rights ......................................................................................100
6.4.5.1 SMEP Details for Intel®Quark SoC X1000 Core ...........................101
6.4.6 Page Level Protection (R/W, U/S Bits)......................................................102
6.4.7 Page Cacheability (PWT and PCD Bits).....................................................103
6.4.8 Translation Lookaside Buffer ..................................................................103
6.4.9 Page-Fault Exceptions ..........................................................................104
6.4.10 Paging Operation..................................................................................106
6.4.11 Operating System Responsibilities...........................................................107
6.5 Virtual 8086 Environment .................................................................................107
6.5.1 Executing Programs ..............................................................................107
6.5.2 Virtual 8086 Mode Addressing Mechanism................................................108
6.5.3 Paging in Virtual Mode...........................................................................108
6.5.4 Protection and I/O Permission Bitmap......................................................109
6.5.5 Interrupt Handling ................................................................................110
6.5.6 Entering and Leaving Virtual 8086 Mode ..................................................111
6.5.6.1 Task Switches to and from Virtual 8086 Mode .............................112
6.5.6.2 Transitions Through Trap and Interrupt Gates, and IRET...............112
7.0 On-Chip Cache .........................................................................................................114
7.1 Cache Organization..........................................................................................114
7.1.1 Write-Back Enhanced Intel®Quark SoC X1000 Core Cache ........................115
7.2 Cache Control .................................................................................................116
7.2.1 Write-Back Enhanced Intel®Quark SoC X1000 Core Cache Control and
Operating Modes ..................................................................................116
7.3 Cache Line Fills................................................................................................117
7.4 Cache Line Invalidations...................................................................................118
7.4.1 Write-Back Enhanced Intel®Quark SoC X1000 Core Snoop Cycles and
Write-Back Mode Invalidation.................................................................118
7.5 Cache Replacement..........................................................................................118
7.6 Page Cacheability ............................................................................................119
7.6.1 Write-Back Enhanced Intel®Quark SoC X1000 Core and Processor Page
Cacheability.........................................................................................121
7.7 Cache Flushing................................................................................................122
7.7.1 Write-Back Enhanced Intel®Quark SoC X1000 Core Cache Flushing............122
7.8 Write-Back Enhanced Intel®Quark SoC X1000 Core Write-Back Cache Architecture .123
7.8.1 Write-Back Cache Coherency Protocol......................................................123
7.8.2 Detecting On-Chip Write-Back Cache of the Write-Back Enhanced Intel®
Quark SoC X1000 Core..........................................................................125
8.0 System Management Mode (SMM) Architectures ...........................................................127

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 7
Contents—Intel®Quark Core
8.1 SMM Overview................................................................................................ 127
8.2 Terminology ................................................................................................... 127
8.3 System Management Interrupt Processing.......................................................... 128
8.3.1 System Management Interrupt (SMI#).................................................... 129
8.3.2 SMI# Active (SMIACT#)........................................................................ 129
8.3.3 SMRAM............................................................................................... 130
8.3.3.1 SMRAM State Save Map........................................................... 131
8.3.4 Exit From SMM..................................................................................... 133
8.4 System Management Mode Programming Model .................................................. 134
8.4.1 Entering System Management Mode ....................................................... 134
8.4.2 Processor Environment.......................................................................... 135
8.4.2.1 Write-Back Enhanced Intel®Quark SoC X1000 Core Environment . 136
8.4.3 Executing System Management Mode Handler.......................................... 136
8.4.3.1 Exceptions and Interrupts within System Management Mode ........ 137
8.5 SMM Features................................................................................................. 138
8.5.1 SMM Revision Identifier......................................................................... 138
8.5.2 Auto Halt Restart ................................................................................. 138
8.5.3 I/O Instruction Restart.......................................................................... 139
8.5.4 SMM Base Relocation............................................................................ 140
8.6 SMM System Design Considerations................................................................... 141
8.6.1 SMRAM Interface.................................................................................. 141
8.6.2 Cache Flushes...................................................................................... 142
8.6.2.1 Write-Back Enhanced Intel®Quark SoC X1000 Core System
Management Mode and Cache Flushing...................................... 144
8.6.2.2 Snoop During SMM.................................................................. 146
8.6.3 A20M# Pin and SMBASE Relocation ........................................................ 146
8.6.4 Processor Reset During SMM.................................................................. 146
8.6.5 SMM and Second-Level Write Buffers ...................................................... 147
8.6.6 Nested SMI#s and I/O Restart ............................................................... 147
8.7 SMM Software Considerations ........................................................................... 147
8.7.1 SMM Code Considerations...................................................................... 147
8.7.2 Exception Handling............................................................................... 148
8.7.3 Halt During SMM .................................................................................. 148
8.7.4 Relocating SMRAM to an Address Above One Megabyte ............................. 148
9.0 Hardware Interface................................................................................................... 149
9.1 Introduction ................................................................................................... 149
9.2 Signal Descriptions.......................................................................................... 150
9.2.1 Clock (CLK) ......................................................................................... 150
9.2.2 Address Bus (A[31:2], BE[3:0]#)........................................................... 150
9.2.3 Data Lines (D[31:0]) ............................................................................ 151
9.2.4 Parity ................................................................................................. 151
9.2.4.1 Data Parity Input/Outputs (DP[3:0]) ......................................... 151
9.2.4.2 Parity Status Output (PCHK#) .................................................. 151
9.2.5 Bus Cycle Definition.............................................................................. 152
9.2.5.1 M/IO#, D/C#, W/R# Outputs ................................................... 152
9.2.5.2 Bus Lock Output (LOCK#)........................................................ 152
9.2.5.3 Pseudo-Lock Output (PLOCK#) ................................................. 153
9.2.5.4 PLOCK# Floating-Point Considerations....................................... 153
