Intraphex MRD-UNO1 User manual

DVR and Backup Camera Mirror
Installation Manual
MRD-UNO1

2
General Description
Features
Technical Specications
Reverse Camera Operation
Panel TFT LCD (Digital) Signal System PAL/AUTO/NTSC
Screen Size 4.3” Two Video Inputs AV1-DVD etc.
AV2-Camera
Resolution 480x272 Memory Card 8GB Micro SD (Included)
Up to 32GB High-Capacity
Aspect Ratio 16:9 Image Sensor 3.2MP CMOS
Picture Pixels JPEG 2 million (Dynamic)
3.2 million (Static)
Image Resolution 2048x1536(3M)
1920x1080(2M)
1280x960(1.2M)
640x480(VGA)
Recording Mode
AVI (supports
H.264)
Full HD - 1920x1080 (30f)
HD - 1920x720 (30f)
HD - 1920x720 (60f)
VGA - 640x480 (30f)
Video Segment /
Motion Detection
1min, 3min, 5min, 10min
5s, 10s, 30s, 1min
Digital Zoom 4x Protection Sensitivity Off/Level 1-4
Gyroscope Video icker compensa-
tion / Image stabilization
Speaker / Mic Built-In
What’s In The Box
Auto–Adjusting Brightness Feature
Factory mirror upgrade with a 4.3” High-Resolution LCD Monitor hidden
behind the mirror surface. Front facing adjustable HD DVR camera with built in
microphone
• OEM Look and Feel Mirror
• 4.3” High-Denition LCD Monitor with Auto-adjusting brightness
• OEM Wire Harness Cover for Factory Look
• Two (2) Video Inputs
• Anti-Glare Mirror
• Built-in Adjustable HD DVR Camera
• Simple Installation
This system is completely signal-sensing. When the Video 1 or 2 inputs see a
signal, the display will automatically turn on. When the signal is removed, it will
automatically turn off. If both inputs see a signal, Input 2 will override Input 1.
The brightness of the 4.3” LCD screen will adjust automatically to its
environment’s lighting conditions. In brighter conditions, the display will brighten
to increase the image’s view ability. In darker conditions, it will decrease its
brightness so as not to over-stimulate the driver’s eyesight.
• Factory Style Rear-View Mirror with 4.3” LCD Monitor with DVR
• Wiring Harness
• OEM Style Wire Harness Cover
• 8GB Micro-SD Card
• Tombstone-style Mirror Mount with Allen Wrench
• Installation / User’s Guide

3
Operation
Installation
87
8586 87a
NA
30
To ACC Input of Camera
GNDVehicle
Reverse Lamp Wire
ACC Input
(From Vehicle)
Mirror
Camera
Black-Ground
Video 2 (To Camera)
Video 1 (Additional Input)
Black-Ground
Red-Accessory
Red-From 87 of Relay
RCA Output to Video
2 Input of Mirror
1. Video 2 (Reverse) will appear automatically when the input senses a signal
2. Video 1 (if used) can be accessed by long-pressing the REC button (about
2s)
3. When vehicle is powered on, the monitor will turn on automatically and
begin recording. To stop recording, short press the REC button.
4. To turn off the monitor, press the PWR button (center button) for 1s. If
the system was recording, it will continue to do so. To turn the unit off
completely, long press the PWR button for about 4s.
5. Use the MENU button enter the sub-menus for the DVR, V1, and V2 sources
6. Use the < Arrow > buttons to navigate sub-menus, and to zoom in photo
taking mode.
1. Remove OEM mirror and replace with supplied LCD mirror.
2. Run your wiring harness into the headliner and down the vehicles A-Pillar, making sure to
avoid any factory airbags. Secure your wiring with zip-ties.
3. Make all necessary wiring connections (See wiring diagram - make sure to use a relay)

Toll Free Tech Support: 888-228-5560
Local: 727-803-0324
Email: suppor[email protected]
