INSTALLATION MANUAL
FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state or
local requirements exist. In the event no such state or local requirement exists, the maintainer must be
a professional with sufficient experience in pool equipment installation and maintenance so that all of
the instructions in this manual can be followed exactly. Before installing this product, read and follow
all warning notices and instructions that accompany this product. Failure to follow warning notices
and instructions may result in property damage, personal injury, or death. Improper installation and/or
operation will void the warranty.
H0312200 Rev C
JandyPro Series
Underwater Pool and Spa White Lights

PAGE 3
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Section 1. Important Safety Information................4
Section 2. Product Description and Model
Numbers .................................................5
Section 3. Installing Jandy Pro Series Pro Series
Light Fixture during New
Construction...........................................6
3.1 Preparing the Light Fixture for Installation..........6
3.2 Installing the Light Fixture ..................................7
Section 4. Replacing Jandy Pro Series Light Fix-
ture in an Existing Pool or Spa.............7
4.1 Preparing the Light Fixture for Replacement......8
4.2 Replacing the Light Fixture ................................8
Section 5. Wiring Options for Controlling Jandy
Pro Series Pro Series Pool or Spa
White Lights ...........................................9
5.1 Wiring to an AquaLink®RS Control System........9
5.2 Wiring to a Time Clock........................................9
5.3 Wiring to a Switch...............................................9
Section 6. Operating Instructions ..........................9
6.1 To Operate the Light...........................................9
Table of Contents
Section 7. Replacing the Lamp.............................11
Section 8. Twelve (12) Volt Installation ................13
Section 9. Exploded View and Replacement
Parts......................................................14
9.1 Jandy Pro Series Pool White Light...................14
9.2 Jandy Pro Series Spa White Light....................15
Figures and Tables
Figure 1. Jandy Pro Series Pool White Light
Installation..................................................6
Figure 2. Jandy Pro Series Spa White Light
Installation..................................................6
Figure 3. 120-Volt Jandy Pro Series Pool and Spa
White Light Wiring Diagram .....................10
Figure 4. 12-Volt Jandy Pro Series Pool and Spa
White Light Wiring Diagram .....................10
Figure 5. Wiring the Jandy Pro Series Pool and Spa
White Light to a Time Clock.....................10
Figure 6. Wiring the Jandy Pro Series Pool and Spa
White Light to a Switch ............................10
Figure 7. Removing the Pool and Spa White Light
Assembly for Lamp Replacement............12
Figure 8. Alignment of the Lens, Face Ring,
Housing and Clamps for Pool
White Lights.............................................12
Figure 9. Jandy Pro Series Pool White Light
Exploded View .........................................14
Figure 10. Jandy Pro Series Pool White Light, Front
and Back View.........................................14
Figure 11. Cross Section of Jandy Pro Series Pool
White Light..............................................14
Figure 12. Jandy Pro Series Spa White Light
Exploded View .........................................15
Figure 13. Jandy Pro Series Spa White Light, Front
and Back View.........................................15
Figure 14. Cross Section of Jandy Pro Series Spa
White Light...............................................15
Table 1. Lamp Specifications.................................11

PAGE 4 ENGLISH Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Section 1. Important Safety Information
IMPORTANT SAFETY INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions should always be followed, including the
following:
ATTENTION INSTALLER: This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/operator of this
equipment.
SAVE THESE INSTRUCTIONS
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. This underwater light must be installed by a
licensed or certied electrician in accordance with the National Electrical Code® (NEC®) in the US, the Canadian
Electrical Code (CEC) in Canada, and applicable local codes and ordinances. Improper installation will create
an electrical hazard, which could result in death or serious injury to pool or spa users, installers, or others due to
electrical shock, and may also cause damage to property. Read and follow the specic instructions below.
WARNING
Before installing this underwater light, read and follow all warning notices and instructions accompanying this light.
Failure to follow safety warnings and instructions can result in severe injury, death, or property damage. Call (800)
822-7933 for additional free copies of these instructions.
WARNING
Except when the Jandy Pro Series Pool and Spa lights are installed in an area of the swimming pool that is not
used for swimming and the lens is adequately guarded to keep any person from contacting it, the light shall be
installed in or on a wall of the pool, with the top of the lens opening not less than 18 inches (457 mm) below the
normal water level of the pool
CAUTION