9.2.6 Bus Control ......................................................................................... 153
9.2.6.1 Address Status Output (ADS#)................................................. 153
9.2.6.2 Non-Burst Ready Input (RDY#)................................................. 153
9.2.7 Burst Control....................................................................................... 154
9.2.7.1 Burst Ready Input (BRDY#) ..................................................... 154
9.2.7.2 Burst Last Output (BLAST#)..................................................... 154
9.2.8 Interrupt Signals.................................................................................. 154

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
8Order Number: 329679-001US
9.2.8.1 Reset Input (RESET)................................................................154
9.2.8.2 Soft Reset Input (SRESET) .......................................................155
9.2.8.3 System Management Interrupt Request Input (SMI#)..................155
9.2.8.4 System Management Mode Active Output (SMIACT#) ..................155
9.2.8.5 Maskable Interrupt Request Input (INTR) ...................................155
9.2.8.6 Non-maskable Interrupt Request Input (NMI)..............................156
9.2.8.7 Stop Clock Interrupt Request Input (STPCLK#) ...........................156
9.2.9 Bus Arbitration Signals ..........................................................................156
9.2.9.1 Bus Request Output (BREQ)......................................................156
9.2.9.2 Bus Hold Request Input (HOLD) ................................................156
9.2.9.3 Bus Hold Acknowledge Output (HLDA)........................................157
9.2.9.4 Backoff Input (BOFF#).............................................................157
9.2.10 Cache Invalidation ................................................................................157
9.2.10.1 Address Hold Request Input (AHOLD) ........................................158
9.2.10.2 External Address Valid Input (EADS#)........................................158
9.2.11 Cache Control ......................................................................................158
9.2.11.1 Cache Enable Input (KEN#)......................................................158
9.2.11.2 Cache Flush Input (FLUSH#).....................................................158
9.2.12 Page Cacheability (PWT, PCD) ................................................................159
9.2.13 RESERVED#.........................................................................................159
9.2.14 Numeric Error Reporting (FERR#, IGNNE#)..............................................159
9.2.14.1 Floating-Point Error Output (FERR#)..........................................159
9.2.14.2 Ignore Numeric Error Input (IGNNE#)........................................160
9.2.15 Bus Size Control (BS16#, BS8#) ............................................................160
9.2.16 Address Bit 20 Mask (A20M#) ................................................................161
9.2.17 Write-Back Enhanced Intel®Quark SoC X1000 Core Signals and Other
Enhanced Bus Features .........................................................................161
9.2.17.1 Cacheability (CACHE#) ............................................................161
9.2.17.2 Cache Flush (FLUSH#).............................................................162
9.2.17.3 Hit/Miss to a Modified Line (HITM#)...........................................162
9.2.17.4 Soft Reset (SRESET)................................................................163
9.2.17.5 Invalidation Request (INV) .......................................................163
9.2.17.6 Write-Back/Write-Through (WB/WT#)........................................164
9.2.17.7 Pseudo-Lock Output (PLOCK#)..................................................164
9.2.18 Test Signals.........................................................................................164
9.2.18.1 Test Clock (TCK) .....................................................................164
9.2.18.2 Test Mode Select (TMS) ...........................................................165
9.2.18.3 Test Data Input (TDI) ..............................................................165
9.2.18.4 Test Data Output (TDO)...........................................................165
9.3 Interrupt and Non-Maskable Interrupt Interface...................................................165
9.3.1 Interrupt Logic .....................................................................................166
9.3.2 NMI Logic ............................................................................................166
9.3.3 SMI# Logic ..........................................................................................166
9.3.4 STPCLK# Logic.....................................................................................167
9.4 Write Buffers...................................................................................................167
9.4.1 Write Buffers and I/O Cycles ..................................................................169
9.4.2 Write Buffers on Locked Bus Cycles.........................................................169
9.5 Reset and Initialization.....................................................................................169
9.5.1 Floating-Point Register Values ................................................................170
9.5.2 Pin State During Reset ..........................................................................171
9.5.2.1 Controlling the CLK Signal in the Processor during Power On.........173
9.5.2.2 FERR# Pin State During Reset for Intel®Quark SoC X1000 Core ...173
9.5.2.3 Power Down Mode (In-circuit Emulator Support)..........................174
9.6 Clock Control ..................................................................................................174
9.6.1 Stop Grant Bus Cycles...........................................................................174
9.6.2 Pin State During Stop Grant...................................................................175

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 9
Contents—Intel®Quark Core
9.6.3 Write-Back Enhanced Intel®Quark SoC X1000 Core Pin States During Stop
Grant State ......................................................................................... 176
9.6.4 Clock Control State Diagram.................................................................. 177
9.6.4.1 Normal State.......................................................................... 177
9.6.4.2 Stop Grant State .................................................................... 177
9.6.4.3 Stop Clock State..................................................................... 179
9.6.4.4 Auto HALT Power Down State................................................... 179
9.6.4.5 Stop Clock Snoop State (Cache Invalidations)............................. 179
9.6.4.6 Auto Idle Power Down State..................................................... 180
9.6.5 Write-Back Enhanced Intel®Quark SoC X1000 Core Clock Control State
Diagram.............................................................................................. 180
9.6.5.1 Normal State.......................................................................... 180
9.6.5.2 Stop Grant State .................................................................... 181
9.6.5.3 Stop Clock State..................................................................... 182
9.6.5.4 Auto HALT Power Down State................................................... 182
9.6.6 Stop Clock Snoop State (Cache Invalidations) .......................................... 183
9.6.6.1 Auto HALT Power Down Flush State (Cache Flush) for the
Write-Back Enhanced Intel®Quark SoC X1000 Core.................... 183
10.0 Bus Operation.......................................................................................................... 184
10.1 Data Transfer Mechanism................................................................................. 184
10.1.1 Memory and I/O Spaces........................................................................ 184
10.1.1.1 Memory and I/O Space Organization ......................................... 185
10.1.2 Dynamic Data Bus Sizing....................................................................... 186
10.1.3 Interfacing with 8-, 16-, and 32-Bit Memories.......................................... 187
10.1.4 Dynamic Bus Sizing during Cache Line Files ............................................. 191
10.1.5 Operand Alignment............................................................................... 192
