Intelligent Home Thor User manual

Video Door Entry System
user manual
CALL
UNLOCK
TALK/MON
IN-USE
www.intelligenthomeonline.com
Thor

PRECAUTIONS
●Read this manual through before using the product.
●Slots or openings in the back of the monitor, are provided for ventilation
and to ensure reliable operation of the video monitor or equipment and
to protect if from overheating. These openings must not be blocked or
covered. The monitor should never be placed near or over a radiator or
heat register and should not be placed in a built-in installation such as a
bookcase unless proper ventilation is provided.
●All parts should be protected from violence vibration. And not allow be
impacting, knocking and dropping.
●For clean the LCD screen, using hands or wet cloth is forbidden.
●Please do the cleanness with soft cotton cloth, please do not use the
organic or chemical clean impregnate. If necessary, please use pure
water or dilute soap water to clean the dust.
●Image distortion may occur if the video door phone is mounted too close
to magnetic eld e. g. Microwaves, TV, computer etc.
●Please keep away the video door monitor from wet, high temperature,
dust, and caustic and oxidation gas in order to avoid any unpredictable
damage.
●Do NOT open the device in any condition, call the administrator for help
if there is any problem or mulfunction happens.

CONTENT
1. Monitor Parts and Functions ------------------------1
2. Monitor Mounting --------------------------------1
3. System Connection- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2
4. Multiple Monitors Connection(optional) -----------------3
5. Multiple Door Cameras Connection(optional) ------------4
6. Talk/Unlock Operation -----------------------------5
7. Entrance Monitoring ------------------------------5
8. Ring Tone Setting --------------------------------6
9. Ring Volum Setting -------------------------------6
10. Intercom -------------------------------------7
11. Unlock Setting ---------------------------------7
12. Monitor Time Setting -----------------------------8
13. Screen Setting ---------------------------------8
14. Restore to Default-------------------------------8
15. Built-in Memory and SD Card ----------------------9
16. Connection Other Device to Monitor -----------------12
17. Specications---------------------------------13

-1-
1. Monitor Parts and Functions
2. Monitor Mounting
CALL
UNLOCK
TALK/MON
IN-USE
LCD Touch Screen
LED indicator
UNLOCK button
CALL button
TALK/MON button
Speaker
DIP switch
BUS port
Ventilation Vent
Extending port
Microphone
1 2 3 4 5 6
ON
DIPS
145~160 cm
1. Use the screws to x the Mounting Bracket on the wall.(tting accesories includes a Bracket )
2. Wire the system correctly(see the later connection chapter) then hang the Monitor on the
Mounting Bracket rmly.

-2-
3. System Connection
●Note 1: Mount the DPS and PS5 side by side on the DIN nail or on the wall.
●Note 2: See Door Camera manual for detail information.
●Note 3: Connect the DPS to the output of PS5, non-polarity connection.
●Note 4: The bit-1 to bit-5 DIP switches are for Monitor address settings when multiple Monitors
installed, the bit-6 is for video impedance setting. When there is only one Monitor installed, set all the
bit-1 to bit-5 to OFF state, and set the bit-6 to ON position.
●Note 5: Conncet to the AC Mains electricity, 100~240 V AC.
●Note 6: Non-polarity 2 wire bus cable. See Table 3-1 for cable usage information.
Cable type Max. distance(meters)
RVV 2 * 1.5 mm2150 (Non-shielded, Twisted)
RVV 2 * 1.0 mm2100 (Non-shielded, Twisted)
RVV 2 * 0.75 mm275 (Non-shielded, Twisted)
Table 3-1
Note 6
Note 4
Camera Monitor
Note 2
Note 5
Note 3
Note 1
-
+
L1 L2 PL S1+ S2+ S-
AC~
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
DPS
PS5
UNLOCK
INTERCOM
MON/TALK
IN-USE

