ION ANYROOM User manual

Confidential ION Audio Service Manual
ION Audio
ANYROOM
[iSP06]
Service Manual
Rev. 1
2011.06.09
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by ION Audio. If you are not the authorized, intended
recipient, you are hereby notified that any review, dissemination, distribution or duplication of this
document is strictly prohibited. If you are not authorized, please contact ION Audio and destroy
Copyright ION Audio, LLC
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH ION AUDIO, LLC.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT

Confidential ION Audio Service Manual
PREFACE
This document is intended to assist the service technician in the operation, maintenance and
repair of the ION Audio device. Together with the User Reference Manual, this document
provides a complete description of the functionality and serviceability of the Device. Any
comments or suggestions you may have pertaining to the document are welcome and
encouraged.
READ THIS!
In addition to any purchase price that ION Audio may charge as consideration for ION Audio
selling or otherwise transferring this service manual (“Manual”) to you, if you are not a service and
repair facility (“Service Center”) authorized by ION Audio in writing to be an authorized Service
Center, ION Audio sells or transfers the Manual to you on the following terms and conditions:
Only Service Centers authorized by ION Audio in writing are authorized to perform service and
repairs covered by an ION Audio warranty (if any), and transfer of the Manual to you does not
authorize you to be an authorized Service Center. Therefore, if you perform, or if the Manual
is used to perform, any service or repairs on any ION Audio product or part thereof, any
and all warranties of ION Audio as to that product and any service contract with ION Audio
for that product shall be voided and shall no longer apply for such product, even if your
services or repairs were done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your
responsibility, and ION Audio shall have no liability for any such repairs or service work. All such
service or repairs are performed at the sole risk of the person performing the service or
repairs. You agree that all such work will be performed in a competent, professional and safe
manner at all times and to indemnify and fully hold ION Audio and its successors and assigns
harmless in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of
resale or other transfer.
As the owner of the copyright to the Manual, ION Audio does not give you the right to copy the
Manual, and you agree not to copy the Manual without the written authorization of ION Audio.
ION Audio has no obligation to provide to you any correction of, or supplement to, the Manual, or
any new or superseding version thereof.
ION Audio shall have the right to refuse to sell or otherwise transfer repair parts or materials to
you in its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts
supplied by ION Audio to you (i) to repair or be used in products manufactured for or by third
parties or (ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of ION Audio or the
use thereof on behalf of ION Audio or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you,
and no other terms shall apply unless in a writing signed by an authorized representative of ION
Audio.
All Trademarks are property of their respective companies.

Confidential ION Audio Service Manual
WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE
THIS PRODUCT TO WATER OR MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the enclosed product which may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point inside a triangle is intended to alert the user
to the presence of important operating, maintenance and servicing
instructions in the literature which accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ION
AUDIO SERVICE CENTER WILL VOID THE ION AUDIO WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO
COMPETE WITH ANY ION AUDIO DISTRIBUTOR OR AUTHORIZED REPAIR
SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE
OR MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED ION
AUDIO SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF
THAT ENTITY, AND ION AUDIO SHALL HAVE NO LIABILITY TO THAT
ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
CAUTION: The product under service may employ the use of a
replaceable fuse. Danger of fire or electrocution if fuse is incorrectly
replaced. Replace with only the same type or equivalent type
recommended by the equipment manufacturer.
Regarding the Internal Battery
CAUTION: The product under service may employ the use of a
internal battery. Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instruction.

Confidential ION Audio Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions
before using this product. Use extra care to follow the warnings written on the product itself and in
the operating instructions. Keep the operating instructions and safety suggestions for reference in
the future.
1. Power Source. The product should only be connected to a power supply which is described
either in the operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely to
step on the cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the product's
AC power supply cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into any
openings of the product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators or
other heat producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate
ventilation. Improperly ventilating the product may cause overheating, which may damage the
product.
8. Mounting. The product should only be used with a rack which the manufacturer
recommends. The combination of the product and rack should be moved carefully. Quick
movements, excessive force or uneven surfaces may overturn the combination which may
damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in
the operating instructions for the user. For any other service required, the product should be
taken to an authorized service center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain
situations including without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate
normally, or
e. The enclosure of the product has been damaged.