PAGE 5
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Section 2. Product Description and
Model Numbers
Jandy Pro Series
Model Number Jandy Pro Series White Light Size Voltage Maximum Watts Cord Length Face Ring Material
WPLV100WS30 Pool 12 Volt AC 100 30 feet Stainless Steel
WPLV100WS50 Pool 12 Volt AC 100 50 feet Stainless Steel
WPLV100WS100 Pool 12 Volt AC 100 100 feet Stainless Steel
WPLV100WS50C Pool (Canadian) 12 Volt AC 100 50 feet Stainless Steel
WPLV100WS100C Pool (Canadian) 12 Volt AC 100 100 feet Stainless Steel
WPLV300WS30 Pool 12 Volt AC 300 30 feet Stainless Steel
WPLV300WS50 Pool 12 Volt AC 300 50 feet Stainless Steel
WPLV300WS100 Pool 12 Volt AC 300 100 feet Stainless Steel
WPLV300WS50C Pool (Canadian) 12 Volt AC 300 50 feet Stainless Steel
WPLV300WS100C Pool (Canadian) 12 Volt AC 300 100 feet Stainless Steel
WPHV300WS30 Pool 120 Volt AC 300 30 feet Stainless Steel
WPHV300WS50 Pool 120 Volt AC 300 50 feet Stainless Steel
WPHV300WS100 Pool 120 Volt AC 300 100 feet Stainless Steel
WPHV300WS150 Pool 120 Volt AC 300 150 feet Stainless Steel
WPHV300WS250 Pool 120 Volt AC 300 250 feet Stainless Steel
WPHV300WS50C Pool (Canadian) 120 Volt AC 300 50 feet Stainless Steel
WPHV300WS100C Pool (Canadian) 120 Volt AC 300 100 feet Stainless Steel
WPHV500WS30 Pool 120 Volt AC 500 30 feet Stainless Steel
WPHV500WS50 Pool 120 Volt AC 500 50 feet Stainless Steel
WPHV500WS100 Pool 120 Volt AC 500 100 feet Stainless Steel
WPHV500WS150 Pool 120 Volt AC 500 150 feet Stainless Steel
WPHV500WS250 Pool 120 Volt AC 500 250 feet Stainless Steel
WPHV500WS50C Pool (Canadian) 120 Volt AC 500 50 feet Stainless Steel
WPHV500WS100C Pool (Canadian) 120 Volt AC 500 100 feet Stainless Steel
WPLV100WP100 Pool 12 Volt AC 100 100 feet Plastic
WPLV300WP100 Pool 12 Volt AC 300 100 feet Plastic
WPHV300WP100 Pool 120 Volt AC 300 100 feet Plastic
WPHV500WP100 Pool 120 Volt AC 500 100 feet Plastic
WSLV100WS30 Spa 12 Volt AC 100 30 feet Stainless Steel
WSLV100WS50 Spa 12 Volt AC 100 50 feet Stainless Steel
WSLV100WS100 Spa 12 Volt AC 100 100 feet Stainless Steel
WSLV100WS50C Spa (Canadian) 12 Volt AC 100 50 feet Stainless Steel
WSLV100WS100C Spa (Canadian) 12 Volt AC 100 100 feet Stainless Steel
WSHV100WS30 Spa 120 Volt AC 60 30 feet Stainless Steel
WSHV100WS50 Spa 120 Volt AC 60 50 feet Stainless Steel
WSHV100WS100 Spa 120 Volt AC 60 100 feet Stainless Steel
WSHV100WS150 Spa 120 Volt AC 60 150 feet Stainless Steel
WSHV100WS250 Spa 120 Volt AC 60 250 feet Stainless Steel
WSHV100WS50C Spa (Canadian) 120 Volt AC 60 50 feet Stainless Steel
WSHV100WS100C Spa (Canadian) 120 Volt AC 60 100 feet Stainless Steel
WSLV100WP100 Spa 12 Volt AC 100 100 feet Plastic
WSHV100WP100 Spa 120 Volt AC 60 100 feet Plastic

PAGE 6 ENGLISH Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Figure 2. Jandy Pro Series Spa White Light
Installation
4" min.
48"
min.
8" min. Junction Box or
Low Voltage Transformer.
18" min. to top of Lens.
6.0"
Concrete must be cut
back around Niche to
allow for a compacted
plaster seal.
Coil 4 ft. of light cable
around Fixture.
#8 AWG Ground
Connector bonded
to rebar.
Rigid
Conduit
To GFCI, Circuit
Breaker and
Power Source.
4. The wet niche must be properly installed so that
the top edge of the underwater light’s lens is at
least 18 inches below the surface of the water in
the pool or spa; see Figure 1 or 2.
5. The wet niche must be properly electrically
bonded and grounded via the No. 8 AWG ground
connector located at the rear of the niche; see
Figure 1 or 2.
NOTE The pool or spa electrical system can be
verified with a Pool and Spa Electrical
Qualification Test kit. The test kit is available
from local distribution. The electrical system
inspection using this kit must be performed by
trained and certified personnel.
To be certain that the pool or spa’s electrical
system meets all applicable requirements, the
electrician should also consult the local building
department.
Figure 1. Jandy Pro Series Pool White Light
Installation
4" min.
48"
min.
8" min. Junction Box or Low
Voltage Transformer, to the
max water level of the pool.
18" min. to top of Lens.
11.50"
Concrete must be cut
back around Niche to
allow for a compacted
plaster seal.
Coil 4 ft. of light cable
around Fixture.
Rigid
Conduit
To GFCI, Circuit
Breaker and
Power Source.
16”
#8 AWG Ground
Connector bonded
Section 3. Installing Jandy Pro Series
Pro Series Light Fixture
during New Construction
Risk of Electrical Shock or Electrocution.
This underwater light must be installed by a
licensed or certified electrician or a qualified pool
or spa serviceman in accordance with the National
Electrical Code® (NEC®) in the US, the Canadian
Electrical Code in Canada, and all applicable local
codes and ordinances. Improper installation will
create an electrical hazard, which could result
in death or serious injury to pool or spa users,
installers or others due to electrical shock, and may
also cause damage to property.
Always disconnect the power to the pool or spa
light at the circuit breaker before servicing the light.
Failure to do so could result in death or serious
injury to serviceman, pool or spa users or others due
to electrical shock.
WARNING
3.1 Preparing the Light Fixture for
Installation
NOTE The electrician must complete preparatory steps
before light fixture is installed; see Figure 1 (or
Figure 2, for spa).
Ensure that the pool or spa meets the requirements of
the current National Electrical Code (NEC) in the US,
the Canadian Electrical Code (CEC) in Canada, and all
applicable local codes and ordinances. A licensed or
certied electrician must install the electrical system
to meet or exceed those requirements before the
underwater light is installed. Some of the requirements
of the National Electrical Code, which the pool or spa’s
electrical systems must meet, are as follows:
1. The lighting circuit must have a Ground Fault
Circuit Interrupter (GFCI) for line voltage 120
volt models, and must have an appropriately rated
circuit breaker.
2. The Junction Box (or, for 12 volt models, the
low voltage transformer) must be located at least
eight (8) inches above water level, at least four (4)
inches above ground level or pool deck level, and
at least four (4) feet from the edge of the pool or
spa; see Figure 1 for pools and Figure 2 for spas.
3. The light xture and all metal items within ve (5)
feet of the pool or spa must be properly electrically
bonded to a reliable point of grounding.

