iSmartHome id Smart Box User manual

Instruction for iPad
id Smart Box
868MHz wireless smart home system
868MHz wireless smart home system

· ID SMART BOX
INTRODUCTION
· ID SMART BOX
HARDWARE INTERFACE
01
· SCECN CONTROL
FUNCTION
55
SCECN CONTROL
FUNCTION
· TIMER CONTROL
FUNCTION
67
TIMER CONTROL
FUNCTION
· REMOTE CONTROL
FUNCTION
79
REMOTE CONTROL
FUNCTION
· FAVORITES
FUNCTION
83
FAVORITES FUNCTION
87
89
COMMON PROBLEM
RESOLUTION
· ID SMART BOX UPDATE11 19
31
15
16
03
05
10
· CENTRAL CONTROL
FUNCTION
41
OPERATION MANUAL
CONTENTS
· ID SMART BOX CONTROL
· ADD DEVICE
· DEVICE ROOM
CHANGING OPERATION
· ID SMART BOX
INTRODUCTION
· ID SMART BOX
STRUCTURE
· SETTING
· RENAME DEVICE
37 · FOUR FUNCTIONS
INTRODUCTION
ID SMART BOX FOUR
FUNCTIONS INTRODUCTION
CENTRAL CONTROL
FUNCTION
NOTE
SETTING INTRODUCTIONID SMART BOX INTRODUCE

Instruction for iPad
id Smart Box
868MHzwirelesssmart home system
Power Voltage: DC 5V-9V
Working Current：＜300mA
Standby power
consumption: ≤200mA
Rated Power: ＜2W
Protection Class: IP40
Antenna: Built-in
Control Point Number: 30
Installation: Horizontal or wall-mounted
Wireless Communication: 433MHz, 868MHz
IEEE 802.11b/g（WIFI)
Communication Distance: 35m (Indoors)
Network Port: 1×RJ45 (10/100 BaseT)
Working Temperature: -10℃ to 55℃
Storage Temperature: -40℃ to 55℃
Smart Box Size: 158mm×83mm×30mm
Specification
Power
Indicator
WiFi
Indicator
Working
Indicator
The Smart Box should be installed in the
central area of the residence at a height
of over 50 cm above the floor.
Installation may be horizontal or
wall-mounted. There should be no metal
objects shielding surrounding the Smart
Box. Other objects should be at least
15cm away from the Smart Box. The
Smart Box should be installed away from
humid environments to avoid unneces-
sary influence on the Smart Box. A
wireless router should be connected to
the installation position of the Smart Box
to enable access of intelligent terminals
(e.g. iPhone, iPad, etc.).
Installation Environment
ID SMART BOX
INTRODUCTION ID SMART BOX HARDWARE INTERFACE
Standard
Configuration
LAN port（to any LAN port
of the wireless router）
RESET Reserved
RS232
Power
DC 5V
SMART BOX | 01 SMART BOX | 02
Adapter (Plugs for different
countries optional)
Smart Box Network Cable Instruction Manual
LANEXT1 EXT2 USBRS232

SMART BOX | 04
2
3
Connect the mobile phone to the Wifi provided by the router connected
with the Smart Box by network cable. · Open idSmartHome app. Enter
“admin” in user name Smart Box and “123456” in password
(modification of user name and password is detailed in Page 06 of this
manual). The user may save the user name and password. If auto login
Smart Box is checked, the user may automatically log in by clicking the icon
on the desktop. · The device ID may be automatically obtained upon
successful login to facilitate remote control next time.
iPad
Software download
For iPad users, download and install id SmartHome app from Apple
Store.
Connect the Smart Box with adapter and then connect the power supply. Connect the
LAN port of the Smart Box with the LAN Port of the home router (Note: Switch on DHCP
Dynamic Host Configuration Protocol of the WI-fi router). Wait till the indication power
indicator “ ” of the Smart Box is normal, proceed other operations.
ID SMART BOX
CONTROL
1
wiring
LAN port
SMART BOX | 03
Smart Box Connection
Ordinary power
socket
Adapter (Plugs for different
countries optional)
Smart Box The third party router

ADD DEVICE
SMART BOX | 05 SMART BOX | 06
Click "OK", and
successfully
add room
OK
· The learning of the remote should be
made within the range of 0.1-5 m to the
Smart Box. After login, find the icon “ "
on the home page to enter the setup
interface.
Add Device
Click “433 Add”
Click“ROOM1”
Add 433MHz device
Click “ ”
Select “Apply”
button
Judgment of 433MHz device: Communication mode on nameplate of the device packing is 433MHz.
Click“ ”
Add Room
Select “Apply”
button
＋
Click “+” and
select room icon
Name the room
(e.g. master bedroom,
guest bedroom)
Click“icon”

433MHz
ADD DEVICE
SMART BOX | 07 SMART BOX | 08
Click to select any one of
the undefined channels
Click device type you want to selectClick match code button
Match Code
433MHz
ADD DEVICE
· Click learning button“ ”press and hold
the “stop” button of the emitter within 10s till the hint
of “Learning Succeeded” displays (The emitter has
been matched with the motor to be added)
· After the hint of “Learning Succeeded” displays,
press “Open/Off/Stop” button respectively to test the
button. If the corresponding motor may execute
“Open/Off/Stop” action properly, the learning is success-
ful. Press “ ” button. Or, learn the codes
again.
· Learning of Multichannel Remote: Learn channel by
channel
Learn Code
Save

