Invacare InTouch PCS ITPCSR Manual

Owner’s Operator and Maintenance Manual
DEALER: This manual MUST be given to
the user of this product.
USER: BEFORE using this product, read this
manual and save for future reference.
InTouch™PCS™
Positioning Back
Models
ITPCSR ITPCST
ITPCSR16 ITPCST16
ITPCSR18 ITPCST18
ITPCSR20 ITPCST20

InTouch™PCS™ Positioning Back 2Part No 1163138
 WARNING
DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING THIS MANUAL. IF YOU ARE UNABLE TO
UNDERSTAND THE WARNINGS, CAUTIONS AND INSTRUCTIONS
CONTACT A QUALIFIED DEALER OR INVACARE TECHNICAL SUPPORT
BEFORE ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE INJURY
OR DAMAGE MAY RESULT.
 ACCESSORIES WARNING
Invacare products are specifically designed and manufactured for use in conjunction with
Invacare accessories. Accessories designed by other manufacturers have not been tested by
Invacare and are not recommended for use with Invacare products.

TABLE OF CONTENTS
Part No 1163138 3InTouch™ PCS™
TABLE OF CONTENTS
SPECIAL NOTES ............................................................................................ 4
SECTION 1—GENERAL GUIDELINES ............................................................... 5
Important Information....................................................................................................................................................5
Seating Pressure Warning .............................................................................................................................................5
Installation Warnings ......................................................................................................................................................5
Weight Capacity ..............................................................................................................................................................5
SECTION 2—INSTALLATION .......................................................................... 6
Installing the Back............................................................................................................................................................7
Install the Back Cane Mounting Assemblies .........................................................................................................7
Install/Adjust the Back on the Back Cane Mounting Assemblies.....................................................................8
Adjusting the Back Depth and/or Angle.....................................................................................................................9
Installing the Back - Invacare Power Wheelchairs with Power Recline .......................................................... 10
Installing/Removing Lateral Supports and/or Pelvic Stabilizers.......................................................................... 11
Removing the Back for Transport............................................................................................................................ 11
SECTION 3—MAINTENANCE ....................................................................... 12
Installing/Removing the Back Cushion..................................................................................................................... 12
Installing/Removing the Back Cushion Cover........................................................................................................ 13
Cleaning .......................................................................................................................................................................... 13
Back Shell................................................................................................................................................................... 13
Outer Cover............................................................................................................................................................. 13
Foam ........................................................................................................................................................................... 13
LIMITED WARRANTY ................................................................................. 14

SPECIAL NOTES
InTouch™PCS™ Positioning Back 4Part No 1163138
SPECIAL NOTES
Signalwordsareusedinthismanualandapplytohazardsorunsafepracticeswhichcouldresultinpersonalinjuryor
propertydamage.Refertothetablebelowfordefinitionsofthesignalwords.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE
WITHOUT NOTICE.
MAINTENANCE
Maintenance MUST be performed ONLY by qualified personnel.
SIGNAL WORD MEANING
DANGER Danger indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING Warning indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION Caution indicates a potentially hazardous situation which, if not avoided, may result in
property damage or minor injury or both.

