InTouch KIO190 User manual

KIO190 USER MANUAL
COPYRIGHT 2020 - INTOUCH SCREENS
1491
600 400
107550
KIO190 - 19.0 inch Touch Screen Display Kiosk
1280 x 1024 Resolution
19.0 inch Active Area - 377.3 x 302.1 mm
5:4 Aspect Ratio
Optional Accessories: Thermal Printer and 2D Scanner
Overall Dimensions: 1491H x 600W x 400D
Weight: 70 kg approx.
Product data available in DXF and 3D PDF formats Mounting Holes to suit
M10 Fasteners
R 100
R 25
Scanner
(Option)
Thermal Printer
(Option)
22°
340
150100
85°

KIO190 SPECIFICATIONS
Touch Screen INOF190
1
• 19” active viewable area
• 10-point PCAP multi-touch
• VGA & HDMI input
• 1280 x 1024 Native Resolution
• Compatible with Windows 7,
8 & 10
2Speaker Lenovo Soundbar
Speaker
• USB delivered audio and power
• Dual Speaker support with 1.25+1.25
total watts of output
• Stylish and sleek design
COPYRIGHT 2020 - INTOUCH SCREENS
1491
600 400
107550
KIO190 - 19.0 inch Touch Screen Display Kiosk
1280 x 1024 Resolution
19.0 inch Active Area - 377.3 x 302.1 mm
5:4 Aspect Ratio
Optional Accessories: Thermal Printer and 2D Scanner
Overall Dimensions: 1491H x 600W x 400D
Weight: 70 kg approx.
Product data available in DXF and 3D PDF formats Mounting Holes to suit
M10 Fasteners
R 100
R 25
Scanner
(Option)
Thermal Printer
(Option)
22°
340
150100
85°
Scanner Datalogic Gryphon
GFS4400 Fixed (OPTIONAL)
3
• Reads 1D & 2D barcodes
• Wide angle eld-of-view
• Reads QR Codes
• Programmable for “Always On”
or “Object Sense” mode
Printer VKP80ii Custom
(OPTIONAL)
4
• Direct thermal printing
• Industrial Auto-Cutter
• Max. print width 82.5mm
• Anti Jamming System

CABLING INFORMATION
Step 1. Connect your desired
display cable.
Step 2. Connect all USB
devices.
Step 3. Connect your PC power
cable into the
powerboard.
HDMI VGA
Touch Screen
Printer
Scanner
Speaker
Fan
Powerboard located directly
under the PC shelf
(Remove the four fastener
screws to reveal powerboard)
{
OPTIONAL ACCESORIES
• Printer
• 2D Scanner (Barcode & QR code)
• EFTPOS Terminal Mounting 9 (*Not shown in illustrations)
• RFID / Mag. Card Reader (*Not shown in illustrations)
Talk to us about your device needs! (suppor[email protected])

CLEANING INSTRUCTIONS
WARRANTY
Applicable to touch screens and kiosks:
InTouch suggests using an isopropyl alcohol spray and clean microbre cloth.
Caution: Be careful when cleaning your kiosk to avoid vinyled graphic areas so as not
to damage the artwork. DO NOT use abrasive cleaners, solvents or cloths.
For more information please visit www.intouchscreens.com.au/cleaning
FOR MORE INFORMATION
For more information please visit www.intouchscreens.com.au/warranty
Visit our Website
Telephone [phone]
suppor[email protected]
[e-mail]
www.intouchscreens.com.au
SECURING YOUR KIOSK TO THE FLOOR (OPTIONAL)
COPYRIGHT 2020 - INTOUCH SCREENS
1491
600 400
107550
KIO190 - 19.0 inch Touch Screen Display Kiosk
1280 x 1024 Resolution
19.0 inch Active Area - 377.3 x 302.1 mm
5:4 Aspect Ratio
Optional Accessories: Thermal Printer and 2D Scanner
Overall Dimensions: 1491H x 600W x 400D
Weight: 70 kg approx.
Product data available in DXF and 3D PDF formats
Mounting Holes to suit
M10 Fasteners
R 100
R 25
Scanner
(Option)
Thermal Printer
(Option)
22°
340
150100
85°
For further information on securing your
kiosk, do not hesitate to contact us on
suppor[email protected]