P/N Part Name Spec Unit Q'ty
RoHS finished product:ISP06(Any Room) ISP06(Any Room) PCS 0
DR000311 RoHS semi-finished product for assembly:ISP06 ISP06 PCS 1
40010034 power jack AN-J0134,DB-8-6S 2.5A/250V PCS 1
16140548 multi-cored wire 18#,UL1617,10+80+10mm,red,with no skin10mm on both ends,tinning PCS 1
12030023 rocker switch AN-S323,PS8A-2-B1B3-1H,(0.8T),printing I/O PCS 1
12070006 voltage selecting switch AN-S706,PS10-4,12A,125/250VAC,seal PCS 1
17050013 onpolarity Electronic Capacity 4.7uF/50V,±20%,-40/+85℃,Φ6*17mm, PCS 2
80220007 3" woofer ISP06,AN-LN07,3" woofer,4ohm,8w PCS 2
10400044 name plate DN-ME4023,aluminum,47*17*1mm.V1.0 PCS 1
56250005 name plate ISP06 DN-ME4023,name plate,silkscreen color cold gray 3C, V1.0 PCS 1
10410111 grill DN-ME5073,SPCC,405*198.68mm,T=0.6mm,V1.0 PCS 1
20290016 bracket DN-PB0017,ABS,black,V1.0 PCS 2
20080020 rear cover DN-PC8018,ABS,black,black printing on surface,V1.0 PCS 1
20130010 PVC sheet DN-PL3010,200*170mm,T=1.0MM,PVC,black PCS 1
10110437 rear panel DN-MC3112,SPCC,160*110*1.5mm,material with barked varnish,V1.0 PCS 1
56270001 rear panel ISP06,DN-MC3112,silkscreen 429C,V1.0 PCS 1
10520160 lock block DN-ME0090,W23-102-2B, PCS 2
30060163 foam 10*1000*1mm,fireproofing EVAE1030 PCS 2
70010082 screw AN-C10082,M3*8mm,cross-round head, head D5.5mm,black PCS 4
70010218 screw AN-C10218,M4*12mm,cross-round head, head D7mm, PCS 2
70010087 screw Φ3*8mm,cross-round head, head D5.5mm, PCS 2
10280010 L shaped bracket DN-MB8016,32*8.0*1.5mm,SPCC,zinc plated PCS 1
20210086 knob DN-PN2060,ABS,black with rubber painting on the surface(knob 2) PCS 1
20300088 foot pad black rubber,T=3.0mm,LS-1803, PCS 4

20630037 transformer pad 27.5*22*1.0mm,black rubber,V1.0 PCS 1
70010193 screw AN-C10193,M4*7mm,cross-round head, head D7mm, PCS 1
70090032 gasket Φ8*Φ4.2*1mm,steel,flat gasket,black zinc PCS 2
70090038 gasket Φ8*Φ5.2*1.5mm,spring sttel,spring gasket,black zinc PCS 2
70070002 hexnut Φ8*M4*3mm,black zinc PCS 2
70010073 screw M3*7mm,cross-round head, head D7.5mm, PCS 2
20260029 LED tube LED3B-7,Φ4*7mm PCS 2
70010556 screw Φ2.6*6mm,cross-round head with pad, head D7.0mm, PCS10
70010111 screw Φ3*10mm,cross-round head, head D5.5mm, PCS 28
30090001 bunch 2.5*80mm,white PCS 2
70010605 screw Φ2.6*7mm,cross-round head, head D4.5mm, PCS 4
24100028 magnet ring SRH16*16*8-B PCS 2
19020009 glass tube fuse 500mA/250V,Φ5*20mm,low seperated capacity(UL&EU certification) PCS 1
30010046 shrinkable tube Φ25*40*0.45mm,UL PCS 2
30010014 shrinkable tube Φ4*15*0.20mm,UL PCS 3
30010010 shrinkable tube Φ3*15*0.20mm,UL PCS 2
30090002 bunch 2.5*80mm,black PCS 8
11130225 carbon resistor 1/4W,4.7KΩ,±5% PCS 1
11130232 carbon resistor 1/4W,10K,±5% PCS 2
11140549 metal film resister 1/2W,100Ω,±1%, PCS 2
50010068 ceramic capacitor 104,VDC100,±20%,Y5V,brown OD=8mm PCS 8
17010191 electrolytic capacitor 100uF/25V,±10%,-40/+85℃,Φ6.3*11m,P=2.5mm,black,cut pin 4mm PCS 2
17010193 electrolytic capacitor 100uF/35V,±20%,-40/+85℃,Φ6.3*11mm,P=2.5mm,black,cut pin 4mm PCS 1
17010280 electrolytic capacitor 1000uF/16V,±20%,-40/+85℃,Φ10*16mm,P=5mm,black,cut pin 4mm PCS 2
17010294 electrolytic capacitor 1000uF/35V,±20%,-40/+85℃,Φ13*20mm,P=5mm,black,cut pin 4mm PCS 3

