IQRF KON-RASP-01 User manual

© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 1
KON-RASP-01
IQRF Shield for Raspberry Pi
User’s guide

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 2
Simplified schematic
Features
Connectable to all Raspberry Pi versions
For any SIM card compatible (DC)TR transceivers,
e.g. (DC)TR-72D or (DC)TR-52D
(DC)TR connected typically as SPI slave
An LED and a pushbutton for user applications
I/O pins protected by controllable analog switch
(DC)TR power supply controlled from Raspberry Pi
SIM connector with metallic holder
Supported by IQRF SDK (Software Development Kit)
Applications
Any user applications utilizing IQRF wireless
connectivity and Raspberry Pi performance
Mesh networks based on IQRF DPA framework
for wireless without programming
Description
KON-RASP-01 is an IQRF shield for Raspberry Pi boards. It is
an adapter enabling to connect an IQRF wireless transceiver to
Raspberry Pi (via GPIO connector).
The shield contains SIM connector, so any SIM card compatible
(DC)TR transceivers, e.g. (DC)TR-72D or (DC)TR-52D can be
used.
IQRF transceiver is intended to be controlled via SPI bus.
However, any other interface implemented in user application is
also possible.

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 3
Electrical specifications Typical values unless otherwise stated
Power supply VCC 3.1 V to 3.4 V
Voltage on GPIO pins -0.3 V to VCC
Size 17.0 mm x 26.4 mm
Weight 2 g
Operating temperature -40 °C to +85 °C
Storage temperature -40 °C to +85 °C, +10 °C to +25 °C recommended

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 4
Hardware
Power supply
KON-RASP-01 and (DC)TR transceiver inside are intended to be supplied from Raspberry Pi 3.3 V power source available
on GPIO connector. Refer to the datasheet of (DC)TR used.
Power supply is connected when signal ENABLE is in log. 1. This signal is controlled from Raspberry Pi,default disabled by
internal pull-down resistor and shared with the GPIOs protection (see Analog switch below).
SIM connector
SIM connector is intended for (DC)TR transceiver.
Caution: The (DC)TR transceiver can be plugged / unplugged into / from the SIM connector while powered off only.
Interface connector
Raspberry Pi is equipped with universal double row connector to provide GPIO
pins and power supply for external peripherals according to specific needs. KON-
RASP-01 occupies 12 pins (15 to 26) of this connector.
Various Raspberry Pi types may differ in GPIO connectors. KON-RASP-01 must
always be plugged in proper pins with respect to pinout described on the
silkscreen on the DK-RASP-01 board and must correspond to simplified
schematic above.
Caution: The KON-RASP-01 shield can be connected to Raspberry PI board while the board is powered off only.
Examples:

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 5
Analog switch
To protect Raspberry Pi GPIO pins, connection to SIM connector is enabled (by the 74HC4066BQ ICs) when signal ENABLE
is in log. 1. It is the same control signal as for power supply connection. It allows interconnection to (DC)TR not until the
Raspberry Pi is properly initialized.
LED
Indication LED is connected to Raspberry Pi GPIO22 pin and is completely under control of the Raspberry Pi application
software.
Pushbutton
The pushbutton is connected to Raspberry Pi GPIO7 pin and is completely under control of the Raspberry Pi application
software.
(DC)TR transceiver
Supported (DC)TR transceivers are all types in SIM card format with 8 pins, e.g. (DC)TR-72D or (DC)TR-52D.
Types intended for SMT mounting (i.e. with more than 8 pins, e.g. (DC)-TR-76D or (DC)TR-56D) must not be used.
The functionality of the (DC)TR depends on application software inside the transceiver. For networks it is highly
recommended to utilize ready to use hardware profiles under the DPA framework which enables wireless networking with no
programming needed.
Raspberry Pi
All verisions of Raspberry Pi up to the time of release of this document (versions A, B and B+) are supported.
Raspberry Pi is intedned as a superordinate device controlling the (DC)TR transceiver, not only enabling (DC)TR power
supply and GPIO interconnection but also operating as an SPI master in most applications.
Example: Raspberry Pi (version B) with KON-RASP-01 plugged and DCTR-72DA transceiver inside.

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 6
Software
IQRF SDK
IQRF Software Development Kit (SDK) is a platform enabling simple development of application software for devices
programmable in Java or C(++) used with IQRF wireless transceivers.
IQRF SDK supports Raspberry Pi with libraries for Java and C enabling an access to Raspberry Pi GPIOs and SPI interface.
The library implements the SPI master for communication with the (DC)TR transceiver. Examples included in the library
illustrate the access to GPIOs and SPI communication under the DPA framework. The libraries and examples are plug and
play when used with KON-RASP-01 kit.
Refer to https://github.com/MICRORISC/iqrfsdk/tree/develop/libs/raspberry for Raspberry Pi support in IQRF SDK.

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 7
Product information
Ordering codes
KON-RASP-01 IQRF Raspberry Pi shield
Document history
151120 IC type specified in the Analog switch chapter. Caution added in the Interface connector chapter.
150507 First release

KON-RASP-01
© 2015 MICRORISC s.r.o. www.iqrf.org User_guide_KON-RASP-01_151120 Page 8
