1
OWNER’S MANUAL
Charging and Drying Stand
Scooba
®
DryDock
™

2
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM
8 YEARS AND ABOVE AND PERSONS WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK
OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE
OF THE APPLIANCE IN A SAFE WAY AND UNDERSTAND
THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY
WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE
SHALL NOT BE MADE BY CHILDREN WITHOUT SUPERVISION.
CAUTION: DO NOT EXPOSE THE ELECTRONICS OF
YOUR CHARGING AND DRYING STAND OR THE BATTERY
CHARGER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL. PLEASE ENSURE VOLTAGE RATING FOR
ENCLOSED BATTERY CHARGER MATCHES STANDARD
OUTLET VOLTAGE.
Important Safety Information
Always exercise caution when operating your Charging and Drying Stand. To reduce
the risk of injury or damage, keep these safety precautions in mind when setting up,
using and maintaining your Charging and Drying Stand.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure they do not play with the Charging and
Drying Stand. Cleaning and maintenance shall not be performed by children
without supervision.
FOR COUNTRIES IN THE EU

3
Important Safety Information
GENERAL SAFETY INSTRUCTIONS
• Read all safety and operating instructions before operating your Charging
and Drying Stand.
• Retain the safety and operating instructions for future reference.
• Heed all warnings on your robot, battery, battery charger and in the owner’s manual.
• Follow all operating and use instructions.
• Refer all non-routine servicing to iRobot.
The symbol on the product or its packaging indicates:
Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities. Contact your local government for
information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging
your health and well-being. When replacing old appliances with new
ones, the retailer is legally obligated to take back your old appliance for
disposals at least free of charge.

4
USE RESTRICTIONS
• Your Charging and Drying Stand is for indoor use only.
• Your Charging and Drying Stand is not a toy. Do not sit or stand on this
device. Small children and pets should be supervised when your Charging
and Drying Stand is operating.
• Store and operate your Charging and Drying Stand in room temperature
environments only.
• Clean with a cloth dampened with water only.
BATTERY AND CHARGING
• Charge using a standard outlet only. Product may not be used with any
type of power converter. Use of other power converters will immediately
void the warranty.
• Use only the battery charger supplied by the manufacturer to charge
this device.
• Do not use a battery charger with a damaged cord or plug. If the cord
or plug is damaged, it must be serviced by the manufacturer or similarly
qualified persons.
• Charge indoors only.
• Your robot’s battery charger may be protected with a surge protector in the
event of severe electrical storms.
• Never handle the battery charger with wet hands.
• Always disconnect your Charging and Drying Stand from the battery
charger before cleaning or maintaining it.
• Please ensure voltage rating for enclosed battery charger matches
standard outlet voltage.

5
3. Plug power supply cord into hole first then lift
and place the power supply into the base.
4. Plug line cord into power supply and snap
bottom plate onto the base.
1. Empty contents of box (pre-assembled).
Charging Stand Base
Charging Stand Base Plate
Charging Stand
2. Press tabs and pull to remove bottom plate.
5. Plug the stand in and place Scooba on the
stand to charge and dry after each use.
Snaps in
Assembly and Use Instructions
For additional maintenance instruction or support please visit global.irobot.com.

6
Declaration of Conformity
iRobot Scooba®Charging and Drying Stand
Manufacturer: iRobot Corporation, 8 Crosby Drive, Bedford, MA 01730, USA
Declares that Scooba along with Model 17063 Battery Charger conform to the
requirements of Low Voltage Directive 2006/95/EC as amended by 93/68/EC
and EMC Directive 2004/108/EC as amended by 93/68/EC and 2004/108/EC.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions. (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Standards below have been applied:
EN 60335-1
Household and similar electrical appliances. Safety. General requirements.
EN 60335-2-2
Household and similiar electrical appliances - Safety - Part 2-2:
Particular requirements for vacuum cleaners and water-suction cleaning
appliances.
EN 55014-1
Electromagnetic compatability - Requirements for household appliances,
electric tools and similar apparatus - Part 1: Emission.
EN 55014-2
Electromagnetic compatability - Requirements for household appliances, electric
tools and similar apparatus - Part 2: Immunity - Product family standard.
EN 61000-3-2
Harmonic current Emissions
EN 61000-3-3
Limits for Voltage Fluctuation and Flicker
EN 62233
Safety due to Electromagnetic Field (EMF)

7
If you have questions or comments about this product, please contact iRobot
before contacting a retailer.
Please visit the iRobot home support site at global.irobot.com for support
tips, frequently asked questions and information about accessories and other
iRobot products.
Should you still need assistance:
Call our Customer Care team at 877.855.8593.
iRobot Customer Care hours:
• Monday – Friday, 9AM – 7PM Eastern Time
• Saturday, 9AM – 6PM Eastern Time
Visit global.irobot.com to:
• Learn hints and tips to improve the performance of your robot
• Get answers to questions
• Download a detailed product manual
• Contact your local distributor
iRobot Customer Care
USA & Canada
iRobot Customer Care Outside
USA & Canada

© 2013-2014 iRobot Corporation, 8 Crosby Drive, Bedford, MA 01730 USA. All rights reserved.
iRobot and Scooba are registered trademarks of iRobot Corporation.
U.S. Pat. http://www.irobot.com/patents | Other Patents Pending. WC:4420267