17010319 electrolytic capacitor 3300uF/50V,±20%,-40/+85℃,Φ18*35mm,P=7.5mm,black,no cut pin PCS 1
18030160 zener diode DO-41,1W,24V PCS 1
18030010 zener diode AN-D30010,DO-41,1W,15V,1N4744 PCS 2
18010017 diode AN-D10017,DO-41,1N4004, PCS 8
14010057 NPN triode TIP102,TO220,ST PCS 1
18020007 rectifier bridge DIP,RS406L PCS 1
14040030 IC L7805CV,TO220 PCS 1
18040153 LED AN-L0153,GL-DSBK14003,Φ3*5.8mm, PCS 1
40370001 male jack AN-JP401,HT-2.5-02P-01A PCS 1
40370103 male jack AN-JP410,3961-07,P=3.96mm,180 deg C PCS 1
16040295 plug wire AN-W4B3,2P,24#,UL1007,80mm,black and red PCS 1
16010360 coloe ribbon wire AN-W226,7P,22#,UL1007,80mm,red black red black red black red PCS 1
10070010 crystal radiator DN-MH7003,15*23*10.5,aluminum,natural color,material only(single fixed pin) PCS 1
30050006 mica film 13*18*0.1mm,transparent with 1 hole PCS 1
20500001 insulation bead W06-263A(material:NYLON46;fireproof level:94V-0) PCS 1
70010517 screw AN-C10517,M3*9mm,cross-round head, head D5.5mm, PCS 1
10250078 bracket PCB-2(M3),U style PCS 2
26010387 PCB ISP06,POWER FR4 2 layer,AN-B10349, PCS 1
50050052 SMT ceramic capacitor 102,VDC50,±10%,X7R,0603 PCS 4
11110297 metal oxide film resitance 1/4W,10Ω,±5%, PCS 4
50020048 Polyester capacity 471,VDC100,±5%, P=3.5mm, PCS 2
50030011 metallized mylar capacitor 104,VDC63,±5%,yellow,7.2(W)*6.5(H)*2.5(T) PCS 2
50030133 metallized mylar capacitor 684,VDC63,±5%,yellow,7.2(W)*11(H)*6(T) PCS 2
17050005 nonpolarity Electronic Capacity 1uF/50V,±10%,-40/+85℃,Φ5*11mm,P=2.0mm,black,4mm pin PCS 4
17010103 electrolytic capacitor 10uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black,cut pin 4mm PCS 16

17010168 electrolytic capacitor 47uF/16V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black,cut pin 4mm PCS 1
17010119 electrolytic capacitor 100uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black,cut pin 4mm PCS 4
17010256 electrolytic capacitor 470uF/25V,±20%,-40/+85℃,Φ8*14mm,P=3.5mm,black,cut pin 4mm PCS 1
17010287 electrolytic capacitor 1000uF/25V,±20%,-40/+85℃,Φ10*16mm,P=5mm,black,cut pin 4mm PCS 2
17010294 electrolytic capacitor 1000uF/35V,±20%,-40/+85℃,Φ13*20mm,P=5mm,black,cut pin 4mm PCS 1
24100002 magnetic bead 9*0.8*3.5mm,±25%,RH03509ST-B246 PCS 1
40370098 male jack AN-JP410,3961-02,P=3.96mm,180 deg C PCS 2
40370006 male jack AN-JP401,HT-2.5-07P-01A PCS 1
18040031 LED AN-L0031,DIP,Φ2.8*4.6,GL-HHR14311, PCS 1
18040033 LED AN-L0033,DIP,GL-UEG14311 PCS 1
40190105 RCA jack AN-J1997,RCA-210A,left red and right white,gold-plating PCS 2
12040026 Tact Switch AN-S426,TS-1168V-160 PCS 1
15010410 rotary potensionmeter AN-V1113,A10K,RA1150GOX0E-VA1-054 ,L=20mm,H=10mm, PCS 1
16040667 plug wire AN-W4237,2P,20#,UL1015,400mm,black and red PCS 2
24060087 magnetic core inductance AN-I6088,22uH,3.5A,RIDR1010-220,ZKH666DR1010-6433, PCS 2
24060093 magnetic core inductance AN-I6083,Φ0.8,2.5mH,T160905-182, PCS 1
40360090 needle AN-JP315,P101-1*06SGF PCS 1
40360357 needle AN-JP420,P101-1*04SGF PCS 1
26020481 PCB ISP06,PRE&,FR4 2 layer PCS 1
11170009 SMT resistor 1/8W,10Ω,±5%,0805 PCS 1
11170364 SMT resistor 1/10W,100Ω,±5%,0603 PCS 2
11170483 SMT resistor 1/10W,1KΩ,±1%,0603 PCS 4
11170517 SMT resistor 1/10W,4.7KΩ,±1%,0603 PCS 11
11170536 SMT resistor 1/10W,10KΩ,±1%,0603 PCS 12
11170388 SMT resistor 1/10W,1.5KΩ,±5%,0603 PCS 4

