Intel S5520HC Guide

I
Intel®ServerBoardS5520HC,
Intel®ServerBoardS5500HCV,
Intel®ServerBoardS5520HCT,
Intel®WorkstationBoardS5520SC,
Intel®ServerChassisSC5600,
Intel®ServerChassisSC5650,
Intel®ServerSystemSC5650HCBRP,
Intel®WorkstationSystemSC5650SCWS
SparesPartsList&ConfigurationGuide
A reference guide to assist customers in ordering the necessary components to configure the
Intel®Server Board S5520HC, Intel® Server Board S5520HCT, Intel®Server Board S5500HCV,
and Intel®Workstation Board S5520SC with appropriate Intel chassis.

2
Rev 1.09
January, 2010
~ Subject to Change ~
Disclaimer
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED
BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH
PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,
COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to
specifications and product descriptions at any time, without notice.
Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which may cause
the product to deviate from published specifications. Current characterized errata are available on request.
Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in
the United States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2009, Intel Corporation

3
Contents
Contents ..........................................................................................................3
Production Configuration.............................................................................4
Production Board SKUs..............................................................................8
Production System ....................................................................................10
Production Chassis....................................................................................12
Production Spares and Accessories ........................................................14
Production RAID Accessories (not including BBU).................................20
Production RAID Controller.......................................................................20
Intel Tested Memory List...........................................................................22
Intel THOL List...........................................................................................22
Intel® System Management Software – (Upgrade SKUs)......................24
Production Intel®Xeon Processor 5500 Series.......................................26
Production Intel Thermal Solution STS100 Series..................................27
Heat Sink Configuration Guide.................................................................27
VMware* vSphere* Virtualization Software Configuration Guide for vSphere* SKUs 28
Product Descriptions – Overview..............................................................28
VMware vSphere* and vCenter* Server SKUs........................................28

I
Production Configuration
This section contains information needed to order and configure the Intel®Server System SC5650HCBRP, Intel®
Workstation System SC5650SCWS, and Intel®Server Chassis SC5600, SC5650 Family with Intel®Server Board
S5520HC, S5520HCT and S5500HCV and Intel®Workstation Board S5520SC.
1) Production boxed Intel Server Boards contain the following:
•One baseboard with unified back plate assembly
•ATX I/O shield
•Cables: Serial B (COM2), 4 SAS/SATA cables
•Resource CD-ROM with utilities, drivers, documentation and technical information* (does not ship with
S5520HCT)
•Quick Start User’s Guide and Quick Reference Label
•ISMS 3.1 DVD * (does not ship with S5520HCT)
•Compatible with Intel®Xeon®processor 5500 series
2) Production OEM 10-packs of Intel Server Boards contain the following:
•One baseboard with unified back plate assembly
•Compatible with Intel®Xeon®processor 5500 series
3) The production SC5600LX KDK is compatible with the Intel®Server Boards S5520HC and S5500HCV. it
includes:
•Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support (2nd
redundancy 750W high efficiency PFC module included)
•Four redundant, hot-swap fans and ducting
•Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-
swap SAS or SATA drives.
•Quick Start User’s Guide and Configuration Label
•Cables (one each):
oFront Panel Cable (baseboard header to front panel)
oUSB Cable (USB header to chassis front panel)
oCOM2 Cable
oAdapter Cable providing two additional SATA power connectors
oAC power cords are included only in SC5600LXNA
•Five Bumpers for installing Intel®Server Board S5520HC or S5500HCV
•The Intel®Server Chassis SC5600LX is designed to work with Intel®Xeon®processor 5500 series with
95W maximum power and FXXRGTHSINK or FXXRGTHS tower heat sink accessory (required).
4) The production Intel®Server Chassis SC5600BRP KDK is compatible with the Intel® Server Boards S5520HC
and S5500HCV. it includes:
•Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support
(2nd redundancy 750W high efficiency PFC module included)
•Three non-redundant fixed cooling fans with ducting
•Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-
swap SAS or SATA drives.
•Quick Start User’s Guide and Configuration Label
•Cables (one each):
oFront Panel Cable (baseboard header to front panel)
oUSB Cable (USB header to chassis front panel)