PAGE 7
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Use only approved wet niches (see following note) to
ensure a safe and proper installation.
NOTE Jandy Pro Series Pool and Spa Lights are
ETL listed (ETL report/file 3101015CHI-
002) for installation with only the following
manufacturer’s wet niche fixtures:
Large / Pool Type Niche Model Numbers:
Jandy Pro Series: PLNICLRG, PLNICVFLRG,
SSNICLRG1(R/S)
Pentair®:620004, 78210200 thru 700,
78210401, 79206700
Hayward® DuraNiche: SP0600U
Sta-Rite®: 05161-2352 thru 2369, 05163-2395
thru 2396
Small / Spa Type Niche Model Numbers:
Jandy Pro Series: PLCNICSM, SSNICSM1(R/S)
Pentair: 78241100, 78242200, 78242300,
78243100 thru 300, 78244100 thru
300, 79206600
Hayward DuraNiche: SP0601U
Sta-Rite: 05166-1017 thru 1034, 05167-1035
thru 1037
3.2 Installing the Light Fixture
NOTE Perform these steps only after the electrical
system requirements are met.
1. Feed cord through conduit to Junction Box,
leaving at least four (4) feet of cord at the light
xture to coil around the light; see Figure 1 (or
Figure 2, for spa). This four (4) feet of cord around
the light allows the light to be serviced after the
pool or spa is lled with water.
2. Cut the cord at the Junction Box, leaving at least
six (6) inches of cord to make connections.
3. Strip six (6) inches of the outer cord jacket to
expose the three insulated wires. Be careful not to
damage the insulation on the three (3) inner wires.
4. Install strain relief over cord jacket and connect
all three (3) wires to the corresponding circuit
wires in the Junction Box. Install the Junction Box
cover.
Never operate this underwater light for more than
10 seconds unless it is totally submerged in water.
Without total submersion, the light assembly will get
extremely hot, which may result in serious burns
or in breakage of the lamp or lens. This may result
in serious injury to pool or spa users, installers, or
bystanders or damage to property.
WARNING
5. Coil the 4-foot length of cord around the xture
and place the light assembly into the niche.
6. Engage the retainer tab on the bottom of the face
ring, then pivot the top of the xture inward and
tighten the special pilot screw.
Use only the special pilot screw provided with this
underwater light. This screw mounts and electrically
grounds the mounting ring to the wet niche. Failure
to use the screw provided could create an electrical
hazard, which could result in death or serious injury
to pool or spa users, installers or others due to
electrical shock.
WARNING
7. Fill the pool or spa until the underwater light is
completely submerged in water before operating
the light for more than 10 seconds. Turn on
main switch or circuit breaker, and the switch,
which operates the underwater light, to check for
proper operation. Refer to Section 6, Operating
Instructions.
Section 4. Replacing Jandy Pro
Series Light Fixture in an
Existing Pool or Spa
Risk of Electrical Shock or Electrocution.
This underwater light must be installed by a
licensed or certied electrician or a qualied pool
or spa serviceman in accordance with the National
Electrical Code in the US, the Canadian Electrical
Code in Canada, and all applicable local codes
and ordinances. Improper installation will create
an electrical hazard, which could result in death
or serious injury to pool or spa users, installers or
others due to electrical shock, and may also cause
damage to property.
Always disconnect the power to the pool or spa
light at the circuit breaker before servicing the light.
Failure to do so could result in death or serious
injury to serviceman, pool or spa users or others due
to electrical shock.
WARNING