11170414 SMT resistor 1/10W,22KΩ,±5%,0603 PCS 4
11170419 SMT resistor 1/10W,39KΩ,±5%,0603 PCS 1
11170429 SMT resistor 1/10W,100KΩ,±5%,0603 PCS 12
24010002 SMT magnetic bead 2.0*1.2mm,120Ω,±25%,FB2012-121 PCS 1
50050045 SMT ceramic capacitor 101,VDC50,±5%,NPO,0603 PCS 8
50050137 SMT ceramic capacitor 331,VDC50,±5%,NPO,0603 PCS 2
50050277 SMT ceramic capacitor 153,VDC50,±10%,X7R,0603 PCS 2
50050074 SMT ceramic capacitor 104,VDC50,±10%,X7R,0603 PCS 16
50050052 SMT ceramic capacitor 102,VDC50,±10%,X7R,0603 PCS 9
18010075 diode AN-D10075,LL-34,1N4148, PCS 1
14010077 NPN triode MMBT3904LT1,SOT23,ONSEMI PCS 1
14040202 IC NJM2068M,DMP8,JRC PCS 4
50050115 SMT ceramic capacitor 221,VDC50,±5%,NPO,0603 PCS 2
50050158 SMT ceramic capacitor 471,VDC50,±10%,X7R,0603 PCS 2
24040043 SMT inductance AN-I4037,FCI1608F-3R3K,3.3uH,±5%,0603 PCS 2
40330010 IPOD connector MFI512S0017 30PIN Apple PCS 1
20020063 top cover DN-PC2046,ABS,black,39*31.34*0.85mm,texture on surface,V1.0 PCS 1
54020005 top cover isp06,DN-PC2046,silkscreen on top cover,silkscreen color cold grey 429C,V1.0 PCS 1
20030056 bottom cover DN-PC3044,ABS,black,39*31.39*0.85mm,texture on surface,V1.0 PCS 1
54030004 bottom cover ISP06,DN-PC3044,bottom silkscreen color 11C,V1.0 PCS 1
20090014 plastic cover DN-PC0011,PE natural color,26*6*1.25mm,with texture on the surface,V1.0 PCS 1
20110087 lense transparent sheet,PC(transparent+30% black),T=0.25MM,REV:A0 PCS 1
26060043 PCB ISP06,TX FR4AN-B60035 PCS 1
11171015 SMT resistor 1/16W,100Ω,±1%,0402 PCS 2
11171016 SMT resistor 1/16W,121Ω,±1%,0402 PCS 1

11171017 SMT resistor 1/16W,150Ω,±1%,0402 PCS 1
11171018 SMT resistor 1/16W,300Ω,±1%,0402 PCS 2
11171019 SMT resistor 1/16W,10KΩ,±1%,0402 PCS 4
11171020 SMT resistor 1/16W,24.9KΩ,±1%,0402 PCS 2
11171013 SMT resistor 1/16W,38.3K,±1%,0402 PCS 4
11171022 SMT resistor 1/16W,47KΩ,±1%,0402 PCS 1
11171023 SMT resistor 1/16W,100KΩ,±1%,0402 PCS 8
11171024 SMT resistor 1/16W,160KΩ,±1%,0402 PCS 1
11171063 SMT resistor 1/16W,549KΩ,±1%,0402 PCS 1
50050337 SMT ceramic capacitor 18PF,VDC50,±5%,NPO,0402 PCS 4
50050338 SMT ceramic capacitor 150PF,VDC50,±5%,NPO,0402 PCS 2
50050107 SMT ceramic capacitor 182,VDC50,±10%,X7R,0603 PCS 2
50050340 SMT ceramic capacitor 104,VDC16,±10%,X5R,0402 PCS 13
50050347 SMT ceramic capacitor 105,VDC6.3,±10%,X7R,0402 PCS 5
50050335 SMT ceramic capacitor 225,VDC6.3,±10%,X5R,0603 PCS 3
50050343 SMT ceramic capacitor 10UF,VDC6.3,±20%,X5R,0603 PCS 3
14010077 NPN triode MMBT3904LT1,SOT23,ONSEMI PCS 2
14040743 IC M95512-RMN6P,SO8,ST PCS 1
14040713 IC KLR3012 Kleer Semiconductor PCS 1
14040721 IC CS53L21-CNZ 32-QFN Cirrus Logic PCS 1
14040718 IC NJM2888F21 SOT-23-5 JRC PCS 1
14040775 IC PIC24FJ16GA002-I/ML QFN-28 MICROCHIP PCS 1
14040820 IC program ISP06 program,PIC24FJ16GA002-I/ML QFN-28 MICROCHIP PCS 1
14040776 IC SN74LVC1T45DCK SC-70 TI PCS 2
18040042 LED 0603,KPH-1608SRW-PRV, PCS 1