5
oCOM2 Cable
oAdapter Cable providing two additional SATA power connectors
oAC power cords are included only in SC5600BRPNA
•Five Bumpers for installing Intel®Server Board S5520HC, S5500HCV
•The Intel®Server Chassis SC5600BRP is designed to work with Intel®Xeon®processor 5500 series with
95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.
5) The production Intel®Server Chassis SC5600 Base KDK is compatible with Intel®Server Chassis S5520HC,
S5500HCV, and Intel® Workstation Board S5520SC. It includes:
•Non-redundant 670W PFC power supply
•Three non-redundant fixed cooling fans with ducting
•Support for six tool free non hot-swap hard drives. Upgradeable to 6 hot-swap SAS or SATA.
•Quick Start User’s Guide and Configuration Label
•Cables (one each):
oFront Panel Cable (baseboard header to front panel)
oUSB Cable (USB header to chassis front panel)
oCOM2 Cable
oAdapter Cable providing two additional SATA power connectors
oAC power cord is included only with SC5600BASENA.
•Five Bumpers for installing Intel®Server Board S5520HC, S5500HCV, and Intel®Workstation Board
S5520SC.
•The Intel®Server Chassis SC5600BASE is designed to work with Intel®Xeon®processor 5500 series with
95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.
6) The production Intel®Workstation Chassis SC5650WS SKU is compatible with the Intel®Workstation Board
S5520SC. It includes:
•Non-redundant 1000W high efficiency PFC power supply
•Three non-redundant fixed cooling fans with ducting
•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
•Quick Start User’s Guide
•Cables (one each):
oFront Panel Cable (baseboard header to front panel)
oUSB Cable (USB header to chassis front panel)
oAdapter Cable providing two additional SATA power connectors
oAC power cord is included only with SC5650WSNA
•Chassis intrusion switch assembly
•Five Bumpers for installing Intel®Workstation Board S5520SC.
•The chassis is designed to work with Intel®Xeon®processor 5500 series with 130W maximum power, and
is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.
7) The production Intel®Server Chassis SC5650DP SKU is compatible with the Intel®Server Board S5520SC,
S5500HCV, and S5500BC. It includes:
•Non-redundant 600W PFC power supply
•Three non-redundant fixed cooling fan with ducting
•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
Note: Check the Power budget spreadsheet for supportable hard drive, memory and PCI configurations.
•Quick Start User’s Guide

6
•Cables (one each):
oFront Panel Cable (baseboard header to front panel)
oUSB Cable (USB header to chassis front panel)
oAdapter Cable providing two additional SATA power connectors
oAC power cord is only included in SC5650DPNA
•Chassis intrusion switch assembly
•Five Bumpers for installing Intel®Server Board S5520SC, S5500HCV, and S5500BC.
•The chassis is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power, and is
compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
8) The production Intel®Server Chassis SC5650BRP SKU is compatible with the Intel®Server Board S5520SC,
S5500HCV, and S5500BC. It includes:
•Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full
redundancy requires additional 600W module purchased separately)
•Three non-redundant fixed cooling fan with ducting
•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
•Quick Start User’s Guide
•Cables (one each):
oFront Panel Cable (baseboard header to front panel)
oUSB Cable (USB header to chassis front panel)
oAdapter Cable providing two additional SATA power connectors
oAC power cord is only included in SC5650BRPNA
•Chassis intrusion switch assembly
•Five Bumpers for installing Intel®Server Board S5520SC, S5500HCV, and S5500BC.
•The chassis is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power, and is
compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
9) The Intel®Server System SC5650HCBRP includes:
•Intel®Server Board S5520HC pre-installed in the Intel®Sever Chassis SC5650BRP
•Expander-based Intel® Hot Swap Drive Bay AXX6DRV3GEXP pre-installed with cooling and mounting kit
(APP3HSDBKIT) in the Intel®Server Chassis SC5650BRP (Require SAS add-in card or SAS module
purchased separately)
•Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full
redundancy requires additional 600W module purchased separately)
•Three non-redundant fixed cooling fan with ducting
•Quick Start User’s Guide and Configuration Label
•Cables (one each)
oFront Panel Cable (baseboard header to front panel, pre-routed))
oUSB Cable (USB header to chassis front panel, pre-routed)
oAdapter Cable providing two additional SATA power connectors (in cable kit)
oAC power cord is only included in SC5650HCBRPNA
•Chassis intrusion switch assembly (pre-routed)
•The server system is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power,
and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
10) The Intel®Workstation System SC5650SCWS includes:

7
•Intel®Workstation Board S5520SC pre-installed in the Intel®Sever Chassis SC5650WS
•Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
•Non-redundant 1000W high efficiency PFC power supply
•Three non-redundant fixed cooling fan with ducting
•Quick Start User’s Guide and Configuration Label
•Cables (one each)
oFront Panel Cable (baseboard header to front panel, pre-routed))
oUSB Cable (USB header to chassis front panel, pre-routed)
oAdapter Cable providing two additional SATA power connectors (in cable kit)
oAC power cord is only included in SC5650SCWSNA
•Chassis intrusion switch assembly (pre-routed)
•The workstation system is designed to work with Intel®Xeon®processor 5500 series with 130W maximum
power, and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
11) Common accessories include:
Hot Swap Drive Bays:
– AXX6DRV3GEXP: Expander-based 6-drive bay that supports SAS/SATA drives. Requires two free
SAS ports from the SAS personality module or SAS RAID card.
– AXX4DRV3GEXP: Expander-based 4-drive bay that supports SAS/SATA drives. Requires two free
SAS ports from the SAS module or SAS RAID card. Only supported in Intel®Server Chassis
SC5600BRP, and SC5600LX.
– AXX6DRV3GR: 6-drive bay that supports SAS/SATA drives. Requires six free SAS or SATA ports.
SAS hard drive support requires SAS connectors from a SAS personality module or SAS RAID Card.
Support 6Gb SAS Hard Drives with compatible 6Gb SAS adapters
– AXX4DRV3GR: 4-drive bay that supports SAS/SATA drives. Requires four free SAS or SATA ports.
SAS hard drive support requires SAS connectors from a SAS personality module or SAS RAID Card.
Only supported in Intel®Server Chassis SC5600BRP and SC5600LX. Support 6Gb SAS Hard Drives
with compatible 6Gb SAS adapters.
AXX750WPS: Spare 750W power supply module for Intel®Server Chassis SC5600LX and SC5600BRP
ARIGRACK: Rack conversion kit (SC5600BASE, SC5600BRP and SC5600LX)
APP3RACKIT: Rack conversion kit (SC5600 chassis family).
AXXRAKSW5: Intel®RAID Activation Key AXXRAKSW5 to enable Intel Embedded RAID technology II for SAS
and/or SATA Software RAID 5 on S5520HC, S5500HCV, and S5520SC boards.
APPT600WHPSU: Additional 600W power supply module- required for full redundancy for SC5650BRP only.
APPTHSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis
family. This kit should be used with AXX6DRV3GR
APP3HSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis
family. This kit should be used with AXX6DRV3GEXP.
AXX25DRVADPTR: 2.5” hard drive carrier kit for installing 2.5” SATA or SAS hard drive or Solid State Drive into
3.5” hot swap drive bay

I
Production Board SKUs
Picture Product Code MM # UPC MOQ Description
S5520HC 900402 00735858207485 5 Boxed Intel
®
Server Board S5520HC. (Includes
I/O shield, cables, resource CD and ISMS DVD)
S5520HCR 905721 00735858213783 5 Boxed Intel
®
Server Board S5520HCR.(Includes
I/O shield, cables, resource CD and ISMS DVD)
BB5520HC 901640 00735858207492 10 Bulk pack of the Intel
®
Server Board S5520HC
BB5520HCR 905718 00735858213790 10 Bulk pack of the Intel
®
Server Board S5520HCR
S5520HCT 904912 00735858213776 1 Boxed Intel
®
Server Board S5520HCT. (Includes
I/O shield, cables)
S5500HCV 902386 00735858207508 5 Boxed Intel
®
Server Board S5500HCV. (Includes
I/O shield, cables, resource CD and ISMS DVD)
S5500HCVR 905723 00735858213820 5 Boxed Intel
®
Server Board S5500HCVR.
(Includes I/O shield, cables, resource CD and
ISMS DVD)
BB5500HCV 902387 00735858207515 10 Bulk pack of the Intel
®
Server Board S5500HCV

9
BB5500HCVR 905720 00735858213875 10 Bulk pack of the Intel
®
Server Board
S5500HCVR
S5520SC 900963 00735858207522 5 Boxed Intel
®
Workstation Board S5520SC.
(Includes I/O shield, cables, resource CD and
ISMS DVD)
S5520SCR 905722 00735858213806 5 Boxed Intel
®
Workstation Board S5520SCR.
(Includes I/O shield, cables, resource CD and
ISMS DVD)
BB5520SC 901634 00735858207539 10 Bulk pack of the Intel
®
Workstation Board
S5520SC.
BB5520SCR 905719 00735858213813 10 Bulk pack of the Intel
®
Workstation Board
S5520SCR.
MOQ = Minimum Order Quantity.

