Intelix HD14S User manual

HD14S Installation Guide
Important notice:
• Do not attempt to disassemble or alter the extender housing. There are no user-serviceable parts inside
the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all source and
destination equipment must be powered o during installation.
• Do not connect the extender to a telecommunication outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through
(point-to-point).
• Allow proper ventilation to reduce the risk of thermal failure.

The Intelix HD14S is a 1x4 HDMI splitter with HDMI 2.0 and HDCP 2.2. The HD14S supports data rates
up to 18Gbps and resolutions of 4K2K@60Hz (4:2:0). The HD14S features EDID management which
provides multiple EDID options for various resolutions output and HDCP encryption between all
devices, ensuring the HDMI source reliably outputs the correct content for the display.
The Intelix HD14S includes input cable equalization and signal regeneration compensation, which
reduces the need for additional signal conditioning equipment by compensating for signal loss
when using long input cables or cascading multiple units.
Front Panel Connections
1. Status LEDs
• Power: Solid red when power is applied.
• Input: Solid blue when HDMI source is acve and connected.
• Output: Solid blue when connected to remote display.
Rear Panel Connections
1. Locking 12V DC power connector.
2. Four (4) HDMI output connecons.
3. One (1) HDMI input connecon.
4. Dip Switch for EDID managment.
5. RS232 port for rmware update.
Descripons Posion Descripons
0 Copy EDID from HDMI output 1 8 1920x1080@60Hz/ 3D, 5.1 Surround
Sound Audio
1 1080i, PCM 2 Channel Audio 9 1920x1080@60Hz/ 3D, 7.1 Audio
2 1080i, 5.1 Surround Sound Audio A 1280x1024 DVI
3 1080i, 7.1 Audio B 1920x1080 DVI
4 1080p, PCM 2 Channel Audio C 1920x1200 DVI
5 1080p, 5.1 Surround Sound Audio D 4K2K @ 30Hz, PCM 2 Channel Audio
6 1080p, 7.1 Audio E 4K2K @ 60Hz, PCM 2 Channel Audio
7 1920x1080@60Hz/ 3D, PCM 2
Channel Audio
F Copy EDID from HDMI output 2
EDID Presets:

Instructions
1. Verify all components included with the distribution amp are present before installation.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instructions.
3. Connect an HDMI cable between the source and HDMI input of the HD14S.
4. Connect an HDMI cable between the display(s) and the HDMI output(s) of the HD14S.
5. Connect the 12V DC power supply to the locking power connector.
6. Power on attached audio/video devices.
Troubleshooting Tips
Symptom Possible Soluons
• Distribution amplifier does
not power on
• Verify power outlet is active.
• Verify the power supply connector is secured to the rear
of the distribution amplifier.
• Distorted or no video output • Verify the video output resolution of the source is
compatible with the display.
• Test with another HDMI cable.
• Test with another HDMI source.
• Cannot hear HDMI input audio • If using a DisplayPort device with a DisplayPort to HDMI
adapter, verify source can pass audio via DisplayPort
connection.

rev 151030
11675 Ridgeline Drive
Colorado Springs, Colorado 80921
1-800-530-8998
[e-mail]
Technical Specicaons
I/O Connecons
HDMI Input One (1) HDMI Type A Receptacle
HDMI Outputs Four (4) HDMI Type A Receptacle (1 per output)
Supported Audio and Video
Maximum Data Rate 18 Gbps
HDTV Video Resolutions 480p, 576p, 720p, 1080i, 1080p, 4Kx2K @30Hz, 4Kx2K @60Hz (4:2:0)
VESA Video Resolutions Up to 1920x1200
Embedded Audio Compatibility Up to PCM 5 channel, Dolby Digital TrueHD, and DTS-HD Master
Audio
Maximum Passive HDMI Distance 5m (16 ft)
Compliance HDMI 2.0, HDCP 2.2
Maximum Pixel Clock 600MHz
Input DDC Signal 5V
Chassis and Environmental
Enclosure Painted Aluminum
Dimensions (W x H x D) 167 mm x 69 mm x 18 mm (6.57 in x 2.71 in x 0.70 in)
Shipping Weight 0.30 kg (0.66 lbs)
Operating Temperature 0° to +45° C (+32° to +113° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -20° to +70° C (+4° to +140° F)
Storage Humidity 10% to 90%, Non-condensing
Power, ESD, and Regulatory
Maximum Power Consumption 1080p: 2 W (max) / 4K: 2.5 W (max)
Power Supply Input Voltage 100-240v AC at 50/60 Hz at 0.35A
Power Supply Output Rating DC 12V 0.5A
ESD Protection 8kV
Device Regulatory CE, RoHS
Power Supply Regulatory CE, UL, FCC
Other
Warranty 2 years
Diagnostic Indicators Power LED, Input LED, Four (4) Output Status LEDs
Included Accessories Installation guide, power supply, mounting “L” brackets (2 ea),
mounting screws (2 ea), 3 pole RS232 connector.
Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment,
RF and electrical interference, and cable patches.