PAGE 8 ENGLISH Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
NOTE The light fixture may be replaced without
removing water from the pool or spa.
1. Turn off the main electrical switch or circuit
breaker, as well as the switch, which operates the
underwater light.
2. Unscrew the special pilot screw at the top of the
face ring and remove the light assembly from the
niche, and place the assembly on the deck.
Be sure to keep the special pilot screw from this
underwater light. This screw mounts and electrically
grounds the housing securely to the mounting ring
and wet niche. Failure to use the screw provided
could create an electrical hazard, which could result
in death or serious injury to pool or spa users,
installers or others due to electrical shock.
WARNING
3. Remove the Junction Box cover, disconnect the
light xture wires and strain relief, and then pull
the cord out of the conduit from the niche.
4. Feed the new light xture cord through the conduit
from the niche to the Junction Box.
NOTE Depending on the length of the conduit, special
tools may be required to pull the cord through
the conduit.
5. Leave at least four (4) feet of cord to coil around
the light xture; see Figure 1 (or Figure 2, for spa).
This allows the light to be serviced after the pool
or spa is lled with water.
6. Cut the cord at the Junction Box, leaving at least
six (6) inches of cord to make connections.
7. Strip six (6) inches of the outer cord jacket from
the cord to expose the three insulated wires. Be
careful not to damage the insulation on the three
(3) inner wires.
8. Install the strain relief over the cord jacket and
connect all (3) three wires to the corresponding
circuit wires in the Junction Box. Install the
Junction Box cover.
4.1 Preparing the Light Fixture for
Replacement
Verify that the pool or spa meets the requirements of
the current National Electrical Code® (NEC®) in the
US, the Electrical Code in Canada, and all applicable
local codes and ordinances. A licensed or certied
electrician must install the electrical system to meet or
exceed those requirements before the underwater light
is installed. Some of the requirements of the National
Electrical Code, which the pool or spa’s electrical
system must meet, are as follows:
1. The lighting circuit must have a Ground Fault
Circuit Interrupter (GFCI) for line voltage 120
volt models, and must have an appropriately rated
circuit breaker.
2. The Junction Box (or, for 12 volt models, the
low voltage transformer) must be located at least
eight (8) inches above water level, at least four (4)
inches above ground level or pool deck level, and
at least 48 inches from the edge of the pool or spa;
see Figure 1 (or Figure 2, for spa).
3. The light xture and all metal items within ve (5)
feet of the pool or spa must be properly electrically
bonded to a reliable point of grounding.
4. The wet niche must be properly installed so that
the top edge of the underwater light’s lens is at
least 18 inches below the surface of the water in
the pool or spa; see Figure 1 (or Figure 2, for spa).
5. The wet niche must be properly electrically
bonded and grounded via the No. 8 AWG ground
connector located at the rear of the niche; see
Figure 1 (or Figure 2, for spa).
To be certain that the pool or spa’s electrical system
meets all applicable requirements, the electrician should
also consult the local building department.
4.2 Replacing the Light Fixture
NOTE Perform these steps only after the electrical
system requirements are met.
Failure to bring the pool or spa’s electrical system
up to code requirements before installing the
underwater light will create an electrical hazard
which could result in death or serious injury to pool
or spa users, installers, or others due to electrical
shock, and may also cause damage to property.
WARNING

PAGE 9
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
9. Reinstall the light assembly into the niche and
tighten the special pilot screw.
Use only the special pilot screw provided with this
underwater light. This screw mounts and electrically
grounds the mounting ring to wet niche. Failure to
use the screw provided could create an electrical
hazard, which could result in death or serious injury
to pool or spa users, installers or others due to
electrical shock.
WARNING
10. Fill the pool or spa until the underwater light is
completely submerged in water before operating
the light for more than 10 seconds. Turn on main
switch or circuit breaker, as well as the switch,
which operates the underwater light, to check for
proper operation. Refer to Section 6, Operating
Instructions.
Never operate this underwater light for more than
10 seconds unless it is totally submerged in water.
Without total submersion, the light assembly will get
extremely hot, which may result in serious burns
or in breakage of the lamp or lens. This may result
in serious injury to pool or spa users, installers, or
bystanders or in damage to property.
WARNING
Section 5. Wiring Options for
Controlling Jandy Pro
Series Pro Series Pool or
Spa White Lights
NOTE The Jandy Pro Series Pool and Spa White
Lights can be dimmed when an optional Light
Dimming Module is added to the control system
or control switch.
To the extent allowed by code and capacity of the
electrical equipment, multiple Jandy Pro Series Pool
and Spa White Lights may be controlled with a single
switch.
5.1 Wiring to an AquaLink®RS Control
System
The Jandy Pro Series Pool and Spa White Lights can
be wired into the Jandy Pro Series AquaLink RS control
system to provide simplied operation of the lights.
Connect the lights to one of the auxiliary relays in the
Power Center.
NOTE It is recommended to connect one light per
relay so each light can be controlled separately.
However, up to four lights can be connected on
a single relay. If there are more than four lights
installed on one AquaLink RS system, ensure
there is more than one auxiliary relay available
in the Power Center.
Refer to Figures 3 and 4 to connect the Jandy Pro
Series Pool and Spa White Lights to the Power Center.
A Ground Fault Circuit Interrupter (GFCI) must be
provided for 120 volt models. The conductors on
the load side of the GFCI circuit shall not occupy
conduit, boxes, or enclosures containing other
conductors unless the additional conductors are
also protected by a GFCI. Refer to local codes for
complete details.
WARNING
NOTE The Jandy Pro Series Pool and Spa White
Lights are available in 120-volt and 12-
volt versions. If installing a 12-volt light, a
120-volt/12-volt step-down (AC) transformer
must be used. For more information about
12-volt installations, refer to Section 8 of this
manual.
5.2 Wiring to a Time Clock
The Jandy Pro Series Pool and Spa White Lights can
be wired into a basic time clock to automatically turn on
the lights at a predesignated time. Refer to Figure 5 to
connect the lights into the time clock.
5.3 Wiring to a Switch
The Jandy Pro Series Pool and Spa White Lights can
be wired into a switch to manually turn on/off the lights.
Refer to Figure 6 to connect the lights into the switch.
Section 6. Operating Instructions
6.1 To Operate the Light
Activate the light by either turning on the switch, setting
a program, or by pushing the button on a pool and spa
controller.

