Intex Pure Spa BUBBLE SB-HWF20 Assembly instructions

Page 1
Pure Spa
2021SSN BUBBLE Spa Control Base Repair Guide
Characteristic Feature
Item #
28442
Control base #: 13032
Model #:
SB-HWF20
Panel Digital
(New) Hexagon type
Control Panel
Wireless control
Tub shape
Round & Octagon type
Production date
Start form 2020-6-15
Introduction
The purpose of this guide is to help you understand how to repair
the most common issues with the main heating and filtration unit.
This includes problems with the various internal sensors, the
internal computer (printed circuit board), water and air pumps.
IMPORTANT
Unplug the power cord before replacing spare parts.

Page 2
28442 Internal Part

Page 3
28442 Internal Part
EG image serial
number
SP#
QTY
DESC
1
13035
1
SPA CONTROL PANEL FOR 28439/28440/28441/28442
2
12913D
1
BUBBLE SPA CONTROL BASE BACK COVER-BLACK
3
12770D
2
CONTROL BASE SIDE COVER
5
12846
1
PTC HEATER FOR 28442
6
12848
1
AIR BLOWER FOR 28442
8
13032
1
SPA CONTROL BASE FOR 28440/28442
9
11998
1
SPA RCD
10
12914D
1
AIR PIPE SET DOWNWARD FOR BUBBLE SPA-BLACK
11
12915D
1
WATER INLET TUBE FOR BUBBLE SPA-BLACK
12
12916
6
SCREW FOR SPA BASE
13
12917
1
BUBBLE SPA BASE-KHAKI
14
13034
1
MAIN CIRCUIT BOARD FOR 28442
15
12772D
2
SIDE COVER FIXER
17
12771D
2
SIDE COVER BASE
20
12775D
1
DEFLATION OUTLET CAP
21
12936
1
SWITCH CONTROLLER BOARD FOR WIRELESS SPA
22
12854
1
TRANSFORMER FOR 28442
26
11687
1
SPA CONTROL STATION AIR INLET O-RING
27
11746D
1
AIR INLET CONNECTOR NUT FOR 28453/54/55/56 (BLACK)
28
10836
1
RUBBER CAP FOR #03R/#638/#638R/638G/637R MOTOR
29
10840
1
RESISTANCE TO RUB WASHER FOR #03R/#638/#638R/638G/637R MOTOR
30
12077
1
CERAMIC BAR FOR 28401MW/28403/04/21/22/23/24/43/44/53/54 & 28402 MADE ON/AFTER
2013-12-10
31
12084
1
MAGNETIC ROTOR AND IMPELLER FOR 28404/28422/28444/28454 & 28402 MADE ON/AFTER
2013-12-10
32
12778
1
FILTER MOTOR FOR 28462
33
12580
1
20-40℃TEMP. SENSOR FOR BUBBLE SPA MADE ON/AFTER OCT 1ST, 2016
34
12581
1
50℃TEMP. SENSOR FOR BUBBLE SPA MADE ON/AFTER OCT 1ST, 2016
35
12029
1
84℃TEMP. FUSE FOR 28402/28404 (14, 15 & 16 VERSION)
36
12310
1
OUTLET FLOW SENSOR FOR BUBBLE SPA (16 VERSION)
37
11745D
1
WATER INLET/OUTLET CONNECTOR NUT FOR 28453/54 (BLACK)
38
12918
1
WATER OUTLET TUBE FOR SPA-KHAKI
39
12006
1
SPA FILTER MOTOR CONNECTING TUBE
40
12751
2
FILTER MOTOR OUTLET O-RING FOR BUBBLE AND COMBO SPA
41
12601
1
BUBBLE SPA CONTROL BASE INLET HOSE W/ KAKHI NUT

Page 4
Table of contents
PCB Schematic .......................................................................................................................6
Basic Tools..............................................................................................................................7
Understanding a Multi-Meter ................................................................................................8
Basic Spa Components...........................................................................................................9
The Wi-Fi binding failure from first time setup.....................................................................11
Offline after Successful Initial Setup.....................................................................................11
Control base repair ..............................................................................................................12
Wiring Schematic .....................................................................................................................................12
Opening the Control Base ....................................................................................................13
Accessing the PCB................................................................................................................14
Internal Parts .......................................................................................................................15
PCB ......................................................................................................................................17
Main circuit Board.................................................................................................................................... 17
Display Errors.......................................................................................................................19
Error Code E81 .........................................................................................................................................19
Error Code E90 .........................................................................................................................................21
Error Code E90 (Flow Sensor) ..........................................................................................................................22
Error Code E90 (Water Pump) .........................................................................................................................23
Error Code E90 (Transformer)..........................................................................................................................24
Error Code E90 (PCB) .........................................................................................................................................25
Error Code E90 (Heating Element / Heater Set)...........................................................................................26
Error Code E94 ....................................................................................................................................................26