10.2 Bus Arbitration Logic........................................................................................ 193
10.3 Bus Functional Description................................................................................ 196
10.3.1 Non-Cacheable Non-Burst Single Cycles .................................................. 196
10.3.1.1 No Wait States ....................................................................... 196
10.3.1.2 Inserting Wait States............................................................... 197
10.3.2 Multiple and Burst Cycle Bus Transfers.................................................... 198
10.3.2.1 Burst Cycles........................................................................... 198
10.3.2.2 Terminating Multiple and Burst Cycle Transfers........................... 199
10.3.2.3 Non-Cacheable, Non-Burst, Multiple Cycle Transfers.................... 200
10.3.2.4 Non-Cacheable Burst Cycles..................................................... 200
10.3.3 Cacheable Cycles ................................................................................. 201
10.3.3.1 Byte Enables during a Cache Line Fill......................................... 202
10.3.3.2 Non-Burst Cacheable Cycles..................................................... 202
10.3.3.3 Burst Cacheable Cycles............................................................ 203
10.3.3.4 Effect of Changing KEN# during a Cache Line Fill ........................ 204
10.3.4 Burst Mode Details ............................................................................... 205
10.3.4.1 Adding Wait States to Burst Cycles............................................ 205
10.3.4.2 Burst and Cache Line Fill Order................................................. 206
10.3.4.3 Interrupted Burst Cycles.......................................................... 207
10.3.5 8- and 16-Bit Cycles............................................................................. 209
10.3.6 Locked Cycles...................................................................................... 211
10.3.7 Pseudo-Locked Cycles........................................................................... 212
10.3.7.1 Floating-Point Read and Write Cycles......................................... 213
10.3.8 Invalidate Cycles.................................................................................. 213
10.3.8.1 Rate of Invalidate Cycles ......................................................... 215
10.3.8.2 Running Invalidate Cycles Concurrently with Line Fills.................. 215
10.3.9 Bus Hold ............................................................................................. 217
10.3.10Interrupt Acknowledge.......................................................................... 219
10.3.11Special Bus Cycles................................................................................ 220
10.3.11.1HALT Indication Cycle.............................................................. 220

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
10 Order Number: 329679-001US
10.3.11.2Shutdown Indication Cycle .......................................................221
10.3.11.3Stop Grant Indication Cycle ......................................................221
10.3.12Bus Cycle Restart .................................................................................222
10.3.13Bus States...........................................................................................224
10.3.14Floating-Point Error Handling for the Intel®Quark SoC X1000 Core.............225
10.3.14.1Floating-Point Exceptions .........................................................225
10.3.15Intel®Quark SoC X1000 Core Floating-Point Error Handling in
AT-Compatible Systems.........................................................................226
10.4 Enhanced Bus Mode Operation for the Write-Back Enhanced Intel®Quark SoC X1000
Core ..............................................................................................................226
10.4.1 Summary of Bus Differences ..................................................................226
10.4.2 Burst Cycles.........................................................................................227
10.4.2.1 Non-Cacheable Burst Operation.................................................227
10.4.2.2 Burst Cycle Signal Protocol .......................................................228
10.4.3 Cache Consistency Cycles ......................................................................228
10.4.3.1 Snoop Collision with a Current Cache Line Operation....................229
10.4.3.2 Snoop under AHOLD................................................................230
10.4.3.3 Snoop During Replacement Write-Back ......................................234
10.4.3.4 Snoop under BOFF# ................................................................235
10.4.3.5 Snoop under HOLD..................................................................237
10.4.3.6 Snoop under HOLD during Replacement Write-Back.....................239
10.4.4 Locked Cycles ......................................................................................239
10.4.4.1 Snoop/Lock Collision................................................................241
10.4.5 Flush Operation....................................................................................241
10.4.6 Pseudo Locked Cycles............................................................................242
10.4.6.1 Snoop under AHOLD during Pseudo-Locked Cycles.......................242
10.4.6.2 Snoop under HOLD during Pseudo-Locked Cycles.........................243
10.4.6.3 Snoop under BOFF# Overlaying a Pseudo-Locked Cycle................244
11.0 Debugging Support ...................................................................................................246
11.1 Breakpoint Instruction......................................................................................246
11.2 Single-Step Trap..............................................................................................246
11.3 Debug Registers ..............................................................................................246
11.3.1 Linear Address Breakpoint Registers (DR[3:0]).........................................247
11.3.2 Debug Control Register (DR7) ................................................................247
11.3.3 Debug Status Register (DR6) .................................................................250
11.3.4 Use of Resume Flag (RF) in Flag Register.................................................251
12.0 Instruction Set Summary...........................................................................................252
12.1 Instruction Set ................................................................................................252
12.1.1 Floating-Point Instructions .....................................................................253
12.2 Instruction Encoding ........................................................................................253
12.2.1 Overview.............................................................................................253
12.2.2 32-Bit Extensions of the Instruction Set...................................................254
12.2.3 Encoding of Integer Instruction Fields......................................................255
12.2.3.1 Encoding of Operand Length (w) Field........................................255
12.2.3.2 Encoding of the General Register (reg) Field ...............................255
12.2.3.3 Encoding of the Segment Register (sreg) Field ............................256
12.2.3.4 Encoding of Address Mode........................................................257
12.2.3.5 Encoding of Operation Direction (d) Field....................................260
12.2.3.6 Encoding of Sign-Extend (s) Field..............................................261
12.2.3.7 Encoding of Conditional Test (tttn) Field .....................................261
12.2.3.8 Encoding of Control or Debug or Test Register (eee) Field.............261
12.2.4 Encoding of Floating-Point Instruction Fields.............................................262
12.2.5 Intel®Quark SoC X1000 Core Instructions...............................................263
12.2.5.1 CMPXCHG8B - Compare and Exchange Bytes ..............................263
12.2.5.2 RDMSR ..................................................................................264

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 11
Contents—Intel®Quark Core
12.2.5.3 RDTSC .................................................................................. 264