I
Production System
Picture Product Codec MM # UPC MOQ Description
SC5650HCBRP 904553 00735858212557 1 Intel
®
Server System SC5650HCBRP with
(1+0) PMBus-compliant 600W Redundant
power supply, 3 fixed chassis fans with
ducting, rackable with optional rack kit.
Supports up to 6 Hot-Swap drives (SAS or
SATA, require SAS add-in card or SAS
module purchased separately). Supports up
to 95W processor. No power cord or heat
sinks included.
SC5650HCBRPR 907331 TBD 1 Intel
®
Server System SC5650HCBRPR with
(1+0) PMBus-compliant 600W Redundant
power supply, 3 fixed chassis fans with
ducting, rackable with optional rack kit.
Supports up to 6 Hot-Swap drives (SAS or
SATA, require SAS add-in card or SAS
module purchased separately). Supports up
to 95W processor. No power cord or heat
sinks included.
SC5650HCBRPNA 903806 00735858213196 1 Same as Intel
®
System SC5650HCBRP
with North American power cord included.
No heat sinks included.
SC5650HCBRPRN
A 905764 TBD 1 Same as Intel
®
System SC5650HCBRPR
with North American power cord included.
No heat sinks included.
SC5650SCWS 904581 00735858212571 1 Intel
®
Workstation System SC5650SCWS
with 1000W fixed PSU, supports up to two
150W workstation graphics cards or single
300W workstation graphics card, 3 fixed
chassis fans with ducting, rackable with
optional rack kit, supports up to 6 fixed
drives, upgradeable to 6 Hot-Swap drives
(SAS or SATA). Supports up to 130W
processor. No power cord or heat sinks
included.
SC5650SCWSR 907332 TBD 1 Intel
®
Workstation System SC5650SCWSR
with 1000W fixed PSU, supports up to two
150W workstation graphics cards or single
300W workstation graphics card, 3 fixed
chassis fans with ducting, rackable with
optional rack kit, supports up to 6 fixed
drives, upgradeable to 6 Hot-Swap drives
(SAS or SATA). Supports up to 130W
processor. No power cord or heat sinks
included.

11
SC5650SCWSNA 903836 00735858213202 1 Same as Intel
®
Workstation System
SC5650SCWS with North American power
cord. No heat sinks included
SC5650SCWSRN
A 905767 TBD 1 Same as Intel
®
Workstation System
SC5650SCWSR with North American
power cord. No heat sinks included
MOQ = Minimum Order Quantity.

I
Production Chassis
Picture Product Codec MM # UPC MOQ Description
SC5600BASE 900403 00735858207546 1 Intel
®
Server Chassis SC5600 base version with
670W fixed PSU, 3 fixed chassis fans with
ducting, 1 PSU fan. Supports up to 6 tool-free
cabled drives, upgradeable to 6 hot-swap drives
(SAS or SATA). Supports Intel®Server Board
S5520HC, S5500HCV and Intel®workstation
board S5520SC. Supports up to 95W processor.
No power cord or heat sinks included.
SC5600BASENA 900891 00735858207553 1 Same as Intel
®
Server Chassis SC5600BASE
with North American power cord included. No
heat sinks included.
SC5600BRP 900877 00735858207560 1 Intel
®
Server Chassis SC5600 base redundant
power (BRP) version with (1+1) PMBus-
compliant 750W redundant PSU. 3 fixed
chassis fans with ducting, 1 PSU fan per
module, includes fixed drive cage to support 6
tool-free cabled drives, upgradeable to 10 fixed,
cabled drives or 10 (6+4 configuration) hot-swap
SAS or SATA drives. Supports Intel®Server
Board S5520HC, S5500HCV. Supports up to
95W processor. No power cord or heat sinks
included.
SC5600BRPNA 900913 00735858207577 1 Same as Intel
®
Server Chassis SC5600BRP
with North American power cord included. No
heat sinks included.
SC5600LX 900878 00735858207584 1 Intel
®
Server Chassis SC5600 LX Chassis with
750W PMBus-compliant (1+1) hot-swap
redundant power supply, 4 hot-swap redundant
fans with ducting, 1 PSU fan per module,
includes fixed drive cage to support 6 tool-free
cabled drives, upgradeable to 10 fixed, cabled
drives or 10 (6+4 configuration) hot-swap SAS or
SATA drives. Supports Intel® Server Board
S5520HC, S5500HCV. Supports up to 95W
processor. No power cord or heat sinks included.
Special tower heat sink FXXRGTHSINK or
FXXRGTHS required and can be purchased
as an accessory.