18040040 LED 0603,KPT-1608SGC PCS 1
25020018 SMT crystal resonator AN-O218,TSX-3225 22.576649 MHZ 3.2MMx2.5MM PCS 1
24040032 SMT inductance AN-I4026 FCM1005KF-102T02 250mA 0402 PCS 2
24040033 SMT inductance AN-I4027 LQH32CN4R7M53,4.7uH 1210 650 MA 20% Murata PCS 1
60100008 antenna AN-E1009,2.4G SMD A5839 12.8*3.9*1.1mm Antenova PCS 1
50050352 SMT ceramic capacitor 0.5PF,VDC50,±0.5%,NPO,0402 PCS 1
14040821 IC program isp06 program,TX-FORM95512 PCS 1
14040805 IC MFI341S2164 QFN20 APPLE,ALESIS PCS 1
24040042 SMT inductance AN-I4036,FCI1005F3N9S RF INDUCTORS 3.9nH 0402 PCS 1
11171012 SMT resistor 1/16W,5.11K,±1%,0402 PCS 2
50050365 SMT ceramic capacitor 4.7UF,VDC10,+80/-20%,Y5V,0603 PCS 1
50050364 SMT ceramic capacitor 10UF,VDC6.3,±10%,X5R,0603 PCS 1
12040027 Tact Switch AN-S427,TS-3225S-250,SMT PCS 1
26060042 PCB ISP06,RX FR4 AN-B60034 PCS 1
11171008 SMT resistor 1/16W,0Ω,±1%,0402 PCS 4
11170772 SMT resistor 1/16W,33.2Ω,±1%,0402 PCS 2
11171011 SMT resistor 1/16W,49.9Ω,±1%,0402 PCS 4
11171012 SMT resistor 1/16W,5.11K,±1%,0402 PCS 5
11171013 SMT resistor 1/16W,38.3K,±1%,0402 PCS 1
11171014 SMT resistor 1/16W,86.6K,±1%,0402 PCS 3
11170576 SMT resistor 1/10W,100KΩ,±1%,0603 PCS 1
50050345 SMT ceramic capacitor 8PF,VDC50,±5%,NPO,0402 PCS 3
50050333 SMT ceramic capacitor 223,VDC16,±10%,X7R,0402 PCS 2
50050340 SMT ceramic capacitor 104,VDC16,±10%,X5R,0402 PCS 11
50050346 SMT ceramic capacitor 105,VDC6.3,±10%,X7R,0603 PCS 2

50050334 SMT ceramic capacitor 105,VDC6.3,±10%,X7R,0603 PCS 3
50050335 SMT ceramic capacitor 225,VDC6.3,±10%,X5R,0603 PCS 2
50050086 SMT ceramic capacitor 10UF,VDC16,±10%,X7R,1206 PCS 1
14010077 NPN triode MMBT3904LT1,SOT23,ONSEMI PCS 2
14040713 IC KLR3012 Kleer Semiconductor PCS 1
14040743 IC M95512-RMN6P,SO8,ST PCS 1
24040035 SMT inductance AN-I4029 2.2NH,220MA,0402,(FCI1005F-2N2S) PCS 1
14040803 IC program RX ForM95512 PCS 1
14040716 IC CS43L21-CNZ 98DB 96KHZ 32-QFN Cirrus Logic PCS 1
14040717 IC MASWSS0151 SC70-SOT-363 TYCO PCS 1
14040718 IC NJM2888F21 SOT-23-5 JRC PCS 1
24040032 SMT inductance AN-I4026 FCM1005KF-102T02 250mA 0402 PCS 1
25020018 SMT crystal resonator AN-O218,TSX-3225 22.576649 MHZ 3.2MMx2.5MM PCS 1
60100008 antenna AN-E1009,2.4G SMD A5839 12.8*3.9*1.1mm Antenova PCS 2
50050350 SMT ceramic capacitor 0.75PF,VDC50,±0.25%,NPO,0402 PCS 1
50050351 SMT ceramic capacitor 1.1PF,VDC50,±0.25%,NPO,0402 PCS 1
80010002 3/4" tweeter AN-L102,5W,4ohm,(T=0.5mm),YDQG52-4NbA(with black grill) PCS 2
20150099 driver frame DN-PT1053,ABS,黑色,182.86*90.5mm,V1.0 PCS 2
30150056 plate DN-MP3001,ABS,L=54mm black PCS 2
70010111 screw Φ3*10mm,cross-round head, head D5.5mm, PCS 4
14040663 IC TDA8932BT,SOP32,PHILIPS PCS 1
14040748 IC TDA8932T,SOP32,PHILIPS PCS 1
16070128 power line AN-W1026,BK,0.75/2C,L=1830mm,(AU Version),90 deg C interface PCS 1
16070129 power line AN-W1027,BK,2X0.75mm2/,L=1830mm(EU version+ 90 deg C interface) PCS 1
16070130 power line AN-W1028,BK,VCTFK,0.75/2C,L=1830mm,(JP version),90 deg C interface PCS 1