PAGE 10 ENGLISH Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Figure 5. Wiring the Jandy Pro Series Pool and
Spa White Light to a Time Clock
Clock
Motor
Ground
Ground
Neutral
Line
A12
GFCI
Black
White
Green
Black White Green
JUNCTION
BOX
120V
Jandy
Light
120 V
SUPPLY
Figure 6. Wiring the Jandy Pro Series Pool and
Spa White Light to a Switch
Ground
Ground
Neutral
Line
120 V
Supply
GFCI
Black
White
Green
JUNCTION
BOX
Black
White
SWITCH
Clock
Motor
Ground
Ground
Neutral
Line
A12
GFCI
Black
White
Green
Black White Green
JUNCTION
BOX
120V
Jandy
Light
120 V
SUPPLY
Figure 3. 120-Volt Jandy Pro Series Pool and Spa
White Light Wiring Diagram
GFCI
Black
White
Green
Ground
Ground
Neutral
120 VAC
Power Supply
Black
White
Green
JUNCTION
BOX
120V
Jandy
Light
Figure 4. 12-Volt Jandy Pro Series Pool and Spa
White Light Wiring Diagram
GFCI Black
White
Green
Ground
Ground
Neutral
120 VAC
Power Supply
Black
White
Green
JUNCTION
BOX
120V
Jandy
Light
120V/12V
Transformer
Black
White
Green
Black
White
Green
Ground
Neutral
120 VAC
Power Supply
Black
White
Green
JUNCTION
BOX
12V
Jandy
Light
120V/12V
Transformer
Black
White
Green

PAGE 11
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
4. Disassemble the light xture and replace lamp as
follows:
Be sure to keep the special pilot screw from this
underwater light. This screw mounts and electrically
grounds the housing securely to the mounting ring
and wet niche. Failure to use the screw provided
could create an electrical hazard, which could result
in death or serious injury to pool or spa users,
installers or others due to electrical shock.
WARNING
a. Loosen the eight (8) Phillips head screws for pool
light or the six (6) Phillips head screws for spa
light to allow the bottom clamp to be removed
from the face ring assembly. Do not remove the
screws or the retaining rings. The retaining rings
prevent the screws from falling free from the top
clamp and also aid in ease of assembly.
b. Remove the lower clamp, the face ring assembly,
the glass lens, and the gasket from the fixture.
Remove the gasket from the lens. Refer to Section
9, Exploded View and Replacement Parts.
c. Install new lamp.
Risk of Electrical Shock or Electrocution. Always
install a new lens gasket whenever disassembling
the light (for Jandy Pro Series Pool Light Gasket
P/N R0451101 and for Jandy Pro Series Spa Light
Gasket P/N R0400501). Failure to do so may permit
water to leak into the assembly, which could cause:
(a) An electrical hazard resulting in death or serious
injury to pool or spa users, installers, or others
due to electrical shock, or
(b) Breakage of the lamp or lens, which likewise
could result in serious injury to pool or spa users,
installers, or bystanders, or in damage to
property.
WARNING
Section 7. Replacing the Lamp
Always disconnect power to the pool or spa white
light at the circuit breaker before servicing the light.
Failure to do so could result in death or serious
injury to installer, serviceman, pool or spa users or
others due to electrical shock.
WARNING
1. Turn off the main electrical switch or circuit
breaker, as well as the switch, which operates the
underwater light.
2. Be sure to have the following items:
• A new lens gasket (P/N R0451101 for Jandy
Pro Series Pool Light and P/N R0400501 for
Jandy Pro Series Spa Light).
• One (1) new lamp. See Table 1 for
specications.
Replace the lamp with one of the same type and
wattage. Failure to replace the lamp with one of
the same type will damage the light assembly and
may cause an electrical hazard resulting in death
or serious injury to pool or spa users, installers, or
others due to electrical shock, and may also cause
damage to property. Be sure the power is switched
OFF before removing or installing lamps. Allow lamp
to cool before replacing.
WARNING
3. To remove the light assembly, unscrew the special
pilot screw at the top of the face ring, remove light
assembly from niche and gently place assembly on
the deck. It is not necessary to drain down the pool
or spa. See Figure 7.
Jandy Pro Series Model Fixture
Voltage Lamp Voltage Lamp Wattage Lamp Type Qty. per Fixture Lamp Kit Part Number
Pool/Spa White Light 12 Volt AC 12V 100 Watt R20 Flood 1 R0450501
Pool White Light 120 Volt AC 120V 300 Watt R40 Flood 1 R0450502
Pool White Light 12 Volt AC 12V 300 Watt R40 Flood 1 R0450503
Pool White Light 120 Volt AC 120V 500 Watt R40 Flood 1 R0450504
Spa White Light 120 Volt AC 120V 60 Watt 1 R0450505R20 Flood
Table 1. Lamp Specications

