intensity VRF V5 Series User manual

VRF V5X | HIGH EFFICIENCY
MAN-S-VRFV5XZ-0420
intensity.mx
SERVICE MANUAL
MV5-X252W/V2ZN1, MV5-X280W/V2ZN1,
MV5-X335W/V2ZN1, MV5-X400W/V2ZN1, MV5-X450W/V2ZN1,
MV5-X500W/V2ZN1, MV5-X560W/V2ZN1, MV5-X615W/V2ZN1.

V5 X VRF 460V 60Hz
1
CONTENTS
Part 1 General Information............................................................................ 3
Part 2 Component Layout and Refrigerant Circuits ................................... 11
Part 3 Control ............................................................................................... 21
Part 4 Field Settings..................................................................................... 35
Part 5 Diagnosis and Troubleshooting......................................................... 41

V5 X VRF 460V 60Hz
2

V5 X VRF 460V 60Hz
3
Part 1 - General Information
Part 1
General Information
1 Indoor and Outdoor Unit Capacities........................................................ 4
2 External Appearance............................................................................... 6
3 Outdoor Unit Combinations.................................................................... 8
4 Combination Ratio .................................................................................. 9

V5 X VRF 460V 60Hz
4
1Indoor and Outdoor Unit Capacities
1.1 Indoor Units
1.1.1 Standard indoor units
Table 1-1.1: Standard indoor unit abbreviation codes
Abbreviation
code
Type
Abbreviation
code
Type
Q1
One-way Cassette
T1
High Static Pressure Duct
Q2
Two-way Cassette
G
Wall-mounted
Q4C
Compact Four-way Cassette
DL
Ceiling & Floor
Q4
Four-way Cassette
F
Floor Standing
T2
Medium Static Pressure Duct
Z
Console
Table 1-1.2: Standard indoor unit capacity range
Capacity
Capacity
index
Q1
Q2
Q4C
Q4
T2
T1
G
DL
F
Z
kW
kBtu/h
HP
1.8
5
0.6
18
18
—
—
—
—
—
—
—
—
—
2.2
7
0.8
22
22
22
22
—
22
—
22
—
22
22
2.8
9
1
28
28
28
28
28
28
—
28
—
28
28
3.6
12
1.25
36
36
36
36
36
36
—
36
36
36
36
4.5
15
1.6
45
45
45
45
45
45
—
45
45
45
45
5.6
19
2
56
56
56
—
56
56
—
56
56
56
—
7.1
24
2.5
71
71
71
—
71
71
71
71
71
71
—
8.0
27
3
80
—
—
—
80
80
80
80
80
80
—
9.0
30
3.2
90
—
—
—
90
90
90
90
90
—
—
10.0
34
3.6
100
—
—
—
100
—
—
—
—
—
—
11.2
38
4
112
—
—
—
112
112
112
—
112
—
—
14.0
48
5
140
—
—
—
140
140
140
—
140
—
—
16.0
55
6
160
—
—
—
—
—
160
—
160
—
—
20.0
68
7
200
—
—
—
—
—
200
—
—
—
—
25.0
85
9
250
—
—
—
—
—
250
—
—
—
—
28.0
96
10
280
—
—
—
—
—
280
—
—
—
—
40.0
136
14
400
—
—
—
—
—
400
—
—
—
—
45.0
154
16
450
—
—
—
—
—
450
—
—
—
—
56.0
191
20
560
—
—
—
—
—
560
—
—
—
—
1.1.2 Fresh air processing unit
Table 1-1.3: Fresh air processing unit capacity range
Capacity
kW
12.5
14
20
25
28
kBtu/h
42
48
68
85
96
Capacity index
125
140
200
250
280
1.2 Heat recovery ventilator
Table 1-1.4: Heat recovery ventilator capacity range
Capacity
m3/h
200
300
400
500
800
1000
1500
2000
CFM
120
180
240
300
470
590
880
1180
INTENSITY V5 X Series Service Manual

V5 X VRF 460V 60Hz
5
Part 1 - General Information
1.3 Outdoor Units
Table 1-1.5: Outdoor unit capacity range
Capacity
8HP
10HP
12HP
14HP
16HP
18HP
20HP
22HP
Model
(MV5-*/V2ZN1)
X252W
X280W
X335W
X400W
X450W
X500W
X560W
X615W
Capacity
24HP
26HP
28HP
30HP
32HP
34HP
36HP
38HP
Model
(MV5-*/V2ZN1)
X670W
X730W
X780W
X840W
X895W
X950W
X1000W
X1065W
Outdoor unit 1
12HP
10HP
10HP
10HP
10HP
12HP
18HP
16HP
Outdoor unit 2
12HP
16HP
18HP
20HP
22HP
22HP
18HP
22HP
Capacity
40HP
42HP
44HP
46HP
48HP
50HP
52HP
54HP
Model
(MV5-*/V2ZN1)
X1115W
X1175W
X1230W
X1285W
X1345W
X1395W
X1455W
X1510W
Outdoor unit 1
18HP
20HP
22HP
12HP
10HP
10HP
10HP
10HP
Outdoor unit 2
22HP
22HP
22HP
12HP
16HP
18HP
20HP
22HP
Outdoor unit 3
—
—
—
22HP
22HP
22HP
22HP
22HP
Capacity
56HP
58HP
60HP
62HP
64HP
66HP
68HP
70HP
Model
(MV5-*/V2ZN1)
X1565W
X1615W
X1680W
X1730W
X1790W
X1845W
X1900W
X1960W
Outdoor unit 1
12HP
18HP
16HP
18HP
20HP
22HP
12HP
10HP
Outdoor unit 2
22HP
18HP
22HP
22HP
22HP
22HP
12HP
16HP
Outdoor unit 3
22HP
22HP
22HP
22HP
22HP
22HP
22HP
22HP
Outdoor unit 4
—
—
—
—
—
—
22HP
22HP
Capacity
72HP
74HP
76HP
78HP
80HP
82HP
84HP
86HP
Model
(MV5-*/V2ZN1)
X2010W
X2070W
X2125W
X2180W
X2230W
X2295W
X2345W
X2405W
Outdoor unit 1
10HP
10HP
10HP
12HP
18HP
16HP
18HP
20HP
Outdoor unit 2
18HP
20HP
22HP
22HP
18HP
22HP
22HP
22HP
Outdoor unit 3
22HP
22HP
22HP
22HP
22HP
22HP
22HP
22HP
Outdoor unit 4
22HP
22HP
22HP
22HP
22HP
22HP
22HP
22HP
Capacity
88HP
Notes:
1. The full model names can be obtained by substituting the asterisk in the model name format given in the
left-hand column of the table above with the shortened model names given in the table. For example, the
model name for the 40HP model is MV5-X1115W/V2ZN1.
2. The combinations of units shown in the table are factory-recommended. Other combinations of units are
also possible.
Model
(MV5-*/V2ZN1)
X2460W
Outdoor unit 1
22HP
Outdoor unit 2
22HP
Outdoor unit 3
22HP
Outdoor unit 4
22HP

V5 X VRF 460V 60Hz
6