SECTION 1—GENERAL GUIDELINES
Part No 1163138 5InTouch™PCS™ Positioning Back
SECTION 1—GENERAL GUIDELINES
 WARNING
SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and
use of this product.
Important Information
Thereareseveraladjustmentsavailablewhenthebackisusedonmanualandpowerwheelchairs.Thoseadjustmentsinclude
height,depthandangle.ThereisnoangleordepthadjustmentavailablewhenthebackisusedonInvacarePower
WheelchairswithPowerRecline.
Theproceduresintheinstallationsectionrequirea3/16Allenwrench.A7/16wrenchisrequiredisrequiredifinstallingthe
backontoanInvacarePowerWheelchairwithPowerRecline.
ThebackcushionisNOTdesignedforuseinthetreatmentofpressuresores.
Thebestwaytoavoidproblemsrelatedtopressuresoresistounderstandtheircausesandyourroleinaskinmanagement
program.
Yourtherapistandphysicianshouldbeconsultedifyouhaveanyquestionsregardingweightrelief,self‐examinationofskin,
orindividuallimitationsandneeds.
Allseatingsystemsshouldbeselectedcarefully.Workingwithyourtherapist,physicianandequipmentsupplieristhebest
waytoassurethataseatingsystemchoicematchestheindividualsneeds.
Astheneedsoftheindividualbecomemorecomplex,theInTouchPCSPositioningBackevaluationbecomesmoreimportant.
Seating Pressure Warning
Skinconditionshouldbecheckedfrequentlyaftertheinstallationanduseofanynewseatingsystem.
Installation Warnings
Afteranyadjustments,repairorserviceandbeforeuse,makesurethatallattachinghardwareistightenedsecurely.
DONOTinstalltheInTouchPCSPositioningBackontobackcaneswithanoutsidediametergreaterthan1”orlessthan7/8”
nominal(0.800”actual)‐otherwise,injuryordamagemayoccur.
EnsuretheInTouchPCSPositioningBackisproperlysecuredtothewheelchairbeforeusing.
Weight Capacity
 WARNING
The weight capacity of the back may be directly limited by the weight capacity of the wheelchair
that it is being installed and used on. The user’s weight MUST NOT exceed the weight capacity of
the wheelchair or back.
SIZE 14 TO 21-INCH WIDTH 22 TO 24-INCH WIDTH
MAXIMUM WEIGHT RATING 300 lbs 500 lbs

SECTION 2—INSTALLATION
InTouch™PCS™ Positioning Back 6Part No 1163138
SECTION 2—INSTALLATION
WARNING
Check ALL fasteners periodically to ensure that mechanical connections and attaching hardware
are tightened securely - otherwise injury or damage may occur.
DO NOT continue to use this product if problems are discovered. Corrective maintenance can be per-
formed at or arranged through your equipment supplier.
NOTE:TheinstallationinstructionsdifferforaInvacarePowerWheelchairwithPowerReclinefromtheinstallationinstructionsfora
manualorapowerwheelchairwithroundcanes7/8”nominalto1”diameter.
1. Removeanyexistingbackupholsteryorbacksystemfromthechairbeforeinstallation.RefertoOwner’sManual
shippedwithwheelchair.
2. Installtheback.Refertothetablebelowforapplicableinstallationandadjustmentinstructions.
TYPE OF
INSTALLATION
FOR INSTALLATION
INSTRUCTIONS, REFER TO
ADJUSTMENTS FOR APPLICABLE
ADJUSTMENTS, REFER TO
Manual or Power wheelchair with
round canes 7/8” nominal to 1” dia.
Installing the Back on page 7. HEIGHT - YES
DEPTH - YES
ANGLE - YES
For height adjustment, refer to
Install/Adjust the Back on the Back
Cane Mounting Assemblies on
page 8. For depth and angle adjust-
ment, refer to Adjusting the Back
Depth and/or Angle on page 9.
Invacare Power Wheelchair
w/Power Recline
Installing the Back - Invacare Power
Wheelchairs with Power Recline on
page 10.
HEIGHT - YES
DEPTH - NO
ANGLE - NO
For height adjustment, refer to
Refer to Installing the Back - Invac-
are Power Wheelchairs with
Power Recline on page 10.

