iSP Technologies HIGH DEFINITION LINE 2208Active Series User manual

IMPORTANT SAFTEY INSTRUCTIONS
Please read the following very carefully before operating this unit
Read ALL instructions carefully before using this unit. Keep these instructions for future reference. Heed all warnings and follow all
instructions.
Do not use this unit near water, in the rain, or where there is moisture. If this warning is ignored a serious electrical shock or death may
occur.
Do not attempt to service this unit. No user serviceable parts inside. Refer servicing to qualified, ISP approved personnel. Servicing is
required when the unit is damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the unit, the unit has been exposed to rain or moisture, does not operate normally, or has been dropped.
Do not block any ventilation openings on the unit. Do not install near heat sources such as radiators, heat registers, stoves, or other
apparatus that produces heat.
Do not defeat the grounding pin on the power plug. A grounding type plug has two blades and a third grounding prong. If the grounded plug
does not fit in your outlet, please consult an electrician for replacement of the outlet, which may be obsolete.
Care should be taken to avoid any foreign objects or liquid into this unit. Avoid exposure of this equipment to dripping or splashing and
ensure that no objects filled with liquid, such as vases, are placed on the equipment.
Only use accessories or attachments that are specified by the manufacturer.
Use only with the caster attachment, stand, connecting bracket, or table specified by the manufacturer, or sold as an accessory with the
unit. When a castor attachment is used, use caution when moving the cart/apparatus combination to avoid injury from tipping over.
To completely disconnect this unit from the AC mains, disconnect the power supply cord plug from the AC receptacle.
This active speaker system has internal power amplifier(s) and a heatsink located internally with cooling ports on the back of the unit for
airflow over the heatsink. Care should be taken to avoid placing this active speaker in a location where the airflow over the heatsink is
impeded and proper cooling of the internal amplifiers is not provided. Avoid placing this system close to other heat sources. The external
heatsink may reach high temperatures under normal use. Do not block the external heatsink with any other object. Make certain there is
proper ventilation for the external heatsink when in use.
Do not drive the unit into excessive heavy distortionfor an extended period of time to avoid premature speaker failure.
Failure to follow these instructions may void the warranty.
THIS UNIT CONTAINS POTENTALLY LETHAL VOLTAGES. TO PREVENT ELECTRIC SHOCK OR
HAZED, DO NOT REMOVE THE POWER AMPLIFIER MODULE, INPUT PANEL OR AC INPUT PANEL.
NO UER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED ISP TECHNOLOGIES
SERVICE PERSONNELL.

Caution: Exposure to extremely high noise levels can
cause permanent hearing loss.
The HIGH DEFINITION LINE 2208 system is capable of producing in excess of 134db SPL
at 1 meter. Continued exposure to noise levels in excess of 90db may cause permanent
hearing loss. Below is a chart of the OSHA (Occupational Safety & Health Administration)
regulations for Occupational Noise Exposure. Please note: OSHA requires hearing
protection for any work environment when the sound levels exceed those shown in Table
G-16 when measured on the A scale of a standard sound level meter at slow response.
INTRODUCTION
Thank you for purchasing ISP Technologies HIGH DEFINITION LINE 2208 active speaker
system. The HIGH DEFINITION LINE 2208 is a high output two-way active speaker
system designed to deliver HI-FI sound quality for high SPL sound reinforcement
applications. ISP Technologies HDL 2208 is a high performance, powered, small-format
line array cabinet providing high fidelity performance and smooth, accurate response.
The HDL 2208 provides a 2-way line array design with little compromise in terms of its mid-
range performance. This is, in part, due to a new high performance non-metallic
compression driver on a multiple-aperture waveguide and dual 8-inch neo woofers. The
result is a new level of performance in a small-format line array system. The HDL 2208 is
a 10-degree vertical by 100-degree horizontal box with user adjustable pin-
points for various splay angles from 1 to 10 degrees in 1 degree increments.
The internal amplifiers are based on ISP Technologies patent pending D-CAT (Dynamic
Current Amplifier Technology) amplifier technology. The D-CAT technology is capable of
delivering extremely high output current providing an improvement in transient response,
output current and a noticeable improvement in PUNCH. The D-CAT amplifier technology
utilizes a high performance power amplifier driver that reduces parts count and greatly
improves reliability. The D-CAT amplifiers provide improved reliability by including short
circuit and over temperature protection.
The HIGH DEFINITION LINE 2208 cabinet is made of high quality 13 ply Baltic birch
plywood built with smooth sides, the boxes provide a very clean look, without any
protruding rigging or pins, and are coated with a durable polyurethane finish.