12.2.5.4 WRMSR ................................................................................. 264
12.3 Clock Count Summary ..................................................................................... 265
12.3.1 Instruction Clock Count Assumptions ...................................................... 265
A Signal Descriptions ................................................................................................... 291
B Testability ............................................................................................................... 296
B.1 On-Chip Cache Testing..................................................................................... 296
B.1.1 Cache Testing Registers TR3, TR4 and TR5 .............................................. 296
B.1.2 Cache Testability Write ......................................................................... 297
B.1.3 Cache Testability Read.......................................................................... 298
B.1.4 Flush Cache......................................................................................... 299
B.1.5 Additional Cache Testing Features for Write-Back Enhanced Intel®Quark
SoC X1000 Core................................................................................... 299
B.2 Translation Lookaside Buffer (TLB) Testing ......................................................... 300
B.2.1 Translation Lookaside Buffer Organization................................................ 300
B.2.2 TLB Test Registers TR6 and TR7............................................................. 301
B.2.2.1 Command Test Register: TR6................................................... 301
B.2.2.2 Data Test Register: TR7........................................................... 303
B.2.3 TLB Write Test ..................................................................................... 303
B.2.4 TLB Lookup Test .................................................................................. 304
B.3 Intel®Quark SoC X1000 Core JTAG................................................................... 304
B.3.1 Test Access Port (TAP) Controller ........................................................... 304
B.3.1.1 Test-Logic-Reset State ............................................................ 305
B.3.1.2 Run-Test/Idle State................................................................. 305
B.3.1.3 Select-DR-Scan State.............................................................. 305
B.3.1.4 Capture-DR State ................................................................... 306
B.3.1.5 Shift-DR State........................................................................ 306
B.3.1.6 Exit1-DR State ....................................................................... 306
B.3.1.7 Pause-DR State ...................................................................... 306
B.3.1.8 Exit2-DR State ....................................................................... 306
B.3.1.9 Update-DR State .................................................................... 307
B.3.1.10 Select-IR-Scan State............................................................... 307
B.3.1.11 Capture-IR State .................................................................... 307
B.3.1.12 Shift-IR State......................................................................... 307
B.3.1.13 Exit1-IR State ........................................................................ 307
B.3.1.14 Pause-IR State ....................................................................... 307
B.3.1.15 Exit2-IR State ........................................................................ 308
B.3.1.16 Update-IR State ..................................................................... 308
B.3.2 TAP Controller Initialization.................................................................... 308
C Feature Determination .............................................................................................. 309
C.1 CPUID Instruction ........................................................................................... 309
C.2 Intel®Quark SoC X1000 Stepping..................................................................... 311
Figures
1Intel
®Quark SoC X1000 Core used in Intel®Quark SoC X1000 .....................................21
2 Address Translation..................................................................................................24
3 Addressing Mode Calculations....................................................................................27
4 Data Types .............................................................................................................29
5 Data Types .............................................................................................................31
6 String and ASCII Data Types .....................................................................................32
7 Pointer Data Types...................................................................................................32
8 Big vs. Little Endian Memory Format...........................................................................33

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
12 Order Number: 329679-001US
9 Base Architecture Registers .......................................................................................40
10 Flag Registers..........................................................................................................41
11 Intel®Quark SoC X1000 Core Segment Registers and Associated Descriptor Cache
Registers.................................................................................................................45
12 System-Level Registers.............................................................................................46
13 Control Registers .....................................................................................................47
14 Intel®Quark SoC X1000 Core CR4 Register .................................................................52
15 Floating-Point Registers.............................................................................................53
16 Floating-Point Tag Word ............................................................................................54
17 Floating-Point Status Word ........................................................................................55
18 Protected Mode FPU Instructions and Data Pointer Image in Memory (32-Bit Format) ........59
19 Real Mode FPU Instruction and Data Pointer Image in Memory (32-Bit Format).................59
20 Protected Mode FPU Instruction and Data Pointer Image in Memory (16-Bit Format)..........60
21 Real Mode FPU Instruction and Data Pointer Image in Memory (16-Bit Format).................60
22 FPU Control Word.....................................................................................................61
23 Real Address Mode Addressing ...................................................................................66
24 Protected Mode Addressing........................................................................................69
25 Paging and Segmentation..........................................................................................69
26 Descriptor Table Registers .........................................................................................71
27 Interrupt Descriptor Table Register Use .......................................................................72
28 Segment Descriptors.................................................................................................73
29 System Segment Descriptors .....................................................................................75
30 Gate Descriptor Formats............................................................................................76
31 Example Descriptor Selection.....................................................................................78
32 Segment Descriptor Caches for Real Address Mode (Segment Limit and Attributes Are
Fixed).....................................................................................................................79
33 Segment Descriptor Caches for Protected Mode (Loaded per Descriptor)..........................80
34 Segment Descriptor Caches for Virtual 8086 Mode within Protected Mode (Segment Limit
and Attributes are Fixed)...........................................................................................81
35 Four-Level Hierarchical Protection...............................................................................82
36 Intel®Quark Core TSS and TSS Registers....................................................................84
