ION TIGER User manual

TIGER
Instrument User Manual V3.10
Unrivalled Gas Detection. ionscience.com

Unrivalled Gas Detection. Page 2 of 72 ionscience.com
Register your instrument online for extended warranty
Thank you for purchasing your ION Science instrument.
The standard warranty of your instrument can be extended to five years.
To receive your extended warranty, you must register your instrument online
within one month of purchase (terms and conditions apply.)
Visit ionscience.com/instrument-registration.

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 3 of 72 ionscience.com
Warning

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 4 of 72 ionscience.com
Avertissement

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 5 of 72 ionscience.com
Contents
1. Safety .....................................................................................................................................8
Legal Notices Regarding the Safe Operation of Equipment...............................................................8
Symbols...............................................................................................................................................8
Warnings and Cautions and Information notifications ......................................................................8
Disposal...............................................................................................................................................9
2. Product Overview ................................................................................................................. 10
Upgrades...........................................................................................................................................12
TigerPC Software ..............................................................................................................................12
TIGER Kit ...........................................................................................................................................12
Keypad Function Descriptions ..........................................................................................................13
3. Getting Started ..................................................................................................................... 14
Fitting the Inlet Probe.......................................................................................................................14
Switching your TIGER On ..................................................................................................................14
Switching your TIGER Off..................................................................................................................14
Checking the Battery Charge............................................................................................................15
Select the Gas ...................................................................................................................................15
Set Alarm Levels................................................................................................................................15
4. Understanding the Display Screen ......................................................................................... 16
Overview...........................................................................................................................................16
Status Icons.......................................................................................................................................17
Soft Key Options ...............................................................................................................................18
5. Using the TIGER..................................................................................................................... 19
Turning On / Off................................................................................................................................19
Turning On .....................................................................................................................................19
Turning Off.....................................................................................................................................19
Setup Functions ................................................................................................................................19
6. Using the TigerPC Software and Downloading Data................................................................ 24
PC Requirements ..............................................................................................................................24
Installation of TigerPC Software .......................................................................................................24
Connecting a TIGER to a PC ..............................................................................................................24

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 6 of 72 ionscience.com
Opening TigerPC ...............................................................................................................................25
Help Screen.......................................................................................................................................26
The Instruments List .........................................................................................................................27
Downloading Data Logged Readings and Instrument Settings .....................................................27
Taking Snapshots ...........................................................................................................................29
Instrument Summary Screen.........................................................................................................30
Features Screen .............................................................................................................................31
Configuration Screen .....................................................................................................................32
Gas Table Screen............................................................................................................................40
Firmware Screen............................................................................................................................42
Datalog Screen...............................................................................................................................44
Health & Safety Screen..................................................................................................................45
Snapshots Screen...........................................................................................................................46
7. Calibration ............................................................................................................................ 50
Calibration ........................................................................................................................................50
Custom Calibration ........................................................................................................................50
8. Maintenance......................................................................................................................... 53
TIGER Parts Diagram.........................................................................................................................53
Batteries............................................................................................................................................54
Battery Packs .................................................................................................................................54
Recharging Batteries......................................................................................................................54
Replacement of Rechargeable Battery Packs................................................................................55
Replacement of Non-rechargeable Batteries................................................................................56
Inlet Probe Assembly........................................................................................................................57
PTFE Filter Disc..................................................................................................................................58
Probe Seal.........................................................................................................................................58
Water Ingress....................................................................................................................................58
Lamp Cleaning and Electrode Stack Replacement ...........................................................................58
When to Clean or Replace the Lamp .............................................................................................58
When to Replace the Electrode Stack ...........................................................................................59
Removing the MiniPID 2 Sensor ....................................................................................................59

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 7 of 72 ionscience.com
Lamp Removal and Examination ...................................................................................................60
Lamp Cleaning................................................................................................................................60
Replacing a Lamp...........................................................................................................................61
Replacing the MiniPID Electrode Stack..........................................................................................62
9. Troubleshooting.................................................................................................................... 64
Diagnostics........................................................................................................................................64
10.Appendix and Supporting Documents.................................................................................... 65
EU Declaration of Conformity...........................................................................................................65
Technical Specifications....................................................................................................................67
Warranty...........................................................................................................................................68
ION Science Contact Details .............................................................................................................69
UK and Head Office........................................................................................................................69
USA Office ......................................................................................................................................69
German Office................................................................................................................................69
Italian Office...................................................................................................................................69
French Office..................................................................................................................................69
Chinese Office................................................................................................................................69
Indian Office...................................................................................................................................69
Manual Log .......................................................................................................................................70