1
3
SC5600LXNA 900955 00735858207591 1 Same as Intel
®
Server Chassis SC5600LX with
North American power cord included. No heat
sinks included. Special tower heat sink
FXXRGTHSINK or FXXRGTHS required and
can be purchased as an accessory.
SC5650WS 900339 00735858207416 1 Intel
®
Workstation Chassis SC5650WS with
1000W fixed PSU, supports up to two 150W
workstation graphics cards or single 300W
workstation graphics card, 3 fixed chassis fans
with ducting, rackable with optional rack kit,
supports up to 6 fixed drives, upgradeable to 6
Hot-Swap drives (SAS or SATA). Supports Intel
workstation board S5520SC. Supports up to
130W processor. No power cord or heat sinks
included.
SC5650WSNA 900450 00735858207607 1 Same as Intel
®
Workstation Chassis SC5650WS
with North American power cord. No heat sinks
included
SC5650DP 900338 00735858207393 1 Intel
®
Server Chassis SC5650DP with 600W
fixed PSU, 3 fixed chassis fans with ducting,
rackable with optional rack kit, supports up to 6
fixed drives, upgradeable to 6 Hot-Swap drives
(SAS or SATA). Check the Power budget
spreadsheet for supportable hard drive,
memory and PCI configurations. Supports
S5520HC, S5500HCV, and S5500BC. Supports
up to 95W processor. No power cord or heat
sinks included.
SC5650DPNA 900453 00735858207614 1 Same as Intel
®
Server Chassis SC5650DP with
North American power cord. No heat sinks
included.
SC5650BRP 900340 00735858207409 1 Intel
®
Server Chassis SC5650BRP with (1+0)
PMBus-compliant 600W Redundant power
supply, 3 fixed chassis fans with ducting,
rackable with optional rack kit. Supports up to 6
fixed drives, upgradeable to 6 Hot-Swap drives
(SAS or SATA). Supports Intel®Server Boards
S5520HC, S5500HCV, and S5500BC. Supports
up to 95W processor. No power cord or heat
sinks included.

1
4
SC5650BRPNA 900452 00735858207621 1 Same as Intel
®
Server Chassis SC5650BRP
with North American power cord. No heat sinks
included.
MOQ = Minimum Order Quantity.
Production Spares and Accessories
Picture Product Code MM # UPC MOQ Description

AXX25DRVADPTR 904083
00735858211567 10 2.5'' Hard Disk Drive Carrier Kit, include ten 2.5”
drive carriers and installation guide.
The 2.5” HDD carrier is for installing 2.5” SAS,
SATA, or SSD into 3.5” hot-swap hard disk drive
bay. Requires hot-swap backplane assembly
cage kit)
Ship with 10 carriers in single package.
See compatible Intel® chassis and systems at:
http://www.intel.com/support/motherboards/serv
er/sb/CS-030726.htm
AXX6DRV3GEXP 877235
00735858180283 1 6-drive hot-swap, expander SATA/SAS
backplane assembly cage kit for Intel®Server
Chassis SC5600/SC5650. Requires 2 SAS
ports from SAS personality module or RAID
card and is compatible with SAS or SATA 3.5”
hard drives. Includes: backplane board, 6 drive
carriers, 2 Data cables, 6-drive bay, IPMB cable,
common installation guide, SATA/SAS
configuration label.
AXX4DRV3GEXP 877236 00735858180290 1 4-drive hot-swap expander, SATA/SAS
backplane assembly cage kit for Intel®Server
Chassis SC5650 family. Requires 2 SAS ports
from SAS personality module or RAID card and
is compatible with SAS or SATA 3.5” hard
drives. Includes: Backplane board, 4 drive
carriers, 2 data cables, 4-drive bay, IPMB cable,
common installation guide, SATA/SAS
configuration label.
Not supported in SC5600BASE, SC5650DP,
SC5650BRP, or SC5650WS
AXX6DRV3GR 900405 00735858207638 1 6-drive hot-swap non-expanded SATA/SAS
backplane assembly cage kit for Intel®Server
Chassis SC5600 / SC5650 family. Requires 6
SAS ports from RAID card for SAS (or SATA)
3.5” hard drive support or 6 SATA ports from
baseboard or RAID card for SATA 3.5” hard
drive support. Includes: Backplane board, 6
drive carriers, 6 data cables, 6-drive bay, IPMB
cable, SES cable and SGPIO cable, common
installation guide, SATA/SAS configuration
label.

