involight LEDBAR508R User manual

1
LEDBAR508R
User Manual
Please read this manual carefully before use!

2
Thank you for purchasing this product. To optimize the performance of this
product,prior to use,please read these operating instructions carefully to
familiarise yourself with the basic operation of this unit.Please keep the manual
in safe price for future reference.
This unit has been tested at our factory before being shipped to you, there is
no assembly required.
Once after received this product , please take and put carefully. And check
cautiously that whether the product was damaged or not during the
transportation.
Checking Parts
Please check if the following parts are included:
1 x Laser bar
1 x Power cable
1 x User manual
Danger Laser Radiation!
Avoid direct eye exposure!
Laser radiation can cause eye damage or skin damage
All protective measures for a safe operation of this laser must be applied.
Installation
1. Please check the voltage whether is the same with the one showed on the
equipment or not.
2. This laser light is 3B, it must ask for the technical person and set the light
safety when installation. And let the light beam at the suitable angle.
3. When install this equipment please make sure there's no flammable
surfaces (decorated things, etc) within at least 2.5M and maintain minimum
distance of 0.5M from the equipment to the walls.
4. Please make sure that there's no other equipment or decorating materials
obstructed the exhaust fan and the vent-pipe.
5. Products should be install immobility.
6. In case of safety, it's very important that to connect the earth with line.

3
Attention
1.Please do not open the bottom cover yourself without permission.Operate it
accord the user manual. Call the technician when the machine breaks down.
2.Please do not see the laser beam directly to avoid any damage.
3.Before connect or disconnect the power, please adjust the luminance of the
laser diode to the least to avoid any damage to the laser diode.
4.This unit should be keep dry, do not use in the rain and dusty environment. It
can be use in the outdoor with the water-proof cover protector.
5. Set the light immobility and try to avoid strong shake or hit.
6.Prevent dust into the equipment to avoid problems.
7.Please keep that there's no other equipment or decorating materials
obstructed the exhaust fan and the vent-pipe when the equipment was
working.
8.Before connect power, check the plug is immobility or not, power line should
be connect well.
9.Please do not open or close the equipment frequently that's to avoid any
affect to the life span of the laser diode, and try the best to avoid the long time
working.
10.Due to the characteristic of the laser diode, after four hours working, it
should be close at least 25 minutes until the laser diode cooling then work
again.
11.Don't touch the light or draw the power line when your hand was wet. And
do not pull the electronic power line.
12.Maintain the distance at least 3M above from the equipment to the object.
13.This equipment does not have any parts can repair for the users, please do
not open the equipment.
14.When the laser diode became dim or damaged please contact the dealer
timely.
15.When you want to re-transfer the products,you'd better use the original
package to shockproof.
Display Function Instruction
No.
Menu
Up/Down
Default
Function
1
Addr
1-512
1
Set address/Control mode/Slave
mode
2
Chnd
22CH
22CH
7CH
7CH
3
Slnd
HoSt
Master
SLAV
Slave
4
LoSt
AUTO
Auto
BLAC
Black-out

4
4
LoSt
HOLD
Hold
SOUN
Sound
5
SEnS
S001-S100
70
Sound sensitivity
6
Inv
ON
Light reverse
OFF
Reset direction of light
7
Corr
0-255
127
Angle fine, for adjust direction
once multi units connected
8
DISP
rdon
display
rdoF
Display reverse
9
LED
ON
Display full on all the time
OFF
Display off once without click after
13secs
10
Deft
YES
Factory default
11
Rest
YES
reset
12
U1.00
U1.00
Software version
Channel Instructions
7channels
Channel
Value
Function
CH1
Dimmer
0-255
Dimmer 0-100%
CH2
Strobe
0-15
No function
16-95
Strobe （1HZ-25HZ Slow-Fast）
96-175
Strobe 1Hz from slow to fast
176-255
Random strobe
CH3
Motor Position
0-255
Motor Position Setection
CH4
Motor fine
adjustment
0-255
Motor Position fine adjustment
CH5
Motor Scanner
Speed
0-255
Motor Scanner Speed
setection(from fast to slow)
CH6
Laser and LED
0~29
No function
30-99
Laser full on
100-199
LED full on
200-255
Both laser and LED full on
CH7
Auto
0-30
No function
31-200
Auto
201-255
Sound

