IPCamPower IPCP-24P2G-AF2 User manual

USER GUIDE
10/100M 24 Ports PoE Switch
PoE & O p t i c a l Tr a n s m i s s i o n
Statement
Product Overview
Product Introduction
The IPCP-24P2G-AF2 is a business class PoE switch that was designed for IP Camera Systems that utilizes 24 IP cameras
or less. This switch has 24 10/100 PoE powered ports with 2 additional 10/100/1000 gigabit non-powered
Uplink ports. The IPCP-24P2G-AF2 has the abilitie to provide up to 30 watts of power IEEE802.3at per port with a total
POE power budget of 250 watts.
Technical Structure and Port Description
330mm
44.5mm
205mm
AC/I N 100-2 40V
ABC
D
A. B.
C. 2 D.AC100-24 0V,5 0/6 0Hz
24 Port P oE Worki ng LE D indicat or
Gigab it Up l ink Ether net Port
Copyright © 2018 IPCamPower.com
This document contains proprietary information that is protected by copyright. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise without the prior written permission
of our company.
The information and product specifications within this document are subject to change at any time, without notice and
without obligation to notify any person of such change.
Packing List
1 Gigabit PoE switch
1 Power Cord / Adapter
1 Mounting Kit
1 User Guide
Features
Complied to IEEE802.3af/at, 10Based-T, 100Based-T, 1000Based-T.
Ethernet Port Rate: 24 self-adaptive 10/100Mbps and 2 self-adaptive 10/100/1000Mbps.
Support IEEE802.3af PoE (15.4Watts) or IEEE802.3at(30Watts)
PIN assignment: End-span(1/2+,3/6-), Mid-span (4/5+, 7/8-)
Working mode: asynchronization, point to point, full/half duplex self-negotiation.
Ethernet Port Transmission Range: 100meters
Cable: UTP 5E, Interface: RJ45
19’ standard cabinet, industrial high reliability.

Indicator description:
Indicator Status Description
OFF
Power Indicator: PWR Green LED ON Power ON, Normal Power Supply
Power OFF or Power failure
1000M SPD indicator Green LED ON Working condition 1000M
Green LED OFF Working condition 10/100M
PoE indicator: POE
Green LED ON Connected standard PD, Normal Power Supply
Green LED Blink Short Circuit or Over Load
OFF No Connection or Connected PD is Non-Standard PD
Connection Diagram
Installation guide
Connect to RJ45 port
1.Connect one en d of RJ45 wire to switch, th e other end to other equip ment, as
shown as the figur e on the right;
2.After power on, p lease check the LED indi ctor status. If it is on, it s hows the
link is OK, otherw ise, the link is down. The n please check the link an d make
sure the other equ ipment is turned on, ref er to the instruction on a bove page
for details.
Connect to power
PoE switch adopts AC 100-240V, 50/60Hz.
1.Please check th e power supply specifi cation matches with th e required;
2.Connect switc h power wire to AC power soc ket, shown as in the follo wing figure.
Powe r Sup ply C onn ect ion Figure Moun tin g Kit s Ins tal lation Fig ure Rack I nst all ati on Fi gure
L Angl e Iro n
Scre w
After installa tion, please check:
If there is enough s pace for heat sink; if the p ower socket is suitabl e for switch specifica tion; if the power, swit ch and rack are
properly groun ded and if the connectio n between switch and oth er network equipments are normal.
Detailed descriptions for the product model numbers
IPCP-24P2G-AF2 24-port 10/100Mbps +2-port 10/100/1000Mbps up-link Ethernet port switch , No. 1-24 ports
support POE , IEEE802.3af/at, POE port output : 30watts , total power : 250watts
PoE Swi tch
Power
Moni tor
NVR
Cat.5 Vi de o li ne
PoE C am er aIP
IP Camer a
PoE S pl it te r
DC OU T
Cat.5
PD-Powered Device
Power over Ethernet Splitter
OFF:12V
ON:5V
PoE RUN
PoE IN
DC OUT
DC RUN
Ethernet out
IN
OUT
Cat.5
PoE I P Ca me ra PoE I P Ca me ra
Rj45 p ort
Plug
Link/ACT indicator
Yellow LED ON Conected port correctly
Yellow LED Blink Receiving or Sending data
OFF Connection failed or Abnormal Link
PoE Indicators: The front panel has light indicators showing the status of PoE activity.
Network Traffic Indicators: The front panel has light indicators showing status of network activity.
SFP Gigabit fiber port: Two combo fiber ports, all ports support wire-speed forwarding, Rich port configuration.
