Intova EDGE X User manual

0
Born in Hawaii –Built for the World
EDGE X
Waterproof HD Video Sports Camera
User’s Manual

1
Table of Contents:
P r e f a c e … … … … … … … … … … … … … … … … … … … … … … … . 2
System requirements for 1080P HD video ……………………3
Getting to know your camera …………………………………..4
Getting Started… … … … … … … … … … … … … … … … … … … … 5
Using EDGE X…………………………………………………….7
Basic Operations of EDGE X camera………………………….8
Camera Settings………………………………………………….9
Video Menu… … … … … … … … … … … … … … … … … … … … … . 9
Photo Menu………………………………………………………12
WiFi Menu………………………………………………………...12
System Menu……………………………………………………..14
Image Quality Menu……………………………………………..15
View Photos or Playback Videos………………………………16
Deleting Files……………………………………………………..17
Specifications…………………………………………………….18

2
PREFACE
Thank you for purchasing the Intova EDGE X waterproof sports camera! The rugged, durable and
waterproof EDGE X will help you capture high quality video and photos in many different venues and
environments. Visit www.intova.net to view the wide range of mount and system options available.
Enjoy!!
Main features:
Video Resolution:
1080p@60fps, 1080p@48fps, 1080p@30fps, 1080p@24fps
1200p@60fps, 1200p@48fps, 1200p@30fps, 1200p@24fps
960p@60fps, 960p@48fps, 960p@30fps, 960p@24fps,
720p@120fps, 720p@60fps, 720p@48fps, 720p@30fps, 720p@24fps,
(WVGA) 848x480p@240fps,848x480p@120fps,848x480p@60fps, 848x480p@48fps,
848x480p@30fps, 848x480p@24fps
VGAp@240fps, VGAp@120fps, VGA Full (60fps), VGAp@48fps, VGA (30 fps), VGAp@24fps
Photo Resolution:
12MP, 10MP, 8MP and 5MP
Rubber armored housing
Waterproof to 200 feet / 60M
Flat optical-glass lens port with water-repellant & anti-reflection coating
Super-wide-angle lens at 160 degrees
Digital Zoom: 60x, 16x, 10x and 4x
Uses same filters and lenses as CONNEX and NOVA HD
WiFi: remote operation and viewfinder, wireless file transfer on smartphone with WiFi app
WiFi remote controller (optional accessory)
1.5” / 3.8cm TFT-LCD 480x240
Rechargeable/Removable Li-ion battery 1150mAh
Battery life: 1.5 hrs (LCD on), 1.5 hrs (WiFi on), 2 hrs (LCD off)
Slave strobe function
Removable LCD glare hood
Diving Mode
Motion Detection Mode
Time Lapse mode
Self-capture mode
Burst Mode: 3, 5, 10, 20 and 30 photos
Video Rotation Mode (rotate video 180° when camera is mounted upside down)
Manual White Balance
Picture in Video
Dual stream mode
LED indicator- Visual Record Alert front and back
Audible record alert
Float Strap
High Definition TV output
Video format: H.264 / Photo format: JPEG
Supports Micro SD Card up to 64GB (class 10 required for HD video recording)

3
Important notice:
Do not attempt to take apart the camera as there are high voltage parts and dangerous electric
shock can occur.
If the camera is dropped or smashed and internal parts are exposed, do not touch as there is a
danger of electric shock.
Do not leave the camera in direct sunlight or near heat sources as these can damage the camera.
If camera becomes hot during use, turn off the power immediately.
For storage, remove the memory card and keep camera in a cool, dry place with housing door
slightly open.
Before each use, clean and maintain O-ring by removing any dirt, sand and other debris and
lightly lubricating with silicone grease to prevent drying and cracking.
Use float strap as extra precaution for water use.
System requirements for 1080P 30fps HD video (minimum)
PC
Mac
Windows® 7, 8
Mac OSR X 10.6.3 or later
Intel® Core 2 DuoTM or faster
Intel® Core 2 DuoTM or faster
DirectX 10.0 or later
Minimum 2GB of system RAM
Recommended: 4GB
Minimum 2GB of system RAM
Recommended: 4GB
Video card with minimum 256MB of RAM
Video card with minimum 256MB of RAM
Recommended screen resolution 1920x1080
(minimum 1024x768)
Recommended screen resolution 1920x1080
(minimum 1024x768)
IMPORTANT NOTE REGARDING CHOPPY OR BROKEN UP PLAYBACK:
HD video files contain very large amounts of data. When recording 1080p video, it is important to use
memory cards that are rated at class 10. 1080p 60fps is too much data for many computers to process.
Most common computers cannot process more than 30fps. We recommend using 30fps for most users
and applications. If 60fps is required, make sure your computer has AT LEAST 3.0-3.7 GHz third
generation Core based processors or equivalent, 4GB RAM and a graphics card that compares to an
NVIDIA GeForce GT650M or better.
Included Accessories:
User’s manual mini CD, lithium ion battery, USB cable, float strap, lens cap, anti-glare hood, silicone
grease, Quick Start Guide, Optional Accessory brochure.

