Intellian T240CK User manual

Global Leader in Marine Satellite Antenna Systems
t240CK
Installation and Operation User Guide

Serial number of the product
This serial number will be required for the all troubleshooting or service inquiries.
© 2017 Intellian Technologies, Inc. All rights reserved. Intellian and the Intellian
logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and other
countries. The t-Series and the t240CK are trademarks of Intellian Technologies,
Inc. Intellian may have patents, patent applications, trademarks, copyrights,
or other intellectual property rights covering subject matter in this document.
Except as expressly provided in any written license agreement from Intellian,
the furnishing of this document does not give you any license to these patents,
trademarks, copyrights, or other intellectual property.
All other logos, trademarks, and registered trademarks are the property of their
respective owners. Information in this document is subject to change without
notice.
Every effort has been made to ensure that the information in this manual is
accurate. Intellian is not responsible for printing or clerical errors.
Doc. No. UM-W0-170327-V2.3

INDEX

5
INDEX
INTRODUCTION 7
Intellian t240CK Introduction 8
Intellian t240CK Features 9
Basic System Congurations 11
INSTALLING THE ANTENNA 15
System Package 16
Planning the Installation 19
Installation Recommendation 24
Antenna Installation 25
INSTALLING THE ACU 59
Mounting the ACU 60
Ship Gyro Connection 62
PC to ACU Communication Setup 64
Wi-Fi Connection 66
OPERATING THE ACU 69
Introduction 70
Normal Mode 72
Setup Mode 76
Installation Settings 77
Antenna Settings 79
Satellite Settings 89
System Settings 96
Aptus®101
Introduction of Aptus®102
Software Installation 103
PC to ACU Communication Setup 104
Toolbar Menus 107
System Property Status Dashboard 113
Work View Tabs 115
Aptus WEB 131
Introduction 132
Main page 133
Antenna Settings 137
Firmware & Conguration 143
Administration 149
TECHNICAL SPECIFICATION 159
WARRANTY 160

t240CK – Marine Satellite TV Antenna System
6
Doc Number IT14-DC0410-03
Intellian Technologies, Inc.
EMEA & APAC Headquarters
348-5 Chungho-Ri, Jinwi-Myeon
Pyeongtaek-Si, Gyeonggi-Do, 451-862 Korea
Tel: + 82 31 379 1000
Intellian Technologies USA, Inc.
US Headquarters
9004 Research Drive
Irvine, CA 92618 USA
Tel: [phone]
CE & FCC Declaration of Conformity (DoC)
We, Intellian Technologies, Inc. located at 2F Dongik Bldg., 98 Nonhyun-dong, Kangnam-gu, Seoul 135-080, Korea
declare under our sole responsibility that the product(s) described in the below to which this declaration relates is in
conformity with the requirements of the EU EMC Directive 89/336/EEC and FCC 47 CFR Part 15 Subpart B when the
methods, as described in EN 60945: 2002, ANSI 63.4: 2003 and EN 60950-1:2006+A11:2009+A1:2010+A12:2011,
respectively.
Product Information:
Product Name(s):
Intellian t240CK 2.4m C-band and Ku-band Maritime TVRO Antenna System
Model Number(s):
T3-246AC
Supplementary Information:
Notified Body Involved:
(Testing Organization)
SK Tech Co., Ltd.
820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, 473-905, Korea
Technical/Compliance
File Held by:
Intellian Technologies, Inc.
348-5 Chungho-Ri, Jinwi-Myeon, Pyeongtaek-Si, Gyeonggi-Do, 451-862 Korea
Authority: Kevin Eom Signature: __ __ ___________
/ CTO, R&D
Date: 10
th
April, 2014