1
5
Picture Product Code MM # UPC MOQ Description
AXX4DRV3GR 900404 00735858207645 1 4-drive hot-swap non-expanded, SATA/SAS
backplane assembly cage kit for Intel®Server
Chassis SC5600 family. Requires 4 SAS ports
from RAID card for SAS (or SATA) 3.5” hard
drive support or 4 SATA ports from baseboard
or RAID card for SATA 3.5” hard drive support.
Includes: Backplane board, 4 drive carriers, 4
data cables, 4-drive bay, IPMB cable, SES
cable and SGPIO cable, common installation
guide, SATA/SAS configuration label.
Not supported with Intel®Server Chassis
SC5600BASE, SC5650DP, SC5650BRP, or
SC5650WS
FXXRGTHSINK 901335 00735858206273 2 Special tower heat sinks required for Intel
®
Server Chassis SC5600LX, Ship with 2 heat
sinks in single package
FXXRGTHS 904992 00735858212809 2 Special tower heat sinks required for Intel®
Server Chassis SC5600LX. Each heat sink is
individually packaged and labeled.
AXXRMM3 900961 00735858206570 1 Intel
®
Remote Management Module 3 for Intel
®
Server Board S5520HC, S5500HCV, and Intel®
workstation board S5520SC.
ARIGRACK 88545
9 00735858164603 1 Pedestal to rack conversion kit for Intel
®
Server
Chassis SC5600. Includes: hinge cover; rack
handles, intrusion switch jumper, new rail kit
assembly, rack hardware kit, icon label,
installation guide
AXXCMA3U7U 862119 00735858168533 1 Universal 3U though 7U Rack Mode Cable
Management Arm (CMA). Requires
ARIGRACK.
APPTHSDBKIT 901181 00735858207676 1 Hot-swap drive mounting Kit for Intel
®
Server
Chassis SC5650, Includes 1 cooling fan, 1 fan
holder and 2 Hot-swap cage brackets.
Note: This mounting kit is required when using
6-bay Hot-swap Hard Disk Cage in SC5650
Chassis. This kit should be used with
AXX6DRV3GR.

1
6
Picture Product Code MM # UPC MOQ Description
APP3HSDBKIT 882456 00735858177450 1 Hot-swap drive mounting Kit for Intel
®
Server
Chassis SC5650, Includes 1 cooling fan, 1 fan
holder and 2 Hot-swap cage brackets.
Note: This mounting kit is required when using
6-bay Hot-swap Hard Disk Cage in SC5650
Chassis. This kit should be used with
AXX6DRV3GEXP.
APP3RACKIT 882457 00735858177375 1 Rack conversion kit for Intel
®
Server Chassis
SC5650 family. Includes rack rails and
hardware for rack installation
APPT600WHPSU 900984 00735858207324 1 2nd Redundant 600W PSU for Intel
®
Server
Chassis SC5650BRP to enable full, hot-swap
power redundancy or use as spare
FXXSCVDCBL 901767 00735858207768 10 Internal video cable to external VGA port for
Intel Workstation Board S5520SC,
AXXLCPPED 879579
00735858167956 1 Intel® Local Control Panel (LCD) for SC5600
and SC5650 pedestal chassis. Fits in unused
5.25” peripheral bay.
AXX4FIXDB 857882 00735858164702 1 Cabled 4 drive tool-less drive bay assembly for
Intel®Server Chassis SC5600. Includes
hardware to mount 4 additional non-hot swap
drives (for total of up to 10).
AXXFHDDBRK 868171 00735858172462 1 Bracket accessory for Intel
®
Server Chassis
SC5600 family to install a 3.5” HDD (cabled) or
a 3.5” USB floppy in a standard 5.25” drive bay.
Remove the bracket bezel for 3.5” HDD
installation.
ARIGDLTRAIL 856600 00735858164610 1 DLT Accessory Kit for Intel
®
Server Chassis
SC5600 family -- left and right rails (10 Pack)
Permits mounting a full height 5.25” peripheral
(e.g. DLT tape drive) in two half height bays.
ARIGBEZPNL 860750 00735858168489 10 Intel
®
Server Chassis SC5600 bezel branding
panels- (1) upper and (1) lower bezel
customization panel.

