ioi FWBU2SATA35DMR User manual

2
1
Panel Introduction
Jumper
Key lock
Power Indicator and HDD Access Indicator
To remove the tray, grab the mobile tray firmly
and pull the tray from the housing gently.
How to Install the SATA HDD
2-1
1-1
1-2
2-2
Installation Guide
Mirror Drive
To install the SATA HDD, simply place the HDD
inside the tray as illustrated below. (A stopper in
the rear of the tray is provided to avoid careless
handling.)
After placing the HDD inside the tray, adjust and
secure the HDD with the provided screwdriver
and four hex-head #6-32 UNC screws.
SATA connector
1. RAID Setting Switch
2. FireWire Connector
3. USB B Connector
4. DC Power Jack (12V/4.16A)
5. Power Switch
6. Cooling Fan
7. Key lock
8. SATA HDD Mobile Tray
9. HDD 1 Status LED
(Green & Red)
10. HDD 2 Status LED
(Green & Red)
1-3
1-4
To insert the tray, grab the mobile tray firmly and push
the mobile tray back into the housing.
A
B
Security status
Locked (Non-removable)
Unlocked (Removable)
Status
Segment
B
A
According different statuses, the indicator displays are as followed:
- Non-RAID: for one or two disks
- RAID 0 (Striping): for two disks with same capacity.
- Disk Spanning: for two disks with different capacity.
- RAID 1 (Mirroring): for two disks with same capacity.
1
2
3
4
5
6
9
10
Normal State
HDD 1 Failed
HDD 2 Failed
HDD 1 under Rebuilding
HDD 2 under Rebuilding
HDD Duplicating
is completed
Green Green
Green Green
Green Red
Red Green
Red/Orange Green
Blinking
Blinking
Green Red/Orange
Blinking
Blinking
Status Display
A
B
How to Remove and Insert the Mobile Tray
A
A
To unlock the tray, insert the key and push to turn
the lock to Position A.
Note: The key cannot be removed when the lock is in Position A.
HDD1 HDD2
To lock the tray in place, turn the lock back to
Position B.
Note: The key can be removed while the lock is in Position B.
B
B
7
8
FWBU2SATA35DMR/UF2SATA35DMR/UFISATA35DMR/U2SATA35DMR
FireWire-6pin (only for UF2SATA35DMR)
Bilingual-9pin (only for FWBU2SATA35DMR)
FireWire-6pin + iLink-4pin (only for UFISATA35DMR)
2
1
T-shape screw driver
Hex-head #6-32 UNC
2

34
How to install AC-to-DC power adapter
The Mirror Drive and the computer can be connected
by using either USB 2.0 or FireWire (IEEE 1394) serial
bus in a plug-and-play fashion.
3-1
4-1
4-2
3-2
3-3
Attach the DC power plug to the DC input of
the Mirror Drive.
Push the power switch to on/off (1/0) of the
mirror drive.
Plug one end of the AC power cord to the AC-
to-DC power adapter and the other end to the
AC power socket.
AC Input
DC Output
JENTE C TECH NOLO GY CO. ,LTD .
AC AD APTOR
MOD EL : JTA0 20 2Y
AC I NP UT : 1 00 -2 40 Vac/ 1. 2A
50 -6 0H z
DC O UTPUT : +5 V/ 2A ,+ 12 V/ 2A
LISTE D
E227163
43DG
I.T.E.
N136
Q03305
KETI -HU1 017 0-30 01
Mad e in C hi na EL
D33 19 0
+5V+5V
RTNRTN
+12V+12V
CAUTION:
RISK OF ELECTRIC
SHOCK
DRY LOCATION ONLY
INDOOR USE ONLY
Turn on Turn off
Note: Push the power switch to turn off the power before
you attach the DC Power plug to the DC input.
How to connect the mirror drive and the computer
USB A plug to B plug cable
FireWire plug to FireWire plug cable
Beta plug to Beta plug cable
iLink plug to FireWire plug Cable
Through USB connection:
use USB A-plug-to-B-plug cable.
Through FireWire (IEEE 1394) connection:
Turn off
Power Code
Europ North America British Standard
(EN 50075) (NEMA 1-15P) (B5 1363A)
Installation Guide
Mirror Drive
Only For FWBU2SATA35DMR
Only For UF2SATA35DMR
Only For UFISATA35DMR
2
FWBU2SATA35DMR/UF2SATA35DMR/UFISATA35DMR/U2SATA35DMR