16070131 power line AN-W1029,UL,NISPT-2,2C/18AWG,1830mm,black,(UL version) PCS 1
16070132 power line AN-W1030,BK,H03VVH2-F,2*0.75mm2,L=1830mm,(3A UK version) PCS 1
90190013 voltage sticker ISP06,sticker,printing color 877C,30*10MM,V1.0 PCS 1
13030189 EI transformer AN-T30187,EI-CZT57451UV, PCS 1
13030190 EI transformer AN-T30188, PCS 1
13030191 EI transformer AN-T30189, PCS 1
90080025 destination sticker ISP06,76*50MM,use when ship to US,V1.0 PCS 1
90080026 destination sticker ISP06,76*50MM,use when ship to Japan,V1.0 PCS 1
90080027 destination sticker ISP06,76*50MM,use when ship to EU,V1.0 PCS 1
90080028 destination sticker ISP06,76*50MM,use when ship to UK,V1.0 PCS 1
19070006 fuse socket AN-F705,R3-54B,UL and VDE certification PCS 1
16040389 plug wire AN-W4N3,1P,20#,UL1617,80mm,red PCS 1
30010014 shrinkable tube Φ4*15*0.20mm,UL PCS 6
30010038 shrinkable tube Φ15*40*0.40mm,UL PCS 1
30010046 shrinkable tube Φ25*40*0.45mm,UL PCS 1
22010561 Safety Manual IPA06,ION version,safety user manual,V14.3 PCS 1
90200056 marking sticker coated paper,BLACK&361C printing,Φ30mm,V1.0 PCS 1
22050008 desiccant 20克,siliscon with no non-woven fabrics PCS 1
22010562 Quickstart Guide ISP06,English manual,V1.1 PCS 1
90150009 installation guide sticker ISP06 installation guide sticker 38.5*38.5mmprinting red words on white background,V1.0 PCS 1
23010020 packing bag PE,120*280*0.06mm PCS 1
23010295 PE bag PE,160*260*0.025mm,with holes PCS 1
23010098 packing bag PE,300*530*0.08mm PCS 1
23030919 outer box ISP06(ION version),A=B,black printing,512*420*320mm,V1.0 PCS 0.5
90020942 UPC code ISP06,black word with white background,64*13MM,V1.0 PCS 5

90040779 bar code sticker ISP06, 38*26MM,V1.0 PCS 3
23090355 giftbox ISP06,(ION version),color printing,499*202*295mm,V1.0 PCS 1
23020213 poly foam ISP06,left poly foam,275*105*190mm,V1.0 PCS 1
23020214 poly foam ISP06,right poly foam,275*105*190MM,V1.0 PCS 1
23010004 packing bag PE,60*100*0.06mm PCS 1
90250007 rear cover sticker ISP06,PVC material,black printing,25*6.5MM,V1.0 PCS 3
22110042 service card Alesis,using for ION verson only,280*210mm,black words on yellow background PCS 1