7
INTRODUCTION
INTRODUCTION

t240CK – Marine Satellite TV Antenna System
8
Intellian t240CK Introduction
Intellian t240CK is the latest addition to Intellian’s line of satellite TV antenna
systems. With a 2.4m (97”) reector, the t240CK is a C-band and Ku-band
solution designed for large vessels such as cruise ships, super yachts and
commercial vessels that travel to remote areas.
The t240CK is capable of receiving both C-band and Ku-band satellite TV signals
simultaneously and is compatible with HD and SD satellite TV service reception
around the global. In addition, the t240CK incorporates Intellian’s multi-band
and multi-polarization WorldView™ LNB that allows users to seamlessly tune
in any satellite TV service by simply pushing of a button without manually
changing the LNB inside the antenna dome each time a vessel crosses into a
different satellite service region.
The t240CK is easy to operate, and simple to upgrade and manage. Each unit
comes preloaded with a ready-to-use, client-customized global satellite library
that can be conveniently updated via Intellian’s Aptus PC interface software
included with the unit. To further simplify operation, rmware updates can be
done entirely through the Wi-Fi interface of the ACU.
Robust and versatile, the t240CK marks a new era of Global TV entertainment
for large vessels that require truly global coverage. For more information about
the t240CK, contact Intellian Today.

9
INTRODUCTION
Intellian t240CK features
Simultaneous C-band and Ku-band TV Reception
The t240CK is designed to receive both C- and Ku-band satellite signal
simultaneously. With multiple RF outputs from the below deck multi-switch,
both C- and Ku-band receivers can be connected, simplifying installation and
providing seamless operation.
Hands-Free WorldView™ LNB
The t240CK incorporates Intellian’s patent pending WorldView LNB which receives
multi-band and multi-polarization satellite TV services around the globe. This
eliminates the need to climb into the radome to change the LNB each time when
traveling to a different satellite service region.
Gyro-Free Satellite Search Capability
Intellian’s new generation Gyro-free satellite search function enables the t240CK
to acquire and track the satellite without requiring a separate input from the ship’s
gyro-compass.
Easy Installation, Setup and Operation
With the t240CK, installation and setup are easier than ever. Once a satellite’s
signal peak position is acquired during the rst-time setup, the antenna system
will re-adjust all the parameters (bow adjust, home sensor offset, azimuth and
elevation position) automatically even after it reboots to save a tremendous
amount of time and effort for the operators.
Remote Management Solution
The t240CK can be accessed, monitored and controlled from any location in
the world by accessing the ACU’s built-in web based Monitoring and Control
software. Additionally, routine maintenance activities can be automated. These
functions include rmware upgrades, tracking parameters logging performance
data, and system diagnosis.
Dedicated Management Ethernet Port
The ACU of the t240CK provides a convenient Management Ethernet Port on the
front panel. The Management Port supports DHCP network connection by default
allowing quick network access without additional PC IP conguration.
Wireless Connectivity and Intellian App
The built-in Wi-Fi enables the ACU to be wirelessly connected and can be either
turned on and off by a switch. Any kind of wireless devices such as PCs, laptops
and smartphones can be used to connect to the ACU and monitor, control
and change the settings of the system wirelessly. The D-Sub Connector on the
antenna can be connected to a Serial to Bluetooth converter (optional) enabling
the user to monitor the antenna inside the Radome using a PC with Bluetooth
connectivity. An Intellian App is available for download to access to the ACU via
Wi-Fi and operate
the antenna from their iPhone, iPad or other network devices.
iPhone and iPad are registered trademarks of Apple Inc.

t240CK – Marine Satellite TV Antenna System
10
Intellian Network Devices
Intellian Aptus Web enables connection to the t240CK to monitor the real
time status of the connected system. This function provides users with direct
connection to network devices allowing an integrated control solution for linking
multiple devices.

