INSTALLING THE ANTENNA
System Package
Antenna Unit
ACU (Antenna Control Unit)
Installation Kit
Planning the Installation
Selection of Antenna Installation Site
System Cables
Power Requirement
Tools Required for Installation
Antenna Installation
Unpacking the Wooden Crate
Remove Antenna Shipping Restraints
Antenna Dimensions
Antenna Mounting Templates
Preparing Antenna Supporting Pole
Mounting the Radome
Installing the System Cables
RF Cable Connections

11
INTRODUCTION
System Package
The Intellian t110/t130 consists of two major units, an antenna assembly unit and
an antenna control unit.
Antenna Unit
The antenna unit includes an antenna pedestal inside a radome assembly unit.
The pedestal consists of the satellite antenna's main dish and sub-reector mod-
ule with a LNB mounted on a stabilized pedestal. The radome protects the an-
tenna pedestal assembly unit from severe marine environments.
Figure 2. Antenna Unit

t110/t130 – Marine Satellite Television System
12
Antenna Control Unit (ACU)
The Antenna Control Unit (ACU) provides power to the antenna and controls
various settings of the antenna. Additionally, VFD (Vacuum Fluorescent
Display) allows for you to operate the ACU in the dark.
Figure 3. Antenna Control Unit
The functions of the ACU are as follows :
• System startup
• Change of target satellite
• Monitoring current status
• Setting antenna manual search
• Setting antenna set skew
• Setting antenna go position
• Setting antenna search parameter
• Setting antenna set parameters
• Executing antenna diagnosis
• Setting the satellite pair
• Edit satellite information
• Setting the region
• Finding transponders
• Setting the local LNB
• Setting the GPS
• Setting the remote control
• System backup & restore
• Display versions
• Installation settings

13
INSTALLING THE ANTENNA
Installation Kit
Contains the items required for securing the antenna unit and ACU to your
vessel.
Figure 4. Installation Kit Components
ACU Q’ty Description Size Remark
5Self-Tapping
Screw ø 4 x 16 Table Mount Bracket
10 Flat Head Screw M3 x 8L Rack Mount
Bracket ACU
5Sems Bolt M3 x 12L Table Mount
Bracket ACU
Antenna Q’ty Description Size Remark
5Hex. Bolt M12 x 80L
Antenna-Deck
5Flat Washer M12
5Spring Washer M12
10 Hex. Nut M12

t110/t130 – Marine Satellite Television System
14
Item Image Q’ty Description Size Remark
1
2
ACU
Bracket
Rack - ACU-19inch Rack
2 Table - ACU-Table
2 1 RG6 Cable 30m Antenna to ACU
3 1 RG6 Cable 15m Antenna to IRD
4 1 AC Power Cord
(CEE7/7) 1.5m ACU Power
5 1 PC Serial Cable 1.8m ACU to PC
Other Components
6 1 USB Cable
(A-A / M-M) 1.8m ACU to PC
7 1 Synchro
Connector AK950-5 ACU (Synchro)
8 1 Step by Step
Connector AK950-4 ACU (Step-by-step)
9 1 NMEA Out
Connector AK950-3 ACU (NMEA Out)
10 2
Gyro NMEA
/GPS NMEA
in Connector
AK950-2
ACU
(Gyro NMEA/GPS NMEA
in Connector)-
11 2 Rubber Gland RG6 RG6 Cable-Antenna

15
INSTALLING THE ANTENNA
Item Image Q’ty Description Size Remark
12 5 Hex Socket
Head Cap M6 x 40L Radome (Top-to-Bottom)
13 5 Dome Washer M6 Radome (Top-to-Bottom)
14 1 Install CD - -
15 1 User Manual - -
16 1 Mounting
Template - -
Figure 5. Components Box Parts List

t110/t130 – Marine Satellite Television System
16
Tools Required for Installation
Power Drill
Cross Head Screwdriver
Flat Head Screwdriver
11 mm Spanner
19 mm Spanner
13 mm Spanner
13 mm Drill Bit 5 mm Allen/Hex key
Figure 6. Tool Sets for Installation

17
INSTALLING THE ANTENNA
15°
Planning the Installation
Antenna Unit Obstacle
Figure 7. Elevation Limit of Obstacle
Selection of Antenna Installation Site
Install the antenna in accordance with the following procedures to ensure maximum
performance of the antenna. The ideal antenna site should have a clear view of
the horizon or satellite all around it. Please be sure there are no obstacles within
15º above the center of the antenna. Any obstacles can prevent the antenna from
transmitting and receiving the satellite signal.
Do not install the antenna near the radar especially on the same plane as its energy
levels may overload the antenna's front-end circuits. It is recommended to position
the antenna at least 4 feet (1.2 m) above or below the level of the radar and a
minimum of 15 feet (4.6 m) away from any high power short wave radars.
The mounting platform should be rigid enough and not subjected to excessive
vibration. The movement of the antenna can be minimized by installing at the center
of the vessel. If these conditions can be only partially satised, choose the best
installation site between various considerations that can satisfy the mentioned
conditions.