iSP06 ANYROOM TX
SHEET: 1 OF 1
APPROVED:ECO NO:LTR
REV:SIZE:CODE:
A
B
C
D
6 5 4 3 2 1
DATE:
D
C
B
A
DRAWING NO:
TITLE:
COMPANY:
RELEASED: DATED:
DATED:QUALITY CONTROL:
CHECKED: DATED:
DATED:DRAWN:
REVISION RECORD
SCALE:
Ion Audio
1.08a
2011.01.01
ZX
RF Test Point
Testpoints for UART access
- 2mm pitch holes
Discharge
Resistor
PIC Debug and
Programming
test points
Apple Authentication IC
V 2.0B, Class 6,
non-automotive
Place close to J3
NOTES:
=======
1. For mass production testing, short TP9 (U5, pin 9) to GND for "no-iPod" mode before applying power. This forces the PIC to immediately power up the LDO
without waiting to communicate with an iPod.
2. The DC_DC_MODE signal is intended for communication to the PIC. It will t ell the PIC whether the KLR3012 is asleep or awake. That way, the PIC will know
that the KLR3012 has gracefully gone to standby mode and it can shut down the LDO. We don't need to stay in standby anymore, now that we have fast boot in
1.9.
3. For bench t esting without an iPod, a dc short is required between a nalog and digital GND. So, short across one of the 100 nF caps that serve as ac shorts, or
short at the iPod connector.
4. LED Blinking Requirements (specified by Alesis):
- Green LED (LED1) - All state indications should be mapped to this LED, except enrollment.
- Red LED (LED2) - Should be solid on in enrollment, off otherwise.
5. R19: This resistor is an option for future PIC code changes. Assign dc-dc mode to this GPIO pin so that it acts as a sleep/wake indicator for the PIC. When the
PIC determines the KLR3012 has reached standby mode, it can cut the power at the LDO. FastBoot will allow a quick resume. Alternatively, the PIC can
determine the KLR3012 state using ACSI.
C19
1U
R32
24.9K
C10
2.2U
H1
R18
47K
C1
18P
TP19
R23
10K
R16
38.3K
1
VCCA
2
GND
3
A
4B
5DIR
6VCCB
U7
SN74LVC1T45DCK
TP9
R19
DNI
0
1 2
SW1
TS-3220S
C8
18P
L2 BLM15HD102SN1D
H7
C12
100N
R20
100
L1
LQH32CN4R7M53L
R12
100K
C6
100N
C18
100N
C31
DNI
100N
TP8
1S2
Q
3W
4
VSS
8
VCC
7HOLD
6C
5D
U3
M95512-RMN6P
C13
DNI
18P
C25150P
C30
DNI
100N
6
VDD_A
28
VDD_XTAL
19
VDD_D1
32
LPF
33 IO_17
34 IO_16
35 IO_15
36 IO_14
27 IO_13
26 IO_12
25 IO_11
24 IO_10
23 IO_9
22 IO_8
18 IO_7
17 IO_6
16 IO_5
15 IO_4
14 IO_3
13 IO_2
12 IO_1
11 IO_0
9
UART0_TX 8
UART0_RX
7
RESET_N
40
TEST
31
OSC_1 30
OSC_2
21
LDO_OUT
1
GND_1 2
GND_2
3
ANT
4
GND_3 5
GND_4
37
GND_5 38
GND_6 39
GND_7 41
GND_8 42
GND_9 43
GND_10
10 NC_1
20
VDD_D2
29 NC_2
44 GNDPAD_1
45 GNDPAD_2
U1
KLR3012
H8
TP4
H2
1CTRL
2
GND
3
NC
4
VOUT
5VIN
U2
NJM2888F21
C37
1800P
C5
10U
C41
100N
TP6
C9
10U
H4
C40
1U
R11
100K
TP2
C15
100N
C2410U
R2 150
R30
100K
R37
5.11K
C29150P
R17100K
TP7
C34
1U
C20
4.7U
R34
DNI
24.9K
TP5
R13 300
3
1
2
Q1
MMBT3904
R21
100K
R6
10K
C39
2.2U
C3
DNI
18P
C35
100N
TP3
D2
GREEN
R27
DNI
5.11K
1NC
2
MODE1/SPI_NSS
