Inventec FLY DS400 Operating instructions

DG12BT(FLY DS400)_Trouble Shooting
Prepared by: Zhong, Ren-Hui
Approved by: Sun, Bang-Li
Proofread by: Wang, York
Released date: Jul. 11, 2008

2
Innovating Customer Value
Inventec Confidential
TABLE OF CONTENTS
1、No power on
2、KEY NG
3、LCD no display
4、No ring or KEY TONE
5、No vibration
6、No charge
7、No Voice
8、SIM Card NG
9、TF card inefficacy
10、FM inefficacy
11、No Bluetooth
12、No service

3
Innovating Customer Value
Inventec Confidential
Check whether the
voltage of the battery
is higher than 3.5V
Charge the battery or
change a new one
NG
OK
NG
Check whether the
battery connector pin
is OK?
Adjust the connector PIN or
change a new battery connector
Check whether the
‘No’ key is locked? Reassemble the key-press
OK
NG
OK
No power on
END

4
Innovating Customer Value
Inventec Confidential
KEY NG
Check whether the Dome and
the Key Pad is cleaned?Clean Dome and Key Pad
NG
Reassemble the K/B
Check whether the keypad
is assembled OK? NG
Reassemble the KB connector
or change a new one
NG
End
Check whether the KB connector
is assembled OK or is broken?
OK
OK
OK

5
Innovating Customer Value
Inventec Confidential
OK
Check whether the
LCD FPC is jointed OK?
NG
LCD no display
Check whether the LCD is OK? Change for another LCD
NG
OK
Reassemble the LCD FPC
END

6
Innovating Customer Value
Inventec Confidential
No ring or KEY TONE
NG
NG
End
Check whether set
in the silent mode? Reset the mode
Check whether the SPK
is welded OK or is broken Re-weld or change a new SPK
OK
OK

7
Innovating Customer Value
Inventec Confidential
No vibration
OK
Check whether the
MOTOR is assembled
OK or is broken?
Reassemble or
Change a new MOTOR
NG
Check whether set in
no vibration mode? Reset the mode
NG
END
OK

8
Innovating Customer Value
Inventec Confidential
No charge
Check whether the I/O connector
Is jointed OK or is broken? Joint the I/O connector or change for another one
NG
Check whether the charger
output voltage is 5V? Change for another charger
NG
OK
OK
END

9
Innovating Customer Value
Inventec Confidential
No Voice
Check whether the
microphone is assembled
OK or is broken?
Reassemble the microphone
or change for another one
NG
Check whether the
receiver is soldered
OK or is broken?
Re-solder the receiver or
change for another one
NG
End
OK
OK

10
Innovating Customer Value
Inventec Confidential
Check if it is in the service Move to service zone
and try again
NG
OK
Check SIM socket is jointed OK
or the socket is broken? Joint the socket or
change for another one
NG
Check whether the SIM card
is assembled OK? Reassemble the SIM card
NG
OK
SIM Card NG
OK
End

11
Innovating Customer Value
Inventec Confidential
Check TF card socket
Pin is jointed OK? Re-solder or change
for another one
NG
Check whether the TF card
is assembled OK? Reassemble the TF card, Ensure to touch is good.
NG
OK
TF card
inefficacy
END

12
Innovating Customer Value
Inventec Confidential
CHK whether FM
set is correct? FM parameter set is correct.
NG
Check whether the
earphone is assembled OK? Reassemble the earphone, Ensure to touch is good.
NG
OK
FM inefficacy
END

13
Innovating Customer Value
Inventec Confidential
Check whether the
Bluetooth equipment is ok?
Open to Bluetooth set is
correctly , confirm to search
external Bluetooth device is OK
NG
OK
OK
Check whether the antenna
spring slice is absolutely
Touched with the PAD
CHK whether external Bluetooth
headset is working well? Change for a good Bluetooth headset
NG
Adjust the spring slice or change
a new one to make it touch well
NG
No Bluetooth
NG
Check whether the Shield cover
of RF module is broken? Reassemble the shield cover of the Module
END

14
Innovating Customer Value
Inventec Confidential
Check whether in the
Service zone Move to service zone or check whether connect to the tester OK
NG
OK
OK
Check whether the antenna
spring slice is absolutely
Touched with the PAD
Check whether the Shield cover
of RF module is broken Reassemble the shield cover of the Module
NG
Adjust the spring slice or change
a new one to make it touch well
NG
No service
OK
END
