IRISBOND DUO User manual

www.irisbond.com
EYETRACKING
SYSTEM
USER
MANUAL

www.irisbond.com
User Manual
This User Guide is subject to change.
To get the latest version, go to www.irisbond.com/en
Version 1.0
© IRISBOND CROWDBONDING, S.L. 2019
Paseo Mikeletegi 56
20009 Donostia-San Sebastián
Gipuzkoa
Spain
Tel: [phone]
Email: [e-mail]
www.irisbond.com

User Manual
Table of Contents
www.irisbond.com
Table of Contents
Welcome to Irisbond .................................................................................................. 5
Irisbond Duo Eyetracker ........................................................................................................ 6
System contents .................................................................................................................... 6
Description of Contents ........................................................................................................ 7
Assembly Options .................................................................................................................. 8
How to position Irisbond Duo when using a laptop .............................................................. 9
How to Attach Irisbond Duo to a Desktop Computer Screen ............................................. 14
How to Attach Irisbond Duo to a Tablet ............................................................................. 16
Installing the Primma Software ................................................................................ 20
Start Up ...................................................................................................................... 24
Manage Users ......................................................................................................... 24
Select Language ................................................................................................................... 24
Create a User Profile ........................................................................................................... 26
Managing User Profiles ....................................................................................................... 27
Click Options ........................................................................................................... 29
Dwelling ............................................................................................................................... 30
Blinking ................................................................................................................................ 31
External ............................................................................................................................... 32
Shared Features of the Click Options .................................................................................. 33
Configuration ........................................................................................................... 35
Positioning ........................................................................................................................... 36
Calibration ........................................................................................................................... 40
Cursor Control Method ....................................................................................................... 44
Problems that Can Arise During the Calibration Process. ................................................... 46
Customizing Points .............................................................................................................. 47
Appearance ............................................................................................................. 51
Button Width (pixels) .......................................................................................................... 51
Auto Minimize Menu (sec) .................................................................................................. 51
Configuring buttons............................................................................................................. 52
About ...................................................................................................................... 54

User Manual
Table of Contents
www.irisbond.com
Primma Menu .......................................................................................................... 55
Instant or Quick Action Buttons .......................................................................................... 56
Buttons with a Click Function .............................................................................................. 57
Certifications ........................................................................................................... 60
Troubleshooting ...................................................................................................... 61
Open Source Library Licenses ................................................................................ 62

User Manual
Introduction
www.irisbond.com Page 5
Welcome to Irisbond
Congratulations on purchasing the Irisbond system which will allow you to use a computer simply by
moving your eyes!
The Irisbond system is based on the latest innovations in artificial vision technology, and more
specifically, on Eye Tracking technology, which allows the user to control a computer mouse by moving
their eyes. Those who benefit most from the system are people with severe motor impairment who
cannot use conventional mouse movement systems. Individuals with Amyotrophic Lateral Sclerosis
(ALS) or Cerebral Palsy using Irisbond can access a variety of apps installed on the computer. Irisbond
gives the user a window to the world, allowing them to communicate, share experiences and knowledge,
watch movies, read, listen to audiobooks, play...there really is no limit!
In addition, by using Augmentative and Alternative Communication (AAC) tools such as a virtual
keyboard, voice synthesizers and environmental control systems, the user can control the remote control
for the TV, or any other infrared device. For perhaps the first time ever, they will able to control devices at
home around them.
The Irisbond eyetracker is safe to use, complies with relevant European Guidelines and Directives and
has been tested by a certified laboratory in accordance with industry standards.

User Manual
IRISBOND Eyetracker
www.irisbond.com Page 6
Irisbond Duo Eyetracker
The system is made up of one eyetracking device connected to computer via a cable
(included with the device) through a USB port (either USB 2.0 or USB 3.0). The
eyetracker emits infrared light beams which create reflections on the user’s corneas. A
camera then registers these reflections and through a series of complex computational
algorithms is able to identify the user’s pupils. The information is then processed by the
computer via the Irisbond Primma software (once installed on the computer). This
allows the user’s eye movements to be translated into onscreen positioning coordinates
for the mouse.
System Components
The Irisbond Duo system comes with the following components:
 1 Irisbond eyetracker.
 1 USB extension cable.
 4 mounting attachments.
 1 memory stick which contains the Primma software, User Manual, Quick Start
Guide and an activation file.

User Manual
IRISBOND Eyetracker
www.irisbond.com Page 7
Description of Components
Irisbond Duo Eyetracker
On the back of the eyetracker there are two metallic
indentations which the eyetracker support fits into.
Support
The eyetracker support holds the device in place.
Cable
The cable enables a connection between the
computer and the eyetracker.
Mounts
The mounts allow you to use the Irisbond system on
various surfaces.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 8
Assembly Options
The Irisbond Duo system is designed to be fully adaptable for use with laptops,
Desktop PCs and tablets:
1.
Laptop
Attached to a flat surface on the laptop. Placed in front of the laptop.
2.
Desktop Computer
Attached to the lower area of the monitor. Placed in front of the monitor.
3.
Tablet
Attached to a tablet using a special adaptor.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 9
How to Position Irisbond Duo When Using a Laptop
When using a laptop, the Irisbond eyetracker can be positioned in three ways:
1. Attached to the laptop in the space between the screen and the keyboard
2. Attached to the bottom section of the laptop screen
3. Placed on a table in front of the laptop
How you choose to position the eyetracker will depend on the model of the laptop you are using
and the position of the user (seated in a chair, reclined in a profiling bed, lying down, using an
inclined table etc.)
Option A. Attached to the laptop in the space between the screen and the keyboard
Instructions:
1. Should you wish to attach the eyetracker to the laptop in the space between the screen
and the keyboard, you must first identify the adhesive mount specifically designed for
use with a laptop. You will be able to recognize it as it has a laptop design on it.
Laptop symbol
Adhesive mount for laptops
2. Remove the protective paper from the adhesive strip and place the mount (adhesive strip
side down) on a clean and flat area between the screen and the keyboard with the arrow