-3-
4. Multiple Monitors Connection(optional)
●Note 1: Set to [8000] on the Installation settings page for Master unit(by default).
●Note 2: Set to [8001] on the Installation settings page for Slave unit 1.
●Note 3: Set to [8002] on the Installation settings page for Slave unit 2.
●Note 4: Set to [8003] on the Installation settings page for Slave unit 3.
●Note 5: The bit-1 to bit-5 of all the Monitors are set to OFF. The bit-6 set to OFF for 1#, 2# and 3#
Monitors.
●Note 6: All the connectors must use In-Out connection.
●Note 7: The bit-6 of the 4# Monitor must set to ON state.(the bit-6 of all the Monitors should be set to
OFF state except the last one which is at the end of the bus line).
How to set the Slave Address:
Get into the Installation settings page(see
11.Unlock setting). On the 2# Monitor, input [8001]
and press to confirm; on the 3# Monitor,
input [8002] and press to conrm; on the 4#
Monitor, input [8003] and press to conrm.
Note 1
Note 6
Note 2 Note 3 Note 4
Note 5 Note 7
L1 L2 PL S1+ S2+ S-
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1# Monitor 2# Monitor 3# Monitor 4# Monitor
DPS
PS5
UNLOCK
INTERCOM
MON/TALK
IN-USE
UNLOCK
INTERCOM
MON/TALK
IN-USE
UNLOCK
INTERCOM
MON/TALK
IN-USE
UNLOCK
INTERCOM
MON/TALK
IN-USE
Camera
Code Number:[----]
[0010]#:Remove all remote control
[0011]#:Add remote control
[8000]#:Set as master unit 0
[8001]#:Set as slaver unit 1
[8002]#:Set as slaver unit 2
[8003]#:Set as slaver unit 3
[8004]#:Set as guard unit
[8005]#:Set as not guard unit
[8010]#:Set lock mode to 0
[8011]#:Set lock mode to 1
[8021]#:Set the lock time of 1s
[8022]#:Set the lock time of 2s
[8023]#:Set the lock time of 3s
[8024]#:Set the lock time of 4s
[8025]#:Set the lock time of 5s
[8026]#:Set the lock time of 6s
[8027]#:Set the lock time of 7s
[8028]#:Set the lock time of 8s
[8029]#:Set the lock time of 9s
1
4
78
0
9
6
5
23
Cancel
Installation settings:

-4-
5. Multiple Door Cameras Connection(optional)
●Note 1: The settings for all the Monitors are the same as chapter 4 Multiple Monitors
connection.
●Note 2: The DBC-4 unit is not included and should be bought separately.
Note 1
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
1 2 3 4 5 6
ON
DIPS
SW+
SW-
RING
GND
VIDEO
UNLOCK
INTERCOM
MON/TALK
IN-USE
UNLOCK
INTERCOM
MON/TALK
IN-USE
UNLOCK
INTERCOM
MON/TALK
IN-USE
UNLOCK
INTERCOM
MON/TALK
IN-USE
Note 2
L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S-L1 L2 PL S1+ S2+ S-L1 L2 PL S1+ S2+ S-
AC~
1# Camera2# Camera3# Camera4# Camera
DPS
PS5
A B C D
BUS
DBC4

-5-
6. Talk/Unlock Operation
7. Entrance Monitoring
2. Press TALK/MON Button or icon, you can talk with the visitor for 90 seconds. During
talking state, press the TALK/MON Button again or press icon to end the conversation. If
nobody answers the phone, the screen will be turned off automatically after 30 seconds. If the
system connects two or more Monitors, when any Monitor starts to talk, the other Monitors will
be automatically shut off.
3. During the conversation, press UNLOCK Button or icon to unlock the door.
4. During the conversation, press icon to record the current picture. If the Auto-Record
function has been turned on (see chapter 12), a picture will be recorded automatically 3 seconds
after the Call Button of the Camera pressed.
1. When visitor presses the Call Button on the Outdoor Station, the Monitor(s) will ring, at the same
time, the screen displays the visitor image.
Name B
Name A
CALL
UNLOCK
TALK/MON
IN-USE
Home
Unlock
Talk
Standard
Screen
Capture
1:1
Press TALK/MON button on monitor in standby
mode,or touch Monitor icon on home
screen.the screen will display the view of the
Outdoor Station. During monitoring, touch
Manual Monitor icon to get into the camera
switching mode, (or directly touch Manual
Monitor icon on home screen), if multi Door
Stations are installed, you can press the camera
1/2/3/4 to monitor the Door Station or CCTV
camera you want.press Home icon to exit
and enter home screen page.
CALL
UNLOCK
TALK/MON
IN-USE
Camera 1 Camera 2 Camera 3 Camera 4
2 3 41
09/30/2010 Thu.16:41
Home
Monitor
Time

