4.1 Turn the inverter On/Off
Without connecting to utility power, press and hold “ON”button for 3 seconds, release it until the buzzer beeps, the inverter
starts up. In the process of the inverter running, press and hold “OFF”button for 3 seconds, release it until the buzzer beeps,
the inverter is shut down.
When the inverter works in mains power / AC mode, press and hold “OFF”button for 3 seconds, release it until the buzzer beeps, the
inverter goes to bypass mode.
When the inverter works in bypass mode, press and hold “ON”button for 3 seconds, release it until the buzzer beeps, the
inverter goes to AC mode.
4.2 Display interface
Inverter mode
Mains power mode
4.3 Settings
4.3.1 Setting operation
In normal mode, press and hold “ON”+ “OFF”button at the same time for 3 seconds to go to Setup mode.
In Setup mode, press and hold “ON”+ “OFF”button at the same time for 3 seconds to exit from Setup mode, and the setting
are not saved.
In Setup mode, press “ON”button for page turning to select configuration options.
In Setup mode, press “OFF”button to configure current settings.
In Setup mode, press “ON”button to turn to page “Save & Exit”interface, press “OFF”button and select “Y”, then press “ON”
button to confirm to save datas and exsit from Setup mode.
After the setting is configured, shut down and restart the inverter before the settings takes effect.