PAGE 12 ENGLISH Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Align pilot screw with arrow
located on fixture label
Align arrow of the lens
with pilot screw
Figure 8. Alignment of the Lens, Face Ring, Housing and Clamps for Pool White Lights
5. Reassemble the xture as follows:
a. If not already done, remove the gasket from
the glass lens and install a new gasket, Jandy
Pro Series Pool Light Gasket (P/N R0451101)
and Jandy Pro Series Spa Light Gasket (P/N
R0400501), on the lens.
NOTE A new lens gasket must be used each
time the light is reassembled.
b. While holding the fixture upright, place the glass
lens with the gasket on top of the fixture. Please
note that the lens gasket is not symmetrical.
Therefore, it must be installed correctly so that
the lens can seal to the fixture housing. Place the
gasket on the lens so that the thick molded side
of the gasket will mate with the housing when the
lens is installed. See Figure 11.
c. Position the lens and gasket on the fixture. Place
the face ring and the top clamp over the lens and
align the pilot screw with the small arrow mark
on the face of the lens. Note that the small arrow
mark on the face of the lens and the pilot screw
of the face ring must be aligned with the arrow
located on fixture label that reads, “Arrow on this
label must line up with the pilot screw on the Face
Ring”. See Figure 8.
d. While holding the aligned face ring assembly and
fixture together, turn the assembly upside down
and set it on the old gasket, using the old gasket
as an assembly fixture. This will keep the lens and
gasket assembly from being pushed out of the face
ring while you secure it to the light fixture.
e. Spread the bottom clamp over the electrical cord
and slide it onto the back of fixture to the top
clamp. See Figure 8.
Figure 7. Removing the Pool and Spa White Light Assembly for Lamp Replacement
1
POOL WALL
POSITIONING TAB
TAB LOCATOR
Power
Cord Niche
PILOT SCREW
Push up on
bottom of
light assembly
2
Power
Cord Niche
SPA WALL
Unscrew pilot screw
and pull top of light
assembly away from
spa wall
1
PILOT SCREW
Push up on
bottom of
light assembly
2
POSITIONING TAB
TAB LOCATOR
Unscrew pilot screw
and pull top of light
assembly away from
pool wall
SPA WHITE LIGHT
ASSEMBLY
POOL WHITE LIGHT
ASSEMBLY
Bonding
cable
Bonding
cable

PAGE 13
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
To ensure compliance with the National Electrical
Code®(NEC®) in the US (Canadian Electrical Code
(CEC) in Canada), and to reduce the risk of electric
shock which could result in serious injury or death, use
only a transformer that has been listed or recognized by
a Nationally Recognized Testing Laboratory (NRTL) for
pool/spa application.
f. Tighten the eight (8) Phillips head screws for pool
light or the six (6) Phillips head screws for spa
light in alternating cross-pattern. Torque screws to
approximately 20 in-lbs. Do not over-tighten.
g. Discard the old gasket.
6. Reinstall the Jandy Pro Series Light into niche
xture.
a. Coil four (4) feet of cord around the fixture and
place the light assembly into the niche.
b. Engage the retainer tab on the bottom of the face
ring, then pivot the top of the fixture inward and
tighten the special pilot screw.
Use only the special pilot screw provided with this
underwater light. This screw mounts and electrically
grounds the housing securely to the mounting ring
and wet niche. Failure to use the screw provided
could create an electrical hazard, which could result
in death or serious injury to pool or spa users,
installers or others due to electrical shock.
WARNING
7. If pool or spa is empty, ll pool or spa until the
underwater light is completely submerged in
water before operating the light for more than 10
seconds. Turn on main switch or circuit breaker, as
well as the switch, which specically operates the
underwater light, to check for proper operation.
Never operate this underwater light for more than
10 seconds unless it is totally submerged in water.
Without total submersion, the light assembly will get
extremely hot, which may result in serious burns
or in breakage of the lamp or lens. This may result
in serious injury to pool or spa users, installers, or
bystanders or in damage to property.
WARNING
Section 8. Twelve (12) Volt
Installation
A separate 12-Volt AC Transformer is required on all
12-Volt Models. Use an appropriately sized transformer
for your model light.
NOTE For optimum performance Jandy Pro Series
recommends to use one transformer per 12-volt
light.

