Aaeon GENE-LN05 User manual

SubCompact Board GENE-LN05 Rev.B
GENE-LN05 Rev.B
Intel® Atom™N455/D525 Processors
Intel®82567V & 82583V
for 10/100/1000Mbps
2 SATA 3.0 Gb/s, 1 CompactFlash™
6 COM, 7 USB2.0, Digital I/O
1 Mini Card/ SMBus/ LPC
GENE-LN05 Rev.B Manual 4th Ed.
July 17, 2015

SubCompact Board GENE-LN05 Rev.B
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i

SubCompact Board GENE-LN05 Rev.B
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
CompactFlash™ is a trademark of the Compact Flash
Association.
Intel®, Atom™are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their
respective owners.
ii

SubCompact Board GENE-LN05 Rev.B
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•CD-ROM for manual (in PDF format) and drivers
•GENE-LN05 Rev.B with Active Cooler (D525 Version)
or with Passive Cooler (N455 Version)
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
iii

SubCompact Board GENE-LN05 Rev.B
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specifications............................................................ 1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions .................................................... 2-2
2.2 Location of Connectors & Jumpers...........................2-3
2.3 Mechanical Drawing..................................................2-5
2.4 List of Jumpers..........................................................2-7
2.5 List of Connectors ..................................................... 2-8
2.6 Setting Jumpers ........................................................2-10
2.7 Touch Screen 4/5/8-wire Mode Selection (JP1) ....... 2-11
2.8 Auto Power Button Selection (JP2)...........................2-11
2.9 COM2 RI/+5V/+12V Selection (JP3)......................... 2-11
2.10 Clear CMOS (JP4) .................................................. 2-11
2.11 LVDS Backlight Bias/PWM Mode Selection (JP5)2-11
2.12 LVDS Operating Voltage Selection (JP6) ............... 2-12
2.13 LVDS Inverter Voltage Selection (JP7)................... 2-12
2.14 2-Pin ATX Power Connector (CN1) (Optional) .......2-12
2.15 CPU FAN Connector (CN2) ....................................2-12
2.16 +5VSB Output With SMBUS (CN3) ........................ 2-12
2.17 External +5VSB Input (CN4)...................................2-13
iv

SubCompact Board GENE-LN05 Rev.B
2.18 SATA Port #2 (CN5)................................................2-13
2.19 SATA Port #1 (CN6)................................................ 2-13
2.20 LPC Expansion I/F (CN7)........................................2-14
2.21 External +5V Input –depends on the power input
configuration (CN8) ......................................................... 2-14
2.22 External +12V Input-depends on the power input
configuration (CN9) ......................................................... 2-14
2.23 Touch Screen Connector (CN10)............................ 2-15
2.24 +5V Output For SATA HDD (CN11)........................2-15
2.25 Front Panel (CN12).................................................2-15
2.26 COM Port #6 (CN13)............................................... 2-15
2.27 USB Port #7 (CN14)................................................2-16
2.28 COM Port #5 (CN15)............................................... 2-16
2.29 USB Port #6 (CN16)................................................2-16
2.30 USB Port #5 (CN17)................................................2-17
2.31 COM Port #4 (CN18)............................................... 2-17
2.32 USB Port #4 (CN19)................................................2-17
2.33 USB Port #3 (CN20)................................................2-17
2.34 COM Port #3 (CN21)............................................... 2-18
2.35 COM Port #2 (CN22)............................................... 2-18
2.36 Audio Line-In/Out and MIC Connector (CN23) ....... 2-19
2.37 RJ-45 Ethernet #2 (CN24) ......................................2-19
2.38 RJ-45 Ethernet #1 (CN25) ......................................2-20
2.39 Digital I/O Connector (CN26) .................................. 2-20
2.40 Parallel Port (CN27)................................................2-21
v

SubCompact Board GENE-LN05 Rev.B
2.41 LVDS Inverter Connector (CN28) ...........................2-22
2.42 LVDS Output (CN29)............................................... 2-22
2.43 USB Port 1 & 2 (CN30) ...........................................2-23
2.44 PS/2 Keyboard & Mouse (CN31) ............................ 2-23
2.45 COM Port #1 (CN32)............................................... 2-23
2.46 CRT Display Connector (CN33).............................. 2-23
2.47 SIM Card Socket (CN34) ........................................2-24
2.48 CompactFlash Disk (CFD1) .................................... 2-24
2.49 Mini-Card Slot #1 (PCIE1).......................................2-25
2.50 DDR2 SODIMM Slot (DIMM1) ................................ 2-26
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 AMI BIOS Setup........................................................ 3-3
Chapter 4 Driver Installation
4.1 Installation ................................................................. 4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 W83627DHG Watchdog Timer Initial Program......A-7
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 1st MB Memory Address Map ................................B-4
B.3 IRQ Mapping Chart................................................B-5
B.4 DMA Channel Assignments...................................B-5
vi

SubCompact Board GENE-LN05 Rev.B
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
vii

SubCompact Board GENE-LN05 Rev.B
General
Information
Chapter
1
Chapter 1 General Information 1- 1

SubCompact Board GENE-LN05 Rev.B
1.1 Introduction
AAEON, a leading embedded boards manufacturer, is pleased to
announce a new 3.5” SubCompact Board—GENE-LN05 Rev.B. The
GENE-LN05 Rev.B is a cutting-edge product that provides high
performance and low power consumption in the embedded market.
GENE-LN05 Rev.B adopts the latest Intel®Atom processors and the
system memory is deployed with SODIMM DDR3 up to 4 GB (D525 is
up to 4 GB, N455 is up to 2 GB). In addition, Intel®82567V & 82583V
supports two 10/100/100Base-TX that allows faster network
connection. This model applies one Mini Card and one LPC Bus
expansions. Moreover, two SATA 3.0 Gb/s (optional RAID 0 &1) and
one Type2 CompactFlashTM storage is configured on the GENE-LN05
Rev.B. In addition to the diverse storages, GENE-LN05 Rev.B also
equips seven USB2.0, six COM, one parallel, and one
keyboard/mouse ports for flexible I/O expansions. There are no more
worries about installing many necessary devices to complete the
functions of your system.
The display of GENE-LN05 Rev.B supports CRT/LCD simultaneous/
dual view displays and 18/24-bit single channel LVDS. Moreover, the
GENE-LN05 Rev.B offers Wide Temperature Solution and the
temperature range will be -40oC~85 oC. This SubCompact Board is
developed to cater to the requirements of Automation, Medical, ticket
machine, transportation, gaming, KIOSK, and POS/POI applications.
Chapter 1 General Information1- 2