868MHz
ADD DEVICE
SMART BOX | 09 SMART BOX | 10
Connect the power supply of
868MHz device. Click the device
to be added within 10s after
hearing the continuous “beep”
sound. One “beep” sound indicates
that the device is added and the adding
action is successful.
Add 868MHz device
Judgment of 868MHz device: Communication mode on nameplate of the device packing is 868MHz.
ROOM1
Select “Apply”
button
DEVICE ROOM
CHANGING OPERATION
Select Room1 Press and hold the
icon of the device
to be edited
The device name
displays (renaming
available)
Click the icon; select
any the room where
the device you
want to be relocated.
Click
“Finish”
Select “Apply”
button
OK
Click “ ” Click “ ”

ID SMART BOX
UPDATE
SMART BOX | 11 SMART BOX | 12
Click“Scene” Select any one of the
undefined channels
Setup of Portable
Emitter is finished
Click scene you
want to select
Click “Learn” button then press
and hold the any button
required on 868MHz remote
Add smart scene remote
Before this operation, all required scenes should be added. Please refer to P27 for scene adding methods.
Select “Apply”
button
Click“Easy sticker”
Learn Code

ID SMART BOX
UPDATE
SMART BOX | 13 SMART BOX | 14
Help Update
The working indicator
in the middle blinks
Click
“Update”
Click
“OK”
Click
“Help”
Return log-in interface
Update is successful
Remote update via network is available in case of addition or
alternation of Smart Box functions
Remote update of Smart Box software

id Smart Box enables distance control and remote control functions on
any wireless controlled motorized blinds and curtains by mobile phones
or iPad. Controls such as opening, closing, stopping and adjustment on
existing motorized blinds and curtains may be achieved by App
software without affecting the normal operation of the original
remotes. In addition, extended control may also be made on devices
such as various wireless lights and electric apparatuses.
ID SMART BOX
INTRODUCTION
Wi-Fi router
ID SMART BOX
STRUCTURE
SMART BOX | 15 SMART BOX | 16
Motorized blinds and curtains
Wireless remote
Light
Smart remote
iPad、iPhone、Android controlled
Available for 2G, 3G, 4G and Wi-Fi network
Network Cable
id Smart Box
id Smart Box

SETTING
INTRODUCTION The setting function enables setup on account, IP address of Smart Box, time
of Smart Box, room configuration and device configuration.
SMART BOX | 17 SMART BOX | 18

Setting Interface
· Select “ " icon in Function Menu; click the icon and enter system
setting interface
· System setting options: Account, Host IP address, host time,room
config,device config,easy sticker.
SETTING
SMART BOX | 19 SMART BOX | 20

· Click “ ” on the right of list in the page of setting accounts, and enter
interface of "create an account" (operation of creating an account is valid in
the registration of admin account)
· Acceptable operations in interface of "create an account" include setting
user name (the name cannot be modified after save), setting login password.
After successful input of account name and password, click " ", account
is created successfully.
· Click sign of user name you want to edit in accounts list. Deletion and
modification of password are acceptable.
SETTING
SMART BOX | 21 SMART BOX | 22
Add Account
OK

· When project menu of setting interface slides to icon of " ", area of
function button below will display host IP address and information of host
port number.
· Click “ ” to enter “Smart Box IP Configuration” interface for
related setup (modification by user not recommended)
· After editing, click OK button “ ” to return “Setting” interface.
· After 10s, click" ", login can be conducted again.
SETTING
SMART BOX | 23 SMART BOX | 24
Smart Box IP Configuration
OK
OK

· When project menu of setting interface slides to icon of " ", area of
function button below will display current date and time information.
· Click “ ” to enter “Time Modification” interface. Make modifica-
tion and then click save button “ ”
Note: Time format is the same as that of ipad. The 24h time system may
be set on ipad
SETTING
SMART BOX | 25 SMART BOX | 26
Smart Box Time
OK

Please refer to my room configuration operation in quick
installation guide part of this manual for details (P06).
Room Configuration
SETTING
SMART BOX | 27 SMART BOX | 28

Applicable in case of newly added device configuration; please refer to
id System Quick Installation Guide or the instruction manual of the
device to be added for details (P06).
Device Configuration
SETTING
SMART BOX | 29 SMART BOX | 30

· Click “ ” on the home page to enter “Setting” interface
· Slide to " ", and click " ", enter interface of room
· Slide list of rooms, and find device to be edited
· Click device icon which shall be edited, and input device name
(composition of name shall not above 15 letters)
Then click " ", device is renamed successfully
RENAME
DEVICE
SMART BOX | 31 SMART BOX | 32
Save

· Click “ ” on the home page to enter “Setting” interface
· Slide to " ", and click " ", enter interface of room
· Slide list of rooms, and find device to be edited
· Select the device icon, and longer press shall be put on it. " "
will appear in two sides of the area, and drag the device icon into
upward side of " " and loosen it. The device is successfully
removed from current room
· In deletion of device, the device can be deleted if it is online
DELETE
DEVICE
SMART BOX | 33 SMART BOX | 34

ID SMART BOX
FOUR FUNCTIONS
INTRODUCTION
Smart Box provides for major functions: Central control function, scene control function,
timer control function and remote control function. In addition, it supports user-defined
editing function, which enables convenient and flexible operation of the user.
SMART BOX | 35 SMART BOX | 36