SUSPENDING LOUDSPEAKERS
Important Notice!!!
The information in this section has been gathered from engineering data and is for
informational purposes only. None of the information in this section should be used without
first obtaining competent advice with respect to applicability to a given circumstance. None of
the information presented herein is intended as a representation of warranty on the part of
ISP Technologies. Anyone making use of this information assumes all liability arising from
such use.
All information presented in this manual is based upon materials and practices that are most
common to The United States of America and may not directly apply to other countries
because of differing material dimensions, specs, and/or local regulations. Users in outside
countries should consult with appropriate engineering and regulatory authorities for specific
guidelines.
Correct use of all flyware is required for secure system suspension. Careful calculations
should always be performed to ensure that all components are used within their working load
limits before the cabinet suspended. Never exceed the maximum load ratings.
Before hanging any speaker system, always inspect all components for cracks, deformations,
corrosion, missing, loose or damaged parts that could reduce strength and safety of the
cabinet. Do not suspend the cabinet until the proper corrective action has been taken.
ATTACHMENT TO STRUCTURES
A licensed professional engineer must approve the placement and method of attachment to
the structure prior to the installation of any overhead object. The following performance
standards should be provided to the professional engineer for design purposes; Uniform
building code as applicable, Municipal Building code as applicable and Seismic Code as
applicable.
INSPECTION and MAINTENANCE
Suspension systems are comprised of mechanical devices and, as such, they require regular
inspection and routine maintenance to insure proper function ability. Any suspended ISP
Technologies loudspeaker must be inspected for fatigue at least annually. The inspection
shall include a visual survey of all corners and load bearing surfaces for signs of cracking,
water damage, de-lamination, or any other condition that may decrease the strength of the
loudspeaker enclosure.
Flyware that is provided with or for any ISP Technologies loudspeakers must be inspected
for fatigue at least annually. The inspection shall include a visual survey of the material for
signs of corrosion, bending, or any other condition that may decrease the strength of the
fastener.
ISP Technologies is not responsible for the application of its products for any purpose or the
misuse of this information for any purpose. ISP is also not responsible for the abuse of its
products caused by avoiding compliance with inspection and maintenance procedures.

REAR PANEL CONNECTION DIAGRAM

THERMAL CONDITIONS
The ISP HIGH DEFINITION LINE 2208 Series is capable of producing in excess of 850 watts
at full power. This generates heat that must be dissipated in order to maintain reliability and
insure the amplifier components stay within their operating temperature specs. To
accomplish this the amplifier is mounted on a heatsink that is internal to the cabinet. Airflow
is forced through a port near the internal heatsink.
In addition the amplifiers are thermally protected internally via a thermal switch which will
attenuate the signal 40db if the heatsink temperature exceeds a certain temperature. When
the temperature drops below a certain point, full signal will be restored. Tests have shown
under extreme conditions that cycling will occur approx. (40 sec. ON, 20 sec. OFF)
It should also be noted that a separate internal thermal breaker also protects the power
transformers. If one power transformer temperature reaches a critical point the internal
thermal breaker will open. If this condition occurs simply reduce the signal level of the
system. This will only occur if the HIGH DEFINITION LINE 2208 is continually pushed into
heavy distortion.

SPECIFICATIONS
(per box)
Configuration: 2-way
LF Drivers: 2 x 8 inch, high sensitivity, neo magnet, water resistant cones.
HF Drivers:2 x 2.6 inch compression, 1.4 inch throat, neo magnet, polymer
diaphragm, on multiple-aperture waveguide.
Coverage: 100 H x 10 V
Frequency Resp.: 68 Hz to 16 kHz
Maximum peak SPL: 134 dB @ 1m
Construction: Baltic Birch Plywood.
Dimensions: 24” W x 9.1” H x 19” D
Weight: 62 lbs.
Amplifier: 850 W RMS, 3 channels
high current DCAT, fan cooled.
Power Required: 5 amps x 120 VAC.
Power Connections: Powercon Input, Powercon Thru.
Audio Connections: Female XLR Input, Male XLR Thru. Electronically balanced, 20k
Ohm differential between pins 2 and 3. Pin 2 hot.
Crossover:Built-in line-level electronic, 900 Hz nominal, 4th order. An array of
boxes will require a DSP unit for equalization.
Rigging: 16 Boxes @ 7:1 Safety Factor, Aluminum Alloy. 1 to 10 degree
adjustments with 1 degree increments.

WARRANTY AND SERVICE
The Internal Circuitry is fully guaranteed to be free of defects under normal use and service
for a period of three years from the date of purchase. The Speakers and Cabinet that are used
in this product are fully guaranteed to be free of defects under normal use and service for a
period of three years.
Any damage resulting from the misuse or the failure to follow the precautions and
instructions will void the warranty.
In the event that the unit needs to be repaired. Please return the unit to ISP Technologies
directly. Simply repack the unit, send a copy of the original receipt, a note stating the
problem, and send it to:
ISP Technologies, LLC
5479 Perry Drive Suite B
Waterford, MI 48329
Attn: Repair Dept.
All shipping charges must be fully prepaid.
ISP will not be responsible for any damages incurred in shipping of any unit. Any claim will
need to be settled with the shipping company.
The warranty will be voided if the serial number has been tampered with in any way.
The warranty card must also be filled out and returned in order to activate the warranty.
Should you have any questions for the repair department prior to returning the product
please call 1-(248)-673-7790
NOTE: If it is determined that the power amp module has failed, it is possible for an ISP
certified service center to remove the module from the cabinet by removing the mounting
screws and disconnecting the speaker terminals and the transformer. The module may be
sent back to ISP separately. Please contact ISP for technical support to help determine if
the amplifier module may be defective.
ISP TECHNOLOGIES, LLC
5479 Perry Drive Suite B
Waterford, MI. 48329
248-673-7790
FAX: [phone]
www.isptechnologies.com
