Intex ULTRA XTR RECTANGULAR POOL User manual

Zusammengeführte PDF Datei. Die Originale sind im folgenden Verzeichnis verlinkt. / Merged PDF File. Original files are linked in the following list. / Sloučený soubor PDF.
Originály jsou propojeny v následujícím adresáři. / Egyesített PDF fájl. Az eredetiek a következő könyvtárban találhatók. / Zlúčený súbor PDF. Originály sú prepojené v
nasledujúcom adresári. / Združena datoteka PDF. Izvirniki so povezani v naslednjem imeniku. / Spojena PDF datoteka. Izvornici su povezani u sljedećem imeniku.
126788GN - Frame Pool Set Prism Quadra 400 x 200 x
100 cm
Ladder 2
Above Ground Pool 13
Cartridge Filter Unit 28
Overview Pool Size vs Pump Running Time 40
Air Valve For Water Revitalization Set 42
Transition Liner For U-Shaped Side Support 44
Setup Video 45
Repair Kit 47
Service Center 48

333
A
English
(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
IMPORTANT
SAFETY RULES
Read, understand, and follow all
instructions carefully before installing
and using this product. Keep for future
reference.
Ladder with
Removable Steps
Model: 42” (107 cm)
Don’t forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may
result in updates to the instruction manual, without notice.
333-*A*-R0-2304
OWNER’S MANUAL
For illustrative purposes only.
©2022 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation
Corp. All rights reserved/Tous droits réservés/Todos los derechos reservados/
Alle Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/
Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in
einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., Hong Kong &
Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans
l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V.,
Ettenseweg 46, 4706 PB Roosendaal – The Netherlands • Distributed in the UK by Unitex Service (UK) Limited,
21 Holborn Viaduct, London EC1A 2DY, UK.
www.intexcorp.com

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 2
TABLE OF CONTENTS
Warnings........................................................................................................... 3
Parts References.............................................................................................. 4
Setup Instructions............................................... .................................... ......... 5-9
Long Term Storage.......................................................................................... 9
General Aquatic Safety.......................................... .................................... ...... 10
Limited Warranty..................... ....................................... .................................. 11

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 3
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.
WARNING
• Supervise children and those with disabilities at all times.
• Always assist children when they use the ladder to avoid falls
and/or serious injury.
• Never dive or jump from this ladder.
• Locate the ladder on a level, solid base.
• One person on this ladder at a time.
• Maximum load: 300 lbs (136 kg). Complies with EN16582
strength requirements.
• Face the ladder at all times for entry/exit of pool.
• Remove and secure ladder when pool is not occupied.
• Do not swim under, through or behind ladder.
• Check all nuts and bolts regularly to ensure ladder stays sturdy.
• If swimming at night use artificial lighting to illuminate all safety
signs, ladders, pool floor and walkways.
• Assembly and disassembly by adults only.
• This ladder is designed and manufactured for a specific pool wall
height and/or deck of the pool. Do not use with other pools.
• Failure to follow the maintenance instructions and warnings may
result in adverse health effects or injury, particularly to children.
• Only use this ladder for the purposes described in this manual.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN
BROKEN BONES, ENTRAPMENT, PARALYSIS, DROWNING OR
OTHER SERIOUS INJURY.
These product warnings, instructions and safety rules provided with
the product represent some common risks of water recreation
devices and do not cover all instances of risk and danger. Please
use common sense and good judgment when enjoying any water
activity.

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
23
1
9
5 (M6*45)
4
10
12
13
11
6
14
7
16 (M6*40)
17 (M6*35)
15
18
8
17 (M6*35)
REF.
NO. DESCRIPTION QUANTITIES SPARE PART NUMBER
1 U-SHAPED TOP RAIL 2 12637A
2 TOP BRACE (CLASP INCLUDED) 1 12524A
3 TOP BRACE WITH LOCKING SYSTEM (CLASP INCLUDED) 1 12525A
4 CLASP 2 12179
5 FASTENER (WITH 1 EXTRA) 3 12268
6 A SIDE (MARKED “A”) 1 12647AA
7 A SIDE (MARKED “B”) 1 12647AB
8 STEP 6 12629
9 STEP ANCHOR SLEEVE 12 12630
10 B SIDE PIPE END CAP (MARKED “A1”) 1 12558A
11 B SIDE PIPE END CAP (MARKED “B1”) 1 12558B
12 B SIDE (MARKED “A1”) 1 12648AA
13 B SIDE (MARKED “B1”) 1 12648AB
14 C SIDE - UPPER SIDE LEG (MARKED “C”) 2 12649A
15 C SIDE - LOWER U-SHAPED SIDE LEG (MARKED “C”) 1 12650A
16 FASTENER (WITH 1 EXTRA) 3 10227
17 FASTENER (WITH 1 EXTRA) 7 10810
18 SUPPORT BASE 2 11356
IMPORTANT
It is very important to lay out the parts correctly and identify which parts connect
together before starting the assembly. Although some parts look alike, they are
not always interchangeable. Refer to the parts list.