Page 5
Error Code E95 .........................................................................................................................................28
Error Code E97 .........................................................................................................................................29
Error Code E99/ 100℃/ 000℃................................................................................................................30
END/ Heating problems ...........................................................................................................................31
Blank panel...............................................................................................................................................32
Random Display or 888............................................................................................................................33
Functional Error ...................................................................................................................34
Air Blower Problems .................................................................................................................................34
How to Replace RCD ............................................................................................................36
How to replace PCB..............................................................................................................37
How to replace the broken base of spa control....................................................................38
How to replace switch controller board ...............................................................................39

Page 6
PCB Schematic
New version Wi-Fi spa main circuit board has a QR code.
New version Wi-Fi spa has a Wi-Fi chip with red color.
New
Old

Page 7
Basic Tools
This is a list of basic tools required to repair almost any problem encountered with a control base.
Tools such as a digital multimeter and clip-on ammeter are used to test the electrical current of
various components on the control base. Psophometers are used to test certain components based
on the loudness of the sound they produce. Water thermometers check the temperature of the
spa’s water and to verify readings provided by the system’s internal thermometers. Screwdrivers
and wrenches will help you disassemble and reassemble the unit.
Tools required for spa control base repair
NAME SPEC. PHOTO
1
digital multimeter
0.1mVac-1000Vac/0.1mVdc-1000Vdc,
0.1uAac-10Aac/0.1uAdc-10Adc
2
clip-on ammeter 20A
3
psophometer 30-130dB
4
water thermometer 0-50◦C
5
electric Phillips screw
driver
5X100mm.
8X200mm.
6
Phillips screw driver 5X100mm.
8X200mm.
7
Slotted screw driver 3X100mm.
8
Adjustable wrench 6", 8"

Page 8
Understanding a Multi-Meter
The range with a V and a wavy line measures AC voltage
The range with a V and a straight line measures DC voltage
First determine whether you will be testing for AC or DC voltage based on this guide and adjust the
meter to a range above the expected reading. For example, if we are looking for a DC voltage
between 12 & 14, the knob should be set to 20V in the DC range.
The position of the black and red probes/ports makes little difference. A negative number will be
displayed if the cables are swapped. Ignore this and the number displayed is the current reading.

Page 9
Basic Spa Components
Control Base - This part houses the heater, water pump, and an air pump.
Control Panel- The Control Panel has a display used to adjust temperature and provide diagnostic
information when there are problems with the Control Base
Spa Tub- Holds the water. The tub is different depending on spa’s features. The inner structure
features Dura-Beam construction for strength
Spa Cover –An inflatable safety cover
Important for insulating spa water
Ground Cloth - A cloth that goes underneath the spa tub and provides protection from the ground
Control Base
Control Panel
Spa Tub

Page 10
Model #
Code
SB-HWF20:
(SB)n1-(H)n2(WF)n3(20)n4
n 1
SB = Spa Bubble
n 2
H = With Hard Water features
n 3
WF= Wi-Fi
n 4
20 = 220-240V working wattage

Page 11
The Wi-Fi binding failure from first time setup
Wi-Fi binding failure is mainly linking to following 2 scenarios.
Scenario #1, Control panel can’t pair with the Wi-Fi router or
Scenario #2, Transmission signal failure between control base and the control panel (E81)
1. Control panel can’t pair with the Wi-Fi router
Try to pair it in local mode and IOT (the internet of things) mode respectively, touch the power
button of wireless control panel for 5 seconds to begin spa Wi-Fi pairing with your mobile device.
If product pairing failed, we need to observe the indicate status.
• ON/Solid: Product pairing completed successfully.
• Flashing slowly: pairing mode stage. If it’s not paired up within 2 minutes, the LED indicator will turn off. Touch
the pairing button for 5 seconds to repeat the pairing process.
• Flashing rapidly: WiFi router/internet network problem
• OFF: WiFi router signal is disconnected with product or first time use–waiting to be paired up with a mobile
device.
Please follow manual to do some troubleshooting, if the problem persists, replace the panel.
2. Transmission signal failure between control base and the control panel (E81)
If the LED display shows E81, please refer to the section “Error code E81”(page#19)to fix it.
s
Offline after Successfully Initial Setup
In general, it is the problem with networks, please follow the manual to do some troubleshooting. If
LED display still shows the blue dot, blank or indicate fast flashing please replace the control panel.
If the problem persists or shows E81, please refer to page#19 for section “Error code E81” for more
details.
Yes
No
No
Yes
Turn on spa and set up app
E81
Touch the power button of control panel for 5
seconds
Pairing
successfully
END
Replace the control panel
Refer to
page#19
2 min

