Intermec Oracle-Ready CK31 User manual

Using the Vehicle Cradle (continued)
CK31
Vehicle cradle
Mounting arm
2Push the retaining bracket toward the top of the
CK31 until it clicks into place.
Retaining
bracket
3Tighten the knob to secure the cradle position on
the arm.
4Use the knob on the mounting arm to adjust the
CK31 to the best-possible viewing angle for the
vehicle operator.
To remove the CK31 from the vehicle cradle
1Pull the release for the retaining bracket.
Release
Retaining
bracket
2Lower the retaining bracket.
3Slide the CK31 out of the vehicle cradle.
Specifications
Width: 9.84 cm (3.875 in)
Length: 26.04 cm (10.25 in)
Height: 6.67 cm (2.625 in)
Vibration: Exceeds MIL-STD-810F
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel [phone]
fax [phone]
www.intermec.com
©2005 Intermec Technologies
Corporation. All rights reserved.
CK31 Vehicle Cradle Instructions
*075441-001*
P/N 075441-001
The CK31 vehicle cradle provides you with a
convenient place to secure the CK31 Handheld
Computer on your vehicle. The vehicle cradle also
provides the CK31 with additional vibration and
shock protection from your vehicle.
These instructions describe how to install and use the
vehicle cradle. Before using the vehicle cradle, please
read these instructions and keep them for future use.
Instructions
Mounting
hardware
Mounting assembly
CK31 vehicle cradle
Shipping Box Contents
CK31 Vehicle Cradle Instructions

Installing the Vehicle Cradle
To install the vehicle cradle, you need these tools and
materials (not included):
•Common hand tools
•Torque driver
•Appropriate mounting hardware for the mounting
surface
•Electric drill and drill bits
Before installing the vehicle cradle, you should
choose a location for the cradle where the operator
can easily see the CK31 screen and use the keypad. If
possible, install the vehicle cradle in a location that
prevents glare from overhead lighting and sunlight.
To install the vehicle cradle
1Remove the
mounting plates
from the
mounting arm.
aTurn the
knob on the
mounting
arm just until
the plate at
the top of the
arm is
released.
Remove the
plate.
a
b
Mounting
arm
Mounting
plate
at top
Mounting
plate
at bottom
Knob
bSqueeze the top of the mounting arm and
remove the plate at the bottom of the
mounting arm.
2Use the hardware included in the vehicle cradle kit
to attach one of the mounting plates to the back of
the vehicle cradle. Tighten the screws to 2.82 Nm
(25 in-lb) torque.
Mounting
plate
Nut
(4 places)
Washer
(4 places)
Screw
(4 places)
Back of
cradle
3Using the second mounting plate as a template,
mark and drill at least four holes in the mounting
surface on the vehicle.
Screw
(at least
4 places)
4Attach the second mounting plate to the
mounting surface on the vehicle using appropriate
hardware (up to a #10 screw, not supplied)
through each of the holes in the mounting plate
and the mounting surface.
5Squeeze the top of the mounting arm and attach
the mounting arm to the mounting plate on the
vehicle.
6Attach the vehicle cradle to the mounting arm.
Mounting
arm
CK31 in
vehicle
cradle
Periodically inspect the knob on the mounting arm
to make sure it is still tight. Check the vehicle cradle
assembly for any signs of fatigue, such as cracking,
which may develop over extended use in extreme
(vibration) environments. Replace any damaged
hardware immediately to ensure continued, safe
operation.
Using the Vehicle Cradle
You can easily insert and remove the CK31 from the
vehicle cradle.
To insert the CK31 in the vehicle cradle
1Position the CK31 as shown on the back of this
page.