1
7
Picture Product Code MM # UPC MOQ Description
AXXRJ45DB92 881944 00735858155212 1
Contains two serial cable converter dongles
(RJ45 to DB9) one for DSD and one for DCD
(modem). The kit also includes one serial ribbon
cable for cabling 2nd serial port from the
baseboard.
Note: Not use the serial ribbon cable with the
Intel®Server Chassis SC5600/SC5650
AXXTIO 901685 00735858207683 50 I/O Shield for Intel
®
Server Boards S5520HC,
S5500HCV, S5500BC, BB5500BC, BB5520HC,
and BB5500HCV.
ASCIO 901686 00735858207690 50 I/O Shield for Intel
®
Workstation Board
S5520SC and BB5520SC.
FRIGTPDB 901540 00735858207355 1 Spare Intel
®
Server Chassis SC5600BRP and
LX Redundant Power Supply Power Distribution
Board
FRIGTHSFANKIT 901657 00735858207652 1 Spare Intel
®
Server Chassis SC5600 hot swap
fan kit : Include 1 hot-swap 92mm fan and 1 hot-
swap 120 mm fan
FRIGTFIXFANS 901513 00735858207706 1 Spare fixed 4-wire fan kit for Intel
®
Server
Chassis SC5600BASE and SC5600BRP.
Includes 1 front Fan (120mm), 1 rear chassis
fan (120mm, blue header), and 1 front PCI zone
fan (92mm).
FXXRIGT670WPSU 901656 00735858207348 1 Spare 670W power supply for Intel
®
Server
Chassis SC5600BASE
APP3STDBEZEL 871862 00735858177474 1 Spare bezel with door for Intel
®
Server Chassis
SC5650 family.
FXXPPT600WPSU 901184 00735858207317 1 Spare 600W PSU for Intel
®
Server Chassis
SC5650DP
FPPTBRPCAGE 901183 00735858207331 1 Spare Intel
®
Server Chassis SC5650BRP
redundant power supply cage. Includes power
distribution board and filler (for empty module
when only 1 module installed).
Also used to upgrade Intel®Server Chassis
SC5650DP or SC5650WS to redundant power
configuration. Requires 1 (or 2)
APPT600WHPSU and the hot-swap

1
8
Picture Product Code MM # UPC MOQ Description
redundant power supply supporting kit
(provided by FPPTPMKIT) to complete
upgrade.
See SC5650 chassis Service Guide for
upgrade instruction.
FPPTFANKIT4W 901182 00735858207713 1 Spare 4-wire fan kit for Intel
®
Server Chassis
SC5650 family. Includes 1 front PCI zone Fan
(120mm), 1 rear chassis fan (120mm, blue
header), and 1 HDD cage fan (92mm).
FXXPPTFPBRD 901360 00735858207737 1 Spare front panel board for Intel
®
Server
Chassis SC5650
FXXIPMBCBL 878135 00735858180085 10 Spare IPMB cables
FXXSESCBL 877945 00735858180092 10 Spare SES cables
FXXSGPIOCBL 877944 00735858180108 10 Spare SGPIO cables
FXX4DRV3GRBRD 901336 00735858206389 1 Spare board for AXX4DRV3GR (4 drive
backplane without an expander).
FXX4DRV3GEXPBRD 879633 00735858180931 1 Spare board for AXX4DRV3GEXP (4 drive
backplane with an expander).
FXX6DRV3GRBRD 901337 00735858206396 1 Spare board for AXX6DRV3GR (6 drive
backplane without an expander).
FXX6DRV3GEXPBRD 879632 00735858180948 1 Spare board for AXX6DRV3GEXP (6 drive
backplane with an expander).