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 5
LADDER SETUP
TOOLS REQUIRED: One (1) Phillips screwdriver, one (1) small flat screwdriver
One (1) pair of pliers or a small adjustable wrench
Estimated assembly time 30-60 minutes. (Note the assembly time is only approximate
and individual assembly experience may vary.)
1. SIDE A LEGS ASSEMBLY (refer to figures 1.1 through 1.3):
WARNING
INCORRECTLY CONNECTED PARTS MAY RESULT IN AN UNSTABLE LADDER OR
LADDER FAILURE WHICH CAN CAUSE FALLING AND PERSONAL INJURY OR DEATH.
IMPORTANT: Ensure the J-shaped legs are pointing outwards before installing the steps.
A
B
7
6
9
1.1
A
B
7
6
8
1.2
AB
9
A
B
9
89
AA
BB
1.3
AA
BB
9
1
3
2
4

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 6
LADDER SETUP (continued)
2. SIDE B LEGS ASSEMBLY (refer to figures 2.1 through 2.3):
A1 B1
9
13
12
2.1
9
13
12
8
2.2
AB
A1 A1
B1 B1
A1 A1 A1
A1
B1 B1 B1
B1
9
9
89
10 11
2.3
BB
AAA1 B1
1
3
2
4
56

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 7
LADDER SETUP (continued)
3. SIDE C LEGS ASSEMBLY (refer to figures 3.1 through 3.4):
4. U-SHAPED TOP RAIL INSTALLATION (refer to figures 4.1 through 4.2):
IMPORTANT: Make sure the “top brace with locking system” (3) feature is facing outward
(your right side when facing the C legs assembly).
17 (M6*35)
C
C
C
C
18
14
3.3
C
C
3.4
15
18
3.1
C
C
5 (M6*45)
16 (M6*40)
12524A
12525A
4.1
17 (M6*35)
17 (M6*35)
12525A
12524A 4.2
18
3.2
C
C
15

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 8
LADDER SETUP (continued)
5. SIDE A & B LEGS INSTALLATION (refer to figure 5):
IMPORTANT: Do not fully tighten fasterners until last assembly operation.
6. MAINTENANCE: Regularly check all nuts, bolts, steps and step anchor sleeves to ensure
all parts are secured properly and the ladder is sturdy.
7. BEFORE USE OF LADDER (refer to figure 6):
With all parts now in place, verify that all fasteners/screws are fully tightened and apply
downward pressure to each step to be sure they are fully anchored in place.
IMPORTANT: The removable steps side must be located outside of the pool.
17 (M6*35) 5
2
3
1
WARNING
WHEN NOT IN USE, LADDER SHOULD BE KEPT IN SAFETY POSITION.
REMOVE THE FRONT STEPS SIDE WHEN THE POOL IS NOT IN USE OR
OCCUPIED. STORE THE REMOVABLE STEPS SIDE IN A SAFE PLACE
AWAY FROM CHILDREN REACH. CLOSE THE CLASPS BACK .
6
SAVE THE CARTON FOR STORAGE AND THE INSTRUCTIONS FOR RE-ASSEMBLY

(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
SAVE THESE INSTRUCTIONS
Page 9
8. AFTER USE OF LADDER (refer to figure 7):
9. REMOVING THE STEPS FROM THE SECURED POSITION (refer to figure 8):
a) With your right hand pull and hold the latch towards you, while at the same time with
your left hand press the white protruding buttons and simultaneously lift that leg out of
the cavity exposing the lower white protruding buttons.
b) Allow the leg to rest over the top brace (make sure it does not fall back into the cavity),
and quickly lift up the “removable step assembly” out of its secured position.
c) See step 5 for re-attaching the removable steps.
WINTERIZING / LONG TERM STORAGE
1. Remove the “removable steps” as shown in the After Use of Ladder section, see figure 7.
2. Remove the ladder from the pool, and make sure the ladder and the removable steps are
thoroughly dry before long term storage.
3. Bring the ladder and all its components indoors and store in a safe and dry area, preferably
between 32°F (0°C) and 104°F (40°C).
4. Be sure the ladder and all components are stored in a safe place away from children’s
reach.
5. Step disassembly:
7
Press
and
Pull
Press
and
Pull
3
1
2
LADDER SETUP (continued)
8
2
2
3
1
1
1