11
INTRODUCTION
Basic System Congurations
For your satellite TV system to work properly, the system will have to be connected
with all of the provided components properly as shown in the gure below (Refer to
next chapter ‘Installation’ in this manual for more detailed connection instructions).
C Band Receiver
C Band Receiver
Ku Band Receiver
Ku Band Receiver
13V, 0Hz
AC100 ~ 240V
AC100 ~ 240V
ACU
Antenna
RF 2
RF 1
RF 3
RF 4
18V, 0Hz
18V, 22Hz
13V, 22Hz
Multi Switch
C-ver C-Hor
Ku-VH
Ku-HH
VL HL VH HH
C Band Receiver
C Band Receiver
C Band Receiver
C Band Receiver
AC100 ~ 240V
AC100 ~ 240V
ACU
Antenna
C-ver C-Hor
RF 2
RF 1
Multi Switch
VL HL VH HH
Dual C-band Linear only Conguration
For C-band Linear Polarized satellite signal reception, a multi-switch is required to be
connected between the antenna and C-band receivers. This conguration allows to receive
C-band Linear Polarized only.
Dual C-band & Ku-band Universal Quad High Conguration
This conguration allows to receive simultaneous C-band and Ku-band Universal High signal.
For C-band and Ku-band Universal High signal receptions, a multi-switch is required to be
connected between the antenna and C-band and Ku-band receivers. A 22kHz tone will be
generated from Ku-band Receiver to receive Ku-band high-band signal.

t240CK – Marine Satellite TV Antenna System
12
Dual C-band & Ku-band Arbitrary Signal (Any Pol / Local) Conguration
For C-band and Ku-band Linear with any programmed LO satellite signal receptions, a multi-
switch is required to be connected between the antenna and C-band and Ku-band receivers.
In addition, a 22kHz tone which can be generated from Ku-band receiver or a Tone generator
is required to send to the multi-switch.
Ku-band Universal Quad Conguration
For simultaneous Ku-band Linear Polarized Low & High satellite signal receptions, a multi-
switch is required to be connected between the antenna and Ku-band receivers.
C Band Receiver
C Band Receiver
Ku Band Receiver
Ku Band Receiver
AC100 ~ 240V
AC100 ~ 240V
ACU
Antenna
RF 2
RF 1
RF 3
RF 4
Multi Switch
C-ver C-Hor
Ku-Ver/RHCP
Ku-Hor/LHCP
VL HL VH HH
TG
: 22kHz tone generator
TG
TG
Ku Band Receiver
Ku Band Receiver
Ku Band Receiver
Ku Band Receiver
AC100 ~ 240V
AC100 ~ 240V
ACU
Antenna
RF 2
RF 1
RF 3
RF 4
Multi Switch
Ku-V/L Ku-H/L
Ku-V/H
Ku-H/H
VL HL VH HH

13
INTRODUCTION
Ku-band Arbitrary Signal (Any Pol / Local) Conguration
For simultaneous Ku-band Linear & Circular with any programmed LO except Universal Quad
satellite signal receptions, a multi-switch is required to be connected between the antenna
and Ku-band receivers.
Ku Band Receiver
Ku Band Receiver
Ku Band Receiver
Ku Band Receiver
AC100 ~ 240V
AC100 ~ 240V
ACU
Antenna
RF 2
RF 1
Multi Switch
Ku-Ver/RHCP Ku-Hor/LHCP
VL HL VH HH

t240CK – Marine Satellite TV Antenna System
14

15
INTRODUCTION
INSTALLING THE ANTENNA
System Package
Antenna Unit
ACU (Antenna Control Unit)
Installation Kit
Planning the Installation
Selection of Antenna Installation Site
System Cable Installation Guide
RF Cables
Power Requirements
Installation and Mounting of Antenna
Conrmation of Size Prior to installation
Installation Recommendation
Antenna Installation

t240CK – Marine Satellite TV Antenna System
16
System Package
Antenna Unit
The antenna unit includes an antenna pedestal inside a radome assembly unit.
The pedestal consists of the satellite antenna's main dish and sub-reector module
with a WorldView™ Ku-band LNB and two C-band LNBs mounted on a stabilized
pedestal. The radome protects the antenna pedestal assembly unit from severe
marine environments.

