KIO-LITE-190P-WOL USER MANUAL
COPYRIGHT 2020 - INTOUCH SCREENS
KIO-LITE-190P WOL - 19 inch Touch Screen Display Kiosk
Desktop Configuration
1280 x 1024 Resolution
19 inch Active Area - 377 x 302 mm
5:4 Aspect Ratio
Intel NUC PC
Overall Dimensions: 410H x 530W x 180D
NOTE: Cabling and External Power Supplies not illustrated

KIO-LITE-190P-WOL SPECIFICATIONS
Touch Screen INDT190
1
• 19” active viewable area
• 10-point PCAP multi-touch
• VGA & HDMI input
• 1280 x 1024 Native Resolution
• Built-in stereo speakers
• Compatible with Windows 7,
8 & 10
Media Player Intel NUC
2
• Intel Core i3 Processor
• Iris Plus Graphics 655
• Bluetooth* 5
• DDR4-2400 RAM
• Windows 10
COPYRIGHT 2020 - INTOUCH SCREENS
586
364
223
Fixed 2D Scanner
Brother QL-800 Label Printer
Intel NUC PC
Camera with Microphone
19" Touchscreen
5:4 Portrait
KIO-LITE-190P WOL - 19 inch Touch Screen Display Kiosk
Desktop Configuration
1280 x 1024 Resolution
19 inch Active Area - 377 x 302 mm
5:4 Aspect Ratio
Intel NUC PC
Overall Dimensions: 410H x 530W x 180D
NOTE: Cabling and External Power Supplies not illustrated
COPYRIGHT 2020 - INTOUCH SCREENS
586
364 223
Fixed 2D Scanner
Brother QL-800 Label Printer
Intel NUC PC
Camera with Microphone
19" Touchscreen
5:4 Portrait
KIO-LITE-190P WOL - 19 inch Touch Screen Display Kiosk
Desktop Configuration
1280 x 1024 Resolution
19 inch Active Area - 377 x 302 mm
5:4 Aspect Ratio
Intel NUC PC
Overall Dimensions: 410H x 530W x 180D
NOTE: Cabling and External Power Supplies not illustrated
Camera Logitech C922
Pro-stream Webcam
3
• Full HD 1080p at 30fps
• Hyperfast frame rate in HD
• Video capture capabilities
• 78° Field of view
Scanner Datalogic Gryphon
GFS4400 Fixed
4
• Reads 1D & 2D barcodes
• Wide angle eld-of-view
• Reads QR Codes
• Programmable for “Always On”
or “Object Snese” mode
Printer Brother QL-800/
820 NWB Label Printer
5
• Direct thermal printing
• Print in black & red
• Fast print speed
• Max. print width 58mm
• Max. print length 1000mm

KIO-LITE-190P-WOL BACK VIEW*
Intel NUC ON / OFF
button located under
the rear cover. (This
can be accessed while
the cover is in place)
CABLING INFORMATION*
Requirement:
You will need three power points to connect the screen, media player and
printer.
Network:
You have the option to connect the media player to your network via
WiFi or Ethernet.
To remove the rear cover and
access the NUC, unscrew the
two fasteners using a 4mm
allen key.
COPYRIGHT 2020 - INTOUCH SCREENS
140 73
61130174
O10 hole to suit
M8 Fastener - 2 places
Setup:
Simply plug in all three power cables, turn power on and you are ready to go!
*Cabling and external power supplies not illustrated
*The default setting for the NUC is to auto start when connected to power

FOR MORE INFORMATION Visit our Website
Telephone [phone]
suppor[email protected].au
[e-mail]
www.intouchscreens.com.au
CLEANING INSTRUCTIONS
WARRANTY
Applicable to touch screens and kiosks:
InTouch suggests using an isopropyl alcohol spray and clean microbre cloth.
Caution: DO NOT use abrasive cleaners, solvents or cloths.
For more information please visit www.intouchscreens.com.au/cleaning
For more information please visit www.intouchscreens.com.au/warranty
SECURING YOUR KIOSK (OPTIONAL)
COPYRIGHT 2020 - INTOUCH SCREENS
140 73
61130174
O10 hole to suit
M8 Fastener - 2 places
For further information on securing
your kiosk, do not hesitate to contact us
on suppor[email protected].au
