involight SONICWAVE1231 User manual

DMX indoor LED sonic wave bar 12*Tri-3W Manual
Our DMX indoor LED sonic wave bar 12*Tri-W have many and nice effects .Very good equaliser
and chasing effects with music .Please read the manual and operation .
A. SPECIFICATION:
1. Weight:4.2kg
2. Size:109*12*3cm
3. Power input: AC 120V/240V, 47Hz/63Hz
4. Wattage: 45W
5. LEDs:12 *tri-3W LEDs
6. Beam angle:30 degrees
7. Built-in programs, sound active, auto run, M/S mode, DMX mode, static colors
8. Selectable 3,4,6,7,9,12,18,36 DMX channels
9. Three sound active modes
10. Very good equalizer and chasing effects with music
11. LED display for easier operation
12. Inner box: 114.5*17.5*8.5cm
13. Master carton: 116.5*21.*13.5cm
14. 4 pcs/ctn
B.OPERATION:
1.Built-in program mode
--Press MODE button ,enter the built in program mode menu“Pr.××”
Press UP or DOWN button ,select the effects program Pr.01～Pr.35。
--Press SETUP button ,enter setup program run speed menu “SP××”
Press UP or DOWN button ,setup the speed value SP01～SP100（FL）
--Press SETUP button ,enter setup program run speed flash menu “FS××”
Press UP or DOWN button ,setup flash value FS00～99
2.Auto run mode
-- Press MODE button ,enter auto run mode menu “AUTO”
-- Press SETUP mode ,enter setup auto run mode speed menu “SP××”
Press UP or DOWN button ,setup speed value SP01～SP100（FL）
-- Press SETUP button ,enter setup auto run mode flash menu “FS××”
Press UP or DOWN button ,setup flash value FS00～99
3.DMX mode
-- Press MODE Button ,enter DMX control run mode menu “d.×××”
Press UP or DOWN button ,setup DMX address value d.001～d.512
-- Press SETUP button ,enter setup DMX mode menu xxch
Press UP or DOWN button ,setup DMX mode 3ch、4ch、6ch、7ch、9ch、12ch、18ch、36ch。
CHANNEL numbers 3、4、6、7、9、12、18、36
DMX mode 1：3ch

CHANNEL VALUE FUNCTION
CH1 0-255 RED
CH2 0-255 GREEN
CH3 0-255 BLUE
DMX mode 2：4ch
CHANNEL VALUE FUNCTION
CH1 0-255 RED
CH2 0-255 GREEN
CH3 0-255 BLUE
CH4 0-255 MASTER
DIMMER
DMX mode 3：6ch
CHANNEL VALUE FUNCTION SECTION
CH1 0-255 RED
1
CH2 0-255 GREEN
CH3 0-255 BLUE
CHANNEL VALUE FUNCTION SECTION
CH4 0-255 RED
2
CH5 0-255 GREEN
CH6 0-255 BLUE
DMX mode 4：7ch
CHANNEL VALUE FUNCTION
CH1 0-255 RED
CH2 0-255 GREEN
CH3 0-255 BLUE
CH4 0-255 MASTER
DIMMER
0-6 CH1~ CH4
DIMMER
7-13 PR.01
14-20 PR.02
21-27 PR.03
28-34 PR.04
35-41 PR.05
42-48 PR.06
49-55 PR.07
56-62 PR.08
63-69 PR.09
70-76 PR.10
77-83 PR.11
84-90 PR.12