4
GETTING TO KNOW YOUR CAMERA
ITEM
FUNCTION
ITEM
FUNCTION
1
POWER ON/OFF, MODE, MENU
SCROLLING button
13
Float strap attachment point
2
Slave strobe sync light
14
Tripod mount
3
Video recording in progress light
15
Removable anti-glare LCD hood
4
Lock latch
16
O-ring
5
Water repellant glass lens port
17
Thumb press backdoor opening system
in case of vacuum; see page 5.
6
Lens port ring
18
High Definition TV output port
7
SHUTTER button
19
Micro SD card port
8
MENU, WiFi ON/OFF, DELETE button
20
USB port
9
Port for rear video recording in
progress light
21
Li-ion battery cover; lift to open
10
UP, ZOOM IN button
22
LCD screen
11
OK, Picture in video( take photos while
video recording) button
23
Rear video recording in progress
indicator light
12
DOWN, ZOOM OUT, LCD ON/OFF
button
24
Microphone
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

5
GETTING STARTED
Opening the housing:
Follow the steps below to open the housing. Sometimes a vacuum seal may occur, use thumb press
system to open.
IMPORTANT: Before each use, clean and maintain O-ring by removing any dirt, sand and other
debris and lightly lubricating with silicone grease to prevent drying and cracking.
Inserting the Micro SD card:
Make sure that camera is turned OFF when inserting or removing Micro SD card. Locate Micro SD card
port on your camera (refer to page 4). Insert card with gold contacts facing towards LCD screen. Push
down until card clicks into place. To remove, press down on inserted card to click and then release.
EDGE X uses Micro SD card up to 64 GB. For HD video, speed class 10 is required.
1. The camera cannot record video or take photos without a properly inserted memory card.
2. Format the Micro SD card before use.
3. If the card does not work with the camera, please try another card.
4. When recording video in 1080p, or using WiFi, card speed class 10 is required.
STEP 1
STEP 2
STEP 3
STEP 4

6
Rechargeable / removable Li-ion Polymer battery:
1) The included lithium-ion battery comes partially charged.
2) To fully charge, connect the included USB cable to the camera and a power source such as a
computer or Intova Universal USB charger/AC adapter. Please note: no damage will occur to the
camera or battery if used prior to a full charge. Important: DO NOT allow Li-ion battery to become
fully discharged. If not using camera for a prolonged period, recharge every 3 months to prevent
battery from becoming fully discharged.
3) If camera stops responding to button controls, reset camera by removing and reinserting battery. To
remove, lift LCD screen, pull battery tag and lift out carefully.
USB charging and transferring:
Connect your computer to EDGE X with USB cable. After connection, camera will turn on, use UP /
DOWN buttons to select MSDC / CHARGE / OPEN.
MSDC: Enter to download video or image files. When this choice is selected, the screen shown below
will appear and EDGE X will be detected by computer and files can be transferred by dragging and
dropping.
CHARGE: Recharge the Li-ion battery power. Full charging time is around 6 hours. When this choice is
selected, LCD will turn off.
OPEN: Recharge the battery power and operate the camera at the same time. When this choice is
selected, LCD will show live view.
If none of the above choices is selected, the camera will automatically go to MDSC mode after 20
seconds and the USB CONNECTED screen will appear.
Status Indicator Lights when camera is charging will show:
• Status Indicator Lights are ON when charging.
• Status Indicator Lights are OFF when charging is complete.