17
INSTALLING THE ANTENNA
ACU (Antenna Control Unit)
The digital VFD (Vacuum Fluorescent Display) and touch keypad panel
allows for easy operation of the ACU, even in the dark.
ACU Front
ACU Back
The functions of the ACU are as follows:
• System startup
• Setting the satellite
• Editing satellite information
• Setting the antenna parameter
• Setting the antenna manual search
• Setting the LNB local frequency
• Setting GPS and Gyrocompass
• Display versions
• Display power status
• Performing real-time diagnostic tests
• Backup and restore the system settings
• Set up the interface with a PC
• Recording antenna activities and upgrading rmware through USB

t240CK – Marine Satellite TV Antenna System
18
Installation Kit
Installation Kit includes three boxes (ACU box, Cable box, and Bolt box). Each box
contains the items required for securing the antenna unit and ACU to the vessel.
ACU Box Cable Box Bolt Box
Antenna Control Unit
(ACU)
ACU to Receiver
Coaxial Cable_3m:1EA Hex Bolt M16x35L :4EA
USB Cable_
A-A Type:1EA
Antenna to ACU Coaxial
Cable_30m:2EA
(Optional)
M16 Spring Washer
& Flat Washer: 4EA
D-sub Connector set_
Spin Male:1EA PC Cable:1EA Hex Bolt M12x65:9EA
N(Male) to F(Female)
Adapter:1EA
M12 Spring Washer
:9EA
USB Flash Drive:1EA AC Power Cord(CEE 7/7):1EA M12 Flat Washer &
Nut:17EA
User Manual:1EA AC Power Cord(USA)
:1EA
Hex Bolt M6x35L
:300EA
Wi-Fi Antenna:1EA M6 Spring Washer
& Nut:300EA
ACU Side Bracket:2EA M6 Flat Washer (Ø18)
:600EA
ACU Rack Bracket:2EA Hex Bolt M12x65:9EA
Self-Tapping M4x16L
:5EA
M12 Spring Washer
:9EA
Sems Bolt M3x12:5EA M12 Flat Washer
& Nut:17EA
Flat Head Screw M4x12L:10EA Silicone:4EA
Aptus CD Silicone Gun:1EA
Radome Top Lift Bracket:4EA
Stable Mount Jig:1EA

19
INSTALLING THE ANTENNA
Planning the Installation
Selection of Antenna Installation Site
The installation of t240CK requires extreme precaution and safety measures given
its size and weight. Failure to follow the correct installation process may lead to
injury to the installer and/or cause damage to the system.
In order to maximize the performance of the system, a thorough review of this
installation guide is strongly recommended, as well as executing the installation
process as it is noted on this manual.
The system should be placed where there would be no blockage that would interfere
the signals. A safe mounting place should be selected for given its heavy weight
and size.
System Cable Installation Guide
Before installing the system cables, you need to take the following points into
consideration.
• All cables need to be well clamped and protected from physical damage
and exposure to heat and humidity.
• Remember to observe the minimum bend radius of the selected cable.
• Where a cable passes through an exposed bulkhead or deck-head,
a watertight gland or swan neck tube should be used.
RF Cables (Customer Supplied)
Due to voltage losses that occur across the length of the RF coax on L-Band,
Intellian recommends the following 75 ohm coax cable types for standard system
installations. For cables that run longer than 100 meters, Intellian recommends
Fiber Optic Cables with Fiber Optic Converters.
Power Requirements
You need to follow the power requirements to avoid damage the system.
Intellian t240CK is designed to work on a power supply between 100 ~ 240V AC.
Cable Type Signal Loss
(dB/100M)
Attenuation/M Recommended
Cable Length
LMR-300-75 30.3 0.303 40 Meters
LMR-400-75 19.6 0.196 60 Meters
LMR-500-75 15.9 0.159 80 Meters
LMR-600-75 12.8 0.128 100 Meters

t240CK – Marine Satellite TV Antenna System
20
Installation and mounting of antenna
The method of installation and mounting of antenna may vary with vessel design but
the following procedures are applicable in most situations, and will result in a secure
and effective installation.
Conrmation of size prior to installation
• Conrm the height and diameter of the bottom surface of the antenna before
installing it.
• The space must be sufcient for installing the antenna unit considering the height
and diameter of the antenna.
• The height and the diameter of the bottom surface of the antenna are as shown
in the following drawing. It is strongly suggested that the installation is conducted
using a crane.
4097mm
3522mm
575mm
3300mm
1868mm
