Interlogix AL1191 User manual

P/N 1040736• REV E • OCT12
Smart Card Reader AL1191, AL-1193
Installation Instructions
Introduction
This is the SmartCard ReaderInstallationInstructionsfor
models AL-1191andAL-1193.The smartcardreaderis a
multifunction,all-purposeproximitycard readersuitableforall
locations (includingoutdoors)thatrequirea short-range
reader.You can connectthe readerdirectly to the Alliance
system RS485databus.
You canconfigurethe readerthroughthe control panelmenu
when it is connectedto the system databus,throughthe DGP
menuwhen it is connectedto the localdatabus,oryou can use
a configurationcard.Refer to the Smart CardReader
ProgrammingManualformore information.
The AL-1191 modelis shippedwithawhiteremovable cover
(there arefive other colors available).
Reader components
Figure 1 belowshows thereadercomponents.
Figure 1:Reader components
Blue LED. Dooropen, disarmed.
Red LED. Dooropen,armed
Comms. LED control, buzzer control, power.
Installation
You shouldprogramthereaderandchangethe default
address (16)before you install thereader.Refer to the Smart
Card ReaderProgramming Manual for programming details.
You can mountthe readeron any flat surfacewithtwo #6 (3 to
3.5 mm diameter)panheadscrews(Figure1).We do not
recommendusing countersunkscrews.
You willexperience a slightlyreduced rangeif you mountthe
readeron a metalsurface.Ifyou mountthe AL-1191 reader
outdoors,ensurethatthe blueLED is at the top.
To mountthe reader,do the following:
1. Gently pry the AL-1191 cover sides awayfrom the main
readerbodyto removecover and exposethe mounting
screws.Do not useexcessive force or the readercanbe
irreparablydamaged.
2. Mount the readerusing themountingscrews.
3. Gently press thecover over the mainbodyof the AL-1191
readeruntilit locks intoplace.
Wiring
Table 1 belowdescribes thereaderwiring components.
Table 1:Wiring components
Wire color
Name
Description
Red
Positiv e 9 to 14 VDC supply.
Black
O V
DC supply ground.
Green
D-/D0/Data
RS485 Data -, Wiegand Data 0 Absolute
maximum, 12 Vat 10 mA
White
D+/D1/Clock
RS485 Data +, Wiegand Data 1 Absolute
maximum, 12 Vat 10 mA
AL-1191
Cover
Blue LED
Red LED
Comms
AL-1193
Blue LED
Red LED
Comms

2 Smart Card ReaderAL1191,AL-1193Installation Instructions
Brown
LED 1
Off line LED control conf igured to two-wire
control will control the red LED only.
Wire grounded: red LED on
Wire open: red LED off
Wire at +5 to +12 V: red LED off
Off line LED Control conf igured to one-wire
control will control both the red and blue LEDs
Wire grounded: blue LED on
Wire open circuit: both LEDs of f.
Wire at +5 V to +12 V: red LED on.
Absolute maximum, 14 V
Yellow
LED 2
Configurable to control the blue LED when
offline.
Wire grounded: blue LED on.
Wire open: blue LED off.
Wire at +5V to +12V: blue LED off.
Request-to-exit input when online to Alliance.
This input may be connected to a push button
connected to ground with RTE only selected on
the option card or in Menu 10. Refer to the
Smart Card Reader Programming Manual.
Blue
Buzzer
Off line buzzer control.
Wire open or +5V to +12V: buzzer off.
Wire grounded: buzzer sounding.
Absolute maximum, 14 V.
Violet
Open
collector
Configurable as: door relay, tamper output,
credit controlled pulse, timed, or latched output.
Absolute maximum, 14 V at 25 mA
This is alow current output and must not be
used to directly energize high current door
openers.
470 ohm
resistor
Used to terminate RS485 bus when the reader
is the last device on the bus.
Install across D+ (white) and D- (green).
System bus connections
Figure 2 belowshows howtoconnect the readerto a RAS on
the Alliance system bus.
Figure 2:System Bus connections
Wiegand block connections
Figure 3 belowshows howtoconnect the readerto the
Wiegand connection blockon a 4-Door/Elevator Controller
DGP.
Figure 3:Wiegand blockconnections
Local bus connections
Figure 4 on page3 shows howtoconnect the readerto a 4-
Door/Elevator ControllerDGPlocalbus with a request-to-exit
input.
AL-1191/AL-1193
Control
Panel
System bus
RAS
Green
White
Black
Red
J10
D-
D+
0V
+12V
D-
D+
0V
+12V
Green
White
Black
Red
Violet (open collector)
DGP
AL-1191/AL-1193
Violet
Red
Black
Green
White
Yellow
Brown
Blue
4K7
J8 to J12
1
C
2
C
3
C
J13 to J16
+12V
+5V
0V
D0
D1
L2
L1
BZ

Smart Card Reader AL1191,AL-1193 Installation Instructions 3
Figure 4:LocalBus connections
Tamper
The readerhas a tamperfeature. Whenthe readeris
connectedto the system databus,tamperdatais transmittedto
the Alliancesystem withsystem data. You can configure a
tampercontrolfor both onlineandoffline operation using an
external open collectoroutput (violet wire)
Specifications
Current consumption
Standby
Active
25 mA
80 mA maximum
Input voltage
9 to 14 VDC
Operating temperature
32 to 120°F (0 to 49°C)
Humidity
85%noncondensing
Regulatory information
UL listings
UL 294Standard for AccessControlSystem
Units
UL 365Standard forPolice Station Connected
Burglar Alarm Units and Systems
UL 609Standard for LocalBurglar Alarm Units
and Systems
UL1610 Standard forCentralStation Burglar
AlarmUnits
UL 1635Standard for Digital Alarm
Communicator SystemUnits
FCC compliance
This devicecomplies withpart15of the FCC
rules.Operation is subjecttothe following
conditions:
1. This devicemay not causeharmful
interference.
2. This devicemust acceptany interference
received,includinginterferencethatmay cause
undesiredoperation.
Changes or modifications not expressly approved
by the party responsibleforcompliancecould
void the user’s authority to operate the
equipment.
This equipment hasbeen testedand foundto
comply withthelimits for aClass B digital device,
pursuanttoPart 15 of theFCC Rules. These
limits are designedto providereasonable
protectionagainstharmful interferenceina
residential installation. This equipment generates,
uses,andcanradiate radio frequency energy
and, if not installed and usedin accordancewith
the instructions,may cause harmfulinterference
to radio communication. However,thereisno
guaranteethat interference willnotoccur ina
particular installation.
If this equipment does causeharmfulinterference
to radio or televisionreception,w hichcan be
determined by turningthe equipment off andon,
the user is encouragedtotry to correctthe
interferenceby oneormore of the following
measures:
Reorient or relocatethereceivingantenna.
Increasethe separationbetweentheequipment
and receiver.
Connect the equipment into an outlet or a circuit
differentfromtheonew here thereceiver is
connected.
Consult the dealer oran experiencedratio-TV
technicianfor help.
FCC ID: CGGATS1190-1192.
Contact information
www.utcfireandsecurity.com orwww.interlogix.com
For customersupport,see www.interlogix.com/customer-
support
© 2012 UTC Fire & Security Americas Corporation,Inc.
Interlogixis part of UTC ClimateControls &Security, a unit of
United Technologies Corporation. Allrights reserved.
DGP
AL-1191/AL-1193
Violet
J8 to J12
1
C
2
C
3
C
J22
D-
D+
0V
+12V
BZ
4K7
Yellow
Red
Black
Green
White
Request-to-exit