37 Sample I/O Permission Bit Map ..................................................................................85
38 Intel®Quark Core TSS .............................................................................................88
39 Simple Protected System...........................................................................................90
40 GDT Descriptors for Simple System.............................................................................91
41 Linear-Address Translation to a 4-KByte Page using PAE Paging......................................95
42 Linear-Address Translation to a 2-MByte Page using PAE Paging .....................................96
43 Formats of CR3 and Paging-Structure Entries in 32-bit Mode with PAE Paging Disabled ......98
44 Formats of CR3 and Paging-Structure Entries in 32-bit Mode with PAE Paging Enabled.......99
45 Translation Lookaside Buffer ....................................................................................104
46 Page-Fault Error Code.............................................................................................105
47 Page Fault System Information.................................................................................107
48 Virtual 8086 Environment Memory Management .........................................................108
49 Virtual 8086 Environment Interrupt and Call Handling .................................................111
50 On-Chip Cache Physical Organization ........................................................................114
51 On-Chip Cache Replacement Strategy .......................................................................119
52 Page Cacheability ...................................................................................................121
53 Basic SMI# Interrupt Service ...................................................................................128
54 Basic SMI# Hardware Interface................................................................................129
55 SMI# Timing for Servicing an I/O Trap......................................................................130
56 Intel®Quark SoC X1000 Core SMIACT# Timing..........................................................130
57 Redirecting System Memory Addresses to SMRAM.......................................................132
58 Transition to and from System Management Mode ......................................................135
59 SMM Revision Identifier...........................................................................................138
60 Auto HALT Restart..................................................................................................139

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 13
Contents—Intel®Quark Core
61 I/O Instruction Restart............................................................................................ 139
62 SMM Base Location ................................................................................................ 140
63 SMRAM Usage ....................................................................................................... 141
64 SMRAM Location .................................................................................................... 142
65 FLUSH# Mechanism during SMM .............................................................................. 143
66 Cached SMM ......................................................................................................... 143
67 Non-Cached SMM................................................................................................... 144
68 Write-Back Enhanced Intel®Quark SoC X1000 Core Cache Flushing for Overlaid
SMRAM upon Entry and Exit of Cached SMM .............................................................. 145
69 Functional Signal Groupings .................................................................................... 150
70 Reordering of a Reads with Write Buffers................................................................... 168
71 Reordering of a Reads with Write Buffers................................................................... 168
72 Pin States During RESET......................................................................................... 172
73 Stop Clock Protocol ................................................................................................ 175
74 Intel®Quark SoC X1000 Core Stop Clock State Machine ............................................. 178
75 Recognition of Inputs when Exiting Stop Grant State .................................................. 179
76 Write-Back Enhanced Intel®Quark SoC X1000 Core Stop Clock State Machine
(Enhanced
Bus Configuration) ................................................................................................. 181
77 Physical Memory and I/O Spaces.............................................................................. 185
78 Physical Memory and I/O Space Organization............................................................. 186
79 Intel®Quark SoC X1000 Core with 32-Bit Memory ..................................................... 188
80 Addressing 16- and 8-Bit Memories .......................................................................... 188
81 Logic to Generate A1, BHE# and BLE# for 16-Bit Buses .............................................. 190
82 Data Bus Interface to 16- and 8-Bit Memories............................................................ 191
83 Single Master Intel®Quark Core System................................................................... 193
84 Single Intel®Quark Core with DMA .......................................................................... 194
85 Single Intel®Quark Core with Multiple Secondary Masters........................................... 195
86 Basic 2-2 Bus Cycle................................................................................................ 197
87 Basic 3-3 Bus Cycle................................................................................................ 198
88 Non-Cacheable, Non-Burst, Multiple-Cycle Transfers................................................... 200
89 Non-Cacheable Burst Cycle...................................................................................... 201
90 Non-Burst, Cacheable Cycles ................................................................................... 203
91 Burst Cacheable Cycle ............................................................................................ 204
92 Effect of Changing KEN#......................................................................................... 205
93 Slow Burst Cycle.................................................................................................... 206
94 Burst Cycle Showing Order of Addresses ................................................................... 207
95 Interrupted Burst Cycle........................................................................................... 208
96 Interrupted Burst Cycle with Non-Obvious Order of Addresses...................................... 209
97 8-Bit Bus Size Cycle ............................................................................................... 210
98 Burst Write as a Result of BS8# or BS16#................................................................. 211
99 Locked Bus Cycle................................................................................................... 212
100 Pseudo Lock Timing................................................................................................ 213
101 Fast Internal Cache Invalidation Cycle ...................................................................... 214
102 Typical Internal Cache Invalidation Cycle................................................................... 214
103 System with Second-Level Cache ............................................................................. 216
104 Cache Invalidation Cycle Concurrent with Line Fill....................................................... 217
105 HOLD/HLDA Cycles................................................................................................. 218
106 HOLD Request Acknowledged during BOFF#.............................................................. 219
107 Interrupt Acknowledge Cycles.................................................................................. 220
108 Stop Grant Bus Cycle.............................................................................................. 221
109 Restarted Read Cycle.............................................................................................. 222
110 Restarted Write Cycle............................................................................................. 223
111 Bus State Diagram................................................................................................. 224
112 Basic Burst Read Cycle ........................................................................................... 227

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
14 Order Number: 329679-001US
113 Snoop Cycle Invalidating a Modified Line ...................................................................231
114 Snoop Cycle Overlaying a Line-Fill Cycle....................................................................232
115 Snoop Cycle Overlaying a Non-Burst Cycle.................................................................233
116 Snoop to the Line that is Being Replaced ...................................................................234
117 Snoop under BOFF# during a Cache Line-Fill Cycle......................................................236
118 Snoop under BOFF# to the Line that is Being Replaced................................................237
119 Snoop under HOLD during Line Fill............................................................................238
120 Snoop using HOLD during a Non-Cacheable, Non-Burstable Code Prefetch .....................239
121 Locked Cycles (Back-to-Back) ..................................................................................240
122 Snoop Cycle Overlaying a Locked Cycle .....................................................................241
123 Flush Cycle............................................................................................................242
124 Snoop under AHOLD Overlaying Pseudo-Locked Cycle .................................................243
125 Snoop under HOLD Overlaying Pseudo-Locked Cycle ...................................................244
126 Snoop under BOFF# Overlaying a Pseudo-Locked Cycle...............................................245
127 Size Breakpoint Fields.............................................................................................248
128 General Instruction Format .....................................................................................253
129 Intel®Quark SoC X1000 Core Cache Test Registers....................................................296
130 TR4 Definition for Standard and Enhanced Bus Modes for the Write-Back Enhanced
Intel®Quark SoC X1000 Core..................................................................................300
131 TR5 Definition for Standard and Enhanced Bus Modes for the Write-Back Enhanced
Intel®Quark SoC X1000 Core..................................................................................300
132 TLB Organization....................................................................................................301
133 TLB Test Registers..................................................................................................302
134 TAP Controller State Diagram...................................................................................305
Tables
1 Manual Contents ......................................................................................................17
2 Related Documents...................................................................................................20
3 Segment Register Selection Rules...............................................................................25
4 BASE and INDEX Registers for 16- and 32-Bit Addresses ...............................................28
5 Interrupt Vector Assignments.....................................................................................35
6 FPU Interrupt Vector Assignments ..............................................................................35
7 Sequence of Exception Checking.................................................................................37
8 Interrupt Vectors Used by FPU ...................................................................................38
9 Data Type Alignment Requirements ............................................................................42
10 Intel®Quark SoC X1000 Core Operating Modes............................................................48
11 On-Chip Cache Control Modes ....................................................................................48
12 Recommended Values of the Floating-Point Related Bits for Intel®Quark SoC X1000
Core .......................................................................................................................50
13 Interpreting Different Combinations of EM, TS and MP Bits.............................................50
14 Condition Code Interpretation after FPREM and FPREM1 Instructions ...............................56
15 Floating-Point Condition Code Interpretation ................................................................56
16 Condition Code Resulting from Comparison..................................................................57
17 Condition Code Defining Operand Class .......................................................................57
18 FPU Exceptions ........................................................................................................58
19 Debug Registers.......................................................................................................62
20 Test Registers..........................................................................................................62
21 Register Usage.........................................................................................................63
22 FPU Register Usage Differences..................................................................................63
23 MSRs for Intel®Quark Core 1 ....................................................................................64
24 Instruction Forms in which LOCK Prefix Is Legal............................................................65
25 Exceptions with Different Meanings in Real Mode (see Table 24) .....................................67
26 Access Rights Byte Definition for Code and Data Descriptions .........................................74
27 Pointer Test Instructions............................................................................................85

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 15
Contents—Intel®Quark Core
28 Descriptor Types Used for Control Transfer..................................................................86
29 Use of CR3 with PAE Paging.......................................................................................93
30 Format of a PAE Page-Directory-Pointer-Table Entry (PDPTE).........................................94
31 Format of a PAE Page-Directory Entry that Maps a 2-MByte Page....................................96
32 Format of a PAE Page-Directory Entry that References a Page Table................................97
33 Format of a PAE Page-Table Entry that Maps a 4-KByte Page .........................................97
34 Page Level Protection Attributes............................................................................... 103
35 Write-Back Enhanced Intel®Quark SoC X1000 Core WB/WT# Initialization.................... 115
36 Cache Operating Modes .......................................................................................... 116
37 Write-Back Enhanced Intel®Quark SoC X1000 Core Write-Back Cache Operating
Modes .................................................................................................................. 117
38 Encoding of the Special Cycles for Write-Back Cache................................................... 119
39 Cache State Transitions for Write-Back Enhanced Intel®Quark SoC X1000
Core-Initiated Unlocked Read Cycles......................................................................... 124
40 Cache State Transitions for Write-Back Enhanced Intel®Quark SoC X1000
Core-Initiated Write Cycles...................................................................................... 125
41 Cache State Transitions During Snoop Cycles............................................................. 125
42 SMRAM State Save Map.......................................................................................... 132
43 SMM Initial Processor Core Register Settings ............................................................. 136
44 Bit Values for SMM Revision Identifier....................................................................... 138
45 Bit Values for Auto HALT Restart.............................................................................. 139
46 I/O Instruction Restart Value................................................................................... 140
