Intermec AV1 User manual

Using the Vehicle Cradle (continued)
CK30
Vehicle cradle
Mounting
arm
2 Push the retaining bracket toward the top of the CK30
until it clicks into place.
Retaining
bracket
3 Tighten the knob to secure the cradle position on the arm.
To remove the CK30 from the vehicle cradle
1 Pull the release for the retaining bracket.
Release
Retaining
bracket
2 Lower the retaining bracket.
3 Slide the CK30 out of the vehicle cradle.
Specifications
Width: 9.84 cm (3.875 in)
Length: 23.5 cm (9.25 in)
Height: 6.67 cm (2.625 in)
Weight: 793.79 g (28 oz)
Vibration: Exceeds MIL-STD-810F
6001 36th Avenue West
Everett, WA 98203
U.S.A.
www.intermec.com
© 2003 Intermec Technologies Corp.
All Rights Reserved
AV1 Vehicle Cradle Instructions
*073511-001*
P/N 073511-001
AV1 Vehicle Cradle Instructions
The AV1 vehicle cradle provides you with a convenient place
to secure the CK30 Handheld Computer on your vehicle.
The vehicle cradle also provides the CK30 with additional
vibration and shock protection from your vehicle.
Note: The CK30 has either a standard case or a
wide case, depending on the type of internal scanner
that is installed. You can only use the vehicle cradle
for a CK30 with a standard case.
These instructions describe how to install and use the vehicle
cradle. Before using the vehicle cradle, please read these
instructions and keep them for future use.
Instructions
Mounting
hardware
Mounting assembly
AV1 Vehicle Cradle
Shipping Box Contents

Installing the Vehicle Cradle
To install the vehicle cradle, you need these tools and
materials (not included):
• Common hand tools
• Torque driver
• Appropriate mounting hardware for the mounting surface
• Electric drill and drill bits
Before installing the AV1 vehicle cradle, you should choose a
location for the cradle where the operator can easily see the
CK30 screen and use the keypad. If possible, install the
vehicle cradle in a location that prevents glare from overhead
lighting and sunlight.
To install the vehicle cradle
1 Remove the mounting
plates from the
mounting arm.
a Turn the knob on
the mounting arm
just until the plate at
the top of the arm is
released. Remove the
plate.
b Squeeze the top of
the mounting arm
and remove the plate
at the bottom of the
mounting arm.
a
b
Mounting
arm
Mounting
plate
at top
Mounting
plate
at bottom
Knob
2 Use the hardware included in the vehicle cradle kit to
attach one of the mounting plates to the back of the
vehicle cradle. Tighten the screws to 2.82 Nm (25 in-lb)
torque.
Mounting
plate
Nut
(4 places)
Washer
(4 places)
Screw
(4 places)
Back of
cradle
3 Using the second mounting plate as a template, mark and
drill at least four holes in the mounting surface.
Screw
(at least
4 places)
4 Attach the second mounting plate to the mounting surface
using appropriate hardware (up to a #10 screw, not
supplied) through each of the holes in the mounting plate
and the mounting surface.
5 Squeeze the top of the mounting arm and attach the
mounting arm to the mounting plate on the vehicle.
6 Attach the vehicle cradle to the mounting arm.
Mounting
arm
CK30 in
vehicle
cradle
7 Use the knob on the mounting arm to adjust the CK30 to
the best-possible viewing angle for the vehicle operator.
Periodically inspect the knob on the mounting arm to make
sure it is still tight. Check the vehicle cradle assembly for any
signs of fatigue, such as cracking, which may develop over
extended use in extreme (vibration) environments. Replace
any damaged hardware immediately to ensure continued, safe
operation.
Using the Vehicle Cradle
You can easily insert and remove the CK30 from the vehicle
cradle.
To insert the CK30 in the vehicle cradle
1 Position the CK30 as shown, and slide it into the vehicle
cradle. See the next illustration.
