ISHTAA ITP Series User manual

ITP- Series
Price Computing Scale
Scale Users Guide
ISHTAA SCALES INC., COIMBATORE, INDIA
www.ishtaascales.com

CONFIGURATION
•PRESS T/Z AND MOD & SWITCH ON THE SCALE. THE DISPLAY WILL SHOW
CONFIG.
•TO CHANGE THE CAPACITY, CHANGE THE DIGIT OF PERTICULAR
CAPACITY…
THEN SET 0 TO 30 KG (30.000) USING ACL & CL KEY.THEN PRESS S T KEY.IT
WILL SHOW R SAL ON DISPLAY.
•TO CHANGE THE R CAL USE ACL & CL KEY
•THEN PRESS T/Z KEY .IT WILL SHOW AUTO-0.
•TO CHANGE AUTO-0, YOU CAN PRESS UP TO 0 TO 9 USING KEY PAD.
•PRESS S T KEY,IT WILL SHOW DP ON DISPLAY
•TO CHANGE THE DP USE ACL & CL KEY FROM KEY PAD
•PRESS S T KEY,IT WILL SHOW DG. OFF ON DISPLAY
•TO CHANGE DG. OFF USE ACL & CL KEY FROM KEY PAD. (EITHER YES OR
NO).
•PRESS S T KEY,IT WILL SHOW LST DG ON DISPLAY
•TO CHANGE LST DIG PRESS ACL & CL KEY FROM KEY PAD (EITHER YES OR
NO).
•PRESS S T KEY,IT WILL SHOW L T R ON DISPLAY
•TO CHANGE L T R PRESS ACL & CL KEY FROM KEY PAD.
•PRESS S T KEY.IT WILL SHOW LT R-U ON DISPLAY.
•TO CHANGE LT R-U PRESS ACL & CL KEY FROM KEY PAD.
•PRESS S T KEY,IT WILL SHOW LT R-D S ON DISPLAY & ASK FOR
PASSWARD.
•TO SET THE PASSWARD USE KEY PAD TO NT R 8756 AS DEFAULT
PASSWARD.
•PRESS S T KEY,IT WILL SHOW D NSITY ON DIPLAY.
•TO SET D NSITY,PRESS ACL & CL KEY FROM KEY PAD.THE D FAULT
VALU OF DENSITY IS 970.

•PRESS S T KEY,IT WILL SHOW PI C ON DISPLAY.
•TO SET PI C , PREE ACL & CL KEY FROM DISPLAY.
•PRESS S T KEY.IT WILL SHOW L-LMIT(LOWER LIMIT) ON DISPLAY.
•TO SET L-LMIT USE KEY PAD
•PRESS S T KEY,IT WILL SHOW H-LMIT(HIGHER LIMIT) ON DISPLAY
•TO SET H-LMIT USE KEY PAD.
•PRESS S T KEY.
NOT : AS YOU PR SS S T K Y, IT WILL AUTO SAV YOUR ALL CONFIG
S TTING.
FACTORY CALIBRATION
•PRESS MOD & MT THEN SWITCH ON THE SCALE, THE DISPLAY WILL
SHOW PASS.
•ENTER THE D FAULT PASS WARD 8756 USING KEY PAD.
•PRESS S T KEY, IT WILL SHOW S G-1 ON DISPLAY.
•TO CHANGE THE CAPACITY OF S G-1,USE KEYPAD TO CHANGE THE
PERTICULAR DIGIT OF CAPACITY.THE DIGIT WILL START BLINKING AS YOU
REACH ON PERTICULAR DIGIT.
•THE PRESS S T KEY AFTER CHANGE THE S G-1. IT WILL SHOW S G-2 ON
DISPLAY.
•TO CHANGE THE CAPACITY OF S G-2,USE KEYPAD TO CHANGE THE
PERTICULAR DIGIT OF CAPACITY.THE DIGIT WILL START BLINKING AS YOU
REACH ON PERTICULAR DIGIT.
•THEN PRESS S T KEY,IT WILL SHOW LOAD ON YOUR DISPLAY.
•FIRST PUT THE W IGHT THAT YOU ENTER IN S G-1 & PRESS S T.
•THEN PUT THE W IGHT THAT YOU ENTER IN S G-2 & PRESS S T.
FI LD CALIBRATION

•PRESS “L FT ARROWK Y ”AND “UP ARROW K Y” & SWITCH ON THE
SCALE.THE DISPLAY WILL SHOW PASS.
•ENTER THE D FAULT PASS WARD 8756 USING KEY PAD.
•PRESS S T KEY, IT WILL SHOW S G-1 ON DISPLAY.
•TO CHANGE THE CAPACITY OF S G-1,USE KEYPAD TO CHANGE THE
PARTICULAR DIGIT OF CAPACITY.THE DIGIT WILL START BLINKING AS YOU
REACH ON PERTICULAR DIGIT.
•PRESS S T, THE DIPPLAY WILL SHOW LOAD.
•PUT THE W IGHT THAT YOU ENTER IN S G-1 &PRESS S T KEY.
FOR M MORY S TTING
•PRESS * KEY ,IT WILL SHOW ‘0’ ON DISPLAY.
•THEN PRESS M1,IT WILL SHOW ‘1’ ON DISPLAY.
•PRESS S T KEY & SIM NTANIOUSLY PRESS * KEY.
•IT WILL SHOW VALU OF M1 ON DISPLAY. TO CHANGE THE ALUE OF M1,
PRESS CL KEY FROM KEYPAD & PRESS S T KEY
TO S T DIR CT VALU
•TO SET THE DIR CT VALU ,PRESS CL KEY & ENTER THE ALUE
•PRESS S T KEY
TO INCR AS M MORY W IGHT
•TO INCREASE MEMORY WEIGHT PRESS MT KEY & INSTALL THE MEMORY.
•TO SEE THE TOTAL VALU , PRESS MR KEY. & AGAIN PRESS MR KEY TO
CLOSE.
•TO CLEAR THE MEMORY PRESS ACL KEY.
•TO SEE ALUE OF 0 TO 99 MEMORY, PRESS *(STAR).
•THE DISPLAY WILL SHOW 0 blank. ENTER ANY NUMBER BETWEEN 0 TO 99 and
PR SS *,WILL SHOW YOU THE VALU OF M MORY.