7
USING EDGE X
Insert Micro SD memory card (class 10 required for HD video) before turning on. EDGE X cannot be
used if a properly inserted Micro SD card is not present.
To turn camera on, press and hold power ON/OFF button for 2 seconds and then release (if camera is in
sleep mode, short press once to waken)
Camera Default Settings: The EDGE X camera powers up with the following default settings:
Video Resolution 1080p@60fps
Photo Resolution 12 MP (megapixels)
Wi-Fi OFF
Video Mode LCD Monitor Display
Video mode idle screen
To start video recording, press the shutter button while in video mode. To take a photo while recording
video (picture in video), press OK button (color of icon will change to orange).
Recording video screen
Video mode icon
Resolution
White Balance
mode icon
WiFi ON/OFF icon
Meter mode icon
Motion Detection
mode icon
Time stamp icon
Battery Level
Video recording
time remaining
Digital Zoom
indicator bar
Microphone ON/Off icon
Quality icon
Blinking Red Dot
(video recording in progress)
Picture in Video icon
(Color will change to orange when OK button is pressed.)
Video recording time
Micro SD card
inserted

8
Photo Mode LCD Monitor Display
To switch to photo mode, press and quickly release MODE - Power ON/OFF button. To take a photo,
hold camera steady while pressing and releasing SHUTTER button.
Photo Mode Screen
Basic Operations of EDGE X camera
BUTTON
BASIC OPERATION PROCEDURES
POWER,
VIDEO/PHOTO/
FILE VIEWING
modes,
MENU SCROLLING
button
1) Press and hold for 2 seconds and release button to turn on or turn off
camera.
2) Quickly press button to switch between Video, Photo, and File Viewing
modes.
3) In either Video or Photo mode, press MENU and OK buttons. Quickly
press button to scroll through MENU.
MENU, WiFi
ON/OFF, DELETE
button
1) To bring up MENU, quickly press and release button.
2) To turn WiFi ON or OFF, press and hold button for 3 seconds and
release.
3) While in File Viewing mode, press button to DELETE single or all files.
SHUTTER button
Press “SHUTTER” button to start and stop video recording or to take a
photo.
UP, ZOOM IN
button
1) Press button to scroll up through sub-menu selections.
2) Press and hold to ZOOM IN when digital zoom mode is activated.
OK button
1) Press button to confirm menu selection
2) During video recording, press button to take a photo (Picture in Video)
DOWN, ZOOM
OUT, LCD ON/OFF
button
1) Press button to scroll down through sub-menu selections.
2) Press and hold to ZOOM OUT when digital zoom mode is activated.
3) Press button to turn LCD ON/OFF.
Photo Mode icon
Resolution
White Balance
mode icon
WiFi ON/OFF icon
Meter mode icon
Time stamp icon
Battery Level
Quality icon
Photo Flash Sync
ON icon
Self Capture icon
Digital Zoom
indicator bar
Microphone ON/Off icon
Micro SD card
inserted
Motion Detection
mode icon

9
CAMERA SETTINGS
To access camera settings, press the MENU button and press UP or DOWN button to scroll through
main menu selections and press OK button to enter sub-menu selections. Shown below are the five
main menu selections screens.
Video Menu:
With VIDEO menu icon highlighted, press OK button to enter video settings sub-menu. Use the UP or
DOWN button to scroll through the sub-menu and press OK button to select from RESOLUTION, VIDEO
QUALITY, MOTION DETECTION, LOOP VIDEO, MUTE, DUAL STREAM, VIDEO STAMP and TIME
LAPSE V. After selecting sub-menu, use UP or DOWN to scroll through choices, press OK button to
select and press MENU button to go back to main screen.
1) RESOLUTION: Setting sub-menu choices are explained in chart below.
RESOLUTION
NTSC/PAL fps
DESCRIPTION
1080P60
60/50
Highest resolution 16:9 HD video @ 1920x1080 pixels. 60/50 frames
per second rate for both action and better slow motion effect*.
1080P30
30/25
Highest resolution 16:9 HD video @ 1920x1080 pixels. 30/25 frames
per second rate for both action and when mounted on stable object.
1080P48
48/48
Highest resolution 16:9 HD video @ 1920x1080 pixels. 48/48 frames
per second rate for both action and better slow motion effect*.
1080P24
24/24
Highest resolution 16:9 HD video @ 1920x1080 pixels. 24/24 frames
per second rate for both action and when mounted on stable object.
1200P60
60/50
High resolution 16:10 HD video @ 1920x1200 pixels. 60/50 frames
per second rate for both action and better slow motion effect*.
1200P30
30/25
High resolution 16:10 HD video @ 1920x1200 pixels. 30/25 frames
per second rate for both action and when mounted on stable object.
1200P48
48/48
High resolution 16:10 HD video @ 1920x1200 pixels. 48/48 frames
per second rate for both action and better slow motion effect*.
1200P24
24/24
High resolution 16:10 HD video @ 1920x1200 pixels. 24/24 frames
per second rate for both action and when mounted on stable object.
