EN1210EOL Single Input Universal with
EOL
Installation Instructions
1 Overview
The Inovonics EN1210EOL single input universal with EOL is a
universal transmitter with an end of line resistor. The included
2.2k ohm resistor is required to operate the EN1210EOL.
The single input universal with EOL is available in North
America, Australia and New Zealand; the radio frequency band
has been configured for the appropriate geographic area at the
factory.
1.1 Inovonics Contact Information
If you have any problems with this procedure, contact Inovonics
Wireless technical services:
• E-mail: [email protected].
• Phone: [phone].
1.2 Single Input Universal with EOL Internal
Components
Figure 1 Single input with EOL universal components
1.3 What’s In The Carton
• Three wall mount screws.
• Three wall mount anchors.
• One selection jumper.
• One 3.0V lithium battery.
• One 2.2K ohm end of line resistor.
2 Installation and Startup
2.1 Installation Notes
• These products are designed to be installed and maintained
by professional security technicians.
• Products are intended for indoor use.
• Manually test all products weekly.
2.2 Install the Battery
1. Pry the top lip of the mounting bracket up, and lift the bracket
off of the transmitter.
2. Use your thumb to depress the housing release tab on the
bottom of the transmitter; separate the housing.
3. Install the battery.
4. Press the reset button to initialize the transmitter.
2.3 Select Input Type
The N/O-N/C selection pins allow the choice of a normally open
or normally closed state for the contact circuit wired to the input
terminal. The transmitter is shipped set for normally closed, with
no selection jumper on the N/O - N/C selection pins.
Set for Normally Open Operation
1. Place a selection jumper on the selection pins to select
normally open.
2. Wire the 2.2K ohm resistor in parallel with the N/O contact
per Figure 2.
3. Press the reset button to complete configuration.
Figure 2 Wired for N/O operation
Set for Normally Closed Operation
1. Remove the selection jumper from the selection pins.
2. Wire the 2.2K ohm resistor in series with the N/C contact per
Figure 3.
3. Press the reset button.
Figure 3 Wired for N/C operation
2.4 Register the EN1210EOL
Transmitters must be registered with the system in order to be
monitored and supervised. Transmitters send a check-in
message every three minutes. Each transmitter has a unique
factory-programmed identification number.
Refer to the receiver installation instructions for details on
registering a transmitter.
1. When prompted by the receiver to reset transmitter, press
the reset button.
2. Replace the cover.
3. Test the EN1210EOL by activating each of the conditions
and ensuring an appropriate response.
For product and installation videos visit us at
www.inovonics.com/videos or use the QR
code below.
AHousing tamper button BNO/NC selection pins
CTer m ina l b l o c k DReset button
ABC
D

8/13/19 357-04857-02 Rev A © Inovonics, 2019 - www.inovonics.com
2.5 Mount the Transmitter
1. Mount the bracket on the wall with the screws provided.
Figure 4 Mount the bracket
2. Clip the transmitter onto the bracket. Hook the bottom catch
first, then press the top into place.
3. As desired, use the third mounting screw to secure the
housing through the screw hole located beneath the battery.
Note: Accessing this screw on an active transmitter requires
opening the housing and removing the battery, causing a tamper
condition.
4. Replace the housing cover.
3 Specifications
Note: A 2.2K ohm resistor is required to operate the
EN1210EOL.
External contacts: N/O or N/C
Distance, external contact to EN1210EOL: 3 meters (10 feet)
maximum
Typical battery life: 3-5 years
Battery type (BAT604): Panasonic CR123A or equivalent
Operating environment: -20° to 60°C (-4° to 140°F),
noncondensing.
Note: Inovonics supports recycling and reuse whenever
possible. Please recycle these parts using a certified electronics
recycler.
Note: Specifications and data are subject to change without
notice.