PAGE 14 ENGLISH Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Section 9. Exploded View and Replacement Parts
9.1 Jandy Pro Series Pool White Light
Figure 10. Jandy Pro Series Pool White Light, Front
and Back View Figure 11. Cross Section of Jandy Pro Series Pool White Light
THICK MOLDED SIDE
OF THE GASKET MUST
MATE WITH THE BODY
OF THE HOUSING
Figure 9. Jandy Pro Series Pool White Light Exploded View
24
3
16
657
88
99
DWG # Part # Description Field Replaceable
1N/A Pool Light Housing NO - Purchase New Light
2N/A Lamp Holder NO - Purchase New Light
3 R0450501 Lamp, 100 Watt, 12 Volt YES
3 R0450502 Lamp, 300 Watt, 120 Volt YES
3 R0450503 Lamp, 300 Watt, 12 Volt YES
3 R0450504 Lamp, 500 Watt, 120 Volt YES
4 R0451101 Silicone Gasket, Pool Light YES
5 R0450601 Glass Lens, Pool Light YES
6 R0450701 Clamp Assembly, Pool Light YES
7 R0450801 Face Ring, Stainless Steel (SS), Pool Light YES
7 R0450802 Face Ring, Plastic, White, Pool Light YES
7 R0450803 Face Ring, Plastic, Black, Pool Light YES
7 R0450804 Face Ring, Plastic, Gray, Pool Light YES
7 R0450805 Face Ring, Plastic Set, Pool Light YES
8 R0450901 Pilot Screw, with Retainer, Pool Light YES
9 R0451001 Clamp Screw (8 Screws and 8 Retainers) Pool Light YES

PAGE 15
ENGLISH
Jandy®Pro Series Underwater Pool and Spa White Lights | Installation Manual
Figure 12. Jandy Pro Series Spa White Light Exploded View
Figure 13. Jandy Pro Series Spa White Light, Front
and Back View Figure 14. Cross Section of Jandy Pro Series Spa
White Light
24
3
16
6
57
88
99
DWG # Part # Description Field Replaceable
1N/A Spa Light Housing NO - Purchase New Light
2N/A Lamp Holder NO - Purchase New Light
3 R0450501 Lamp, 100 Watt, 12 Volt YES
3 R0450505 Lamp, 60 Watt, 120 Volt YES
4 R0400501 Silicone Gasket, Spa Light YES
5 R0400601 Glass Lens, Spa Light YES
6 R0451201 Clamp Assembly, Spa Light YES
7 R0451301 Face Ring, Stainless Steel (SS), Spa Light YES
7 R0451302 Face Ring, Plastic, White, Spa Light YES
7 R0451303 Face Ring, Plastic, Black, Spa Light YES
7 R0451304 Face Ring, Plastic, Gray, Spa Light YES
7 R0451305 Face Ring, Plastic Set, Spa Light YES
8 R0450901 Pilot Screw, with O-ring, Spa Light YES
9 R0451401 Clamp Screw (6 Screws and 6 Retainers) Spa Light YES
9.2 Jandy Pro Series Spa White Light

Zodiac Pool Systems, Inc.
2620 Commerce Way, Vista, CA 92081
1.800.822.7933 | www.ZodiacPoolSystems.com
©2014 Zodiac Pool Systems, Inc. ZODIAC®is a registered trademark of Zodiac International,
S.A.S.U., used under license. All other trademarks referenced herein are the property of their
respective owners.
H0312200 Rev C
ETL LISTED
CONFORMS TO UL STD 676
Certied to CAN/CSA C22.2 No. 89

FRANÇAIS
GUIDE D’INSTALLATION
AVERTISSEMENT
POUR VOTRE SÉCURITÉ – Ce produit doit être installé et entretenu par un technicien qualié spécialisé dans l’installation et
l’entretien des piscines et des spas. Les consignes de ce manuel doivent être suivies scrupuleusement. Toute infraction aux
consignes de sécurité et d’emploi pourrait causer des dommages matériels, des blessures graves ou même la mort. Une
installation et/ou une utilisation incorrecte de la lampe annulerait la garantie. Avant d’installer ce produit, lisez et respectez
toutes les consignes d’avertissement et instructions incluses avec cette lampe.
H0312200 Rev C
Lampes Blanches Immergées de
Piscine et de Spa JandyPro Series

