Intermec Oracle-Ready CK31 User manual

To remove the CK31 from the vehicle cradle
1Pull the release for the retaining bracket and lower the
retaining bracket.
Release
Retaining
bracket
2Slide the CK31 out of the vehicle cradle.
Using a Tethered Scanner with the Cradle
If you want to use a tethered scanner while you have the CK31
inserted into the vehicle cradle, you can remove the bottom
bracket.
To remove the bottom bracket
1Remove the two nuts that secure the bottom bracket to the
vehicle cradle.
Nut
(2 places)
Bottom
bracket
2Screw the two plastic caps onto the bolts that secured the
bottom bracket to the vehicle cradle.
Cap
(2 places)
3Insert the CK31 with the tethered scanner.
Specifications
Width: 9.84 cm (3.875 in)
Length: 26.04 cm (10.25 in)
Height: 6.67 cm (2.625 in)
Vibration: Exceeds MIL-STD-810F
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel [phone]
fax [phone]
www.intermec.com
©
2005 Intermec Technologies
Corporation. All rights reserved.
CK31 Vehicle Cradle Instructions
*075441-002*
P/N 075441-002
The CK31 vehicle cradle provides you with a convenient place
to secure the CK31 Handheld Computer on your vehicle. The
vehicle cradle also provides the CK31 with additional vibration
and shock protection from your vehicle. These instructions
describe how to install and use the vehicle cradle.
Instructions
Mounting
hardware
Mountin
g
assembl
y
CK31 vehicle cradle
Shipping Box Contents
Installing the Vehicle Cradle
To install the vehicle cradle, you need these tools and materials
(not included):
•Common hand tools
•Torque driver
•Appropriate mounting hardware for the mounting surface
•Electric drill and drill bits
Before installing the vehicle cradle, you should choose a location
for the cradle where the operator can easily see the CK31 screen
and use the keypad. If possible, install the vehicle cradle in a
location that prevents glare from overhead lighting and sunlight.
CK31 Vehicle Cradle Instructions

To install the vehicle cradle
1Remove the mounting
plates from the mounting
arm.
aTurn the knob on the
mounting arm just until
the plate at the top of
the arm is released.
Remove the plate.
bSqueeze the top of the
mounting arm and
remove the plate at the
bottom of the mounting
arm.
a
b
Mounting
arm
Mounting
plate
at top
Mounting
plate
at bottom
Knob
2Use the hardware included in the vehicle cradle kit to attach
one of the mounting plates to the back of the vehicle cradle.
Tighten the screws to 2.82 Nm (25 in-lb) torque.
Mounting
plate
Nut
(4 places)
Washer
(4 places)
Screw
(4 places)
Back of
cradle
3Using the second mounting plate as a template, mark and
drill at least four holes in the mounting surface on the
vehicle.
Screw
(at least
4 places)
4Attach the second mounting plate to the mounting surface
on the vehicle using appropriate hardware (up to a #10
screw, not supplied) through each of the holes in the
mounting plate and the mounting surface.
5Squeeze the top of the mounting arm and attach the
mounting arm to the mounting plate on the vehicle.
6Attach the vehicle cradle to the mounting arm.
Mounting
arm
CK31 in
vehicle
cradle
Periodically inspect the knob on the mounting arm to make
sure it is still tight. Check the vehicle cradle assembly for any
signs of fatigue, such as cracking, which may develop over
extended use in extreme (vibration) environments. Replace any
damaged hardware immediately to ensure continued, safe
operation.
Using the Vehicle Cradle
You can easily insert and remove the CK31 from the vehicle
cradle.
To insert the CK31 in the vehicle cradle
1Insert the CK31 into the vehicle cradle as shown next.
CK31
Vehicle cradle
Mounting arm
2Push the retaining bracket toward the top of the CK31 until
it clicks into place.
Retaining
bracket
3Tighten the knob to secure the cradle position on the arm.
4Use the knob on the mounting arm to adjust the CK31 to
the best-possible viewing angle for the vehicle operator.