47 Cache Flushing (Non-Overlaid SMRAM) ..................................................................... 144
48 Cache Flushing (Overlaid SMRAM)............................................................................ 145
49 ADS# Initiated Bus Cycle Definitions ........................................................................ 152
50 Differences between CACHE# and PCD ..................................................................... 161
51 CACHE# vs. Other Intel®Quark Core Signals ............................................................ 162
52 HITM# vs. Other Intel®Quark Core Signals............................................................... 163
53 INV vs. Other Intel®Quark Core Signals................................................................... 163
54 WB/WT# vs. Other Intel®Quark Core Signals............................................................ 164
55 Register Values after Reset...................................................................................... 170
56 Floating-Point Values after Reset.............................................................................. 170
57 FERR# Pin State after Reset and before FP Instructions............................................... 174
58 Pin State during Stop Grant Bus State ...................................................................... 175
59 Write-Back Enhanced Intel®Quark SoC X1000 Core Pin States during Stop Grant Bus
Cycle.................................................................................................................... 176
60 Byte Enables and Associated Data and Operand Bytes................................................. 184
61 Generating A[31:0] from BE[3:0]# and A[31:A2]....................................................... 185
62 Next Byte Enable Values for BSx# Cycles.................................................................. 187
63 Data Pins Read with Different Bus Sizes .................................................................... 187
64 Generating A1, BHE# and BLE# for Addressing 16-Bit Devices..................................... 189
65 Generating A0, A1 and BHE# from the Intel®Quark SoC X1000 Core Byte Enables ........ 191
66 Transfer Bus Cycles for Bytes, Words and Dwords ...................................................... 192
67 Burst Order (Both Read and Write Bursts) ................................................................. 206
68 Special Bus Cycle Encoding ..................................................................................... 221
69 Bus State Description ............................................................................................. 224
70 Snoop Cycles under AHOLD, BOFF#, or HOLD............................................................ 228
71 Various Scenarios of a Snoop Write-Back Cycle Colliding with an On-Going Cache Fill or
Replacement Cycle................................................................................................. 230
72 Debug Registers .................................................................................................... 247
73 LENi Encoding........................................................................................................ 248
74 RW Encoding......................................................................................................... 248
75 Fields within Intel®Quark Core Instructions .............................................................. 254
76 Encoding of Operand Length (w) Field....................................................................... 255
77 Encoding of reg Field when the (w) Field is Not Present in Instruction............................ 255

Intel®Quark Core—Contents
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
16 Order Number: 329679-001US
78 Encoding of reg Field when the (w) Field is Present in Instruction..................................256
79 2-Bit sreg2 Field.....................................................................................................256
80 3-Bit sreg3 Field.....................................................................................................257
81 Encoding of 16-Bit Address Mode with “mod r/m” Byte................................................258
82 Encoding of 32-Bit Address Mode with “mod r/m” Byte
(No “s-i-b” Byte Present).........................................................................................259
83 Encoding of 32-Bit Address Mode (“mod r/m” Byte and “s-i-b” Byte Present)..................260
84 Encoding of Operation Direction (d) Field...................................................................260
85 Encoding of Sign-Extend (s) Field .............................................................................261
86 Encoding of Conditional Test (tttn) Field ....................................................................261
87 Encoding of Control or Debug or Test Register (eee) Field............................................262
88 Encoding of Floating-Point Instruction Fields...............................................................263
89 Clock Count Summary.............................................................................................267
90 Task Switch Clock Counts........................................................................................279
91 Interrupt Clock Counts............................................................................................279
92 Notes and Abbreviations (for Table 89 through Table 91).............................................280
93 I/O Instructions Clock Count Summary......................................................................281
94 Floating-Point Clock Count Summary.........................................................................283
95 Intel®Quark SoC X1000 Core Pin Descriptions...........................................................291
96 Cache Control Bit Encoding and Effect of Control Bits on Entry Select and Set Select
Functionality..........................................................................................................298
97 State Bit Assignments for the Write-Back Enhanced Intel®Quark SoC X1000 Core..........299
98 Meaning of a Pair of TR6 Protection Bits.....................................................................302
99 TR6 Operation Bit Encoding .....................................................................................302
100 Encoding of Bit 4 of TR7 on Writes............................................................................303
101 Encoding of Bit 4 of TR7 on Lookups .........................................................................303
102 CPUID with PAE/XD/SMEP features implemented ........................................................309
103 Intel®Quark SoC X1000 CPUID................................................................................310
104 Component Identification.........................................................................................311
§ §

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 17
About this Manual—Intel®Quark Core
1.0 About this Manual
This manual describes the embedded Intel®Quark SoC X1000 Core. It is intended for
use by hardware designers familiar with the principles of embedded microprocessors
and with the Intel®Quark SoC X1000 Core architecture.
1.1 Manual Contents
Table 1 summarizes the contents of the remaining chapters and appendixes. The
remainder of this chapter describes notation conventions and special terminology used
throughout the manual and provides references to related documentation.
Table 1. Manual Contents (Sheet 1 of 2)
Chapter Description
Chapter 2.0, “Intel®
Quark SoC X1000 Core
Overview”
Provides an overview of the current embedded Intel®Quark SoC X1000 Core,
including product features, system components, system architecture, and
applications. This chapter also lists product frequency, voltage, and package
offerings.
Chapter 3.0,
“Architectural Overview” Describes the Intel®Quark SoC X1000 Core internal architecture, with an
overview of the processor’s functional units.
Chapter 4.0, “System
Register Organization”
Details the Intel®Quark SoC X1000 Core register set, including the base
architecture registers, system-level registers, debug and test registers, and Intel®
Quark SoC X1000 Core Model Specific Registers (MSRs).
Chapter 5.0, “Real Mode
Architecture” When the Intel®Quark SoC X1000 Core is powered-up, it is initialized in Real
Mode, which is described in this chapter.
Chapter 6.0, “Protected
Mode Architecture” Describes Protected Mode, including segmentation, protection, and paging.
Chapter 7.0, “On-Chip
Cache” The Intel®Quark SoC X1000 Core contains an on-chip cache, also known as L1
cache. This chapter describes its functionality.