PAGE 19
FRANÇAIS
Lampes Blanches Immergées de Piscine et de Spa Jandy®Pro Series | Guide d’installation
Section 1. Consignes de sécurité ............20
Section 2. Description du produit et
numéros de modèles ...............21
Section 3. Installation d’une lampe Jandy
Pro Series sur un chantier de
construction .............................22
3.1 Préparation de la lampe pour l’installation 22
3.2 Installation de la lampe .............................23
Section 4. Remplacement d’une lampe
Jandy Pro Series dans une
piscine ou un spa existants.....24
4.1 Préparation de la lampe
pour son remplacement ............................24
4.2 Remplacement de la lampe ......................24
Table des matières
Section 5. Options de câblage pour
contrôler les lampes blanches
de piscine et de spa Jandy Pro
Series.........................................25
5.1 Câblage à un système de contrôle RS
Aqualink ®..................................................25
5.2 Câblage à une horloge .............................26
5.3 Câblage à un interrupteur .........................26
Section 6. Consignes d’utilisation ...........26
6.1 Pour faire fonctionner la lampe .................26
Section 7. Remplacement de la lampe ....26
Section 8. Installation 12 volts .................30
Section 9. Vue éclatée et pièces de
rechange ...................................31
9.1 Lampe blanche de piscine Jandy Pro
Series.........................................................31
9.2 Lampe de spa blanche Jandy Pro
Series.........................................................32
Figures et tableaux
Figure 1. Installation de la lampe blanche de
piscine Jandy Pro Series .........................22
Figure 2. Installation de la lampe blanche de spa
Jandy Pro Series......................................23
Figure 3. Schéma de câblage de la lampe
blanche de 120 volts pour piscine et spa
Jandy Pro Series......................................27
Figure 4. Schéma de câblage de la lampe
blanche de 12 volts pour piscine et spa
Jandy Pro Series......................................27
Figure 5. Câblage de la lampe blanche
de piscine et de spa Jandy Pro Series
à une horloge...........................................27
Figure 6. Câblage de la lampe blanche
de piscine et de spa Jandy Pro Series
à un interrupteur.......................................27
Figure 7. Démontage de la lampe blanche
de piscine et de spa pour
remplacer l’ampoule.................................28
Figure 8. Alignement du verre de protection,
de la bague avant, du boîtier et des
crochets supports des lampes
blanches de piscine .................................28
Figure 9. Vue éclatée de la lampe blanche
de piscine Jandy Pro Series ....................31
Figure 10. Vues avant et arrière de la lampe
blanche de piscine Jandy Pro Series.......31
Figure 11. C Vue en coupe de la lampe
blanche de piscine Jandy Pro Series.......31
Figure 12. Vue éclatée de la lampe blanche
de spa Jandy Pro Series..........................32
Figure 13. Vues avant et arrière de la lampe
blanche de spa Jandy Pro Series............32
Figure 14. Vue en coupe de la lampe blanche
de spa Jandy Pro Series..........................32
Tableau 1. Caractéristiques de la lampe ...................26

PAGE 20 FRANÇAIS Lampes Blanches Immergées de Piscine et de Spa Jandy®Pro Series | Guide d’installation
Section 1. Consignes de sécurité
DIRECTIVES DE SÉCURITÉ IMPORTANTES RELATIVEMENT
À UN RISQUE D’INCENDIE, DE CHOC ÉLECTRIQUE,
OU DE BLESSURES AUX PERSONNES.
LIRE ET SUIVRE TOUTES LES DIRECTIVES
Lors de l’installation et de l’utilisation de cet équipement électrique, des précautions de base doivent toujours être
suivies, entre autres :
À L’ATTENTION DE L’INSTALLATEUR : ce guide contient des informations importantes
concernant l’installation, le fonctionnement et les consignes de sécurité de ce produit. Ces
informations doivent être données au propriétaire/opérateur de ce matériel.
CONSERVEZ CES DIRECTIVES
RISQUE DE CHOC ÉLECTRIQUE OU D’ÉLECTROCUTION. Cette lampe immergée doit être installée
par un technicien breveté ou certifié en accord avec le Code national d’électricité américain (NEC®) et le Code
électrique canadien (CEC) et avec les autres codes et arrêtés locaux applicables. Une installation incorrecte
peut entraîner un risque de problème électrique (choc électrique ou électrocution) pouvant causer des blessures
graves et même la mort des installateurs ou utilisateurs du spa et de la piscine. Lisez et respectez les
instructions détaillées ci-dessous.
AVERTISSEMENT
Avant d’installer la lampe immergée, lisez et respectez toutes les consignes d’avertissement et instructions
incluses avec cette lampe. Toute effraction à ces consignes de sécurité et instructions peut causer des blessures
graves ou mortelles, ou des dommages matériels. Composez le (+1) [phone] pour recevoir gratuitement
des manuels supplémentaires des consignes de sécurité.
AVERTISSEMENT
La lampe doit être installée à l’intérieur de la paroi ou sur la paroi de la piscine de façon à ce que le bord supérieur
du verre de protection soit situé à au moins 18 pouces (457 mm) au-dessous du niveau normal de l’eau de la
piscine, à moins que les lampes de piscine et de spa Jandy Pro Series ne soient installées dans une partie de
la piscine non utilisée pour la baignade et que les lentilles soient protégées adéquatement pour empêcher toute
personne d’y toucher.
MISE EN GARDE