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 10
pointing towards the screen. Allow at least 8 hours before attaching the eyetracker
support to the mount.
3. Connect the USB cable to the Irisbond eyetracker.
4. Attach the support to the Irisbond eyetracker by bringing together the metal contacts on
the back of the Irisbond device and the magnets on the support. When bringing these
into contact, be sure that both tabs are facing downwards.
5. Slot the support (now holding the Irisbond eyetracker) in the mount attached to
the laptop.
WARNING The strip on the mount is made of a strong adhesive
material. We recommend carefully considering where to place the mount
before attaching to the computer as the adhesive is semi-permanent.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 11
Option B. Attached to the bottom section of the laptop screen
Instructions:
1. Should you wish to attach the eyetracker to the bottom section of the laptop screen you
must first identify the adhesive mount specifically designed for use with a laptop. You will
be able to recognize it as it has a laptop design on it.
Laptop symbol
Adhesive mount for laptops
2. Remove the protective paper from the adhesive strip and place the mount (adhesive strip
side down) on the bottom area of the screen with the arrow pointing downwards. Allow at
least 8 hours before attaching the eyetracker support to the mount.
3. Attach the support to the Irisbond eyetracker by bringing together the metal contacts on
the back of the Irisbond device and the magnets on the support. When bringing these
into contact, be sure that the tabs are facing upwards.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 12
4. Slot the support (now holding the Irisbond eyetracker) in the mount attached to the
laptop.
Option C. Placed on a table in front of the laptop.
WARNING The strip on the mount is made of a strong adhesive
material. We recommend carefully considering where to place the mount
before attaching to the computer as the adhesive is semi-permanent.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 13
Instructions:
Another way of positioning the eyetracker is to place it in front of the screen on the rest designed
for using the device on tables. The tabletop rest creates a larger surface area for the eyetracker
support and allows the user to securely position the eyetracker on a flat surface.
1. Identify the tabletop rest.
2. Slot the support (holding the Irisbond eyetracker) into the tabletop rest. Finally, place the
eyetracker in front of the laptop.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 14
How to Attach Irisbond Duo to a Desktop Computer Screen
When using a desktop PC, the Irisbond eyetracker can be positioned in two ways:
1. Attached to the bottom section of the monitor
2. Placed on the table in front of the monitor
Option B. Attached to the bottom section of the monitor
Instructions:
1. To attach the eyetracker to the bottom area of the monitor you must first identify the
adhesive mount specifically designed for use with a monitor. You will be able to
recognize it as it has a monitor design on it.
2. Remove the protective paper from the adhesive strip and place the mount (adhesive strip
side down) on the bottom area of the monitor with the arrow pointing downwards. Allow
at least 8 hours before attaching the eyetracker support to the mount.
3. Attach the support to the Irisbond eyetracker by bringing together the metal contacts on
the back of the Irisbond device and the magnets on the support. When bringing these
into contact, be sure that the tabs are facing upwards.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 15
WARNING The strip on the mount is made of a strong adhesive
material. We recommend carefully considering where to place the mount
before attaching to the computer as the adhesive is semi-permanent.
4. Slot the support (now holding the Irisbond eyetracker) in the mount attached to the
monitor.
Option B. On a table in front of the monitor

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 16
Instructions:
Another way of positioning the eyetracker is to place it in front of the screen on the rest designed
for using the device on tables. The tabletop rest creates a larger surface area for the eyetracker
support and allows the user to securely position the eyetracker on a flat surface.
1. Slot the support (holding the Irisbond eyetracker) into the tabletop rest. Next, place the
eyetracker in front of the monitor.
How to Attach Irisbond Duo to a Tablet
To attach the Irisbond Duo Eyetracker to a tablet, a special adaptor is required. Irisbond is
compatible with tablets with a 12 to 15’’ screen and have a Windows operating system.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 17
Instructions:
1. Remove the screws in the center of both magnetic contacts on the back of the Irisbond Duo
Eyetracker.
2. Take the special adaptor for tablets and the two screws; place the adaptor on the back of
the Irisbond Duo device as illustrated in the images below. Next, fix the eyetracker to the
adaptor using the two screws.
3. Attach the adaptor fixed to the eyetracker to the tablet cradle by using the four screws (or
as otherwise specified according to the cradle model). Complete the below steps:
Special adaptor for tablets Fixing the adaptor to the eyetracker

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 18
Unscrew all four screws to release
the fastening device at the back of
the cradle.
Line up the screws on the fastening
device to the adaptor. Adjust the
height of the cradle by sliding it up or
down. Tighten the screws.
4. Insert the tablet in the cradle.

User Manual
IRISBOND Eyetracker
Positioning
www.irisbond.com Page 19
5. Finally, take the articulated arm supporting the tablet and clamp it to a wheelchair or
surface. The system of joints which allows the arm to support the tablet offers the user
endless accessibility options.

User Manual
Installation
www.irisbond.com Page 20
Installing the Primma Software
Before you can control your computer using your eyes you need to install the software
downloading it from https://www.irisbond.com/products/downloads . This must be done
before connecting the Irisbond eyetracker to your computer.
The software is compatible with computers and portable devices which have a
Windows operating system (Vista, 7, 8 and 10).
1. Select the language you require for installation and click OK.
2. A Wizard will open to guide you through the installation. Read the information on
screen and click Next.
3. You must accept the terms of the License Agreement to continue installation. Click
the checkbox to accept the terms of the agreement and click Next.