1
9
Picture Product Code MM # UPC MOQ Description
FXX10DVCARBLK 880265 00735858181938 10 Spare hot swap drive carrier with black baffle.
FPWRCABLENA 879287 00735858180740 1 Spare North America Power cable for Intel
®
Server Chassis SC5600, SC5650 family
FXX1000WHEPS 904977 00735858213226 1 Spare 1000W PSU for Intel
®
Server Chassis
SC5650WS
AXX750WPS 901681 00735858207294 1 Spare 750W power supply module for Server
Chassis SC5600LX and SC5600BRP
FXXRIGTFPBRD 901441 00735858208055 1 Spare front panel board for Intel
®
Server
Chassis SC5600
AXXLCPPED 879579
00735858167956 1 Intel® Local Control Panel (LCD) for SC5600
and SC5650 pedestal chassis. Fits in unused
5.25” peripheral bay.
N/A
FRIGTPMKIT 901658 00735858207669 1 Chassis Preventative Maintenance kit for Intel
®
Server Chassis SC5600 family. Includes 1 Front
Panel USB Cable; 1 Serial Cable; 1 Front
92mm Fixed Fan Holder with screws; 1 Front
120mm Fixed Fan Holder with screws; 1 Rear
120mm Fixed Fan Holder with screws; 4 Hot
Swap Fan Wires , 1 Bezel Intrusion Switch, 2
sets / 4 pcs 5.25” tool-less bay rails, 2 sets / 4
pieces of fixed hard drive bay rails, 4 chassis
feet, 1 Air Duct for Intel®Server
SC5600BASE/BRP, 1 Air Duct for Intel®Server
Chassis SC5600LX
N/A
FPPTPMKIT 901659 00735858207720 1 Chassis Preventative Maintenance Kit for Intel
®
Server Chassis SC5650 family. Includes 2 Hard
Drive Bay Lockers with Screws and Spring, 1
Air Duct, (1) Intrusion Switch Assembly, 1 USB
Cable, 1 Rear 120mm Fixed Fan Holder with
Screws, 1 Fan Holder with Screws for 92mm
fan, 1 Full-length PCI Card Guide, 4 Rivets for
front 120mm Fixed Fan, 1 Adapter Plate with
Screws for Fixed Power Supply, 1 Fixed Power
supply tool-less locker, 4 Chassis Feet, 1 Fixed
HDD Fan Plate, 1 Supporting kit for upgrading

2
0
Picture Product Code MM # UPC MOQ Description
to redundant power supply on SC5650DP/WS
MOQ = Minimum Order Quantity.
Production RAID Accessories (not including BBU)
Picture Product Code MM # UPC MOQ Description
AXX4SASMOD 900946 00735858206372 1 Intel
®
SAS Entry RAID Module AXX4SASMOD
provides 4 port pass through SAS, entry-level
RAID 0/1/1E, and optional host RAID 5.:
Includes 1 AXX4SASMOD module card; 3 snap
standoffs, 4 SAS/SATA cables, Configuration
Label and Quick Installation Guide
AXXROMBSASMR 901641 00735858208017 1 Intel
®
Integrated RAID Module ROMBSASMR
provides 4 ports full featured SAS/SATA RAID
0, 1, 5, 6 and striping capability for spans 10, 50,
60. 128 MB cache. Up to 16 SAS/SATA HDDs
with expander enclosures. No PCI-E slot used.
Optional backup battery AXXRSBBU3 should
be ordered separately.
AXXRSBBU3
900954 00735858181853 1 Intel® RAID Smart Battery AXXRSBBU3, optional battery
back up for use with AXXROMBSASMR, AXXRAK18E
and SRCSAS144E. RoHS Complaint.
AXXRAKSW5 878958 00735858181860 5 Intel
®
RAID Activation Key AXXRAKSW5 to
enable SAS and/or SATA Software RAID 5
MOQ = Minimum Order Quantity
Production RAID Controller
Picture Product Code MM # UPC MOQ Description
RS2BL080 903493 00735858210140 5 Intel® RAID Controller RS2BL080 (Big Laurel 8)
- 6Gb/s SAS, 3Gb/S SAS/SATA, x8 PCIe 2.0, 8
internal ports, 512MB embedded memory, MD2
Low Profile, half length form factor. Includes 2
internal cables, Quick Start Users Guide, and
CD ROM with technical documentation and
software.