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 8 of 72 ionscience.com
1. Safety
Legal Notices Regarding the Safe Operation of Equipment
•Whilst every attempt is made to ensure the accuracy of the information contained in this
manual, ION Science accepts no liability for errors or omissions in the manual, or any
consequences deriving from the use of information contained herein. It is provided “as is”
and without any representation, term, condition or warranty of any kind, either expressed
or implied.
•To the extent permitted by law, ION Science shall not be liable to any person or entity for
any loss or damage which may arise from the use of this manual.
•We reserve the right at any time and without any notice to remove, amend or vary any of
the content which appears in this manual.
Symbols
WARNING!
USED TO INDICATE DANGER WARNINGS WHERE THERE IS A RISK OF INJURY OR
DEATH.
Caution
Used to indicate a caution where there is a risk of damage to equipment.
Information
Important information or useful hints about usage.
Recycling
Recycle all packaging.
WEEE Regulations
Ensure that waste electrical equipment is disposed of correctly.
Warnings and Cautions and Information notifications
The following apply to the product described in this manual.
BATTERY CHARGING: CHARGE THE TIGER AND ITS LITHIUM BATTERY PACKS IN A
NON HAZARDOUS ENVIRONMENT ONLY.
The instrument should be used in accordance with the safety standards and
installation instructions given in this manual, and in compliance with local safety
standards.

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 9 of 72 ionscience.com
Responsibility for use: TIGER instruments detect a large range of gases which are
potentially dangerous from both a poisoning and/or an explosive perspective.
TIGER instruments have many adjustable and selectable features allowing the
instrument to be used in a variety of ways.
ION Science Ltd can accept no responsibility for the incorrect adjustment of
features that cause harm or damage to persons or property. TIGER can be used
as a personal safety device. It is the user’s responsibility to respond
appropriately to an alarm situation.
The TIGER must not be exposed to atmospheres known to have an adverse
effect on Thermoplastic polyolefin or Anti-static PC/ABS.
The instrument must be serviced in a Non-Hazardous environment and by ION
Science Ltd authorised service centres only. Substitution of components may
impair intrinsic safety.
Do not service the instrument live; Remove the Battery Pack before servicing.
Ingress Protection: Continuous exposure to wet weather conditions should be
limited to less than one day and harsh water spray conditions should be
avoided.
When using the Probe part numbers A-861414, A-861413 the Safety rating of the
TIGER Instrument drops from II 1 G Ex ia IIC T4 Ga to II 1 G Ex ia IIB T4 Ga. The
temperature performance of the unit is unaffected.
Disposal
•The equipment does not include any toxic materials, but if it has been contaminated by toxic
materials, then exercise due care and follow the appropriate regulations when disposing.
•Always adhere to local regulations and procedures when disposing of the equipment.
RECYCLING
Recycle all Packing.
WEEE REGULATIONS
Ensure that all waste electrical equipment is disposed of correctly.
Ion Science Ltd offer a take back service. Please contact us for more
information.

TIGER Instrument User Manual V3.10
Unrivalled Gas Detection. Page 10 of 72 ionscience.com
2. Product Overview
The TIGER is a portable gas detector that uses photo-ionization technology to detect a large range of
Volatile Organic Compounds (VOCs) which can be dangerous from both a poisoning and explosive
perspective.
The TIGER uses a Photo-Ionization Detector (PID) to measure gas concentrations. The patented
fence electrode technology minimises the effects of moisture and contamination, avoiding the need
for compensation.
Survey is the default mode of operation. This mode is often used in applications such as Head Space
Sampling and Leak Detection where several areas (or Zones) are to be monitored and readings data
logged. All sensor readings are real time measurements and alarm levels are set manually.
Health and Safety mode (optional) is used to check for conformity of short-term exposure levels
(STEL) or time- weighted averages (TWA) that are specific for particular hazardous environments (for
example EH40 in the UK and OSHA in the USA). In this mode of operation STELs and TWAs are
continually calculated and compared to levels set in the instrument’s gas table.
The TIGER has an intuitive graphical interface allowing easy access to instrument settings. Two keys
Aand Bcan be configured to suit the user’s application, so many functions can be
selected without entering the main menu structure. This improves efficiency of use, particularly with
repeatable tasks.
The TIGER has been designed and certified Intrinsically Safe.