SECTION 2—INSTALLATION
Part No 1163138 7InTouch™PCS™ Positioning Back
Installing the Back
NOTE:ThisproceduredoesnotapplytoInvacarePowerWheelchairswithPowerRecline.RefertoInstallingtheBack‐InvacarePower
WheelchairswithPowerReclineonpage 10.
Install the Back Cane Mounting Assemblies
NOTE:Forthisprocedure,refertoFIGURES2.1through2.3.
NOTE:Toremovethebackcaneassemblies,reversethis
procedure.
NOTE:Itmaybenecessarytoraiseorlowerthebackcanesto
achievethedesiredheightinstallation.RefertoOwner’s
Manualshippedwithwheelchair.
NOTE:DONOTdisassemblethebackcanemounting
assembliesduringSTEP1ofthisprocedure.
1. Loosen,butDONOTremove,thesocketheadscrews
onthebackcanemountingassemblies,justenoughto
allowthebackcanemountingassembliestosliponto
thebackcanes.
NOTE:Somewheelchairshavebackcaneswithabend.Make
surethatthebackcanemountingassembliesarecompletely
aboveorbelowandnotstraddlingthebend.
NOTE:Thereisaleft‐handandaright‐handbackcane
mountingassemblyusedwitheachInTouchPCSPositioning
Back.Wheninstalledproperly,theballisupandtheconeis
down,asshowninFIGURE2.1.
2. Slidethebackcanemountingassemblyontotheback
cane.
3. Alignthescoredverticallineontheoutsidebackcane
mountingassemblywiththecenterofthebackcane
asshowninFIGURE 2.2.
4. Adjustthebackcanemountingassembliesuntilthe
ballandconeoneachassemblyispositionedinward
ofthebackcanesasshowninFIGURE2.3.
5. Looselytightenthesocketheadscrewsontheback
canemountingassembly.
NOTE:DONOTtightenthesocketheadscrewscompletely
untilthebackisinstalledandcenteredbetweenthebackcanes.
6. RepeatSTEPS1‐5toinstalltheoppositebackcane
mountingassemblyontotheoppositebackcane.
FIGURE 2.1 Check hardware orientation
FIGURE 2.2 Check vertical alignment
FIGURE 2.3 Check ball and cone position
Right-Hand Back Cane
Mounting Assembly
Back Cane
Ball (up)
Cone (down)
Socket Head
Screws
NOTE:Thisviewisfromthebackofthewheelchair,lookingatthe
backcanes.
Left-Hand Back Cane
Mounting Assembly
Scored Vertical Line
(align with center of back cane)
Right-Hand Back Cane
Mounting Assembly
Seat
NOTE:Thisviewislookingattherightsideofthewheelchair.
Back Cane
Ball and cone on back cane mounting
assemblies MUST be installed inward
of the back canes
NOTE:Thisviewisfromthetopofthewheelchair,lookingdown
attheseat.
Inward of Back Canes

SECTION 2—INSTALLATION
InTouch™PCS™ Positioning Back 8Part No 1163138
Install/Adjust the Back on the Back Cane Mounting Assemblies
 WARNING
The installed location of the back is directly related to the wheelchairs stability. Check the stability of the
wheelchair after installation and before use. Refer to STABILITY in the wheelchair Owner’s Manual.
NOTE:Forthisprocedure,refertoFIGURES2.4through2.6.
NOTE:BothlatchesMUSTbeintheup(unlocked)positionto
installtheback.
1. Oneachbackmountingbracket,slightlypulloutasyou
rotatethebottomofthelatchoutward180°totheup
(unlocked)position.
2. Alignandputthereceiversonthebackmounting
bracketsontothebackcanemountingassembliesas
showninFIGURE2.4.
3. Adjustthebackcanemountingassembliesuntilthe
receiversarefullyseatedoneachsideandthebackis
centeredbetweenthebackcanes.
NOTE:Ifnootheradjustmentisneeded,proceedtoSTEP5.
NOTE:Thepositionofthesocketheadscrews,washerandnut
platescanbeadjustedintheslotsinthebackshellandback
mountingbrackets.RefertoFIGURE2.5.UseSTEP4tomake
theseadjustments.
4. Performthefollowing:
A. Removethebackcushion.Referto
Installing/RemovingtheBackCushiononpage 12.
B. Onbothsidesofthewheelchair,loosenbutDO
NOTremovethetwosocketheadscrewsthatsecure
thewasherplate,nutplateandbackmounting
brackettothebackshell.
C. Adjustthehardwareuntilthedesiredheightis
obtainedandthereceiversarefullyseatedontothe
backcanemountingassembliesasshownin
FIGURE 2.6.Makesurethebackiscentered
betweenthebackcanes.
D. Onbothsidesofthewheelchair,tightenthetwo
socketheadscrewsthatattachthewasherplate,nut
plateandbackmountingbrackettothebackshell.
E. Installthebackcushion.Referto
Installing/RemovingtheBackCushiononpage 12.
5. Oneachbackmountingbracket,rotatethelatch
outwardanddowntothelockedposition.
NOTE:Makesureanaudible“click”isheardforeachlatch.
6. Tightenthesocketheadscrewsonthebackcane
mountingassemblies.
7. Pulluponthebacktomakesureitislockedinplace.
FIGURE 2.4 Align the back mounting hardware
FIGURE 2.5 Secondary adjustments
FIGURE 2.6 Check hardware alignment
Back
Receiver on Back
Mounting Bracket
Ball and Cone on Back Cane
Mounting Assembly
Latch
(rotated 180° to the up
(unlocked) position)
Socket Head Screws
Washer Plate
DETAIL “A” -
PARTIAL BACK VIEW
NOTE:BackCaneMountingAssemblynotshownforclarity.DO
NOTremovethebackcanemountingassemblytomakethis
adjustment.
Socket Head Screw
Height Adjustment Slot in
Back Shell
Nut Plate
(cut away to show slot in back
mounting bracket)
Back Mounting Bracket
Hardware is centered
and seated in the
receivers
NOTE:Thisviewisfromthetopofthewheelchair,lookingdownat
theseat.