Chapter 8.0, “System
Management Mode
(SMM) Architectures”
Describes the System Management Mode architecture of the Intel®Quark SoC
X1000 Core, including System Management Mode interrupt processing and
programming.
Chapter 9.0, “Hardware
Interface”
Describes the hardware interface of the Intel®Quark SoC X1000 Core, including
signal descriptions, interrupt interfaces, write buffers, reset and initialization, and
clock control.
Chapter 10.0, “Bus
Operation” Describes the features of the processor bus, including bus cycle handling, interrupt and reset signals, cache control, and floating-point error control.
Chapter 11.0,
“Debugging Support” Describes the Intel®Quark SoC X1000 Core debugging support, including the
breakpoint instruction, single-step trap, and debug registers.
Chapter 12.0,
“Instruction Set
Summary”
Describes the Intel®Quark SoC X1000 Core instruction set and the encoding of
each field within the instructions.

Intel®Quark Core—About this Manual
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
18 Order Number: 329679-001US
1.2 Notation Conventions
The following notations are used throughout this manual.
# The pound symbol (#) appended to a signal name indicates that
the signal is active low.
Variables Variables are shown in italics. Variables must be replaced with
correct values.
New Terms New terms are shown in italics.
Instructions Instruction mnemonics are shown in upper case. When you are
programming, instructions are not case-sensitive. You may use
either upper or lower case.
Numbers Hexadecimal numbers are represented by a string of
hexadecimal digits followed by the character H. A zero prefix is
added to numbers that begin with A through F. (For example, FF
is shown as 0FFH.) Decimal and binary numbers are
represented by their customary notations. (That is, 255 is a
decimal number and 1111 1111 is a binary number. In some
cases, the letter B is added for clarity.)
Units of Measure The following abbreviations are used to represent units of
measure:
Appendix A, “Signal
Descriptions” Lists each Intel®Quark SoC X1000 Core signal and describes its function.
Appendix B, “Testability” Describes the testability of the Intel®Quark SoC X1000 Core, including on-chip
cache testing, translation lookaside buffer (TLB) testing, and JTAG.
Appendix C, “Feature
Determination” Documents the CPUID function, which is used to determine the Intel®Quark SoC
X1000 Core identification and processor-specific information.
Table 1. Manual Contents (Sheet 2 of 2)
Chapter Description
Aamps,amperes
mA milliamps, milliamperes
µA microamps,
microamperes
Mbyte megabytes
Kbyte kilobytes
Gbyte gigabyte
W watts
KW kilowatts
mW milliwatts
µW microwatts
MHz megahertz
ms milliseconds
ns nanoseconds
µs microseconds

Intel®Quark SoC X1000 Core
October 2013 Developer’s Manual
Order Number: 329679-001US 19
About this Manual—Intel®Quark Core
Register Bits When the text refers to more that one bit, the range of bits is
represented by the highest and lowest numbered bits,
separated by a colon (example: A[15:8]). The first bit shown
(15 in the example) is the most-significant bit and the second
bit shown (8) is the least-significant bit.
Register Names Register names are shown in upper case. If a register name
contains a lower case, italic character, it represents more than
one register. For example, PnCFG represents three registers:
P1CFG, P2CFG, and P3CFG.
Signal Names Signal names are shown in upper case. When several signals
share a common name, an individual signal is represented by
the signal name followed by a number, whereas the group is
represented by the signal name followed by a variable (n). For
example, the lower chip select signals are named CS0#, CS1#,
CS2#, and so on; they are collectively called CSn#. A pound
symbol (#) appended to a signal name identifies an active-low
signal. Port pins are represented by the port abbreviation, a
period, and the pin number (e.g., P1.0, P1.1).
1.3 Special Terminology
The following terms have special meanings in this manual.
Assert and De-assert The terms assert and de-assert refer to the act of making a
signal active and inactive, respectively. The active polarity
(high/low) is defined by the signal name. Active-low signals are
designated by the pound symbol (#) suffix; active-high signals
have no suffix. To assert RD# is to drive it low; to assert HOLD
is to drive it high; to de-assert RD# is to drive it high; to de-
assert HOLD is to drive it low.
DOS I/O Address Peripherals compatible with PC/AT system architecture can be
mapped into DOS (or PC/AT) addresses 0H–03FFH. In this
manual, DOS address and PC/AT address are synonymous.
Expanded I/O Address All peripheral registers reside at I/O addresses 0F000H–0FFFFH.
PC/AT-compatible integrated peripherals can also be mapped
into DOS (or PC/AT) address space (0H–03FFH).
PC/AT Address Integrated peripherals that are compatible with PC/AT system
architecture can be mapped into PC/AT (or DOS) addresses 0H–
03FFH. In this manual, the terms DOS address and PC/AT
address are synonymous.
Set and Clear The terms set and clear refer to the value of a bit or the act of
giving it a value. If a bit is set, its value is “1”; setting a bit gives
it a “1” value. If a bit is clear, its value is “0”; clearing a bit gives
it a “0” value.
µF microfarads
pF picofarads
Vvolts

Intel®Quark Core—About this Manual
Intel®Quark SoC X1000 Core
Developer’s Manual October 2013
20 Order Number: 329679-001US
1.4 Related Documents
The following Intel documents contain additional information on designing systems that
incorporate the Intel®Quark SoC X1000 Core.
Table 2. Related Documents
Ref. Document Name Order Number
[HRM] Intel®Quark SoC X1000 Core Hardware Reference Manual 329678
[Intel Arch SDM] Intel®64 and IA-32 Architectures Software Developer’s Manual
Combined Volumes: 1, 2A, 2B, 2C, 3A, 3B and 3C 325462