t110/t130 – Marine Satellite Television System
18
System Cables
Before installing the system cables, you need to take the following points into
consideration.
• All cables need to be well clamped and protected from physical damage and
exposure to heat and humidity.
• A cable with an acute bend is not allowed.
• Wherever a cable passes through an exposed bulkhead or deck head, a
watertight gland or swan neck tube should be used.
RF Cables (Customer Supplied)
Due to voltage losses that occur across the length of the RF coax on L-Band,
Intellian recommends the following 75 ohm coax cable types for standard system
installations. For cables that run longer than 100 meters, please consult Intellian
Technologies.
Run Length Coaxial Cable Type
Up to 35 meters RG-6 or LMR-300-75
Up to 60 meters RG-11 or LMR-400-75
Up to 100 meters LMR-600-75
Power Requirements
Intellian t110/t130 has been designed to work on a vessel’s power supply rated at
110-220 V AC.
Type Multi-conductor, Shielded
Number of wires 2 conductors for NMEA
5 conductors for Synchro
Gyro Compass / GPS Interface Cable (Customer Furnished)
Figure 8. Recommended RF Cables
Figure 9. Recommended Gyro/GPS Cables

19
INSTALLING THE ANTENNA
Antenna Installation
Unpacking the Wooden Crate of t110/t130
The antenna pedestal is shipped completely assembled in its radome. Remove the
four shipping bolts which mount the antenna to the pallet. The pallet should be
lifted by means of a suitable sized lifting equipment.
Figure 10. Unpacking the Wooden Crate

t110/t130 – Marine Satellite Television System
20
Antenna Dimensions
The method of installation and mounting of the antenna may vary with vessel
design but the following procedures are applicable in most situations, and will
result in a secure and effective installation. Conrm the height and diameter of the
antenna before installing it.
Antenna Mounting Templates
Figure 11. Radome Dimension of t110 Figure 12. Radome Dimension of t130
Figure 13. Mounting Pattern of t110 Figure 14. Mounting Pattern of t130
ø54cm (21.3")
ø54cm (21.3")
ø48cm (18.9")
ø48cm (18.9")
24.75cm (9.74")
142cm(56")
168.9cm(66.5") 24.75cm (9.74")
24.75cm (9.74")
133cm(52.4") 165.2cm(65")
24.75cm (9.74")

21
INSTALLING THE ANTENNA
Preparing Antenna Supporting Pole
WARNING: Ensure that cables have been run through watertight ttings to prevent
water entry into the vessel when installation is completed.
Figure 15. Recommended Dimension of Mounting Pole (Unit: cm/inch)
Min. 120 cm (47”)
Base panel
Min. 1cm(0.4”)
Max. 3cm(1.2”)
Support Pedestal
Appr. Ø25.4 cm (10”)

t110/t130 – Marine Satellite Television System
22
Mounting the Radome
Bolt the Radome base directly to the support pedestal. Makesure to use the
Intellian supplied bolts from the accessory box when you mount the radome.
Figure 16. Mounting Components Diagram

23
INSTALLING THE ANTENNA
Warning: : Please ensure that your Intellian system is ALWAYS powered ON upon
leaving the dock. Failure to follow these instructions could result in damaging
mechanical parts in the antenna and/or possibly void your warranty. Intellian strongly
recommends to restrain the antenna pedestal properly while underway when power
is removed from the antenna. The normal operating condition for the t110/t130 is to
remain powered up at all times.
Remove Antenna Shipping Restraints
Open the radome's hatch and remove the shipping restraints from the pedestal.
Using your hand, gently check that the antenna moves freely in azimuth, elevation,
and cross level without hitting any areas of the interior of the radome.
Figure 17. Open the Radome Hatch
Figure 18. Remove Shipping Restraints (Ratchet strap, 2 Brackets that x the Azimuth Axis.)

t110/t130 – Marine Satellite Television System
24
Figure 19. Cable Entry
Figure 20. Cable Entry Diagram
Installing the System Cables
The coax cables must be inserted through the cable strain relief(s) at the base of
the radome. The cables must be routed from the antenna through the deck and
through various ship spaces to the antenna control unit. When pulling the cables
in place, avoid sharp bends, kinking, and the use of excessive force. After place-
ment, seal the deck penetration glad and tie the cables securely in place.

25
INSTALLING THE ANTENNA
RF Cable Connections
Before installing the RF cable, ensure that the RF cable labeled with RF1 has to be
connected properly between the antenna control unit and the power switch box.
Connect the four RF cables to the RF connectors using an 11mm spanner. Ensure
that the power switch is off during the installation period. When all the hardware
and cables have been installed, turn on the power switch. Use an RG11 rubber
gland if you’re using an RF11 cable instead of an RG6 cable supplied by Intellian.
Figure 21. Cable Connection on Power Switch Box