5-1
5-2
5
6
How to Set Up Non-RAID, Spanning, and
Striping
How to Set Up Mirroring (RAID 1)
To install one or two SATA HDDs, see 1.1 to 1.4.
- Non-RAID: for one or two disks
- RAID 0 (Striping): for two disks with same capacity.
- Disk Spanning: for two disks with different capacity.
RAID 1 initialization
The system will write RIB into both HDD.
To set different RAID modes, see the
illustration shown below.
6-1 To set the mirroring mode, see the
illustration shown below.
Note: Striping & Spanning need to install 2 HDDs.
HDD1 HDD2
6-2-1
6-2-2
6-2
To install two HDDs, see 1.1 to 1.4.
After installing the two HDDs, power up the
Mirror Drive. The two HDDs will be initialized
as a RAID 1 pair. The host connection can be
enabled through either USB or FireWire
(IEEE 1394).
HDD1 HDD2
Pre-Requisites for Disk-Mirroring
- Although It is preferable that drives share the same manufacturer
and model type, it is not mandatory.
- "Target Drive" must be equal or bigger capacity than the "Source
Drive".
Note: Any data on the HDDs will be lost.
Installation Guide
Mirror Drive
To partition and format a disk, connect the Mirror
Drive to the host through USB or FireWire 1394
port and perform one of the following
Windows XP
right-click "My Computer"
click "Manage"
click "Disk Management"
the disk appears in the lower right-hand corner.
See the Windows help for further guidance.
Mac OS X
when you connect the disk, the operating system
should prompt you to initialize the disk; otherwise,
run "Disk Utility".
Note: We recommend that you use a journalled file system, such as
NTFS or journalled MacFS.
Note: RIB =RAID Information Block.
3
FWBU2SATA35DMR/UF2SATA35DMR/UFISATA35DMR/U2SATA35DMR

6-4
Installation Guide
Mirror Drive
Managing Disk Failures
When one Hard Disk Drive is broken-down, the Error
indicator LED (Red color) will turn on, you may know
which HDD is broken down.
6-4-1 To replace the disk, unmount it from the host (for
Windows systems, use safe removal; for Mac OS,
use eject), disconnect the host connection and power
down the "Mirror Drive".
6-4-2 Replace the failing disk with one of equal or large capacity
and power up the "Mirror Drive" again
6-4-3 The "Auto-Rebuild" function will copy the content
of the "Source Drive" into the "Target Drive" automatically.
When "Auto-Rebuild" is completed, the indicator LEDs
will return to normal status.
HDD 1 Failed
HDD 2 Failed
Green Red
Red Green
HDD Duplicating
is completed
Green Green
6-3-1 Install HDD1 (the drive for the data and software).
See 1.1 to 1.4 for HDD installation instruction.
6-3-2
6-3-3 Power off the mirror drive and install the second
HDD (HDD2) (the "Target Drive").
Power on the "Mirror Drive" and the "Auto-Rebuild"
function will copy the content of the "Source Drive"
into the "Target Drive" automatically. When the duplication
is completed, data in these two HDDs are synchronous.
6-3-4
Note: HDD2 LED is red
Red
Power on the Mirror Drive. The system will
write RIB into HDD1 (the "Source Drive").
6-3 RAID 1 Backup
You may have system write RIB into one HDD
first, and then use "Auto-Rebuild Function"
to copy the content of the first HDD into the
other HDD. When the duplication is completed,
data in these two HDDs are synchronous.
HDD 1 HDD 2
rebuilding
Green Orange/Red
Blinking Blinking
Turn off
Note: RIB =RAID Information Block.
Windows (safe removal)
Mac OS (safe removal)
HDD1
HDD2
Disconnect
Turn on
Turn on
Turn on
Turn off
4
FWBU2SATA35DMR/UF2SATA35DMR/UFISATA35DMR/U2SATA35DMR