5
22channels
Channel
Value
Function
CH1
Dimmer
0-255
Dimmer 0-100%
CH2
Strobe
0-15
No function
16-95
Strobe （1HZ-25HZ Slow-Fast）
96-175
Strobe 1Hz from slow to fast
176-255
Random strobe
CH3
Motor Position
0-255
Motor Position Setection
CH4
Motor fine
adjustment
0-255
Motor Position fine adjustment
CH5
Motor Scanner
Speed
0-255
Motor Scanner Speed
setection(from fast to slow)
CH6
Laser and LED
effect
0~15
No function
16-35
effect 1
36-55
Effect 2
56-75
Effect 3
76-95
Effect 4
96-115
Effect 5
116-135
Effect 6
136-155
Effect 7
156-175
Effect 8
176-195
Effect 9
196-255
Effect 10
CH7
Speed
0-255
Chasing speed from slow to fast
CH8
Laser 1
0-127
Closed
128-255
On
CH9
Laser 2
0-127
Closed
128-255
On
CH10
Laser 3
0-127
Closed
128-255
On
CH11
Laser 4
0-127
Closed
128-255
On
CH12
Laser 5
0-127
Closed
128-255
On
CH13
Laser 6
0-127
Closed
128-255
On
CH14
Laser 7
0-127
Closed
128-255
On
CH15
Laser 8
0-127
Closed
128-255
On
CH16
LED1
0-255
0-100%
CH17
LED2
0-255
0-100%
CH18
LED3
0-255
0-100%

6
CH19
LED4
0-255
0-100%
CH20
LED5
0-255
0-100%
CH21
LED6
0-255
0-100%
CH22
LED7
0-255
0-100%
Note:Set master-slave,master machine at auto or sound mode and slave
machine at d001.
Maintenance
Maintenance should be performed every 15-day period, by using a sponge
which is dipped with alcohol, rather than wet cloth or other chemical liquid, to
clean the mirror.
Always disconnect from the mains when the device is not in use or before
cleaning it.
Warning
Power must be disconnected before maintenance or repair. Do not look at the
light source directly
Note
Don't separate laser machine from laser power and repair them by yourself,
otherwise no good repair service will be supplied.
Technical Specifications
1.Power Supply: AC 100-240V 50/60Hz
2.Rated Power: 60W
3.Fuse: BDGP 5*20mm,2A
4. Single Red: Red 500mW/638nm*8 (200mW/650nm*8 option) + 7*3W
Amber LEDs
5. Working Mode: Sound Active/ Auto-play/DMX512/Master-Slave
6. Output laser spot diameter: 14mm
7.Control Signal: DMX512 signal
8.DMX Control Channels: 7/22
9.Operating Temperature: -1º--35º
10.Storage Temperature: -10º--60º
11.Warm-Up Time :<15 min
12.Laser Classification: 3B
13.Modulation: TTL

7
Declaration
This device has left our premises in absolutely perfect condition. In order to
maintain this condition and to ensure a safe operation, it is absolutely
necessary for the user to follow the safety instructions and warning notes
written in this user manual.
We cannot be made liable for damages caused by incorrect installations and
unskilled operation!
Warranty Card
This product is made of high-brightness transistor. We will provide 1 year
warranty under the condition that user has operated the light normally and
lifetime service. We won't provide warranty if the damage is caused by
artificial or force majeure event. Cost of fittings should be charged by user
if product need maintenance after 1 year .Please cut this warranty card
and shipped it along with the product to our factory when applying for
warranty.
