ISO Preferred OA DUAL UPRIGHT FLEXION/EXTENSION KNEE BRACE User manual

ISO PREFERRED, 1419 DONELSON PIKE, SUITE A, NASHVILLE, TN 37217
ISOPREFERRED.COM
kjljljlk
PREPARATION:
Do not wear the brace over clothes. Carefully cut off the attached plastic bag with the extension
and flexion parts and set aside.
APPLICATION:
1. Open all closure straps, leaving the brace open. Sitting on the edge of a chair, step into the
brace with the upper thigh aluminum frame on the front of the leg and the lower calf
aluminum frame on the back of the leg. Flex your knee to 45 degrees. Position the joints
(covered condylar hinge pads) so that the center of the hinges are level with the top of the
kneecap.
2. First, find the front calf straps. Fasten the lowest front strap around the front of the calf.
3. Next, find the uppermost thigh strap on the back of the brace and fasten. Keep your knee
in a flexed position and push both brace joints toward the back of the leg, aligning the knee
to the hinge.
4. Find the lower thigh strap in the back and fasten. Ensure that the hinge joints are not
sitting in front of the midline of the leg.
5. Next, find the upper calf strap (5a) at the front and fasten. Find the upper calf strap (5b)
in the back and fasten.
6. Finish by fastening the lower thigh strap (6a) in the front. Each strap includes a gripping
comfort cushion. Place the gripping comfort cushion as desired for a secure and snug fit
on all six (6) straps, to keep the brace in the proper position (6b).
 Bend your knee slightly a few times and make any adjustment as needed.
 If the fit is too small or too large, or hinges are not properly positioned, unfasten,
adjust and refasten the straps again in the order described above to prevent the brace
from slipping. DO NOT OVERTIGHTEN.
7. ROM Hinge Adjustment: Using provided Screwdriver, loosen both screws on the outer
hinge cover. Per physician’s instructions, identify the correct Hinge Stops with correct
degree markers for the Flexion, Extension or both (see illustration below to identify the
hinge stops by markings on the back side of each). Insert the selected Hinge Stop(s) into
the correct side of the Hinge. Insert screws into holes and tighten until screw top is flush
with hinge plate cover. Repeat these instructions for the inner hinge cover.
ISO Preferred OA Dual Upright Flexion/Extension Knee Brace (KN23xx) is intended for ACL, MCL, LCL, PCL or mixed instabilities,
Osteoarthritis, Rheumatoid arthritis, Meniscal cartilage derangement, Chondromalacia of the patella, Tears or instability of the
collateral ligaments
.
OA DUAL UPRIGHT FLEXION/EXTENSION KNEE BRACE
The ISO Preferred OA Dual Upright Flexion/Extension Knee Brace is a lightweight double upright knee
orthosis with adjustable ROM hinges for flexion/extension and is designed to guide and stabilize the knee
joint using limitation of range of motion to prevent hyperextension. The solid metal double uprights
provide medial/lateral control. A tool set includes custom hinge stops to provide individualized
flexion/extension settings. Models are left or right knee oriented and sizes are S to XL, allowing the brace
to fit a wide variety of patients.
Always Putting Our Patients First
4
2
5b
6b
2
1
3
2
5a
6a
7

ISO PREFERRED, 1419 DONELSON PIKE, SUITE A, NASHVILLE, TN 37217
ISOPREFERRED.COM
INTRODUCTION
Your ISO Preferred OA Dual Upright Flexion/Extension Knee Brace (KN23xx) is designed to provide your body with
the support and stability that it needs to successfully manage or eliminate your mobility concerns. It is critical that
you follow your orthopedic professional’s directions closely to ensure that the apparatus is worn properly and in the
manner that will be most beneficial in addressing your issues. For correct application, please read the enclosed
instructions and watch the on-line instructional video (if available) at www.ISOpreferred.com so that this device can
provide you with superior long-term usability and care.
USAGE RECOMMENDATIONS
It is vital that you read the included instructions and when applicable watch the instructional video for the ISO
Preferred OA Dual Upright Flexion/Extension Knee Brace (KN23xx). The brace is intended for application by qualified
professionals only. It is not recommended for patients to fit or apply or adjust their new brace without an orthopedic
professional’s expertise, unless otherwise instructed. Further questions regarding adjustments or changes, frequency
of use, and/or duration of use should be presented to your orthopedic professional, as they are familiar with the
specific needs and conditions, for which this device was prescribed.
CARE AND CLEANING INSTRUCTIONS
Please do not place your brace in the washing machine or dryer at any time. When preparing to clean the ISO
Preferred OA Dual Upright Flexion/Extension Knee Brace (KN23xx) you will want to separate the parts where
applicable and care for them individually.
 Do not dry clean, iron, bleach, or use an abrasive cleaning instrument on any part of the brace. Failure
to follow these instructions may damage your brace and void the manufacturer's warranty and it may
no longer work properly.
 Remove the pads and straps for hand washing. Wipe the metal brace and hinges with damp cloth.
 Hand wash pads and straps in cold water with a mild detergent. Lay flat to air dry. Allow all parts to air
dry prior to reassembling the device.
CAUTION
The ISO Preferred OA Dual Upright Flexion/Extension Knee Brace (KN23xx) is for single patient use only. While
every effort has been made to obtain maximum strength, function and durability, there is no guarantee that injury
will be prevented through the use of this device, especially if the instructions are not followed correctly.
DO NOT OVERTIGHTEN.