-6-
8. Ring Tone Setting 9. Ring Volum Setting
12 pieces ring tone can be selected. When
the Monitor is in standy, press anywhere
on the screen, a full screen calendar will be
showed.
You can set a ring volume for day time,6:00
AM~18:00 PM is the day time by default.
Touch the scteen tiwce to enter home
screen page, then touch User Setup
icon to enter next page,and then touch
Ring Volume icon to enter Ring Volume
page,Touch / icon to decrease/
increase the volume.and then touch
icon to save and exit,or touch icon to
unsave and exit.
You can active a ring volume for night
time,18:00 PM~6:00 AM is the night time by
default,if you don't want to be disturbed at
night ,you can set the volume to 0. Touch
the scteen tiwce to enter home screen page,
touch User Setup icon to enter next
page, then touch Night Ring Volume
icon to enter Night Ring Volume page,Use
/ icon to decrease/increase the
volume.After setting a value you want, you
should touch Ring Volume icon to
active the setting, after that the Ring Volume
icon will change to Night Ring Volume icon.
then touch icon to save and exit.
Touch the screen again to enter the main
menu. then touch User Setup icon to
enter call tone setting screen,touch Door
station call tone/intercom call tone/door
bell call tone,12 pieces ring tones will be
displayed ,you can choose a ring tone which
you want,and then touch icon to save
and exit,or touch icon to unsave and
exit.
1. Current date.
2. Current weekday.
3. Current time.
CALL
UNLOCK
TALK/MON
IN-USE
09/30/2010
16:41
Thu.
CALL
UNLOCK
TALK/MON
IN-USE
Door Station
Call Tone
Exit&Save
Carman
Ding Dong
Rhythm of the rain
For Elise
Sonatine
Edelweiss
Going Home
Congratulate
Do Re Me
Happy Birthday
Jingle Bell
Telephone Ring
Exit&Unsave
CALL
UNLOCK
TALK/MON
IN-USE
Ring Volume
6
7
Adjust - Adjust +
Exit&Save
Exit&Unsave
CALL
UNLOCK
TALK/MON
IN-USE
Night Ring
Volume Night Ring
Volume
4
7
Adjust - Adjust +
Exit&Save
Exit&Unsave

-7-
10. Intercom
11. Unlock Setting
When multiple monitors are installed,
intercom function is available. Intercom can
be initiated by either Monitor. Press the
CALL Button, then touch the Inner Call
icon the other Monitor will ring. Press TALK
Button on the other Monitor to answer.
When the Monitor is in standby, press the
screen to open the time screen, press
again to enter the main menu. then touch
icon on the bottom left to enter
Information page:
On the Information page, press the screen
on hold for 2 seconds to enter the page
below:
The default setting for the Unlock mode
is mode 0; and default Unlock time is 1
second. The Unlock mode and Unlock
time settings is according to the e-lock you
used, see Door Camera manual for detail
information.
To change the unlock mode, input [8010] or
[8011], then touce to conrm; to change
Unlock time, input[8021]~[8029] for 1 to
9 second Unlock time and touce to
conrm.
use to cancel the input; use to save
the setting. Touch icon to return last
page.
Touch the Installer setup icon to enter
the installation settings page:
To end the intercom conversation, press
TALK. If no one answers, it will exit
automatically after 30 seconds.
The doorbell function will always override
the intercom function.
Note: the Intercom by Namelist and Direct
Call Guard Unit function is reserved.
CALL
UNLOCK
TALK/MON
IN-USE
Intercom
by Namelist
Inner CallD irect Call
Guard Unit
09/30/2010 Thu.16:41
Home
CALL
UNLOCK
TALK/MON
IN-USE
H/W --- a1.3
S/W: V11.01008.00
Voltage: ---
Local addr: 01.00
Unlock timing: 5s
Video standard: PAL
Cancel
CALL
UNLOCK
TALK/MON
IN-USE
Home
Installer
setup
Device
Property
Caliber
TouchScreen
CALL
UNLOCK
TALK/MON
IN-USE
Code Number:[----]
[0010]#:Remove all remote control
[0011]#:Add remote control
[8000]#:Set as master unit 0
[8001]#:Set as slaver unit 1
[8002]#:Set as slaver unit 2
[8003]#:Set as slaver unit 3
[8004]#:Set as guard unit
[8005]#:Set as not guard unit
[8010]#:Set lock mode to 0
[8011]#:Set lock mode to 1
[8021]#:Set the lock time of 1s
[8022]#:Set the lock time of 2s
[8023]#:Set the lock time of 3s
[8024]#:Set the lock time of 4s
[8025]#:Set the lock time of 5s
[8026]#:Set the lock time of 6s
[8027]#:Set the lock time of 7s
[8028]#:Set the lock time of 8s
[8029]#:Set the lock time of 9s
1
4
78
0
9
6
5
23
Cancel
Installation settings:
