Invacare H450LA Omega User manual

Invacare®
Commode chairs
Invacare Glideabout commode
■Stable, robust frame made from powder-coated steel
■High corrosion protection
■Space-saving push bar for optimal positioning over the toilet
■Swing-away armrests and swing-away, detachable footrests
■Stable commode seat with integrated toilet pan holder
■Supplied with 4 braked castors as standard
Supplied with leg rests as standard
2 Year Warranty
160kg
maximum user
weight
22

Invacare Omega Pliante
■Foldable, Space saving commode
■Ideal for infrequent or travel use
■Contoured backrest
■Complete with sanitary pan
Invacare Omega height adjustable
■Height adjustable commode chair
■Space-saving: can be stacked
■Seat height adjustable in 7 steps from 510 - 660 mm
■Attractive design: fits well into a domestic setting
■Easy to clean
Invacare®
Commode chairs
23











Invacare Glideabout commode
CK
IJ
B
E
F
A
D
G
H
Invacare Omega Height adjustable
Order numbers Invacare Glideabout
commode
Invacare H450LA
height adjustable
Invacare Omega H407
Commode chair, mobile [phone]
Omega mobile commode chair with castors
Static commode 1471166
Omega height adjustable commode chair 1471010
(2 pack)
Dimensions
Seat width 450 mm (A) 495 mm (A) 440 mm (A)
Seat depth 450 mm (B) 455 mm (B) 420 mm (B)
Seat height 480 mm (C) 510 - 660 mm (C) 450 mm (C)
Total width 575 mm (D) 670 mm (D) 580 mm (D)
Total depth 810 mm (E) 630 mm (E) 560 mm (E)
Total height 945 mm (F) 900 - 1050 mm (F) 910 mm (F)
Depth without footrests 545 mm (G) – –
Footplate depth 155 mm (H) – –
Height to armrests 755 mm (I) 700 - 850 mm (H) 660 mm (H)
Height, footrests to seat 345 - 460 mm (J) – –
Height, ground to lower seat edge:
with holder for toilet pan
without holder for toilet pan
420 mm (K)
–
380 - 530 mm (I)
440 - 590 mm (J)
–
–
Height, floor to cover plate 525 mm (L) 535 - 685 mm (K) 475 mm (K)
Width between the armrests 470 mm (M) 510 mm (G) 460 mm (G)
Width, cut out in seat plate 220 mm 215 mm 215 mm
Depth, cut out in seat plate 260 mm 250 mm 255 mm
Ø Castors 5" (127 mm) – –
More info
Weight 14,0 kg 8,8 kg 8,5 kg
Load capacity 160kg 130 kg (21 stone) 80 kg
(13.5 stone)
Colour Black anthracite Lavender blue / Blue Lavender blue
Warranty 2 years 2 years 2 years
Technical data
CK
IJ
B
E
F
A
D
G
H
Invacare Omega Pilante
Invacare®
Commode chairs
24

Technical data
Invacare Styxo 9630E
The Invacare 9630 Styxo combines two functions in one
product. It can either be used as toilet frame over the
toilet or as a toilet commode with usage of the toilet
pan. The toilet pan with lid and the spash guard are
included in the delivery.
Product Description:
■Easy to handle seating height adjustment in 7 steps
from 410mm to 560mm
■Complete with elongated toilet seat and lid, pan with
lid and splash guard
■Tool less assembly and easy to clean
■High load capacity: 160kg (25 Stone)
Order numbers Invacare Styxo Invacare Adeo
Toilet frame 9630E C407A
Dimensions
Seat width 360 mm 590 mm
Seat depth 420 mm 440 mm
Seat height 410-560 mm 640 - 740 mm
Total width 620 mm 590 mm
Total depth 490 mm 440 mm
Total height 600 - 750mm 740 mm
More info
Weight 5,5 kg 2kg
Load capacity 160kg 100kg (16 stone)
Colour grey Chrome
Warranty 2 years 2 years
C
B
E
F
A
D
Invacare Styxo 9630E
Invacare®
Commode chairs
Invacare Adeo C407A
■Height adjustable 640 - 740 mm
■Fits most standard toilets
■Complete with armrests
C
B
E
F
A
D
Invacare Adeo C407A
25

A
C
F
B
B
J
I
F
2013-03 135 kg LN
H720T
!
AQUATEC Operations GmbH
Alemannenstrasse 10
88316 Isny - GERMANY
4 0 2 8 6 9 8 1 1 1 2 4 8
( 01 ) 040 28 6 98 111 248 ( 10 ) 13CRA00 01
( 01) 04028698111248( 10) 13CRA0001 0001
D
K
L
Fig. 2
Fig. 1
Fig. 4Fig. 3
This manual must be given to the user of the product.
Before using the product, read this manual and safe it
for future reference!
A
C
D
E
F
G
C
H
B
E
D
Fig. 5
N
M
Fig. 6
Invacare®
H720T / H720T4 Cascata
EN Commode
User Manual
DE Toilettenrollstuhl
Gebrauchsanweisung
FR Chaise roulante pour toilettes
Manuel d‘utilisation
NL Toiletrolstoel
Gebruiksaanwijzing
NO Toalettstol
Brukerveiledning
LT Naktipuodžiokėdė
Veikimo nurodymai
LV Tualeteskrēslsuzriteņiem
Lietošanas instrukcija
BG Стол за тоалет
Указание за използване