SECTION 2—INSTALLATION
Part No 1163138 9InTouch™PCS™ Positioning Back
Adjusting the Back Depth and/or Angle
NOTE:TheseadjustmentsdonotapplytoInvacarePowerWheelchairswithPowerRecline.
NOTE:Forthisprocedure,refertoFIGURE2.7.
1. Oneachsideofthewheelchair,loosenbutDONOTremovethetwosocketheadscrewsthatsecurethebackshell
mountingbracketsandwasherplatestothebackcanemountingassemblies.
2. Adjustthebacktothedesireddepthand/orangle.
3. Tightenthesocketheadscrewssecuringthewasherplatesandbackshellmountingbracketstothebackcane
mountingassemblies.
FIGURE 2.7 Adjusting the Back Depth and/or Angle
120° ANGLE FROM
SEATING SURFACE
90° ANGLE FROM
SEATING SURFACE 60° ANGLE FROM
SEATING SURFACE
NOTE:Thisviewisfromtherightsideofthewheelchair,rightbackcaneandattachinghardwarenotshownforclarity.Theangle
measurementsarerelativetobackcanesat90°totheseatingsurface.
120° 90°
Seating Surface
60°

SECTION 2—INSTALLATION
InTouch™PCS™ Positioning Back 10 Part No 1163138
Installing the Back - Invacare Power Wheelchairs with Power
Recline
NOTE:Thismountingsystemisfixedanddoesnotallowfor
width,angleordepthadjustment.
NOTE:Forthisprocedure,refertoFIGURE 2.8and
FIGURE 2.9.
1. Placeaflatwasherontotwohexheadscrews.
2. Insertahexheadscrewintoeachmountingholeinthe
backcanemountingbracket.
3. Looselyattachthehexheadscrewsandflatwashersto
thebackcanemountingbracketwithtwot‐nuts.
4. RepeatSTEPS1‐3toattachthehardwaretothe
oppositebackcanemountingbracket.
5. Alignandinsertthet‐nutsintotheT‐slotsintheback
canes.
6. Adjustthebacktothedesiredpositionontheback
canes.
7. Looselytightenthehexheadscrews.
NOTE:Ifnootherheightadjustmentisnecessary,proceedto
STEP11ofthisprocedure.
8. Oneachsideofthewheelchair,loosenbutDONOT
removethetwosocketheadscrewsthatsecurethe
backshellandwasherplatestothebackcane
mountingbracket.
9. Adjustthebacktothedesiredheightalongthevertical
slotsonbothsidesofthebackshell.
10. Tightenthesocketheadscrewssecuringthewasher
platesandbackshelltothebackcanemounting
brackets.
11. Securelytightenthehexheadscrews.
NOTE:Afterinstallationandbeforeuse,pulluponthebackto
ensureitislocked.
FIGURE 2.8 Installation Details on an
Invacare Power Wheelchair with Power Recline
FIGURE 2.9 Secondary Height Adjustment
T-Slot in
Back Cane
Back Cane
Mounting Bracket
Hex Head Screws
and Flat Washers
Socket Head
Screws
Washer Plate