3NC
4
NRESET
5
VCC
6NC
7NC
8NC
9NC
10 NC
11
VSS
12
I2C_SCL/SPI_SIMO
13
I2C_SDA/SPI_SOMI
14
MODE0/SPI_CLK
15 NC
16 NC
17 NC
18 NC
19 NC
20 NC
U4
MFI341S2164
C7
100N
R10
38.3K
R31
24.9K
TP10
TP13
C42
100N
TP20
C33
100N
1
DGND 2
DGND 3
TPA+ 4
USB_D+ 5
TPA- 6
USB_D- 7
TPB+ 8
USB_VBUS 9
TPB- 10
ACC_IDENTIFY 11
FW_PWR+ 12
FW_PWR+ 13
ACC_POWER 14
RESERVED 15
DGND 16
DGND 17
RESERVED 18
RX_(TO_IPOD) 19
TX_(FROM_IPOD) 20
ACC_DETECT 21
S_VIDEO_Y 22
S_VIDEO_C 23
COMP_VIDEO 24
REMOTE_SENSE 25
LINE_IN_L 26
LINE_IN_R 27
LINE_OUT_L 28
LINE_OUT_R 29
AUDIO_RETURN 30
IPOD_DETECT
31 SHIELD1
J2
MFI512S0017
R36
5.11K
R24
10K
H3
TP15
C16
100N
R1 121
C28
DNI
100N
TP11
C21
100N
C11
18P
R35
DNI
200
R3100K
R8
DNI
0
1RB0/RP0
2RB1/RP1
3RB2/RP2
4RB3/RP3
5VSS
6RA2
7RA3
8RB4/RP4
9RA4
10
VDD
11 RB5/RP5
12 RB6/RP6
13 RB7/RP7
14
RB8/RP8 15
TDO/RP9
16
DISVREG
17
VCAP/VDDCORE
18
PGD2/RP10 19
PGC2/RP11 20
RB12/RP12 21
RB13/RP13 22
RB14/RP14 23
RB15/RP15
24 VSS
25
VDD
26
MCLR
27 RA0
28 RA1
29 GND_PAD
U5
PIC24FJ16GA002-I/ML
TP16
1
VCCA
2
GND
3
A
4B
5DIR
6VCCB
U8
SN74LVC1T45DCK
TP12
R14 300
3
1
2
Q2
MMBT3904
1
GND
2FEED
3
NC1 4
NC2 5
NC3
Y1
3030A5839-01 (RUFA_LEFT)
1
3
2
4
Y2
22.576649 MHz
C23 1U
C22
1U
C27
DNI
100N
C17
100N
H5
R15
160K
R25
100K
R29
100
L3 BLM15HD102SN1D
R26
549K
C14 10U
R7
0.5P
TP18
R5 10K
C32 18P
C4
100N
TP1
D1
RED
R33100K
C26
DNI
100N
TP14
1LRCK
2SDA/CDIN
3SCL/CCLK
4AD0/CS
5
VA_PULLUP
6TSTO
7AGND
8TSTO
9TSTO
10
NIC 11
NIC
12
VA
13 AGND
14 TSTO
15
VQ
16
FILT+
17
MICIN1/AIN3A 18
MICIN2/BIAS/AIN3B
19
AIN2A 20
AIN2B/BIAS
21
AFILTA 22
AFILTB
23
AIN1A 24
AIN1B
25 RESET
26
VL
27
VD
28 DGND
29 SDOUT
30 MCLK
31 SCLK
32
TSTN
33 PAD
U6
CS53L21
R9
38.3K
TP17
C2
DNI
18P
H6
R22
38.3K
C38
1800P
R4 3.9nH
C36
2.2U
VCC
VCC
VCC
VCC_IPOD
VCC_IPOD
VCC
VCC_IPOD
VCC_IPOD
VCC
VCC_IPOD
VCC_IPOD
VCC
VCC
VCC_IPOD
VCC
WAKE
UART1_TX
DC_DC_MODE
DC_DC_RUN
SPI_MISO
MCLK
TWI_CLK
RIGHT
FS
ADC_RESETN UART0_TX
DATA
SPI_CLK
BCLK
LEFT
TEST
UART0_RX
KEYS_IN
SPI_MOSI
SPI_SSEL0
LED2
TWI_DATA
UART1_RX
LED1
Other manuals for ANYROOM
1
This manual suits for next models
1
Table of contents
Other ION Speakers manuals

ION
ION Block Rocker Series Use and care manual

ION
ION Aquaboom User manual

ION
ION Game Day User manual

ION
ION PRO GLOW ULTRA User manual

ION
ION BLOCK ROCKER FLASH User manual

ION
ION Party Boom FX User manual

ION
ION Pickup User manual

ION
ION TAILGATER BLUETOOTH User manual

ION
ION Planter User manual

ION
ION Bright Max Plus User manual

ION
ION ARENA User manual

ION
ION Magnet Rocker User manual

ION
ION ROAD ROCKER User manual

ION
ION Block Rocker Max iPA76C2 User manual

ION
ION BLOCK ROCKER BLUETOOTH User manual

ION
ION CENTER STAGE User manual

ION
ION Clipster User manual

ION
ION UBER BOOM User manual

ION
ION Stadium User manual

ION
ION PRO GLOW EXPRESS User manual
