Intermatic CU-M001-SA / CU-M001-SB Home Settings HA22 User manual

Intermatic, Inc. Spring Grove, IL 60081-9698 www.intermatic.com
Thank you for purchasing Intermatic’s Home Settings devices. With the HomeSettings program, you
can reliably and remotely control lighting and appliances.
The outstanding features of the Home Settings HA02 Appliance Module includes:
• Feedback that will allow you to see whether your device has received the ON/OFF (you cannot
DIM with this module) signal.
• RF signal reliability – each HomeSettings product has a special feature that virtually
guarantees that RF signals are received
• Ease of installation
• Manual override
• Heavy-duty plug and receptacle
• Controls compact fluorescent lights up to 42 Watts
• Compatible with other Z-Wave™ enabled devices
The HA02 Appliance Module is a Z-Wave™ enabled device and is fully compatible with any Home
Settings network and any Z-Wave™ enabled network. Z-Wave™ enabled devices displaying the Z-
Wave™ logo can also be used with Home Settings modules and controllers regardless of the
manufacturer, and Home Settings modules and controllers can also be used in other manufacturer’s
Z-Wave™ enabled networks. Each module in a Home Settings network is designed to act as a
repeater. Repeaters will re-transmit the RF signal to ensure that the signal is received by its intended
destination by routing the signal around obstacles and radio dead spots.
INSTALLATION _
Enclosed you will find:
1 USB Z-Wave
TM
Stick
1 CD-rom containing a USB stick software driver
Instruction sheets
Customer response card
Install USB driver.
Plug USB stick into an available USB Type A Female port on your personal computer.
…Additional instructions to be inserted here…
PROGRAMMING _
See the instructions for HomeSettings ThinkEssentials by Intermatic.
FEDERAL COMMUNICATIONS COMMISSION STATEMENT_____________
This device complies with part 15 of the FCC rules. Operation of this device is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
For Indoor Use Only
MODEL HA22
USB Z-WaveTM Stick

Intermatic, Inc. Spring Grove, IL 60081-9698 www.intermatic.com 158HAXXXXX
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna or device.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
WARNING!
Changes or modifications not expressly approved by Intermatic Inc. could void the user’s authority to operate the equipment.
The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.
TECHNICAL INFORMATION Specificatios_
Plug: USB Type A Male
USB Power Input: ~4.40 to 5.25VDC
Range: >50 feet
Suitable for use in dry locations
Operating Temperature Range: 0°C to 40°C
Made in China.
_WARRANTY INFORMATION Specificios_
LIMITED 6-YEAR WARRANTY
If within six (6) years from the date of purchase, this product fails due to a defect in material or workmanship, Intermatic Incorporated will
repair or replace it, as its sole option, free of charge. This warranty is extended to the original household purchaser only and is not
transferable. This warranty does not apply to: (a) damage to units caused by accident, dropping or abuse in handling, acts of God or any
negligent use; (b) units which have been subject to unauthorized repair, opened, taken apart or otherwise modified; (c) units not used in
accordance with instructions; (d) damages exceeding the cost of the product; (e) sealed lamps and/or lamp bulbs, LED’s and batteries; (f)
the finish on any portion of the product, such as surface and/or weathering, as this is considered normal wear and tear; (g) transit damage,
initial installation costs, removal costs, or reinstallation costs.
INTERMATIC INCORPORATED WILL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS OR IMPLIED WARRANTIES. ALL
IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY AND THE WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY MODIFIED TO EXIST ONLY AS CONTAINED IN THIE LIMITED WARRANTY, AND SHALL BE
OF THE SAME DURATION AS THE WARRANTY PERIOD STATED ABOVE. SOME STATES DO NOT ALLOW LIMITATIONS ON THE
DURATIONS OF AN IMPLIED WARRANTY, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
This warranty service is available by either (a) returning the product to the dealer from whom the unit was purchased, or (b) mailing the
product, along with proof of purchase, postage prepaid to the authorized service center listed below. This warranty is made by: Intermatic
Incorporated/After Sales Service/7777 Winn Rd., Spring Grove, Illinois 60081-9698/815-675-7000 http://www.intermatic.com Please be
sure to wrap the product securely to avoid shipping damages.