CH5
CH5
91-97 PR.13
98-104 PR.14
105-111 PR.15
112-118 PR.16
119-125 PR.17
126-132 PR.18
133-139 PR.19
140-146 PR.20
147-153 PR.21
154-160 PR.22
161-167 PR.23
168-174 PR.24
175-181 PR.25
182-188 PR.26
189-195 PR.27
196-202 PR.28
203-209 PR.29
210-216 PR.30
217-223 PR.31
224-230 PR.32
231-237 PR.33
238-244 PR.34
245-251 PR.35
252-255 Sound Mode
CH6 0-255 Sound Sensitivity+speed
CH7
0-15 NO FUNCTION
Sound Mode :S1
16-84 Strobe(R\G\B DIMMER、
PR.XX)
Sound Mode :S1
85-169
Strobe(R\G\B DIMMER、
PR.XX)
Sound Mode :S2
170-255 Strobe(R\G\B DIMMER、
PR.XX)
Sound Mode :S3
DMX mode 5：9ch
CHANNEL VALUE FUNCTION SECTION
CH1 0-255 RED
1
CH2 0-255 GREEN

CH3 0-255 BLUE
CH4 0-255 RED
2
CH5 0-255 GREEN
CH6 0-255 BLUE
CH7 0-255 RED
3
CH8 0-255 GREEN
CH9 0-255 BLUE
DMX mode 6：12ch
CHANNEL VALUE FUNCTION SECTION
CH1 0-255 RED
1
CH2 0-255 GREEN
CH3 0-255 BLUE
CH4 0-255 RED
2
CH5 0-255 GREEN
CH6 0-255 BLUE
CH7 0-255 RED
3
CH8 0-255 GREEN
CH9 0-255 BLUE
CH10 0-255 RED
4
CH11 0-255 GREEN
CH12 0-255 BLUE
DMX mode 7：18ch
CHANNEL VALUE FUNCTION SECTION
CH1 0-255 RED
1
CH2 0-255 GREEN
CH3 0-255 BLUE
CH4 0-255 RED
2
CH5 0-255 GREEN
CH6 0-255 BLUE
CH7 0-255 RED
3
CH8 0-255 GREEN
CH9 0-255 BLUE
CH10 0-255 RED
4
CH11 0-255 GREEN
CH12 0-255 BLUE
CH13 0-255 RED
5
CH14 0-255 GREEN
CH15 0-255 BLUE
CH16 0-255 RED
6
CH17 0-255 GREEN
CH18 0-255 BLUE

DMX mode8：36ch
CHANNEL VALUE FUNCTION SECTION
CH1 0-255 RED
1
CH2 0-255 GREEN
CH3 0-255 BLUE
CH4 0-255 RED
2
CH5 0-255 GREEN
CH6 0-255 BLUE
CH7 0-255 RED
3
CH8 0-255 GREEN
CH9 0-255 BLUE
CH10 0-255 RED
4
CH11 0-255 GREEN
CH12 0-255 BLUE
CH13 0-255 RED
5
CH14 0-255 GREEN
CH15 0-255 BLUE
CH16 0-255 RED
6
CH17 0-255 GREEN
CH18 0-255 BLUE
CH19 0-255 RED
7
CH20 0-255 GREEN
CH21 0-255 BLUE
CH22 0-255 RED
8
CH23 0-255 GREEN
CH24 0-255 BLUE
CH25 0-255 RED
9
CH26 0-255 GREEN
CH27 0-255 BLUE
CH28 0-255 RED
10
CH29 0-255 GREEN
CH30 0-255 BLUE
CH31 0-255 RED
11
CH32 0-255 GREEN
CH33 0-255 BLUE
CH34 0-255 RED
12
CH35 0-255 GREEN
CH36 0-255 BLUE
4.Sound active mode
-- Press MODE button ,enter sound active mode “SOUN”
Press SETUP button ,enter setup sound active mode and sensitivity menu “S×.××”

Press UP or DOWN button more than 2 seconds then release ,switch over sound active mode S1.××、
S2.××、
Press UP or DOWN button ,setup the go on direction of sound active sensitivity value S1.00～S1.31、
S2.00～S2.31、S3.00～S3.31 & S1.××、S2.××
5.Slave mode
-- Press MODE button ,enter slave mode “SLAV”
*The running effect program of master light is the same with all slave light
6.Static color mode
-- Press MODE button ,enter static color mode “CL.××”
Press UP or DOWN button ,changing over static color CL.r-，CL.g-，CL.b-