Page 12
Control base repairs
Wiring Schematic
Main circuit Board

Page 13
Opening the Control Base
(Using 28426 as example, same layout and construction)
Begin by removing 6 screws around the enclosure. Then take strength to pull out the connector.
Removing 4 vertical screws around the cover that hold enclosure and then remove 2 horizontal
screws.
Removing 2 screws near on side, remove the panel from control base
The switch controller board connector is attached to the main circuit board, lift the cover vertically
carefully to ensure the cable is not pulled and connection between main circuit board and cover is
not damaged.

Page 14
Accessing the PCB
Remove the 2 screws that secure the white PCB cover to reveal the PCB. Unscrew the 2 screws on
the holder to remove the PCB set from the Control Base.
Loosen all the screws on the PCB to remove the wires, take the PCB out from the control base.

Page 15
Internal Parts
B
C
G
D
H
F
A
I
E

Page 16
NO.
ITEM
Part #
A
Transformer
12919
B
Air Blower
12848
C
PCB (Main Circuit Board)
10066
D
Base
12917
E
20-40℃Temperature Sensor
12025
F
Heating Element
12846
G
Flow sensor
12310
H
84℃Temperature Sensor
12029
I
50℃Temperature Sensor
12026
N
M
J
K
L

Page 17
NO.
ITEM
Part #
J
Water Inlet for Tub
12601
K
Water Outlet for Tub
12915
L
Air Inlet nut
12914
M
Electrical Cord with RCD
11998
N
Water Pump (Filter)
12778
PCB
Main circuit Board
Black:"50C 黑" - Water Temperature Sensor
White:"20~40C 白" - Water Temperature
Green: "FLOW 绿" - Flow Sensor one (E90)
Yellow:"84 C 黄" - Dry Fire Protection (E97)
1 & 2 - Main power supply
5 & 6 - Transformer power input
7 & 8 - Air blower power
9 to 12 - Heating element power

Page 18
Letters and numbers are clearly marked on the main circuit board.
A & B - Filter pump power input
C & D - Transformer output for Filter Pump
E & F –Input for control/Output of rectifier
G & H - Hard water coil

Page 19
Display Errors
Error Code E81
This code indicates transmission signal failure of wireless spa which could be due to a problem with
an internal component, such as main circuit board and switch controller board.
END
No
Yes
E81?
Replace the panel
Verify the main circuit board/switch controller
board problem and replace it
No
Display E81
Yes
1. Press TEST button to turn off the spa
2. Press Rest button to turn on the spa
Check the socket power
and replace the RCD
RCD working?
1. Press and hold Power button for 5 seconds to turn off (this
step can’t be on the control base)
2. Put the panel back on the top of control base to charge and
the panel will automatically turn on

Page 20
1. Press TEST button to turn off the spa, press RESET button to turn on the spa.
2. If RCD is not working, check the socket power and replace the RCD.
How to replace RCD? (please refer to page#36 for more details)
3. Take the panel out of the control base, press and hold POWER button for 5 seconds to turn off
(this step: the panel can’t be on the control base)
4. Put the panel back on the top of control base to charge and the panel will automatically turn on,
if still E81, please replace the panel.
5. If the issue doesn’t disappear, please verify the main circuit board/switch controller board
problem and replace it. (Please refer to Page#37-39 on how to replace the main circuit
board/switch controller board for more details)
Remark: Refer to the section replacing the PCB and replace the switch controller board for more
details. If you replace the panel to verify, please make sure turn off the original one.
Take 28468 as an example
Reset RCD, if RCD doesn’t
work replace RCD
Press power button for
5 seconds
If still shows E81, Replace
the main circuit board
Replace the switch
controller board
If panel failed, replace
the panel
